Toro reelmaster 3550 series User manual

FormNo.3375-852RevB
Right/Left-HandGroomerKit
Reelmaster®3550Series18-inchCutting
Unit
ModelNo.03914
ModelNo.03915
Registeratwww.Toro.com.
OriginalInstructions(EN)*3375-852*B

WARNING
CALIFORNIA
Proposition65Warning
Thisproductcontainsachemicalorchemicals
knowntotheStateofCaliforniatocausecancer,
birthdefects,orreproductiveharm.
Coveredbyoneormoreofthefollowingpatents:U.S.Patent
7,337,601
Introduction
Thegroomerkitsaremountedtothereelmowersona
ride-onmachineandisintendedtobeusedbyprofessional,
hiredoperatorsincommercialapplications.Itisprimarily
designedforgroominggrassonwell-maintainedlawnsin
parks,sportselds,andoncommercialgrounds.
Readthisinformationcarefullytolearnhowtooperateand
maintainyourproductproperlyandtoavoidinjuryand
productdamage.Youareresponsibleforoperatingthe
productproperlyandsafely.
YoumaycontactTorodirectlyatwww .Toro.comforproduct
andaccessoryinformation,helpndingadealer,ortoregister
yourproduct.
Wheneveryouneedservice,genuineToroparts,oradditional
information,contactanAuthorizedServiceDealerorToro
CustomerServiceandhavethemodelandserialnumbersof
yourproductready.Thenumbersareprintedontheshipping
carton.Writethenumbersinthespaceprovided.
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhassafety
messagesidentiedbythesafetyalertsymbol(Figure1),
whichsignalsahazardthatmaycauseseriousinjuryordeath
ifyoudonotfollowtherecommendedprecautions.
Figure1
1.Safetyalertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanicalinformation
andNoteemphasizesgeneralinformationworthyofspecial
attention.
Contents
Introduction..................................................................2
Safety...........................................................................3
SafeOperatingPractices...........................................3
Setup............................................................................4
PreparingforSetup..................................................4
InstallingtheGroomer.............................................4
AdjustingtheHydraulicHoses..................................9
InstallingtheBroomerKit(optional)..........................9
Operation....................................................................10
AdjustingtheGroomerHeight.................................11
TestingtheGroomerPerformance............................12
Maintenance.................................................................13
CleaningtheGroomer............................................13
LubricatingtheGroomer.........................................13
InspectingtheBlades..............................................13
AligningtheGroomerPulley/Belt............................13
GroomerBindingTroubleshooting...........................14
©2013—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN554202
Contactusatwww.Toro.com.
PrintedintheUSA
AllRightsReserved

Safety
SafeOperatingPractices
•Read,understand,andfollowallinstructionsinthe
tractionunitandcuttingunitoperatormanualsbefore
operatingthegroomer.
•Read,understand,andfollowallinstructionsinthis
operator’smanualbeforeoperatingthegroomer.
•Neverallowchildrentooperatethecuttingunits.Donot
allowadultstooperatethetractionunitorcuttingunits
withoutproperinstruction.Onlytrainedoperatorswho
havereadthismanualshouldoperatethecuttingunits.
•Neveroperatethecuttingunitswhenundertheinuence
ofdrugsoralcohol.
•Keepallshieldsandsafetydevicesinplace.Ifashield,
safetydevice,ordecalisillegibleordamaged,repairor
replaceitbeforeoperationiscommenced.Alsotighten
anyloosenuts,bolts,andscrewstoensurethatthecutting
unitisinsafeoperatingcondition.
•Alwayswearsubstantialshoes.Donotoperatethecutting
unitwhilewearingsandals,tennisshoes,sneakers,or
shorts.Also,donotwearloose-ttingclothingwhich
couldgetcaughtinmovingparts.Alwayswearlongpants
andsubstantialshoes.Wearingsafetyglasses,safetyshoes,
andahelmetisadvisable,andrequiredbysomelocal
ordinancesandinsuranceregulations.
•Removealldebrisorotherobjectsthatmightbepicked
upandthrownbythecutting-unitblades.Keepall
bystandersawayfromthemowingarea.
•Ifthebladesstrikeasolidobjectorthecuttingunit
vibratesabnormally,stopandshuttheengineoff.Check
cuttingunitfordamagedparts.Repairanydamagebefore
restartingandoperatingthecuttingunit.
•Lowerthecuttingunitstothegroundandremovethe
keyfromtheignitionswitchwheneverthemachineisleft
unattended.
•Besurethatthecuttingunitsandgroomersareinsafe
operatingconditionbykeepingnuts,bolts,andscrews
tight.
•Removethekeyfromtheignitionswitchtoprevent
accidentalstartingoftheenginewhenservicing,adjusting,
orstoringthemachine.
•Lightningcancausesevereinjuryordeath.Iflightning
isseenorthunderisheardinthearea,donotoperate
themachine;seekshelter.
•Performonlythosemaintenanceinstructionsdescribedin
thismanual.Ifmajorrepairsareeverneededorassistance
isdesired,contactanAuthorizedToroDistributor.
•Toensureoptimumperformanceandsafety,always
purchasegenuineTororeplacementpartsandaccessories
tokeeptheToroallToro.Neveruse“will-t”
replacementpartsandaccessoriesmadebyother
manufacturers.LookfortheTorologotoassure
genuineness.Usingunapprovedreplacementpartsand
accessoriescouldvoidthewarrantyofTheToro®
Company.
3

