Thermo Scientific Fisherbrand GT2 User manual

Fisherbrand GT2 Centrifuge
Fisherbrand GT2R Centrifuge
Instruction manual
50156459_a • 04 / 2018
15808722
15818722

IMPORTANT Read this instruction manual. Failure to follow the instructions in this manual can result in
damage to the unit, injury to operating personnel, and poor equipment performance.
CAUTION All internal adjustments and maintenance must be performed by qualified service personnel.
Material in this manual is for informational purposes only. The contents and the product it describes are
subject to change without notice. Fisher Scientific makes no representations or warranties with respect to this
manual. In no event shall be held liable for any damages, direct or incidental, arising from or related to the use
of this manual.
BIOShield™, Fiberlite™, HIGHConic™, Microliter™, MicroClick™and Auto-Lock ™.
All trademarks are the property of Thermo Fisher Scientific and its subsidiaries unless otherwise specified.
© 2018 Fisher Scientific Inc. All rights reserved.

Contents
Preface .................................................................... 1
Scope of Supply....................................................... 1
Intended Use............................................................ 1
Accident Prevention ................................................. 1
Precautions.............................................................. 1
Introduction and Description ........................................ 3
Characteristics ......................................................... 3
Technical Data ......................................................... 3
Directives, Standards and Guidelines ....................... 4
Functions and Features............................................ 4
Mains Supply ........................................................... 5
Refrigerant ............................................................... 5
Rotor Selection ........................................................ 6
Before Use................................................................... 7
Before Setting up ..................................................... 7
Transporting the Centrifuge...................................... 7
Location................................................................... 7
Aligning the Centrifuge ............................................. 7
Mains Connection .................................................... 8
Storage .................................................................... 8
Control Panel............................................................... 9
Control Panel ........................................................... 9
Keys......................................................................... 9
Operation..................................................................... 10
Switch on Centrifuge................................................ 10
Lid Opening ............................................................. 10

Close Lid.................................................................. 10
Rotor Installation ...................................................... 10
Entering Parameters................................................. 11
Saving programs...................................................... 12
Centrifugation........................................................... 12
Temperature Adaptation during Standstill................. 13
Short-term Centrifugation......................................... 13
Removing the Rotor ................................................. 13
Aerosol-tight Rotors ................................................. 14
Aligning the Centrifuge ............................................. 14
System Menu............................................................... 15
Description............................................................... 16
Maintenance and Care................................................. 17
Cleaning Intervals ..................................................... 17
Cleaning................................................................... 17
Disinfection .............................................................. 18
Decontamination ...................................................... 18
Autoclaving .............................................................. 19
Service of Fisher Scientific........................................ 19
Troubleshooting........................................................... 20
Mechanical Emergency Door Release ...................... 20
Troubleshooting by User .......................................... 21
When to Contact Customer Service ......................... 24
Chemical Compatibility Chart ....................................... 25

Centrifuge GT 2/2R | 1
Preface
Before starting to use the centrifuge, read through this
instruction manual carefully and follow the instructions.
The information contained in this instruction manual is the
property of Fisher Scientific; it is forbidden to copy or pass on
this information without explicit approval.
Failure to follow the instructions and safety information in this
instruction manual will result in the expiration of the sellers
warranty.
Scope of Supply
If any parts are missing, please contact your nearest Fisher
Scientific representative.
Intended Use
• This centrifuge is designed to separate sample mixtures
of different densities like chemicals, environmental
samples and other non-human body samples.
Accident Prevention
Prerequisite for the safe operation of the Centrifuge GT 2/2R
is a work environment in compliance with standards,
directives and trade association safety regulations and proper
instruction of the user.
The safety regulations contain the following basic
recommendations:
• Maintain a radius of at least 30 cm around the centrifuge.
• Implementation of special measures which ensure that no
one can approach the centrifuge for longer than
absolutely necessary while it is running.
• The mains plug must be freely accessible at all times. Pull
out the power supply plug or disconnect the power
supply in an emergency.
Precautions
In order to ensure safe operation of the Centrifuge GT 2/2R,
the following general safety regulations must be followed:
• Do not manipulate the safety devices.
• The centrifuge should be operated by trained specialists
only.
• The centrifuge is to be used for its intended use only.
• Plug the centrifuge only into sockets which have been
properly grounded.
• Do not move the centrifuge while it is running.
• Do not lean on the centrifuge.
• Use only rotors and accessories for this centrifuge which
have been approved by Thermo Scientific. Exceptions to
this rule are commercially available glass or plastic
centrifuge tubes, provided they have been approved for
the speed or the RCF value of the rotor.
• Do not use rotors which show any signs of corrosion
and/or cracks.
• Do not touch the mechanical components of the rotor
and do not make any changes to the mechanical
components.
• Use only with rotors which have been properly installed.
Follow the instructions on the Auto-Lock in section Rotor
Installation.
• Use only with rotors which have been loaded properly.
Follow the instructions given in the rotor manual.
• Never overload the rotor. Follow the instructions given in
the rotor manual.
• Never start the centrifuge when the lid is open.
• Never open the lid until the rotor has come to a complete
stop and this has been confirmed in the display.
• The lid emergency release may be used in emergencies
only to recover the samples from the centrifuge, e.g.
during a power failure (Refer to Mechanical Emergency
Door Release).
• Never use the centrifuge if parts of its cover panels are
damaged or missing.
• Do not touch the electronic components of the centrifuge
or alter any electronic or mechanical components.
• Observe the safety instructions.
Pay particular attention to the following aspects:
Item Description Quantity Check
Centrifuge GT 2/2R 1
Power supply cable 1
Instruction manual 1
CD 1
Anti-corrosion oil 1

