1 Introduction
1.1 Purpose of the Peripheral
1.2 Features
1.3 Functional Block Diagram
User's GuideSPRUE30B – September 2006
Multimedia Card (MMC)/Secure Digital (SD) CardController
This document describes the multimedia card (MMC)/secure digital (SD) card controller in theTMS320DM644x Digital Media System-on-Chip (DMSoC).
A number of applications use the multimedia card (MMC)/secure digital (SD) card to provide removabledata storage. The MMC/SD card controller provides an interface to external MMC and SD cards. Thecommunication between the MMC/SD card controller and MMC/SD card(s) is performed according to theMMC/SD protocol.
The MMC/SD card controller has the following features:•Supports interface to multimedia cards (MMC)•Supports interface to secure digital (SD) memory cards•Ability to use the MMC/SD protocol•Programmable frequency of the clock that controls the timing of transfers between the MMC/SDcontroller and memory card•256-bit read/write FIFO to lower system overhead•Signaling to support enhanced direct memory access (EDMA) transfers (slave)•20 MHz maximum clock to MMC (specification 3.31)•50 MHz maximum clock to SD (specification version 1.1)
The MMC/SD card controller transfers data between the ARM and the EDMA controller on one side andthe MMC/SD card on the other side, as shown in Figure 1 . This means you have a choice of performingdata transfers using the CPU or EDMA as a mechanism to move data between the device memory andthe FIFO. The ARM and the EDMA controller can read from or write to the data in the card by accessingthe registers in the MMC/SD controller.
SPRUE30B – September 2006 Multimedia Card (MMC)/Secure Digital (SD) Card Controller 9Submit Documentation Feedback

www.ti.com
Status
and
registers
DMA requests
Interrupts
ARM CPU
FIFO
MMC/SD
interface
CLK
divider
MMC/SD
card
interface
1.4 Supported Use Case Statement
1.5 Industry Standard(s) Compliance Statement
2 Peripheral Architecture
Peripheral Architecture
Figure 1. MMC/SD Card Controller Block Diagram
The MMC/SD card controller supports the following user cases:•MMC/SD card identification•MMC/SD single-block read using CPU•MMC/SD single-block read using EDMA•MMC/SD single-block write using CPU•MMC/SD single-block write using EDMA•MMC/SD multiple-block read using CPU•MMC/SD multiple-block read using EDMA•MMC/SD multiple-block write using CPU•MMC/SD multiple-block write using EDMA
The MMC/SD card controller supports the following industry standards (with the exception noted below):•MMC (Multimedia Card) Specification V3.31•SD (Secure Digital) Physical Layer Specification V1.1
The information in this document assumes that you are familiar with these standards.
The MMC/SD controller does not support the SPI mode of operation.
The MMC/SD controller uses the MMC/SD protocol to communicate with the MMC/SD cards. You canconfigure the MMC/SD controller to work as an MMC or SD controller, based on the type of card thecontroller is communicating with. Figure 2 summarizes the MMC/SD mode interface. Figure 3 illustrateshow the controller interfaces to the cards in MMC/SD mode.
In the MMC/SD mode, the MMC controller supports one or more MMC/SD cards. Regardless of thenumber of cards connected, the MMC/SD controller selects one by using identification broadcast on thedata line. The following MMC/SD controller pins are used:•CMD: This pin is used for two-way communication between the connected card and the MMC/SDcontroller. The MMC/SD controller transmits commands to the card and the memory card drivesresponses to the commands on this pin.•DAT0 or DAT0-3: MMC cards only use one data line (DAT0) and SD cards use one or four data lines.The number of DAT pins (the data bus width) is set by the WIDTH bit in the MMC control register(MMCCTL), see Section 4.1 ).•CLK: This pin provides the clock to the memory card from the MMC/SD controller.
10 Multimedia Card (MMC)/Secure Digital (SD) Card Controller SPRUE30B – September 2006Submit Documentation Feedback

www.ti.com
Native packets
Native
signals
CMD
CLK
DAT0 or DAT0−3
MMC/SD
controller
ARM
EDMA
Memory
MMCs or SD cards
SD_CLK
SD_CMD
SD_DATA0
SD_DATA1
SD_DATA2
SD_DATA3
MMC/SD controller MMC and SD (1−bit mode)
CLK
CMD
DAT0
MMC/SD configuration
MMC/SD controller
SD_DATA0
SD_CMD
SD_CLK
DAT0
CMD
SD card (4−bit mode)
CLK
SD_DATA2
SD_DATA3
SD_DATA1
SD configuration
DAT1
DAT2
DAT3
Peripheral Architecture
Figure 2. MMC/SD Controller Interface Diagram
Figure 3. MMC Configuration and SD Configuration Diagram
SPRUE30B – September 2006 Multimedia Card (MMC)/Secure Digital (SD) Card Controller 11Submit Documentation Feedback