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
DescriptionQty.Use
Height-of-cutbracketassembly,right-hand1
Height-of-cutbracketassembly,left-hand1
Flangelocknut,3/8inch2
Splineddriveinsert1
Splinedinsert1
Groomershaftassembly1
Shimwasher(asrequiredforbeltalignment)1
Socket-headscrew,3/8x1inch4
Drivepulley1
Squarekey1
Flange-headbolt(3/8x3/4inch)3
Groomerbelt1
Idlerspring1
InstalltheGroomer.
Nopartsrequired–Adjustthehydraulichoses.
Nopartsrequired–Installthebroomerkit(optional).
TractionUnitRequirements
ThesekitscanbeusedonReelmaster355018-inchDPA
CuttingUnit(Models03911and03912).
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
PreparingforSetup
Ensurethatyouhavethefollowingtoolsavailablebefore
installingthegroomer:
•5/16inchsocket
•7/16inchsocket
•1/2inchdeep-wellsocket
•9/16inchdeep-wellsocket
•1/2inchwrench
•9/16inchwrench(2)
•5/16inchAllenwrench
•Needle-nosepliers
•6inchruler,Toropart114-5446
•Flatscrewdriver
•Lockingpliers
•Torquewrench—20to26N-m(15to19ft-lb)
•Torquewrench—37to45N-m(27to33ft-lb)
•Torquewrench—46to54N-m(34to40ft-lb)
•Torquewrench—115to128N-m(85to95ft-lb)
•Reeldriveshafttool,partTOR4112
•Blue242Loctite
•Anti-seizecompound
Allcuttingunitsareshippedwiththecounterweightmounted
totheleftendofthecuttingunit.Usethefollowingdiagram
todeterminethepositionofthegroomerkitsandreelmotors.
G020212
Figure2
Note:Theseinstructionsandillustrationsshowthe
installationoftheLeft-HandGroomerKitontothecutting
unitswiththecounterweightsmountedontheleftendofthe
cuttingunit.InstalltheRight-HandGroomerKitsontothe
cuttingunitswiththecounterweightsmountedontheright
endofthecuttingunit.
Note:Ifyouwanttoinstallagroomerandabrush,
obtaintheappropriateGroomerandBrushKitfromyour
AuthorizedToroDistributor.
InstallingtheGroomer
1.Parkthemachineonalevelsurfaceandengagethe
parkingbrake.
2.Ensurethatthecuttingunitsaredisengaged.Lower
thecuttingunitstotheground.Turntheengineoff
4