2 | Centrifuge GT 2/2R
• Location: well-ventilated environment, set-up on a level
and rigid surface with adequate load-bearing capacity.
• Rotor installation: make sure the rotor is locked properly
into place before operating the centrifuge.
• Especially when working with corrosive samples (salt
solutions, acids, bases), the accessory parts and vessel
have to be cleaned carefully.
• Always balance the samples.
Centrifuging hazardous substances:
• Do not centrifuge explosive or flammable materials or
substances which could react violently with one another.
• The centrifuge is neither inert nor protected against
explosion. Never use the centrifuge in an explosion-prone
environment.
• Do not centrifuge toxic or radioactive materials or any
pathogenic micro-organisms without suitable safety
precautions.
When centrifuging microbiological samples from the Risk
Group II (according to the Bio-safety Manual of the World
Health Organization WHO), aerosol-tight biological seals
have to be used.
For materials in a higher risk group, extra safety measures
have to be taken.
• If toxins or pathogenic substances have gotten into the
centrifuge or its parts, appropriate disinfection measures
have to be taken (Refer to section Disinfection).
• Highly corrosive substances which can cause material
damage and impair the mechanical stability of the rotor,
should only be centrifuged in corresponding protective
tubes.
IF A HAZARDOUS SITUATION OCCURS, TURN OFF
THE POWER SUPPLY TO THE CENTRIFUGE AND
LEAVE THE AREA IMMEDIATELY.
This symbol refers to general hazards.
CAUTION: means that material damage could
occur.
WARNING: means that injuries or material
damage or contamination could occur.
This symbol refers to biological hazards.
Observe the information contained in the
instruction manual to keep yourself and your
environment safe.

Centrifuge GT 2/2R Introduction and Description | 3
Introduction and Description
Characteristics
Several rotors with a wide range of tubes can be used.
The set speed is reached within seconds. The maintenance-
free induction motor ensures quiet and low-vibration
operation even at high speeds, and guarantees a very long
lifetime.
The user-friendly control panel makes it easy to pre-set the
speed, RCF value, running time, temperature, and running
profile (acceleration and braking curves). You can choose
between the display of speed and RCF or the entry mode.
These settings can be changed even while the centrifuge is
running.
With the help of the PULSE key , you can also centrifuge
a sample for just a few seconds, if called for.
The Centrifuge GT 2/2R is equipped with various safety
features:
• The housing and rotor chamber consist of steel plate, the
interior of armour steel, while the front panel is made of
high-impact resistant plastic.
• The lid is equipped with a view port and a lock.
• The lid of the centrifuge can only be opened while the
centrifuge is switched on and the rotor has come to a
complete stop. The centrifuge cannot be started until the
lid has been closed properly.
• The integrated rotor detection systems ensures that no
inadmissible speed settings can be preselected.
• Electronic imbalance recognition
• Lid emergency release: For emergencies only, e.g. during
power failures (Refer to the section Mechanical
Emergency Door Release)
Technical Data
The technical data of the Centrifuge GT 2/2R is listed in the following table.
PULSE
Table 1. Technical Data Centrifuge GT 2/2R
Feature Values
Environmental conditions
Use in interior spaces
Altitudes of up to 2
000 m above sea level
Max. relative humidity 80% up to 31 °C; decreasing linearly up to 50%
relative humidity at 40 °C.
Permissible ambient temperature +2 °C to +35 °C +2 °C to +35 °C
Overvoltage category II II
Pollution degree 2 2
Heat dissipation
Refrigerated Ventilated
230 V 230 V
4 778 BTU/h 3 447 BTU/h
IP 20 20
Running time unlimited unlimited
Max Speed nmax
15 200 rpm (depending on the rotor) 15 200 rpm (depending on the rotor)

