Toro 30392 User manual

FormNo.3363-652RevA
CEKit
Groundsmaster®7200/7210TractionUnit
ModelNo.30392
InstallationInstructions
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
Safety
SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyareaof
potentialdanger.Replaceanydecalthatisdamagedorlost.
106-6754
1.Warning—donottouchthehotsurface.
2.Cutting/dismembermenthazard,fanandentanglement
hazard,belt—stayawayfrommovingparts.
112-1689
1.Tippinghazard—donotoperateonslopesgreaterthan14
degrees.
©2009—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.Toro.com.OriginalInstructions(EN)
PrintedintheUSA.
AllRightsReserved

Installation
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescriptionQty.Use
Latchlocatorbracket1
Bolt(5/16x3/4inch)1
Locknut(5/16inch)1
Lockinglatch1
Hoodsupport1
Bolt(5/16x2inches)2
Washer(5/16inch)4
1
Locknut(5/16inch)2
Installthelockinglatch.
Floorlockinglatch1
Carriagebolt(1/4x3/4inch)2
2Locknut(1/4inch)2
Installtheoorplatelockinglatch(for
2008andlatermodels)
Hoodhandle1
Plastitescrew(1/4x1.12inch)2
Washer(5/16inch)2
3Clamp1
Installthehoodhandle.
Bolt(5/16x1-1/4inches)2
Retainingnut(5/16inch)2
4Pushnut2
Securethebeltcovers.
5Bolt(5/16x1-1/4inches)1Securetheseatplate.
6Bolt(5/16x1-1/4inches)1Securethefootrest.
Safetydecal,112-16891
7Safetydecal,106-67541Installthedecals.
2

1
InstallingtheHoodLocking
Latch
Partsneededforthisprocedure:
1Latchlocatorbracket
1Bolt(5/16x3/4inch)
1Locknut(5/16inch)
1Lockinglatch
1Hoodsupport
2Bolt(5/16x2inches)
4Washer(5/16inch)
2Locknut(5/16inch)
Procedure
1.Unlatchandraisethehood.Usetheproprodto
holditinplace.Locatetheupper(rear)metalframe
supportrunningacrosstheundersideofthehood.
2.Intheupper,leftcornerofthemetalframe,locate
theholedrilledinthefaceofthesupport.Usea
drilltoopentheholetoaccepta5/16inch(8mm)
fastener.
3.InstallthelatchlocatorbracketasshowninFigure1
usingabolt(5/16x3/4inch)andlocknut(5/16
inch).
4.Useapenciltomarkthehoodatthecenterholeon
thepunch-outofthelatchlocatorbracket.Remove
thelatchlocatorbracket.
5.Pilotdrillaholeintheplastichoodatthemarked
spotandthenexpandtheholetoadiameterof1
inch.
6.Removethepunch-outfromthelatchlocator.Install
thelatchlocatorbrackettotheframeasinStep3
usingthebolt(5/16x3/4inch)andlocknut(5/16
inch).
7.Removethelockingnutfromthelatchassembly.
8.Installthelockinglatchthroughtheholedrilledin
thehoodandthepunchedoutholeinthelatch
locatorbracketwiththecatchfacingtheforward.
9.Installthelockingnutontothebottomofthelatch
tosecureitinplace.
3

G004787
2
1
3
4
5
6
Figure1
1.Holeinthefaceofthemetalframe
support
3.Latchlocatorbracket5.Lockinglatch,catchfacingforward
2.Locknut(5/16inch)4.Bolt(5/16x3/4inch)6.Lockingnut
10.Installthecatchplatetothelefthandframemember,
directlybelowtheinstalledlatch,attheexistingholes
asshowninFigure2.Securethecatchplatetothe
framememberwithtwobolts(5/16x2inches),two
washers(5/16inch)andtwolocknuts(5/16inch).
4

