TIPTEL 6120 User manual

User Guide (en)
tiptel Ergophone
6120/6121
tiptel

3
Important information
This phone is intended for inexperienced users. The
factory settings only make available the functions
that are generally used most often. This manual
therefore concentrates primarily on these basic
functions.
Use menu option "User level settings" in the "Set-
tings" menu to switch the phone from "Beginner
mode" to "Advanced mode". Additional functions
then become available to you.
Note: If you change phone settings in "Advanced
mode", these changes remain available
even if you later revert back to "Beginner
mode".
All options in the Main menu described in this man-
ual are in the factory settings for the device. You
can mask the main menu options that you do not
intend to use via menu option "Visibility main menu"
in the "Settings" menu.

4
Contents
Important information ........................................ 3
Contents ............................................................. 4
Safety information .............................................. 9
Initial use .......................................................... 11
Installing the SIM card(s),
memory card and battery.............................11
Charging the battery ....................................13
Switching on the phone ...............................14
Setting the date and time.............................15
Display symbols ............................................... 16
General information on using the phone ........ 17
Custom setup ................................................... 18
Using the phone as you want to ..................18
Call signalling as you want it........................19
Making calls as you want to.........................21
Making and accepting calls ............................. 21
Accepting calls .............................................21
Rejecting calls ..............................................22
Calling with direct dial ..................................22
Dialling with redial function ..........................22
Dialling from Contacts..................................22
Dialling via the Photo Speed Dial
Contacts .......................................................23

5
Contacts............................................................ 23
Options.........................................................24
Call.............................................................24
Send text message ...................................24
Add new contact .......................................24
Edit ............................................................26
Delete ........................................................26
Additional options .....................................26
Main contacts...............................................26
Messages (SMS) .............................................. 27
Viewing received messages ........................27
Sending messages ......................................28
Writing message text....................................29
More message options .............................29
Silent mode....................................................... 30
Call histories..................................................... 30
Displaying missed calls................................31
Camera.............................................................. 31
Image settings..............................................32
Storage.........................................................32
Image viewer ................................................32
Transferring photos to a computer...........33
Magnifier function ............................................ 33

6
FM radio............................................................ 34
Radio mode options.....................................34
Channel list................................................34
Auto search ...............................................35
Additional options .....................................35
Sound recorder ................................................ 35
Recorder options..........................................35
New record................................................36
List .............................................................36
Settings......................................................36
Additional options .....................................36
Alarm................................................................. 37
Calculator ......................................................... 38
Tasks................................................................. 38
Services ............................................................ 39
Bluetooth .......................................................... 39
Settings............................................................. 40
Phone settings..............................................40
Time and date ...........................................41
Tone settings.............................................41
Talking keys ...........................................41
Volume ......................................................41
Alert type ...................................................42
Language ..................................................42
Font size ....................................................42

7
Additional phone settings .........................42
Ring type ................................................42
System alert ...........................................42
Display settings......................................43
User level settings ........................................43
Security settings...........................................43
Additional settings ........................................... 44
Call settings..................................................44
Visibility main menu .....................................44
Order main menu .........................................45
Emergency settings .....................................46
Dual SIM settings .........................................46
Network settings...........................................46
Connections .................................................47
Restore settings ...........................................47
Connection to a computer ............................... 48
SOS call ............................................................ 48
Testing of the emergency call function........51
Emergency call configuration ......................51
Emergency button active on/off................52
Emergency numbers ................................52
Confirmed emergency call On/Off............53
Cancelling an emergency call .....................53
Important information on
emergency functions....................................54

8
Appendix........................................................... 55
Warranty .......................................................55
Guarantee.....................................................55
Declaration of conformity.............................55
Disposal........................................................56

9
Safety information
Only use the phone at places where it is permit-
ted. As a rule, use of mobile phones is prohibit-
ed in hospitals, aircraft and at filling stations.
Do not open the device yourself, and do not at-
tempt repairs on your own. Repairs may only be
performed by qualified specialists.
Do not expose the phone to smoke, chemicals,
humidity, dust or excessive heat (direct sun-
light).
Keep the phone and accessories away from
children.
The phone's speaker can be set to a
very loud volume. Check the volume
before use to avoid damaging your
hearing. Loud noises over longer pe-
riods can result in hearing damage.
When driving, only use this phone with an ap-
proved hands-free set. Observe the legal regula-
tions specific to the country of use.
Keep the phone 20cm from any implanted
pacemaker. Switch off the phone immediately if
you feel or suspect any impairment.
Do not use any power supply unit other than the
one supplied.

