Topdon PulseQ AC Home US Version User manual

AC EV Charger
User Manual
US Version

Abbreviations
Contents
International Electrotechnical Commission
Electrical Vehicle, this can be BEV (battery EV) or PHEV (plug-in hybrid EV)
Electric Vehicle Supply Equipment [IEC61851-1]
On-board charger (of an EV)
Kilo Watt (unit of Power)
Ampere (unit of Current)
Volt (unit of Voltage)
Hertz (unit of Frequency)
Liquid Crystal Display
Light-emitting Diode
Abbreviations
Section 1—PRECAUTIONS
Section 2—STANDARDS COMPLIANCE
Section 3— PRODUCT OVERVIEW & INFO
Section 4—What's in the Box?
Section 5—Installation
Section 6—Network Conguration
Section 7—LED Indicators
Section 8—Fault Handling
Section 9—Warranty
Section 10—FCC
3
4
10
12
16
17
29
36
37
38
39
....................................................................................................
....................................................................................................
....................................................................................................
....................................................................................................
....................................................................................................
....................................................................................................
....................................................................................................
....................................................................................................
....................................................................................................
....................................................................................................
....................................................................................................
IEC
EV
EVSE
OBC
KW
A
V
Hz
LCD
LED
1
2
3
4
5
6
7
8
9
10
Human-Machine Interface
Charging Circuit Interrupting Device
Ground Monitor Interrupter
Ground Fault Circuit Interrupter
HMI
CCID
GM/I
GFCI
13
14
15
16
Central Management System, manages EVSE and has the information for
authorizing users for using its EVSE.
CMS11
Open Charge Point Protocol
A standard open protocol for communication between EVSE and a Central
System and is designed to accommodate any type of charging technique.
(www.openchargealliance.org)
OCPP12
S/N Abbreviations Description

Section 1—PRECAUTIONS
1.1 IMPORTANT SAFETY PRECAUTIONS
4
WARNING- When using electric products, basic precautions should always be followed, including
the following. This manual contains important instructions for Models and PULSEQ AC HOME that
shall be followed during the installation, operation, and maintenance of the charging station.
Read all the instructions before using this product.
This device should be supervised when used around children.
Do not put ngers into the electric vehicle connector.
Do not use this product if the exible power cord or EV cable is frayed, has broken insulation, or has
any other signs of damage.
Do not use this product if the enclosure or the EV connector is broken, cracked, open, or shows any
other indication of damage.
Note the ambient temperature rating: -22°F to 131°F (-30°C to 55°C)
CAUTION: To reduce the risk of re, connect only to a circuit provided with 50 amperes maximum
branch circuit overcurrent protection in accordance with the National Electrical Code, ANSI/NFPA
70, and the Canadian Electrical Code, Part I, C22.1.
6.
7.
5.
4.
1.
2.
3.
Current RatingModel
50 APulseQ AC Home

5
1.2.1 Safety signs used
The following warning signs, mandatory signs and information signs are used in this manual, on and in the AC EV
Charger.
CAUTION: Warning of electrical hazards.
This sign is intended to alert the user that severe personal injury or substantial property damage can
result if the device is not operated as requested.
ATTENTION: Warning of a dangerous spot or dangerous situation.
This sign is intended to alert the user that minor personal injury or material damage can result if the
device is not operated as requested.
CAUTION: Do not touch in case of ESD.
Indicates possible consequences of touching electrostatically sensitive components.
No access for unauthorized persons.
Use protective footwear.
Must wear a safety helmet.
Indicates important texts, notes, or tips.
1.2 SAFETY NOTES
Safety protection must be worn when installing the EV Charger.
Installation must be performed carefully due to risk of electric shock.
Must be installed vertically to allow for ventilation. Do not install in areas of vibration or risk of impact.
Install in noncombustible areas due to risk of re.
Do not drop any foreign objects, especially metal objects, inside the Charger due to risk of re.
The lead nose of the Charger must be securely attached due to risk of damage.
1.2.2 Safety Precautions for Installation
