Toro TR-34D User manual

FormNo.3377-640RevB
ControlCoverKit
TR-34DTrenchRoller
ModelNo.68070
InstallationInstructions
WARNING
CALIFORNIA
Proposition65Warning
Thisproductcontainsachemicalorchemicals
knowntotheStateofCaliforniatocausecancer,
birthdefects,orreproductiveharm.
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
DescriptionQty.Use
Nopartsrequired–Disconnectthebattery.
Nopartsrequired–Drilltheholes(machineswithoutexistingholes).
Cover1
Latchclip1
Latchmountassembly1
Catchmountassembly1
Washer(5/16inch)2
Hex-socketbolt(1/4x5/8inches)13
Hex-socketbolt(1/4x1-1/4inches)2
Flangenut(1/4inch)15
Installthecontrolcover.
DisconnectingtheBattery
1.Opentherearhood;refertotheOpeningtheHood
sectionintheOwner’ sManual
2.Loosenthenutandboltsecuringthenegative-cable
clamptothebatterypost,andremovetheclampfrom
thebattery.
Note:Ensurethatthenegative-cableclampdoesnot
contactthebatterypost.
DrillingtheHoles(Machines
withoutExistingHoles)
1.Covertherearcompartmentofthemachinewith
adropclothtoprotectthecomponentsinthe
compartmentfrommetalshavingsthatwillbecreated
whiledrillingmountingholesforthecontrolcover.
2.Alignthecoverlefttorightoverthecontrolpanel
(Figure1).
3.Whilekeepingthehoodcentered,alignthebottom
edgeofthecovertotherearedgeofthehood(Figure
1).
©2013—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.T oro.com.OriginalInstructions(EN)
PrintedintheUSA.
AllRightsReserved*3377-640*B

G021638
1
2
3
4
5
6
Figure1
1.Rearedgeofthehood4.Cover
2.Bottomedgeofthecover5.Holesincover
3.Hingedcover6.Alignthecovertotheedge
ofthehood
4.Usingthecoverasatemplate,marktheoutlineofthe
holesontherearhood(Figure2).
5.Removethecoverfromthemachine.
6.Center-punchthehoodatthemarkedlocationscreated
instep4.
7.Drill7holesintotherearhoodwitha9/32inchdrill
bitatthecenter-punchmarks(Figure2).
g021622
2
1
1
Figure2
1.Markanddrill9/32inch
holeshere
2.Usethecoverasa
template
8.Removethedropclothundertherearhoodand
components.
2

InstallingtheControlCover
1.Installthecovertotherearhoodwith7hex-socket
bolt(1/4x5/8inches)and7angenuts(1/4inch)
(Figure3).
Note:Applyathread-lockingcompound.
g021624
1
2
Figure3
1.Hex-socketbolt(1/4x5/8
inches)
2.Flangenuts(1/4inch)
2.Installthelatchmountassemblytothemachinewith2
hex-socketbolts(1/4x5/8inches)and2angenuts
(1/4inch)(Figure4).
Note:Removeanystickersblockingtheholes.
Note:Applyathread-lockingcompound.
g024194
3
2
4
1
Figure4
1.Cutslotsoutindecal3.Hex-socketbolt(1/4x5/8
inches)
2.Latchmountassembly4.Flangenuts(1/4inch)
3.Assemblethelatchcliptothelatchmountwith2
hex-socketbolts(1/4x1-1/4inches),2washers(5/16
inch),and2angenuts(1/4inch)(Figure5).
Note:Applyathread-lockingcompound.
1
234
g024193
Figure5
1.Hex-socketbolt(1/4x
1-1/4inches)
3.Latchclip
2.Washer4.Flangenuts(1/4inch)
4.Installthecatchmountassemblytothemachinewith4
hex-socketbolts(1/4x5/8inches)and4angenuts
(1/4inch)(Figure6).
1
2
3
g024192
Figure6
1.Flangenuts(1/4inch)3.Hex-socketbolt(1/4x5/8
inches)
2.Catchmountassembly
5.Connectthenegativebatterycabletothebattery.