10
Only use original accessories and batteries.
The phone is not waterproof. Avoid contact with
liquids.
Do not rely exclusively on your mobile phone's
emergency function in emergencies. Establish-
ing an emergency connection may not always
be possible for technical reasons.
Dispose of the device and the battery in line with
environmental guidelines. Your local waste dis-
posal provider offers collection points for elec-
tronic waste and batteries. Do not dispose of the
device or battery in household rubbish or throw
into a fire.
Please dispose of packaging materials in line
with local regulations.

11
Initial use
Installing the SIM card(s), memory card and battery
A SIM card, available from your phone
supplier, is required to use the phone.
The SIM card(s), battery and memory card must be
installed before the phone is used for the first time.
A memory card (not included) is required
to send multimedia messages (MMS), to
save photos with the integrated camera
and to record voice notes with the integrated re-
corder. The Ergophone 6120/6121 supports Micro
SD memory cards with a capacity of up to 16 GB -
these can be purchased on the accessories market
and at electronics shops.
Fig. 1 Fig. 2

12
Fig. 3 Fig. 4
Remove the case cover on the back of the device to
insert the SIM card(s), the battery and a memory
card. Press the casing cover and slide it downward
until it can be removed (Fig. 1).
Slide the metal catch of the slot for the first SIM
card (SIM1) towards the top of the device and fold it
upward (Fig. 2). Exercise extra care here.
Carefully install the (first) SIM card in the card hold-
er. After the card is inserted, the metal holder is
pushed forward, so that it secures the card and can
no longer slide upward (Illustration 3). Exercise ex-
tra care here. If the metal holder does not slide easi-
ly, it is usually an indication that the card is not in-
serted correctly.
If you want to use the phone with two SIM cards,
install the second SIM card in the same way as the
slot next to it (underneath the emergency button).

13
The battery is inserted next (only possible in the
correct position - Fig. 4).
Then replace the case cover and slide it towards
the emergency button until it clicks into place.
Charging the battery
A charger and a power supply unit are supplied
with your phone.
Insert the small connector on the
power supply unit into the jack on
the rear of the charger cradle. The
side of the connector with the USB
logo must be facing the underside of
the charger cradle. If it is not easy to insert the con-
nector into the jack, check the direction and avoid
applying force. Then plug the power supply unit in-
to the socket.
Place the telephone in its closed position in the
charger; the battery now charges. During the charg-
ing process, the red battery LED at the front of the
device blinks. When the charging process is com-
plete, the battery LED goes out.
Instead of charging via the charger cradle, the
power supply plug can also be connected directly
to the jack on the side of the telephone. The battery
can also be charged via a computer's USB con-

14
nector. In both cases, the USB logo on the con-
nector must be facing the front of the phone.
Battery performance diminishes over time. If you
notice after a time that you need to recharge your
phone more frequently, replace the battery.
For safety reasons, the battery switches off be-
fore it is totally discharged. If you have not used
the telephone for a long time, wait up to 10
minutes after you have plugged in the charger.
This switches the battery back on and the charg-
ing process starts.
Switching on the phone
To switch on the phone, press the red hang up key
for 3 to 5 seconds .
You are then prompted to enter the SIM card PIN (if
enabled for the SIM card). Enter the PIN from the
keyboard, then press the display button on the left
(OK).
Note: In "Settings" "Security Settings", you
can change the SIM card PIN and ena-
ble/disable the prompt.

15
Setting the date and time
After switching on for the first time (and when the
battery is removed for longer periods), the tele-
phone automatically synchronises date and time
from the service provider network.
If your service provider does not support this func-
tionality, the date and time must be set manually.
To do this, press the left Display key under
"Menu", then keep pressing the "down arrow" key
until "Settings" is displayed. Then press the
key under "OK" three times to access "Set-
tings", then "Phone Settings", then "Time and date".
Select "Set date" then "Set time", and use the key-
pad to enter the current date and time.
You can close the settings by repeatedly pressing
the key under "Back", and also by pressing the
red hang-up key once.
The correct date and time are then shown on the
display.

