Toro 02720 User manual

FormNo.3367-853RevC
36in(92cm)Mid-SizeFlail
Attachment
ModelNo.02720—SerialNo.312000001andUp
ToregisteryourproductordownloadanOperator'sManualorPartsCatalogatnocharge,gotowww.Toro.com.OriginalInstructions(EN)

ThisproductcomplieswithallrelevantEuropean
directives,fordetailspleaseseetheseparateproduct
specicDeclarationofConformity(DOC)sheet.
Introduction
Thisail-bladelawncuttingdeckismountedtoa
walk-behindtractionunitandisintendedtocutgrass
andotherlow-lyingvegetationwithinthelimitations
statedinthismanual.Useinanyotherwayisconsidered
ascontrarytotheintendeduse.Youareresponsiblefor
operatingtheproductproperlyandsafely.
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoidinjury
andproductdamage.
YoumaycontactTorodirectlyatwww.Toro.comfor
productandaccessoryinformation,helpndingadealer,
ortoregisteryourproduct.
Wheneveryouneedservice,genuineToroparts,or
additionalinformation,contactanAuthorizedService
DealerorToroCustomerServiceandhavethemodel
andserialnumbersofyourproductready.Themodel
andserialnumbersarestampedonaplateontheright
sideofthecuttingunit.Writethenumbersinthespace
provided.
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhassafety
messagesidentiedbythesafetyalertsymbol(Figure1),
whichsignalsahazardthatmaycauseseriousinjury
ordeathifyoudonotfollowtherecommended
precautions.
Figure1
1.Safetyalertsymbol
Thismanualuses2otherwordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.
Contents
Introduction.................................................................2
Safety...........................................................................3
SoundPowerLevel...............................................3
SoundPressureLevel...........................................3
VibrationLevel....................................................3
SafetyandInstructionalDecals.............................3
ProductOverview........................................................4
Specications.......................................................4
Attachments/Accessories.....................................4
Operation.....................................................................4
SettingtheHeightofCut......................................4
AdjustingtheAnti-scalpSkids..............................5
Maintenance.................................................................6
RecommendedMaintenanceSchedule(s)..................6
PreparingtheMachineforMaintenance................6
GreasingtheMachine...........................................6
MaintainingtheBlades.........................................7
CleaningUndertheGuards..................................7
CheckingtheRubberDischargeGuards................8
CheckingandAdjustingtheBrake.........................8
ReplacingtheGearboxDriveBelt.........................8
ReplacingtheRotorDriveBelt..............................9
CheckingtheGearboxOilLevel...........................9
Storage.......................................................................10
©2012—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN554202
Contactusatwww.Toro.com.
PrintedintheUK.
AllRightsReserved

Safety
Thisequipmenthasbeendesignedandconstructedso
that,insofarasisreasonablypractical,theymeetthe
safetyrequirementsofEuropeanstandardEN12733
andtheywillnotendangerthehealthandsafetyofthose
workingwiththem.Thisis,however,subjecttothe
machinebeingproperlymaintainedandusedaccording
totheconditionsstatedinthisOperator’sManual,which
havebeenfoundnecessaryasaresultoftheresearch
andtestingoftheTorocompany.
Thiscuttingailattachmentiscapableofamputating
handsandfeetandthrowingobjects.Failuretoobserve
thesafetyinstructionscouldresultinseriousinjuryor
death.Forallsafetyinformationrefertothetraction
unitOperator’sManual.
SoundPowerLevel
Thisunithasaguaranteedsoundpowerlevelof107
dBA,whichincludesanUncertaintyValue(K)of2dBA.
Soundpowerlevelwasdeterminedaccordingtothe
proceduresoutlinedinEN12733.
SoundPressureLevel
Thisunithasasoundpressurelevelattheoperator’s
earof93dBA,whichincludesanUncertaintyValue(K)
of2dBA.
Soundpressurelevelwasdeterminedaccordingtothe
proceduresoutlinedinEN12733.
VibrationLevel
Measuredvibrationlevelforrighthand=3.3m/s2
Measuredvibrationlevelforlefthand=3.3m/s2
UncertaintyValue(K)=1.6m/s2
Measuredvaluesweredeterminedaccordingtothe
proceduresoutlinedinEN12096.
SafetyandInstructional
Decals
Safetydecalsandinstructionsareeasily
visibletotheoperatorandarelocated
nearanyareaofpotentialdanger.
Replaceanydecalthatisdamagedor
lost.
320006
1.Heightofcut
40-13–010
1.Cuttinghazardofhand
2.Cuttinghazardoffoot
3