www.ti.com
2.1 Clock Control
MMCCLK
(CLKRT)
Function clock for
MMC/SD controller
MMC/SD controller
MMC/SD
input clock card
MMC/SD
Memory clock
on CLK pin
Peripheral Architecture
There are two clocks, the function clock and the memory clock, in the MMC/SD controller (Figure 4 ).
The function clock determines the operational frequency of the MMC/SD controller and is the input clockto the MMC/SD card(s). The MMC/SD controller is capable of operating with a function clock up to100 MHz.
The memory clock appears on the SD_CLK pin of the MMC/SD controller interface. The memory clockcontrols the timing of communication between the MMC/SD controller and the connected memory card.The memory clock is generated by dividing the function clock in the MMC/SD controller. The divide-downvalue is set by CLKRT bits in the MMC memory clock control register (MMCCLK) and is determined by thefollowing equation:
memory clock frequency = function clock frequency/(2 × (CLKRT + 1))
Figure 4. MMC/SD Controller Clocking Diagram
(1) Maximum memory clock frequency in MMC card can be 20 MHz.(2) Maximum memory clock frequency in SD card can be 50 MHz.
Multimedia Card (MMC)/Secure Digital (SD) Card Controller12 SPRUE30B – September 2006Submit Documentation Feedback

www.ti.com
2.2 Signal Descriptions
2.3 Protocol Descriptions
2.3.1 MMC/SD Mode Write Sequence
Peripheral Architecture
Table 1 shows the MMC/SD controller pins that each mode uses. The MMC/SD protocol uses the clock,command (two-way communication between the MMC controller and memory card), and data (DAT0 forMMC card, DAT0-3 for SD card) pins.
Table 1. MMC/SD Controller Pins Used in Each Mode
Function
MMC and SD (1-bit mode) SD (4-bit mode)Pin Type
(1)
Communications Communications
CLK O Clock line Clock lineCMD I/O Command line Command lineDAT0 I/O Data line 0 Data line 0DAT1 I/O (Not used) Data line 1DAT2 I/O (Not used) Data line 2DAT3 I/O (Not used) Data line 3
(1)
I = input to the MMC controller; O = output from the MMC controller.
The MMC/SD controller follows the MMC/SD protocol for completing any kind of transaction with themultimedia card and secure digital cards. For more detailed information, refer to the supported MMC andSD specifications in Section 1.5 .
Figure 5 and Table 2 show the signal activity when the MMC/SD controller is in the MMC/SD mode and iswriting data to a memory card. The same block length must be defined in the MMC/SD controller and inthe memory card before initiating a data write. In a successful write protocol sequence, the following stepsoccur:
•The MMC/SD controller requests the CSD content.•The card receives the command and sends the content of the CSD register as its response.•If the desired block length, WRITE_BL_LEN value, is different from the default value determined fromthe response, the MMC/SD controller sends the block length command.•The card receives the command and sends responses to the command.•The MMC/SD controller requests the card to change states from standby to transfer.•The card receives the command and sends responses to the command.•The MMC/SD controller sends a write command to the card.•The card receives the command and sends responses to the command.•The MMC/SD controller sends a block of data to the card.•The card sends the CRC status to the MMC/SD controller.•The card sends a low BUSY bit until all of the data has been programmed into the flash memory insidethe card.
SPRUE30B – September 2006 Multimedia Card (MMC)/Secure Digital (SD) Card Controller 13Submit Documentation Feedback

www.ti.com
2 CRC bytes Busy low
Start
bit End bit Start bit End bit
CMD
Data
CLK
2.3.2 MMC/SD Mode Read Sequence
Peripheral Architecture
Figure 5. MMC/SD Mode Write Sequence Timing Diagram
Table 2. MMC/SD Mode Write Sequence
Portion of theSequence Description
WR CMD Write command: A 6-byte WRITE_BLOCK command token is sent from the ARM to the card.CMD RSP Command response: The card sends a 6-byte response of type R1 to acknowledge the WRITE_BLOCK to theARM.DAT BLK Data block: The ARM writes a block of data to the card. The data content is preceded by one start bit and isfollowed by two CRC bytes and one end bit.CRC STAT CRC status: The card sends a one byte CRC status information, which indicates to the ARM whether the data hasbeen accepted by the card or rejected due to a CRC error. The CRC status information is preceded by one startbit and is followed by one end bit.BSY BUSY bit: The CRC status information is followed by a continuous stream of low busy bits until all of the data hasbeen programmed into the flash memory on the card.
Figure 6 and Table 3 show the signal activity when the MMC controller is in the MMC/SD mode and isreading data from a memory card. The same block length must be defined in the MMC controller and inthe memory card before initiating a data read. In a successful read protocol sequence, the following stepsoccur:
•The MMC/SD controller requests for the CSD content.•The card receives the command and sends the content of the CSD register as its response.•If the desired block length, READ_BL_LEN value, is different from the default value determined fromthe response, the MMC/SD controller sends the block length command.•The card receives the command and sends responses to the command.•The MMC/SD controller requests the card to change state from stand-by to transfer.•The card receives the command and sends responses to the command.•The MMC/SD controller sends a read command to the card.•The card drives responses to the command.•The card sends a block of data to the ARM.
14 Multimedia Card (MMC)/Secure Digital (SD) Card Controller SPRUE30B – September 2006Submit Documentation Feedback