andremovethekey.Removeallthecuttingunitsfrom
themachine.
Note:Makesurethatalltheblackplastictiestraps
havebeenremovedfromthegroomerassemblies.
3.Removethecarriageboltsandnutssecuringthe
height-of-cutbracketstothecutting-unitsideplates
(Figure3).
Figure3
1.Height-of-cutbracket2.Carriagebolt
4.Loosenthescrewssecuringtheheight-of-cutbrackets
tothefrontrollershaft.
5.Removetheheight-of-cutbracketsandthefrontroller
fromthecutting-unitsideplates(Figure3).
6.Removethe4boltssecuringtheleftsideplatetothe
cuttingunitandloosentherearrollerclampnuts;pull
thesideplateoffofthecuttingunit(Figure4).
1
G021697
2
3
Figure4
1.Sideplate3.Bed-barbolt/nut
2.Rearrollerclampnut
7.Removethe2nutsandboltssecuringthecounter
weighttothesideplate.Removethecounterweight
andboltsfromthesideplate(Figure5).
Figure5
1.Counterweight2.Bolts
8.Removethereelfromthecuttingunittoaccessthe
insideoftherightsideplate.
9.Removethetwoboltsfromtheinsideoftherightside
plateasyoudidontheleft.
10.Installthereelintothecuttingunitandsecureitwith
theleftsideplateand4boltsremovedpreviously.
11.Looselyinstallthenewrightandleftheight-of-cut
bracketstotheexistingfrontrollerwithnew5/16x
1-1/8inchboltsand5/16inchange-headlocknuts.
Positiontheheight-of-cutbracketsasshowninFigure
6.
Note:Theleftheight-of-cutbracketismarkedwith
an“L”andtherightheight-of-cutbracketismarked
withan“R”.
G021698
Figure6
1.Height-of-cutbracket3.Carriagebolt
2.Boltandlocknut
12.Usingtheuppersquareholeineachsideplate,loosely
mounttheheight-of-cutbracketstothecutting-unit
sideplateswiththecarriageboltspreviouslyremoved
and(2)new3/8inchangenuts,positioningthemas
showninFigure6.
5

Note:Thewashersontheheight-of-cutadjusting
boltsmustbelocatedoneachsideoftheangeonthe
sideplate(Figure7).
13.Tightenthelocknutontheheight-of-cutadjusterbolt
untilthewasherscontactthesideplateange,then
backoffthenut1/2turn(Figure7).
Figure7
1.Washer3.Sideplateange
2.Locknut
14.Centertherollerbetweentheheight-of-cutbrackets
andlockitinplacewiththeboltsandlocknutsonthe
brackets(Figure6).
15.Usingthereeldriveshafttool,removethesplinedinsert
fromthereelmotorsideofthereelshaft(Figure8).
Important:Thesplinedinsertontheleft-hand
sideofthecuttingunithasleft-handthreads.The
splinedinsertontheright-handsideofthecutting
unithasright-handthreads.
1
2
G021695
3
4
Figure8
Reelmotorside
1.New(longer)splinedinsert3.Oldsplinedinsert
2.Add242Loctite(Blue)
here
4.Fillwithgreasehere
16.Installthenew(longer)splineddriveinserttothe
reelshaft(Figure8).Apply242Loctite(Blue)tothe
threadsoftheinsertpriortoinstallation.Torqueitto
115to128N-m(85to95ft-lb).
17.Filltheendoftheinsertwithall-purposegrease(Figure
8).
18.Usingthereeldriveshafttool,removethesplinedinsert
fromthegroomerdrivesideofthereelshaft(Figure9).
G021694
3
1
2
Figure9
Groomerdriveside
1.New(longer)splineddrive
insert
3.Old(shorter)splinedinsert
2.Add242Loctite(Blue)
here
19.Installthenew(longer)splineddriveinserttothe
reelshaft(Figure8).Apply242Loctite(Blue)tothe
threadsoftheinsertpriortoinstallation.Torqueitto
115to128N-m(85to95ft-lb).
20.Onthenon-drivesideofthegroomerassembly,
slidethegroomerplatewithquick-upleveroffthe
groomershaftassembly(Figure10).
6

