TMG TMG-SFM60 User manual
Skid Steer Forestry Drum Mulcher Attachment
www.tmgindustrial.com (USA)
www.tmgindustrial.ca (Canada) Toll Free:1-877-761-2819
PRODUCT MANUAL
Model:TMG-SFM60
•Please read the product manual completely before assembly
•Check against the parts list to make sure all parts are received
•Wear proper safety goggles or other protective gears while in assembly
Missing parts or questions on assembly?
Do not return the product to dealer, they are not equipped to handle your
requests
TABLE OF CONTENTS
TO THE OWNER..................................................................................................................................2/27
SAFETY PRECAUTIONS.....................................................................................................................3/27
SKID STEER FORESTRY DRUM MULCHER ATTACHMENT ASSEMBLY.........................................7/27
OPERATION INSTRUCTIONS.............................................................................................................21/27
MAINTENANCE INSTRUCTIONS.......................................................................................................23/27
STORAGE INSTRUCTIONS................................................................................................................26/27
SPECIFICATIONS................................................................................................................................27/27
www.tmgindustrial.com (USA) www.tmgindustrial.ca (Canada) Toll Free:1-877-761-2819
P 1 / 27
TO THE OWNER
GENERAL COMMENTS
Congratulations for having this skid steer forestry drum mulcher attachment!
Your skid steer forestry drum mulcher attachment was carefully designed and
manufactured to give you years of dependable service. Your skid steer forestry
drum mulcher attachment will require some minor maintenance(such as
cleaning and lubricating) to keep it in top working condition.
Be sure to observe all safety precautions and maintenance procedures as
described in this manual.
ABOUT THIS MANUAL
This manual has been designed to help you do a better and safer job. Read this
manual carefully and become familiar with its contents. Remember, never let
anyone operate this unit without reading the "Safety Precautions" and
"Operation Instructions" sections of this manual. Unless noted otherwise, right
and left sides are determined from the position of the skid steer operator sitting
in the seat facing forward.
SERVICE
When service your skid steer forestry drum mulcher attachment,pls. remember
to use only manufacturer replacement parts. Substitute parts may not meet the
standards required for safe, dependable operation. To facilitate parts ordering,
pls. record the model No. and serial No. of the metal plate on your unit.
www.tmgindustrial.com (USA) www.tmgindustrial.ca (Canada) Toll Free:1-877-761-2819
P 2 / 27
SAFETY PRECAUTIONS
The skid steer forestry drum mulcher attachments are designed to be easy to
use and maintain. They are operated by the skid steer auxiliary hydraulics. The
skid steer forestry drum mulcher attachments mount to the toolbar or quick
attach mechanism for easy mounting.
BEFORE OPERATION
1.The operator must read the operation manual carefully before installation,
operation or maintenance. Improper operation will cause the machine damaged
or the operator dead.
2.Read all the safe signs and safe declarations. Obey all the professional safe
terms, local laws or the professional directions.
3.Familiar with the skid steer forestry drum mulcher attachment about
functions, specs and operation. Replace the to-be-damaged parts in time. Make
sure all the hydraulic installations and couplings connect firmly, and all the
safe signs stick on the suitable positions clearly.
TO THE OPERATOR
WARNING! PROTECT AGAINST FLYING DEBRIS
1. Always wear proper safety glasses, goggles, or a face shield when
driving pins in or out, or when any operation causes dust, flying debris,
or any other hazardous material.
2. Don’t modify the skid steer forestry drum mulcher attachment casually.
3. Should keep the machine on the flat ground when repair, far away from the
transportation and other dangerous places.
4. Should use the right tools to repair.
5. Don’t operate the machine, unless you are professional, have certificates,
and familiar with its functions, specs and safe operation rules.
6. Must not leave the machine when the machine is running. Must stop the
engine at first and then remove the key if want to leave.
www.tmgindustrial.com (USA) www.tmgindustrial.ca (Canada) Toll Free:1-877-761-2819
P 3 / 27
SKID STEER FORESTRY DRUM MULCHER ATTACHMENT ASSEMBLY
PART NO.