ProductOverview
Specications
Note:Specicationsanddesignaresubjecttochange
withoutnotice.
Length83.5inches(212cm)
Width43.1inches(109.5cm)
Height44inches(112cm)
Weight,
cuttingunit
only
298lb(135kg)
Engine
Speed
3600rpm
Rotor
Speed
3000rpm
Numberof
Blades
24
Attachments/Accessories
AselectionofToroapprovedattachmentsand
accessoriesareavailableforusewiththemachineto
enhanceandexpanditscapabilities.Contactyour
AuthorizedServiceDealerorDistributororgoto
www.Toro.comforalistofallapprovedattachments
andaccessories.
Operation
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
SettingtheHeightofCut
Youcansettheheightofcutofthemowerfrom1/2to
5-1/2inches(12.7mmto140mm)asfollows:
1.Stoptheengineandallowallmovingpartstostop.
2.Whilefacingthemowerfromthefront,releasethe
turnbucklelock(Figure2).
Figure2
1.Turnbucklelock2.Turnbuckle
4

3.Turntheturnbuckleclockwisetolowertheheight
ofcutandcounterclockwisetoraiseituntilyou
reachthedesiredsettingontheheight-of-cutgauge
(Figure2).
Height-of-cutPosition
(HeightinInches)
HeightofCut(mm)
1/213mm
125mm
1-1/238mm
251mm
2-1/264mm
376mm
3-1/289mm
4102mm
4-1/2114mm
5127mm
5-1/2140mm
4.Settheturnbucklelocktolocktheheight-of-cut
settinginplace.
AdjustingtheAnti-scalpSkids
1.Parkthemachineonaatlevelsurface,stopthe
engine,andwaitforallmovingpartstostop.
2.Loosenthetwoboltsandnutssecuringananti-scalp
skidandraiseorloweritsothattheyarelowerthan
thebladesbutnottouchingtheground(Figure3).
Figure3
1.Heightofcut2.Anti-scalpskid
3.Tightentheboltsandnuts.
4.Repeatthisprocedurefortheothersideusingthe
samemeasurementyousetinstep2.
5

Maintenance
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
RecommendedMaintenanceSchedule(s)
MaintenanceService
IntervalMaintenanceProcedure
Beforeeachuseordaily
•Inspectthebladesforwearordamage.
•Cleanundertheguards.
•Checktherubberdischargeguards.
Every50hours
•Greasethettings
•Checkthebrake.
•Checkthegearboxdrivebeltforwearordamage.
•Checktherotordrivebeltforwearordamage.
•Checkthegearboxoillevel.
Every400hours•Greaseinternalparts
CAUTION
Ifyouleavethekeyintheignitionswitch,someonecouldaccidentlystarttheengineandseriouslyinjure
youorotherbystanders.
Removethekeyfromtheignitionanddisconnectthewirefromthesparkplugbeforeyoudoany
maintenance.Setthewireasidesothatitdoesnotaccidentallycontactthesparkplug.
PreparingtheMachinefor
Maintenance
Beforecarryingoutanyinspectionormaintenance,
completethefollowing:
1.Parkthemachineonalevelsurface,disengagethe
bladesandsettheparkingbrake.
2.TurntheignitionkeytotheOffpositionandremove
thekey.
3.Disconnectthesparkplugwiresfromthespark
plugs.
GreasingtheMachine
ServiceInterval:Every50hours—Greasethettings
Every400hours—Greaseinternal
parts
Greaseallttings(Figure4)withNo.2generalpurpose
lithiumbasedgreaseormolybdenumbasegrease,after
every50hoursofoperation.Cleaneachgreasetting
witharagandpumpgreaseintothettinguntilasmall
amountbeginstooozeoutofthebearings.Wipeup
anyexcessgrease.
Note:Youwillneedtoremovesomeofthemachine
guardstoreachallofthegreasettings.Replacethe
guardswhennished.
Figure4
1.Greasettings—greaseevery50hours
2.Internalgreasepoints—greaseevery400hours
Every400operatinghoursdisassemblethepoints
illustratedat#2inFigure4andapplyanti-seazegrease.
6