16
Display symbols
Multiple symbols are displayed at the top of the
display depending on your current situation.
Shows the signal strength of the wire-
less network. In dual-SIM mode, the left-
hand symbol shows the signal strength
of the SIM1 network, the right-hand
symbol that of the SIM2 network.
Battery charge status.
Unread text message(s) (SMS or MMS)
on SIM1/SIM2.
Call(s) received in your absence on
SIM1/SIM2.
Silent profile enabled/disabled.
Call divert for SIM1/SIM2 enabled.
Alarm enabled.
Headset connected.
Compatibility with Bluetooth devices
enabled.
Roaming. The phone is registered in a
network abroad.

17
The phone is connected to a computer.
Data transmission active.
General information on using the phone
The left and right Display keys have different
functions depending on the status of the device.
The functions currently available for the keys are
shown above the keys on the display.
The right-hand Display key is usually used to cancel
the function or to go back one step. Confirm func-
tions or open the Options menu with the left-hand
Display key.
In standby, the left Display key calls up the main
menu, the right Display key opens the contacts.
The and keys are used to select entries
in menu lists.
The red hang-up key is used to end a call, to
reject a call and (with prolonged pressing) to switch
the device on and off. Within menus, settings can
be cancelled with this key.
The green Dial key is used for calling after en-
tering a number, or to select a contact. Pressing
this key in standby opens the list of recently called
numbers for redial.

18
Prolonged pressing of the key enables and
disables Silent mode.
The key enables you to toggle between upper
and lower case during the text entry of, for example,
an SMS or a name in Contacts.
Custom setup
An ergonomic telephone should be simple to use
and make communication more easy for the user.
At the same time it should also meet your needs,
however individual they may be. The tiptel Ergo-
phone [phone] enables you to customise the
phone to your needs in a special way.
Note: Some of these functions can only be set in
"Advanced mode", but are also available af-
terwards in "Beginner mode".
Using the phone as you want to
Are you a new user wanting a mobile that enables
you to "only" make and receive calls quickly and
easily, or are you an experienced user who attaches
importance to comprehensive functionality?
"Tell" this to your tiptel Ergophone 6120/6121 under
Settings Userlevel settings.

19
In Settings, and when using the phone, the "Begin-
ner mode" setting only makes available functions
that are normally used frequently. "Advanced mode"
gives you access to the full functionality of the de-
vice. As a new user, you are able to read and write
text messages (SMS) for example. As an experi-
enced user, you can in addition use templates, cre-
ate drafts and create multimedia messages (MMS).
Not using all of the phone's functions and do not
want to be shown functions that are not used?
"Tell" your tiptel Ergophone 6120/6121, under Set-
tings Visibility main menu, the functions you
want to be shown in the main menu.
You want quick access to frequently used func-
tions?
"Tell" your tiptel Ergophone 6120/6121, under Set-
tings Order main menu, the order in which you
want functions to be displayed.
Call signalling as you want it
Have a favourite tune and want to use it as the ring-
tone for your mobile?
Install in the mobile a memory card with the tune on
it, and "tell" your tiptel Ergophone 6120/6121, under
Settings Phone settings Tone settings

20
Incoming Call, that you would like this tune to
be used.
Not only want to hear that you are being called, but
also know who is calling?
Save your contacts in the telephone's memory and
select, in the contact details with caller ringtone, a
specific ringtone for this caller. Or use the integrat-
ed sound recorder to record a message, such as
"William is calling", and select it as your caller ring-
tone.
Do you also want to see as well as hear who is call-
ing?
"Tell" this to your tiptel Ergophone 6120/6121 by
adding a picture of the caller to the memory under
Contacts. It is then shown on the display for incom-
ing and outgoing calls.
Good at remembering numbers and want the num-
ber of the caller to be announced before the phone
rings?
"Tell" your tiptel Ergophone 6120/6121, under Set-
tings Phone Settings Tone settings
Number announcement, that you would like num-
bers to be announced.