www.ti.com
Start
bit End bit
CMD
Data
CLK
1 transfer
source bit 2 CRC bytes
2.4 Data Flow in the Input/Output FIFO
Peripheral Architecture
Figure 6. MMC/SD Mode Read Sequence Timing Diagram
Table 3. MMC/SD Mode Read Sequence
Portion of theSequence Description
RD CMD Read command: A 6-byte READ_SINGLE_BLOCK command token is sent from the ARM to the card.CMD RSP Command response: The card sends a response of type R1 to acknowledge the READ_SINGLE_BLOCKcommand to the ARM.DAT BLK Data block: The card sends a block of data to the ARM. The data content is preceded by a start bit and isfollowed by two CRC byte and an end bit.
The MMC/SD controller contains a single 256-bit FIFO that is used for both reading data from the memorycard and writing data to the memory card (see Figure 7 ). The FIFO is organized as 32 eight-bit entries.The conversion from the 32-bit bus to the byte format of the FIFO follows the little-endian convention(details are provided in later sections). The read and write FIFOs act as an interim location to store datatransferred from/to the card momentarily via the CPU or EDMA. The FIFO includes logic to generateEDMA events and interrupts based on the amount of data in the FIFO and a programmable number ofbytes received/transmitted. Flags are set when the FIFO is full or empty.
SPRUE30B – September 2006 Multimedia Card (MMC)/Secure Digital (SD) Card Controller 15Submit Documentation Feedback

www.ti.com
ARM/EDMA reads/writes
Write Read
FIFO
8−bit x 32
(256−bit)
FIFO
EDMA event
128 or 256 bit
128 or 256 bit
EDMA event
EDMA event
the end of a
transfer
Pointer increment
or decrease
Pointer increment
or decrease
FIFO
16−bit DXR 16−bit DRR
16−bit DXR
shifter 16−bit DRR shifter
DXR DRR
EDMA
request
is created
Transmission of data
Step 1: Set FIFO reset
Step 2: Set FIFO direction
Step 4: CPU driven transaction:
Fill the FIFO by writing to
MMCDXR (only first time)
Step 5: EDMA send xmit data
Step 6: If DXR ready is active,
FIFO −> 16−bit DXR
Reception of data
Step 3:
Step 2:
Step 1: Set FIFO reset
Set FIFO direction
If DRR ready is active,
16−bit DRR −> FIFO
Step 6: EDMA read reception data
Step 4: EDMA driven transaction
Step 5: DRRDYINT interrupt occur
Step 3: EDMA driven transaction
or every 128 or 256−bits
transmitted and DXRDYINT
interrupt is generated
when FIFO every 128 or
256−bits of data received
by FIFO
Peripheral Architecture
A high-level operational description is as follows:•Data is written to the FIFO through the MMC data transmit register (MMCDXR). Data is read from theFIFO through the MMC data receive register (MMCDRR). This is true for both the CPU and EDMAdriven transactions; however, for the EDMA transaction, the EDMA access to the FIFO is transparent.•The ACCWD bits in the MMC FIFO control register (MMCFIFOCTL) determines the behavior of theFIFO full (FIFOFUL) and FIFO empty (FIFOEMP) status flags in the MMC status register 1 (MMCST1):– If ACCWD = 00b:•FIFO full is active when the write pointer + 4 > read pointer•FIFO empty is active when the write pointer - 4 < read pointer– If ACCWD = 01b:•FIFO full is active when the write pointer + 3 > read pointer•FIFO empty is active when the write pointer - 3 < read pointer– If ACCWD = 10b:•FIFO full is active when the write pointer + 2 > read pointer•FIFO empty is active when the write pointer - 2 < read pointer– If ACCWD = 11b:•FIFO full is active when the write pointer + 1 > read pointer•FIFO empty is active when the write pointer - 1 < read pointer
Figure 7. FIFO Operation Diagram
Multimedia Card (MMC)/Secure Digital (SD) Card Controller16 SPRUE30B – September 2006Submit Documentation Feedback

