FormNo.3380-737RevA
LEDLightKit
GreensPro™1240GreensRoller
ModelNo.44923
InstallationInstructions
WARNING
CALIFORNIA
Proposition65Warning
ThisproductcontainsachemicalorchemicalsknowntotheStateofCaliforniato
causecancer,birthdefects,orreproductiveharm.
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
DescriptionQty.Use
Lightmountingbracket(right)1
Lightmountingbracket(left)1
LEDlight2
Hex-headbolt(M6x20mm)2
Locknut(M6)2
Washer(1/4x7/8inch)2
Washer(M6x20mm)2
InstalltheLEDlights.
Switch1
Wiringharness1
Cabletie4
Installtheswitchandthewiringharness.
©2014—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.T oro.com.OriginalInstructions(EN)
PrintedintheUK
AllRightsReserved*3380-737*A
InstallingtheLEDLights
1.Aligntheleftlightmountingbracketwiththeholein
therearleftcorneroftheseatpan(Figure1).
Note:Thebracketshouldbenearlyparallelwiththe
ground.Ifitisnot,trytheotherbracket;referto
Figure2.
G025237
1
6
7
2
3
4
5
Figure1
1.LEDlight5.Washer(M6x12mm)
2.Lightmountingbracket6.Washer(1/4x7/8inch)
3.Nut(includedwithlight)7.Hex-headbolt(M6x20
mm)
4.Locknut(M6)
G025238
Figure2
2.Securethebrackettotheseatpanwithahex-headbolt
(M6x20mm),alargewasher(1/4x7/8inch),asmall
washer(M6x12mm),andalocknut(M6).
3.AlignthebottomoftheLEDlightontheleftsidewith
theholeonthelightmountingbracket(Figure1).
4.Securealighttothemountingbracketbytighteningthe
locknut(includedwiththelight)asshowninFigure1.
5.Repeatsteps1through4toinstalltherightlight.
2
InstallingtheSwitchandthe
WiringHarness
1.Removeanddiscardtheholeplugthatisinstalledin
theholenearthehourmeterinthesideoftheseatpan.
1
G025239
2
Figure3
1.Lightswitch2.Holeplug
2.Inserttheswitchintothehole(Figure3).
3.Connecttheappropriateconnectorofthelightkit
wiringharnesstothebackoftheswitch(Figure4).
1
G025240
2
Figure4
1.Lightkitwiringharness2.Switch
4.Connecttheappropriateconnectorofthelight
kitwiringharnesstotheunusedconnectorofthe
hour-meterwiringharness(Figure5).
1
G025241
2
Figure5
1.Hour-meterwiringharness2.Lightkitwiringharness
5.RoutethelightkitwiringharnessasshowninFigure6.
2
G025245
2
1
Figure6
Undersideshown
1.Lightkitwiringharness2.Cableties
6.Connecttheremainingconnectorstothelights.
7.Securethewiringharnesswiththecabletiesinthe
locationsshowninFigure6.
8.Ensurethatallofthecomponentsaresecure.
9.Inawell-ventilatedarea,startthemachineandsetthe
enginetofullspeed.
10.Operatetheswitch,andensurethatbothofthelights
work.
Important:Ifthelightsdonotturnon,checkall
theconnections.
11.Ifnecessary,loosenthescrewandthenutonthesides
ofeachlight,androtatethelightsupordownandfrom
sidetosidetoattainthedesiredoperatingposition.
Important:Securetheadjustmentsbytightening
thescrewandthenutonthesidesofeachlight.
3