G02 1696
6
9
10
1
2
3
4
5
7
8
11
12
13
14
15
3
Figure10
1.Groomerplatew/quick-uplever(non-driveend)9.Socket-headscrew
2.Pivothub(non-driveend)10.Flange-headbolt—long
3.Quick-uplever11.Belt
4.Squarekey12.Pivothub(driveend)
5.Shim(mustremainlooseafterinstallation)13.Groomerplatew/quick-uplever(driveend)
6.Flange-headbolt—short14.Groomershaftassembly
7.Idlerspring15.Sealspring
8.Drivepulley
21.Onthedrivesideofthecuttingunit,mountthe
pivothub,thedrive-sidegroomerplatewiththe
quick-uplever,andtheshimtothecutting-unitside
platewith(2)socket-headscrews(3/8x1inch);refer
toFigure10.Apply242Loctite(Blue)tothescrew
threadspriortoinstallation.
Important:MakesurethattheO-ringisproperly
positionedonthepivothub(Figure11).
Figure11
1.O-ring
Important:Makesurethatthepivothub
mountingsurfaceisushwiththesideplateon
thecuttingunit.Theshimmustnotbepinched
betweenthepivothubandthesideplate.
22.Installthenon-drivegroomerplateontothegroomer
shaft(Figure10).Becarefulnottoknocktheseal
springoff.
23.Securethenon-drivepivothubtothecutting-unitside
platewith2socket-headscrews(3/8x1inch);refer
toFigure10.Apply242Loctite(Blue)tothescrew
threadspriortoinstallation.
24.Makesurethatthesealliponeachexcludersealisin
lightcontactwitheachbearinghousing(Figure12).
7

Figure12
1.Excluderseal2.Bearinghousing
25.Mountthequick-upleverassembliestothesideplates
with2ange-headbolts(3/8x3/4inch);referto
Figure10.
26.Applyanti-seizecompoundtothekeyslotofthedrive
pulley,insertthesquarekeyintothekeyslot,andslide
thedrivepulleyandkeyontothedriveshaft(Figure10).
27.Apply242Loctite(Blue)tothescrewthreadsofa
ange-headbolt(3/8x3/4inch),threaditintotheend
ofthedriveshaft,andtorqueitto37to45N-m(27to
33ft-lb),securingthedrivepulley(Figure10).
28.Installthegroomerbeltontothepulleys(Figure10).
Makesurethattheribsonthebeltareproperlyseated
inthegroovesoneachpulley.
29.Hooktheidlerspringaroundthegrooveonthe
groomer-platelowerstud,pushupontheidlerpulley,
andhookthefreespringendintotheholeinthe
idler-platetab(Figure13).Ensurethatyoupositionthe
openendofthespringhooktowardthedrivepulley.
Figure13
1.Idlerpulley3.Idlerspring
2.Idler-platetab4.Lowerstud
30.Checkthealignmentofthebelt/pulleysasfollows:
•Layastraightedgealongtheouterfaceofthedrive
pulley(Figure14).
Important: Do not usetheidlerpulleyto
checkalignment.
Figure14
•Theouterfacesofthedriveanddrivenpulleys
shouldbeinlinewithin0.76mm(0.030inch).
•Ifthepulleysarenotaligned,refertoAligningthe
GroomerPulley/Belt(page13).
•Ifthepulleysarealigned,continuewiththe
installation.
Important:Thebeltmayfailprematurelyifthe
pulleysarenotproperlyaligned.
31.Removetheaccesscoverfromthegroomercover
assembly(Figure15).
32.Installthegroomercoverandsecureitwith(2)ange
nuts(5/16inch);refertoFigure15.
Important:Donotover-tightenthenuts,as
damagetothecovermayoccur.
1
2
G021755
Figure15
1.Groomercover2.Accesscover
33.Installtheaccesscoverontothegroomercoverwith
thefastenersyouremovedpreviously(Figure15).
34.Greaseeachofthegroomerbearings(2or3pumps
maximum);refertoFigure16.Donotover-grease
them,asexcessgreasemaycausesealfailure.Wipeoff
anyexcessgrease.
8