www.ti.com
2.5 Data Flow in the Data Registers (MMCDRR and MMCDXR)
1st
2nd
3rd
4th
34th 3rd 2nd 1st
Support byten = ”1111”
Support byten = ”0111”
3rd
2nd
1st 33rd 2nd 1st
Support byten = ”0011”
1st
2nd
32nd 1st0
Support byten = ”0001”
1st 31st0
0
0
FIFO MMCDRR or MMCDXR registers
Peripheral Architecture
The CPU or EDMA controller can read 32 bits at a time from the FIFO by reading the MMC data receiveregister (MMCDRR) and write 32 bits at a time to the FIFO by writing to the MMC data transmit register(MMCDXR). However, since the memory card is an 8-bit device, it transmits or receives one byte at atime. Figure 8 and Figure 9 show how the data-size difference is handled by the data registers inlittle-endian and big-endian configurations, respectively.
Figure 8. Little-Endian Access to MMCDXR/MMCDRR from the ARM CPU or the EDMA
SPRUE30B – September 2006 Multimedia Card (MMC)/Secure Digital (SD) Card Controller 17Submit Documentation Feedback

www.ti.com
1st
2nd
3rd
4th
34th3rd2nd1st
Support byten = ”1111”
Support byten = ”1110”
3rd
2nd
1st 33rd2nd1st
Support byten = ”1100”
1st
2nd
32nd1st 0
Support byten = ”1000”
1st 31st 0
0
0
Peripheral Architecture
Figure 9. Big-Endian Access to MMCDXR/MMCDRR from the ARM CPU or the EDMA
18 Multimedia Card (MMC)/Secure Digital (SD) Card Controller SPRUE30B – September 2006Submit Documentation Feedback

www.ti.com
2.6 FIFO Operation During Card Read Operation
2.6.1 EDMA Reads
2.6.2 CPU Reads
Peripheral Architecture
The FIFO controller manages the activities of reading the data in from the card and issuing EDMA readevents. Each time an EDMA read event is issued, an EDMA read request interrupt generates.
Figure 10 provides details of the FIFO controllers operation. As data is received from the card, it is readinto the FIFO. When the number of bytes of data received is equal to the level set by the FIFOLEV bits inMMCFIFOCTL, an EDMA read event is issued and new EDMA events are disabled until the EDMA isdone with the transfer issued by the current event. Data is read from the FIFO by way of MMCDRR. TheFIFO controller continues to read in data from the card while checking for the EDMA event to occur or forthe FIFO to become full. Once the EDMA event finishes, new EDMA events are enabled. If the FIFO fillsup, the FIFO controller stops the MMC/SD controller from reading any more data until the FIFO is nolonger full.
An EDMA read event generates when the last data arrives, as determined by the MMC block lengthregister (MMCBLEN) and the MMC number of blocks register (MMCNBLK) settings. This EDMA eventflushes all of the data that was read from the card from the FIFO.
Each time an EDMA read event generates, an interrupt (DRRDYINT) generates and the DRRDY bit in theMMC status register 0 (MMCST0) is also set.
The system CPU can also directly read the card data by reading the MMC data receive register(MMCDRR). The MMC/SD peripheral supports reads that are 1, 2, 3, or 4 bytes wide as, shown inFigure 8 and Figure 9 .
As data is received from the card, it is read into the FIFO. When the number of bytes of data received isequal to the level set by the FIFOLEV bits in MMCFIFOCTL, a DRRDYINT interrupt is issued and theDRRDY bit in the MMC status register 0 (MMCST0) is set. Upon receiving the interrupt, the CPU quicklyreads out the bytes received (equal to the level set by the FIFOLEV bits). A DRRDYINT interrupt alsogenerates when the last data arrives as determined by the MMC block length register (MMCBLEN) andthe MMC numbers of blocks register (MMCNBLK) settings.
SPRUE30B – September 2006 Multimedia Card (MMC)/Secure Digital (SD) Card Controller 19Submit Documentation Feedback

www.ti.com
FIFO Check1/Start
FIFO
full
?
Counter
=FIFOLEV
?
Yes
No
Capture data,
no DMA pending
Increment counter
No
Yes
Generate DMA
Reset counter
FIFO check 2
Yes
No
?
full
FIFO
No
=FIFOLEV
?
Counter
Increment counter
DMA
Capture data,
done
?
DMA
No
Yes
Yes
Yes
Generate DMA
Reset counter
Idle, DMA pending
DMA
No done
?
Peripheral Architecture
Figure 10. FIFO Operation During Card Read Diagram
Multimedia Card (MMC)/Secure Digital (SD) Card Controller20 SPRUE30B – September 2006Submit Documentation Feedback