4 | Introduction and Description Centrifuge GT 2/2R
Directives, Standards and Guidelines
Functions and Features
The following table gives an overview of the important functional and performance characteristics of the Centrifuge GT2/2R.
Min Speed nmin 300 rpm 300 rpm
Maximum RCF value at nmax
25 830 x g 25 830 x g
Maximum kinetic energy 62.5 kJ 51.7 kJ
Noise level at maximum speed < 63 dB (A) < 63 dB (A)
Temperature setting range -10 °C to +40 °C
Dimensions refrigerated ventilated
Height
Height with lid open
Width
Depth
Table top height
360 mm
870 mm
623 mm
605 mm
310 mm
360 mm
870 mm
440 mm
605 mm
310 mm
Weight without rotor 91.5 kg 57.5 kg
Table 1. Technical Data Centrifuge GT 2/2R
Feature Values
Table 2. Directives, Standards and Guidelines
Te n s i o n /
Frequency Directives
Produced and inspected
according to the following
standards and guidelines
220-230 V
50/60 Hz
2006/42/EC Machinery
2014/35/EU Low Voltage
(Protective Goals)
2014/30/EC Electromagnetic Compatibility (EMC)
2011/65/EC RoHS
Directive on the Restriction of the use of certain Hazardous
Substances in electrical and electronic equipment
EN 61010-1, 2nd Edition
EN 61010-2-020, 2nd Edition
EN 61326-1
EN ISO 14971
EN ISO 9001
Table 3. Functions and Features
Component/Function Description/Features
Structure/Housing Galvanized steel chassis with armoured plating
Chamber Stainless steel
Drive Induction drive without carbon brushes

Centrifuge GT 2/2R Introduction and Description | 5
Mains Supply
The following table contains an overview of the electrical connection data for the Centrifuge GT 2/2R. This data is to be taken
into consideration when selecting the mains connection socket.
*Contact an authorized customer service representative for running the centrifuge at 60 Hz.
Refrigerant
*Contains fluorinated greenhouse gases in a hermetically sealed system.
Keys and display Easy-to-clean keypad and display surface
Controls Microprocessor-controlled
Internal memory The most recent data is saved
Functions RCF-selection, temperature control, pretemp with cooling equipped devices
Acceleration/braking profiles 9 acceleration and 10 braking curves
Rotor recognition Automatic
Imbalance recognition Electronic, contingent on rotor and speed
Lid lock Automatic lid closing and locking starting from an initial hold position
Table 3. Functions and Features
Component/Function Description/Features
Table 4. Electrical connection data of the Centrifuge GT 2/2R.
Ty p e Mains
Voltage Frequency Rated Current
Power
Consumption
Equipment
Fuse
Building
Fuse
Refrigerated 230 V 50/60 Hz 8 A 1 400 W 15 AT 16 AT
Ventilated 230 V 50/60 Hz 6 A 1 010 W15 AT 16 AT
Table 5. Refrigerant Fisherbrand GT 2R Centrifuge
Order no. Refrigerant Quantity Pressure GWP CO2e
75004524 R-404A 0.38 kg 31 bar 3 922 2.04 t

6 | Introduction and Description Centrifuge GT 2/2R
Rotor Selection
Various rotors are available to choose from.
The technical data of the rotors and the corresponding
adapters and reduction sleeves for various commercially
available containers can be found in the corresponding rotor
operating manuals.
For more information visit our website at:
http://www.thermofisher.com
TX-400 75003629
with round buckets 75003655
TX-200 75003658
with round buckets 75003659
BIOShield™720 75003621
M-20 75003624
Microliter™30x2 sealed 75003652
CLINIConic™30x15 75003623
8x50 sealed 75003694
FIBERLite™F15-6x100 75003698
HIGHConic™II 75003620
TX-1000
TX-750
BIOShield™1000 A
M-20
75003017
75003180
75003182
75003624