Figure16
Note:Aftergreasingthegroomerbearings,operate
thegroomerfor30seconds,stopthemachine,and
wipeexcessgreasefromthegroomershaftandseals.
35.Adjusttheheightofthegroomer.RefertoAdjusting
theGroomerHeight(page11).
AdjustingtheHydraulicHoses
Afterinstallingthegroomers,themovementofthequick-up
leverisobstructedbytherearhydraulichose.Adjusttherear
hosesforcuttingunits2,3,4,and5(Figure2)asfollows:
1.Loosenthenutonthettingthatconnectstherear
hydraulichosetothereeldrivemotor(Figure17).
1
2G021741
Figure17
1.Quick-uplever2.Nut
2.Rotatethehoseawayfromthemachineuntilitno
longerobstructsthemovementofthequick-uplever
(Figure17).
3.Tightenthenutuntilitissecure.
InstallingtheBroomerKit
(optional)
1.Fromonesideofthegroomerreel,slideabrushinto
eachgroovearoundthefulllengthofthegroomerreel
(Figure18).
G021758
1
2
3
Figure18
1.Strap3.Front
2.Brush
2.Verifythatthebrushesareseatedinthegroomerblade
slots(Figure19&Figure20).
3.Looselywrapthestraps,asshowninFigure20,around
thegroomerreelshaftandbrushesinsertingthestraps
inthegroovesinthebrushes.
Important:Thestrapsmustbewrappedaround
thegroomerbladeandbrushassemblyinthe
correctdirection.
Figure19
1.Brush2.Blade
Note:Ifthebroomerbrushesarenotseatedproperly
inthebladeslots,loosenthegroomerbladeretaining
nutsoneachendofthegroomershaft,positionthe
broomerbrushesproperlyinthebladeslotsandtighten
thegroomerbladeretainingnuts(Figure20).
4.Whilepushingascrewdriveragainstthestrapbuckle,
graspthestrapwithlockingpliers,andpullthestraps
tightuntiltheylockinthebrushgrooves(Figure20).
9

Figure20
1.Brush3.Retainingnut(2)
2.Strap4.Strapbuckle
5.Trimoffthestraptoapproximately6.4mm(1/4inch)
fromthebuckle,andfoldtheexcessstrapoverthe
buckle(Figure20)
Operation
Groomingisperformedintheturfcanopyabovethesoil
level.Groomingpromotesverticalgrowthofgrassplants,
reducesgrainandseversstolonsproducingadenserturf.
Groomingproducesamoreuniformandtighterplaying
surfaceforfasterandtrueractionofthegolfball.
Verticuttingisamoreaggressivecultivationtechnique
designedtoremovethatchbycuttingthroughtheturfcanopy
andintothethatch/matlayer.Groomingshouldnotbe
consideredareplacementforverticutting.Verticuttingis
generallyamorerigorousandperiodictreatmentthatcan
temporarilydamagetheplayingsurface,whilegroomingisa
routineandgentlertreatmentdesignedtomanicuretheturf.
Figure21
1.Grassrunners(stolons)2.Thatch
Groomingbrushesareamorerecentdevelopmentwhich
aredesignedtobelessintrusivethanconventionalgrooming
bladeswhenadjustedtolightlycontacttheturfcanopy.
Brushingmaybemorebenecialfortheultra-dwarfcultivars,
sincethesegrasstypeshavemoreofauprightgrowthpattern
anddonotllinthatwellthroughhorizontalgrowth.
Brushes,however,caninjureleaftissueiftheyaresetto
penetratetoodeeplyintothecanopy.
Groomingissimilartoverticuttinginitsrunnercutting
action.Groomingbladeshowever,shouldneverpenetrate
thesoillikeverticuttingordethatching.Groomerblades
arespacedclosertogetherandareusedmoreoftenthan
verticutterssothattheyaremoreeffectiveincuttingrunners
andremovingthatch.
Becausegroominginjuresleaftissuetosomedegree,itshould
beavoidedduringperiodsofhighstress.Coolseasonspecies
suchascreepingbentgrassandannualbluegrassshouldnot
begroomedduringhightemperature(andhighhumidity)
periodsinmidsummer.
Itisdifculttomakespecicrecommendationsonthe
useofgroomingreelsbecausesomanyvariablesaffectthe
performanceofgrooming,including:
•Thetimeoftheyear(thegrowingseason)andweather
pattern
•Thegeneralconditionofeachfairway
•Thefrequencyofgrooming/cutting—bothhowmany
cuttingsperweekandhowmanypassespercutting
•Theheight-of-cutsettingonthemainreel
•Theheight/depthsettingonthegroomingreel
•Howlongthegroomingreelhasbeeninuse
10