S/N NUMBER
PART DESCRIPTION
QTYS
NOTE
1
051360-01
Cutting Drum Assembly
1
2
051360-02
Bolt M8X16
34
3
051360-03
Spring Washer D8
46
4
051360-04
Flat Washer D8
46
5
051360-05
Mechanical Transmission Assembly
1
6
051360-06
Transparent Air tubeφ12-600
1
7
051360-07
Pagoda-Shape Connector G3/8
2
8
051360-08
Hose Clampφ16
2
9
051360-09
Vent Plug G1/4
4
10
051360-10
Oil Filling Port
1
11
051360-11
Split Pin D8x60
1
12
051360-12
Hexagon Bolt M6x16
17
13
051360-13
Spring Washer D6
17
14
051360-14
Flat Washer D6
17
15
051360-15
Side Seal Plate
1
16
051360-16
Cover Plate For Tighten or Loosen
1
17
051360-17
Hexagon Bolt M16x60
4
18
051360-18
Spring Washer D16
8
www.tmgindustrial.com (USA) www.tmgindustrial.ca (Canada) Toll Free:1-877-761-2819
P 9 / 27
SKID STEER FORESTRY DRUM MULCHER ATTACHMENT ASSEMBLY
PART NO.
S/N NUMBER
PART DESCRIPTION
QTYS
NOTE
19
051360-19
Flat Washer D16
8
20
051360-20
Nut M16
4
21
051360-21
Upper Refueling Board
1
22
051360-22
Upper Cover Plate 1
1
23
051360-23
Hexagon Bolt M8x20
18
24
051360-24
Hexagon Bolt M16x50
4
25
051360-25
Hydraulic System
1
26
051360-26
Hexagon Bolt M8x25
6
27
051360-27
Radiator Support Plate
2
28
051360-28
Rubber Plate
2
29
051360-29
Pressure Gauge
1
30
051360-30
Dust Cover
1
31
051360-31
Upper Cover Plate 2
1
32
051360-32
Hexagon Bolt M12x80
1
33
051360-33
Spring Washer D12
19
34
051360-34
Flat Washer D12
19
35
051360-35
Backing Plate
2
36
051360-36
Hexagon Bolt M12x30
18
37
051360-37
Reinforcing Plate
1
www.tmgindustrial.com (USA) www.tmgindustrial.ca (Canada) Toll Free:1-877-761-2819
P 10 / 27
SKID STEER FORESTRY DRUM MULCHER ATTACHMENT ASSEMBLY
PART NO.
S/N NUMBER
PART DESCRIPTION
QTYS
NOTE
38
051360-38
Hexagon Bolt M10x30
2
39
051360-39
Spring Washer D10
2
40
051360-40
Flat Washer D10
2
41
051360-41
Hexagon Bolt M12x40
1
42
051360-42
Hexagon Bolt M16x120
4
43
051360-43
Pull Rod
2
44
051360-44
Hexagon Bolt M16x90
2
45
051360-45
Front Push Bar
1
46
051360-46
Rear Cover Plate
2
47
051360-47
Hexagon Bolt M12x25
12
48
051360-48
Skid Chain Mounting Base
1
49
051360-49
Hanger Rod
1
50
051360-50
Hexagon Bolt M10
4
51
051360-51
Chain
73
www.tmgindustrial.com (USA) www.tmgindustrial.ca (Canada) Toll Free:1-877-761-2819
P 11 / 27
SKID STEER FORESTRY DRUM MULCHER ATTACHMENT ASSEMBLY
PART NO.
S/N NUMBER
PART DESCRIPTION
QTYS
NOTE
A1
051360-01-01
Hexagon Bolt M6x25
6
A2
051360-01-02
Spring Washer D6
6
A3
051360-01-03
Flat Washer D6
6
A4
051360-01-04
Seal End Cap A
1
A5
051360-01-05
O-ring 147x1.8
1
A6
051360-01-06
Round Nut M65x2
1
A7
051360-01-07
Cylindrical Roller Bearing
1
A8
051360-01-08
Left Bearing Seat
1
A9
051360-01-09
Purge Plug M12x1
1
A10
051360-01-10
Tab Washers for Round Nut D65
1
A11
051360-01-11
Skeleton Seal 80x100-10
2
A12
051360-01-12
Hexagon Bolt M12x60
6
A13
051360-01-13
Spring Washer D12
6
A14
051360-01-14
Flat Washer D12
6
A15
051360-01-15
O-ring133x1.8
1
A16
051360-01-16
Skeleton Seal 60x80-10
1
A17
051360-01-17
Right Cover Plate
1
www.tmgindustrial.com (USA) www.tmgindustrial.ca (Canada) Toll Free:1-877-761-2819
P 13 / 27
SKID STEER FORESTRY DRUM MULCHER ATTACHMENT ASSEMBLY
PART NO.