MaintainingtheBlades
InspectingtheBlades
ServiceInterval:Beforeeachuseordaily
Checkthebladesforwearordamagepayingparticular
attentiontothecuttingedge,curvedarea,andinstallation
hole(Figure5).Ifthebladeisexcessivelywornor
damagedreplacetheblade.Toensureasuperiorquality
ofcut,keepthebladessharp.
Figure5
1.Cuttingedge3.Installationhole
2.Curvedarea
WARNING
Awornordamagedbladecanbreak,andapiece
ofthebladecouldbethrownintotheoperator’s
orbystander’sarea,resultinginseriouspersonal
injuryordeath.
•Inspectthebladesperiodicallyforwearor
damage.
•Replaceawornordamagedblade.
ReplacingaBlade
1.Holdingthebladeinaragorpaddedglove,remove
thenut,bladebolt,andblade(Figure6).
Figure6
1.Bladebolt3.Nut
2.Blade
2.Discardtheblade,nut,andbolt.
3.Installanewbladewithanewnutandbladebolt
(Figure6).
4.Torquethefastenersto7.3ft-lb(10N-m).
CleaningUndertheGuards
ServiceInterval:Beforeeachuseordaily
Removethetopandsideguardsandremoveanydebris.
Replacetheguardswhennished.
Figure7
1.Sidebeltguard2.Topguard
7

CheckingtheRubber
DischargeGuards
ServiceInterval:Beforeeachuseordaily
Inspecttherearandthefrontrubberguardsforwearor
damage(Figure8).Replacedamagedrubberguardsto
preventobjectsbeingthrownintotheoperator’sarea.
Figure8
1.Rearrubberguard2.Frontrubberguard
CheckingandAdjustingthe
Brake
ServiceInterval:Every50hours
WiththePTOdisengaged,checkthebrakeclearanceto
ensurethatitis1to2mm(Figure9).Ifnot,adjustthe
brakenuttogivetheproperclearance.
Figure9
1.1to2mm2.Brakenut
ReplacingtheGearboxDrive
Belt
ServiceInterval:Every50hours—Checkthegearbox
drivebeltforwearordamage.
Visuallyinspectthebelt(Figure10),lookingfordirt,
wear,cracks,andsignsofoverheating.Ifbeltis
excessivelywornorshowsanysignsofdamage,replace
thebelt.
Figure10
1.1/2inch(13mm)deection
here
3.Idlerpulley
2.Locknut/adjusternut
Toreplacethebelt,completethefollowingprocedure,
referringtoFigure10throughout:
1.Loosenthelocknutandadjustingnuttoremove
tensioninthebelt
2.Removetheidlerpulleyandthewornbelt.
3.Installthenewbeltwiththeidlerpulley.
4.Checkthebelttension.
Thepropermowerbelttensionis4.5lb(2kg)of
forcetodeectthebelt1/2inch(13mm)atthe
midpointofthelongestspan(Figure10).
Adjustthetensionasfollows:
A.Loosenthelocknut(Figure10)
B.Turntheadjustingnuttoincreaseordecrease
thetensioninthebelt.
C.Tightenthelocknut.
8

ReplacingtheRotorDriveBelt
ServiceInterval:Every50hours—Checktherotor
drivebeltforwearordamage.
Visuallyinspectthebelt(Figure11),lookingfordirt,
wear,cracks,andsignsofoverheating.Ifbeltis
excessivelywornorshowsanysignsofdamage,replace
thebelt.
Note:Figure11showsthebeltviewedfromunderneath
butthebeltcanbechecked,adjustedorreplacedfrom
eitherthetoporthebottomaftertheremovalofthe
relevantguard.
Figure11
1.Locknut3.1/2inch(13mm)deection
here
2.Turnbuckle4.Idlerpulley
Toreplacethebelt,completethefollowingprocedure,
referringtoFigure11throughout:
1.Removetheidlerpulleyandthewornbelt.
2.Installthenewbeltwiththeidlerpulley.
3.Engagetheblade(PTO)leverandcheckthebelt
tension.
Thepropermowerbelttensionis10lb(4.5kg)of
forcetodeectthebelt1/2inch(13mm)atthe
midpointofthelongestspan(Figure11).
Important:Thebeltmustbetightenoughto
notslipduringheavyloadswhilecuttinggrass.
Overtensioningthebeltwillreducethegearbox,
belt,andidlerpulleylife.
Adjustthetensionasfollows:
A.Loosenthelocknut(Figure11)
B.Rotatetheturnbuckle.Increasethelength
betweentheeyeboltstoaddmoretensioninto
thebeltordecreasethelengthtodecreasethe
tensioninthebelt.
C.Tightenthelocknut.
CheckingtheGearboxOil
Level
ServiceInterval:Every50hours
1.Removethetopguard(Figure7).
2.Removetheplugfromthegearboxllholeand
checktheoillevel(Figure12).
Theoilshouldbeevenwiththebottomofthell
hole.
Figure12
1.Gearboxllhole
3.Ifitneedsoil,addEP220gearoiltothellhole
untilitstartstorunoutofthehole.
4.Installthepluginthellhole.
5.Installthetopguard.
9

Storage
RefertothetractionunitOperator’sManualfordetails
ofmachinestorage.
10