•Thetypeofgrass
•Theoverallmanagementprogram(suchasirrigation,
fertilizing,spraying,coring,andover-seeding)
•Thetrafconthefairway
•Stressperiods(suchashightemperatures,highhumidity,
unusuallyhightrafc)
Thesefactorscanvaryfromgolfcoursetogolfcourse.It
isimportant,therefore,toinspectthefairwaysfrequently
andvarythegroomingpracticeinaccordancewiththe
need.
Note:Thepracticeofchangingthedirectionofcuteach
timethefairwayiscutshouldbecontinuedwhenagroomeris
used.Thisrotationwillenhancetheeffectsofthegrooming.
Note:Usingthegroomerreelinanimproperoroverly
aggressivemanner(toodeeportoofrequentgrooming)may
causeunnecessarystressoftheturfleadingtosevereturf
damage.Usethegroomercautiously.
Note:Operatethegroomerinastraightlineasmuchas
possible.Usecautionwhenturningwhileoperatingthe
groomer.
AdjustingtheGroomerHeight
1.Parkthemachineonacleanandlevelsurface,lower
thecuttingunitscompletelytotheground,stopthe
engine,engagetheparkingbrakeandremovethekey
fromtheignitionswitch.
2.Makesurethattherollersarecleanandcuttingunit
issettothedesiredheightofcut;refertothecutting
unitOperator’sManual.
3.Rotatethequick-uplevers(Figure22)totheengaged
position(handlepointingtowardthefrontofthe
cuttingunit).UsetheHeightofCut(HOC)and
HeightofGroom(HOG)recommendedrange
chartforsettingthegaugebar.
4.On1endofthegroomerreel,measurethedistance
fromthelowesttipofthegroomerbladetothe
workingsurface(Figure22).Turntheheight-adjuster
knob(Figure22)toraiseorlowerthegroomerblade
tiptothedesiredheight.
Figure22
1.Quick-uplever(engaged
position)
3.Height-adjusterknob
2.Groomerheight(HOG)4.Numberofrearroller
spacers(belowside-plate
pad)
5.Repeatstep4ontheoppositeendofthegroomer.
Thencheckthesettingontherstsideofthegroomer.
Theheightsettingonbothendsofthegroomershould
beidentical.Adjustasrequired.
Important:Afteradjustingtheheightofthe
groomer,adjustthejamnutsonthreadedrodso
thatthespringsare3.5cm(1-3/8inches)long
whenthequick-upleversareinthedisengaged
position(handlepointedtowardtherearofthe
cuttingunit);refertoFigure23.
Note:3.5cm(1-3/8inches)isthedistance
fromthetopofthejamnuttothebottomofthe
groomer-mountingbracket.
Figure23
1.Quick-uplever2.Jamnuts
11