Figure2
1.Leftframemember4.Washer(5/16inch)
2.Catchplate5.Locknut(5/16inch)
3.Bolt(5/16x2inches)
Note:Theboltsshouldbeapproximatelycentered
intheslotsofthecatchplate.
11.Closethehoodslowlytoseeiflatchcatches.Ifit
doesnot,loosentheboltssecuringthecatchplateto
theframememberandadjusttheplateasnecessary.
Tightentheboltsandverifythelatchcatches.
2
InstallingtheFloorPlate
LockingLatch(for2008and
latermodels)
Partsneededforthisprocedure:
1Floorlockinglatch
2Carriagebolt(1/4x3/4inch)
2Locknut(1/4inch)
Procedure
1.Raisetheoorplate(Figure3).
Figure3
1.Holeinoorplate3.Latch
2.Lockinglatch
2.Installthelatchbrackettotheframeusingtwo
carriagebolts(1/4x3/4inch)andtwolocknuts
(1/4inch)(Figure3).
3.Insertthelockinglatchintotheholeintheoor
platewiththecatchfacingtotheleft.
4.Installthelockingnutsontothebottomofthelatch
tosecureitinplace.
Note:Themountingholesinthelatchareslotted
sothelatchcanbeadjusted.
3
InstallingtheHoodHandle
Partsneededforthisprocedure:
1Hoodhandle
2Plastitescrew(1/4x1.12inch)
2Washer(5/16inch)
1Clamp
Procedure
1.Locatethehoodsupportrailontheinsideofthe
leftsideofthehood.
5

2.Measureup,fromthesupportedge,alongtherail
1-1/2inches(3.8cm)(Figure4).Installtheclamp
aroundtherailatthislocation.
3.Usingtheclampasatemplate,markaspotinthe
hoodanddrilla5/16inch(8mm)diameterhole.
4.Installawasher(5/16inch)andplastitescrew(1/4x
1.12inch)throughtheclampanddrilledholeinthe
hoodandintothehoodhandle.
5.Withthehoodhandleintheapproximateposition
showninFigure4markthesecondspottodrill4.8
inches(12.2cm)fromtheinitialdrilledhole.Swing
thehoodhandleoutofpositionanddrilla0.3125
inchdiameterholeatthatpositioninthehood.
6.Installawasherontotheotherplastitescrew(1/4x
1.12inch)andthroughthehood.Securethehandle
tothehoodbytighteningplastitescrews.
Figure4
1.Hood3.Drilledhole,5/16inch
diameter(8mm)
5.Washer(5/16inch)7.4.8inches(12.2cm)
2.1-1/2inches(3.81cm)4.Clamp6.Plastitescrew(1/4x1.12
inch)
6

4
SecuringtheBeltCovers
Partsneededforthisprocedure:
2Bolt(5/16x1-1/4inches)
2Retainingnut(5/16inch)
2Pushnut
Procedure
Performthisprocedurefortherightandleftsidebelt
covers.
1.Removethehandknobssecuringthebeltcoversto
themowerdeck.Removethebeltcovers.
2.Installaretainingnutattheforwardholeinthedeck
bracket.
Figure5
Leftsidebeltcovershown.
1.Beltcover5.Bolt(5/16x1-1/4inches)
2.Mowerdeck6.Handknob
3.Retainingnut7.Pushnut
4.Deckbracket
3.Installtheboltintothebeltcoverusingapushnut
(5/16inch).Installthebeltcoverwiththebolt(5/16
x1-1/4inches).Replacethehandknob.
5
SecuringtheSeatPlate
Partsneededforthisprocedure:
1Bolt(5/16x1-1/4inches)
Procedure
Installaboltintheseatplatetothesecureit.Locatethe
holeinthefront,rightsideoftheseatplate,infrontof
theOperator’sManualtube(Figure6).Installaboltinthe
thisholetosecuretheseatplate.
Figure6
1.Holeinseatplate3.Rightsideofseat
2.Holeinfootrest(for2007
modelsonly)
4.Rightmotioncontrollever
6
SecuringtheFootRest(2007
modelsonly)
Partsneededforthisprocedure:
1Bolt(5/16x1-1/4inches)
Procedure
Installaboltinthefootresttothesecureit.Locatethe
holeintheright,frontcornerofthefootrest(Figure6).
Installaboltinthisholetosecurethefootrest(for2007
modelsonly).
7

7
InstallingtheDecals
Partsneededforthisprocedure:
1Safetydecal,112-1689
1Safetydecal,106-6754
Procedure
Installeachdecalasfollows:
1.Thoroughlycleantheareawhereyouwillinstallthe
decal.
2.Dampentheareawithwaterormildlysoapywater.
3.Peelthedecalfromthebackingandinstallitinplace.
4.Squeegeeacrossthesurfaceofthedecal,starting
atthecenterofthedecalandworkingtowardthe
edges,usingoverlappingstrokes.
Figure7
1.Decal110-67543.Lockinglatch
2.Hood4.Decallocation
G004790
1
2
3
Figure8
Installoverexistingdecalatlocationshown
1.Decal112-16893.Installdecal112-1689at
thislocationoverexisting
decal
2.Existingdecal
8