S/N NUMBER
PART DESCRIPTION
QTYS
NOTE
A18
051360-01-18
Left Drive Shaft
1
A19
051360-01-19
Cutting Drum
1
A20
051360-01-20
Cutting Tooth
49
A21
051360-01-21
Outer Hexagon Bolt M16x60
49
A22
051360-01-22
Flat Washer D16
61
A23
051360-01-23
Spring Washer D16
61
A24
051360-01-24
Right Connecting Shaft
1
A25
051360-01-25
Sealing Cover
1
A26
051360-01-26
O-ring C132X1.8
1
A27
051360-01-27
Bearing Seat
1
A28
051360-01-28
Bearing
1
A29
051360-01-29
End Cap
1
A30
051360-01-30
O-ring
1
A31
051360-01-31
Bolt M16x50
12
A32
051360-01-32
Bearing End Cover
1
A33
051360-01-33
Bolt M6x40
6
www.tmgindustrial.com (USA) www.tmgindustrial.ca (Canada) Toll Free:1-877-761-2819
P 14 / 27
SKID STEER FORESTRY DRUM MULCHER ATTACHMENT ASSEMBLY
PART NO.
S/N NUMBER
PART DESCRIPTION
QTYS
NOTE
B1
0513-05-01
Synchronous Belt
1
B2
0513-05-02
Driven Wheel
1
B3
0513-05-03
Expansion Sleeve Z2-60X90
2
B4
0513-05-04
Hexagon Bolt M12x45
1
B5
0513-05-05
Spring Washer D12
1
B6
0513-05-06
Flat Washer D12
1
B7
0513-05-07
Rotation Shaft
1
B8
0513-05-08
Square Steel
1
B9
0513-05-09
Deep Groove Ball Bearing
2
B10
0513-05-10
Tension Wheel
1
B11
0513-05-11
Nut M20
2
B12
0513-05-12
Screw Stem
1
B13
0513-05-13
Driving Wheel
1
B14
0513-05-14
Bolt M6x25
6
B15
0513-05-15
Spring Washer D6
6
www.tmgindustrial.com (USA) www.tmgindustrial.ca (Canada) Toll Free:1-877-761-2819
P 16 / 27
SKID STEER FORESTRY DRUM MULCHER ATTACHMENT ASSEMBLY
PART NO.
S/N NUMBER
PART DESCRIPTION
QTYS
NOTE
B16
0513-05-16
Flat Washer D20
6
B17
0513-05-17
Bearing End Cover
1
B18
0513-05-18
O-ring
1
B19
0513-05-19
Skeleton Seal
1
B20
0513-05-20
Output Shaft
1
B21
0513-05-21
Cylindrical Roller Bearing
2
B22
0513-05-22
Lock Nut
2
B23
0513-05-23
Stop Gasket
1
B24
0513-05-24
Bearing Seat
1
B25
0513-05-25
O-ring
1
B26
0513-05-26
Ventilating Screen
2
B27
0513-05-27
Plug
1
www.tmgindustrial.com (USA) www.tmgindustrial.ca (Canada) Toll Free:1-877-761-2819
P 17 / 27
SKID STEER FORESTRY DRUM MULCHER ATTACHMENT ASSEMBLY
PART NO.
S/N NUMBER
PART DESCRIPTION
QTYS
NOTE
C1
051360-25-01
Pressure Tap
1
C2
051360-25-02
Manifold Block
1
C3
051360-25-03
Drain Hose A
1
C4
051360-25-04
Bulkhead Connector
1
C5
051360-25-05
End Straight Joint
4
C6
051360-25-06
Angle one-way valve
1
C7
051360-25-07
End Straight Joint
2
C8
051360-25-08
Drain Hose B
1
C9
051360-25-09
Motor Hose A
1
C10
051360-25-10
Flange Joint
2
C11
051360-25-11
O-ring 30X3.55-G-N
2
C12
051360-25-12
Inclined Shaft Axial Piston Motor
1
C13
051360-25-13
End Straight Joint
1
C14
051360-25-14
Motor Hose B
1
C15
051360-25-15
Motor Hose C
2
C16
051360-25-16
Plug M18*1.5
2
www.tmgindustrial.com (USA) www.tmgindustrial.ca (Canada) Toll Free:1-877-761-2819
P 19 / 27
Table of contents
Other TMG Farm Equipment manuals
Popular Farm Equipment manuals by other brands
Crary
Crary CWS CASE IH 2162 Owner's manual and parts manual
MASCHIO GASPARDO
MASCHIO GASPARDO ADMIRAL Use and maintenance
Smithco
Smithco TCV 5000 Parts & Service operators
Raven
Raven RS1 installation manual
GSI Group
GSI Group PNEG-1020 Installation & operation manual
Johnny's Selected Seeds
Johnny's Selected Seeds Bio Plus PATIO user guide