HeightofCut(HOC)andHeightofGroom(HOG)RecommendedRange
HeightofCutNumberofRearRoller
Spacers
RecommendedHOG=HOC-GroomerEngagement
0.250inch(6.35mm)00.125to0.250inch(3.175to6.35mm)
0.375inch(9.525mm)
0.375inch(9.525mm)
0
1
0.187to0.375inch(4.750to9.525mm)
0.187to0.375inch(4.750to9.525mm)
0.500inch(12.7mm)
0.500inch(12.7mm)
0.500inch(12.7mm)
0
1
2
0.250to0.500inch(6.35to12.7mm)
0.250to0.500inch(6.35to12.7mm)
0.250to0.375inch(6.35to9.525mm)
0.625inch(15.875mm)
0.625inch(15.875mm)
0.625inch(15.875mm)
0
1
2
0.375to0.625inch(9.525to15.875mm)
0.375to0.625inch(9.525to15.875mm)
0.375to0.500inch(9.525to12.7mm)
0.750inch(19.05mm)
0.750inch(19.05mm)
0.750inch(19.05mm)
1
2
3
0.500to0.750inch(12.7to19.05mm)
0.500to0.750inch(12.7to19.05mm)
0.500to0.625inch(12.7to15.875mm)
0.875inch(22.225mm)
0.875inch(22.225mm)
0.875inch(22.225mm)
1
2
3
0.625to0.875inch(15.875to22.225mm)
0.625to0.875inch(15.875to22.225mm)
0.625to0.750inch(15.875to19.05mm)
1.00inch(25.4mm)
1.00inch(25.4mm)
1.00inch(25.4mm)
2*
3
4
0.750to1.00inch(19.05to25.4mm)
0.750to1.00inch(19.05to25.4mm)
0.750to0.875inch(19.05to22.225mm)
Note:ThemaximumHOGrecommendedishalftheHOC
to0.25inch(6.35mm)maximumengagement.
*Movethegroomerfrontheight-of-cut(HOC)bracketto
thebottom(cuttingunitlocation)side-platehole.
TestingtheGroomer
Performance
Important:Improperoroverlyaggressiveuseofthe
groomingreel(toodeeportoofrequentgrooming)may
causeunnecessarystressontheturfleadingtosevere
damage.Usethegroomercautiously.
DANGER
Contactwiththereelsorothermovingpartscan
resultinpersonalinjury.
•Beforemakinganyadjustmentstothecutting
units,disengagethereels,settheparkingbrake,
stoptheengine,andremovetheignitionkey.
•Keepngers,hands,andclothingawayfromthe
reelsorothermovingparts.
Itisimportanttodeterminetheperformanceofthegroomer
beforeputtingitintoregularuse.
Wesuggestthataformaltestprocedurebeused.The
followingisapracticalwayofdeterminingtheproper
height/depthsetting:
1.Setthemaincuttingreelstotheheightofcutthat
wouldnormallybeusedwithoutthegroomingreel.
UseaWiehlerolleronthefrontandafullrolleron
therear.
2.Seteachofthegroomingreelstothedesiredheight
setting.
3.Examinethetestareaanddetermineifthegroomed
areasgivesthedesiredresults.Ifnot,increaseor
decreasetheheightofthegroomers,andmakeanother
testpass.Theamountofgrassremovedisakey
indicatorindeterminingtheheight/depthsettingof
thegroomingreel.
Checkthetestarea2or3daysaftertherstgroomingfor
generalcondition/damage.Ifthegroomedareasareturning
yellow/brown,andthenon-groomedareasaregreen,then
thegroomingwastooaggressive.
12

Maintenance
CleaningtheGroomer
Hoseoffthegroomingreelafterusingit.Donotdirect
thewaterstreamdirectlyatthegroomerbearingseals.Do
notpermitthegroomingreeltostandinwatersothatthe
componentsrust.
LubricatingtheGroomer
Lubricatethegreasettingsevery50hours(Figure24).Wipe
offanyexcessgrease.
Note:Aftergreasingthegroomerbearings,operatethe
groomerfor30seconds,stopthemachine,andwipeexcess
greasefromthegroomershaftandseals.
Figure24
InspectingtheBlades
Inspectthegroomingreelbladesfrequentlyfordamageand
wear.Bentbladesmaybestraightenedwithapliers.Worn
bladesmaybereplaced.Wheninspectingtheblades,checkto
seethattherightandleftbladeshaftendnutsaretight.
Note:Becausethegroomermayintroducemoredebris
(suchasdirtandsand)intothecuttingunitthanwhatthereel
wouldnormallybeexposedto,thebedknifeandmainreel
shouldbecheckedforwearmorefrequently.Thisisespecially
importantinsandysoil.
Important:Backlappingattheincorrectreelspeed
mayloosenandstripthedrive-pulleythreads.Referto
thecuttingunit Operator’ s Man ual forthebacklapping
procedure.
Note:Thegroomerblades,idlerbearing,andbelt(s)are
consideredconsumableitems.
AligningtheGroomer
Pulley/Belt
1.Thedrivenpulley(atthegroomershaft)canmoveinor
out.Makenoteofwhichwaythepulleyneedstomove.
2.Removetheidlerspring,releasingtensionfromthe
belt.
3.Removethebelt.
4.Removethelocknutsecuringthedrivenpulleytothe
endofthegroomershaft.Inserta5/8inchwrenchon
theatsonthegroomershafttokeeptheshaftfrom
rotating.
5.Removethepulleyfromtheshaft.
6.Ifthepulleyneedstomoveout,add(1)0.032inch
spacer.Ifthepulleyneedstomovein,removethe
existing0.032inchspacer.
7.Installthepulley.
Note:Makesurethatthepulleykeyisinstalled,ifso
equipped.
8.Holdthegroomershaftfromrotatingbyputtinga5/8
inchwrenchontheatsontheshaft.Securethepulley
ontheshaftwiththeangenut.
9.Torquethenutto37to45N-m(27to33ft-lb).
10.Installthebeltandidlerspring.
11.Checkthealignment;theouterfacesofthedrive
anddrivenpulleysshouldbeinlinewithin0.7mm
(0.030inch).Donotusetheidlerpulleytocheck
alignment.
Figure25
13

GroomerBinding
Troubleshooting
1.Makesurethatthegroomerissettothedesiredheight
ofgroom(HOG);refertoFigure26.
Figure26
1.Quick-uplever(engaged
position)
3.Height-adjusterknob
2.Groomerheight(HOG)4.Numberofrearroller
spacers(belowside-plate
pad)
2.Loosenthequick-upmountingboltandmakesure
thatthethreadedrodisinlineandnotbindingonthe
bottomquick-upramp(Figure27).Tightenthebolts.
3.Checkthelengthofthequick-upspringsonthe
threadedrods,thelengthshouldbe3.5cm(1-3/8
inches);refertoFigure27.
Figure27
1.Quick-upmountingbolt2.Height-adjusterknob
4.Iftheheight-adjusterknobdoesnotrotatefreely,the
bushingmaybedirty(Figure27).Cleanthebushing
ifnecessary.
5.Makesurethatthemaindrivebushing(Figure28)
pivotsfreelyaroundthedrivehub.
Figure28
1.Maindrivebushing
6.Makesurethattheshim(Figure29)betweenthedrive
sidegroomerpivotplateandthecutting-unitsideplate
isnotpinchedbythepivothub.Theshimmustbeable
tomovefreely.
Figure29
1.Shim
7.Makesurethatnutsonthecovers(Figure30)arenot
over-tightened.
1
2
G021755
Figure30
1.Groomercover2.Accesscover
14

Notes:
15

DeclarationofIncorporation
TheToroCompany,8111LyndaleAve.South,Bloomington,MN,USAdeclaresthatthefollowingunit(s)
conform(s)tothedirectiveslisted,wheninstalledinaccordancewiththeaccompanyinginstructionsontocertain
ToromodelsasindicatedontherelevantDeclarationsofConformity.
ModelNo.SerialNo.ProductDescriptionInvoiceDescriptionGeneralDescriptionDirective
2000/14/EC
03914—
Left-HandGroomerKitfor
Reelmaster3550Series
18-inchCuttingUnit
RM355018”GROOMER-(LH)GroomerKit2006/42/EC
2000/14/EC
03915—
Right-HandGroomerKit
forReelmaster3550Series
18-inchCuttingUnit
RM3550
18”GROOMER-(RH)GroomerKit2006/42/EC
RelevanttechnicaldocumentationhasbeencompiledasrequiredperPartBofAnnexVIIof2006/42/EC.
Wewillundertaketotransmit,inresponsetorequestsbynationalauthorities,relevantinformationonthispartly
completedmachinery.Themethodoftransmissionshallbeelectronictransmittal.
ThismachineryshallnotbeputintoserviceuntilincorporatedintoapprovedT oromodelsasindicatedonthe
associatedDeclarationofConformityandinaccordancewithallinstructions,wherebyitcanbedeclaredin
conformitywithallrelevantDirectives.
Certied:EUT echnicalContact:
PeterTetteroo
ToroEuropeNV
B-2260Oevel-Westerloo
Belgium
DavidKlisTel.003214562960
Sr.EngineeringManagerFax003214581911
8111LyndaleAve.South
Bloomington,MN55044,USA
May29,2012
16
