FormNo.3406-387RevA
BedRackKit
Workman®GTXSeriesUtilityVehicles
ModelNo.07031
InstallationInstructions
WARNING
CALIFORNIA
Proposition65Warning
ThisproductcontainsachemicalorchemicalsknowntotheStateofCaliforniato
causecancer,birthdefects,orreproductiveharm.
Safety
SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyareaofpotential
danger.Replaceanydecalthatisdamagedorlost.
133-7204
1.Attention—readtheOperator’sManual;donotexceedload
weightsof18kg(40lbs).
©2016—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.T oro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3406-387*A

Installation
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
DescriptionQty.Use
Nopartsrequired–Preparethemachine.
Sideuprightframebracket2
Frontuprightframebracket2
Pipebracket1
Frontsupportbracket(with2holesoneach
side)1
Cross-supportbracket1
Fire-extinguishermount1
Fire-extinguishersupport1
Shovelmount3
Frontsupportbracket(with1holeoneach
side)1
Hex-headscrew(1/4x3/4inch)8
Carriagebolt(5/16x3/4inch)34
Flangenut(5/16inch)34
Cup-cutterbracket1
Installthebedrackkit.
PreparingtheMachine
Parkthemachineonalevelsurface,settheparkingbrake,
shutofftheengine,andremovethekey.
InstallingtheBedRackKit
IfyouwanttoinstalltheBedRackKitonbothsidesofthe
cargobed,youwillneedthefollowingadditionalparts:
•1sideuprightframebracket
•1pipebracket
•1cross-supportbracket
•1re-extinguishermount
•1re-extinguishersupport
•3shovelmounts
•4hex-headscrews(1/4x3/4inch)
•26carriagebolts(5/16x3/4inch)
•26angenuts(5/16inch)
•1cup-cutterbracket
Note:TheBedRackKitcanbeinstalledoneithersideof
thecargobed.
1.Looselyinstallthe2sideuprightframebracketstothe
outsideofthecargobedwith4hex-headscrews(1/4x
3/4inch)asshowninFigure1.
Figure1
1.Sideuprightframebracket2.Hex-headscrew(1/4x3/4
inch)
2

2.Installthe3shovelmountstothesideuprightframe
bracketswith12carriagebolts(5/16x3/4inch)and
12angenuts(5/16inch)asshowninFigure2.
Figure2
1.Carriagebolt(5/16x3/4
inch)
3.Flangenut(5/16inch)
2.Sideuprightframebracket4.Shovelmount
3.Looselyinstallthe2frontuprightframebracketstothe
insideofthecargobedwith4hex-headscrews(1/4x
3/4inch)asshowninFigure3.
Figure3
1.Frontuprightframe
bracket
2.Hex-headscrew(1/4x3/4
inch)
4.Installthepipebrackettothe2sideuprightframe
bracketsandfrontuprightframebracketwith6carriage
bolts(5/16x3/4inch)and6angenuts(5/16inch)as
showninFigure4.
Figure4
1.Pipebracket4.Carriagebolt(5/16x3/4
inch)
2.Flangenut(5/16inch)5.Frontuprightframe
bracket
3.Sideuprightframebracket
5.Installthefrontsupportbracket(with2holesoneach
side)tothetopofthe2frontuprightframebrackets
with4carriagebolts(5/16x3/4inch)and4ange
nuts(5/16inch)asshowninFigure5.
Figure5
1.Carriagebolt(5/16x3/4
inch)
3.Frontsupportbracket(with
2holesoneachside)
2.Flangenut(5/16inch)4.Frontuprightframe
bracket
3

6.Installthefrontsupportbracket(with1holeoneach
side)tothe2frontuprightframebracketswith2
carriagebolts(5/16x3/4inch)and2angenuts(5/16
inch)asshowninFigure6.
Figure6
1.Carriagebolt(5/16x3/4
inch)
3.Flangenut(5/16inch)
2.Frontuprightframe
bracket
4.Frontsupportbracket(with
1holeoneachside)
7.Installthecross-supportbrackettothefrontsupport
bracket(with2holesoneachside)andpipebracket
with4carriagebolts(5/16x3/4inch)and4ange
nuts(5/16inch)asshowninFigure7.
Figure7
1.Carriagebolt(5/16x3/4
inch)
4.Frontsupportbracket(with
2holesoneachside)
2.Pipebracket5.Flangenut(5/16inch)
3.Cross-supportbracket
8.Installthere-extinguishermounttothesideupright
framebracketandfrontuprightframebracketwith4
carriagebolts(5/16x3/4inch)and4angenuts(5/16
inch)asshowninFigure8.
Figure8
1.Sideuprightframebracket4.Fire-extinguishermount
2.Carriagebolt(5/16x3/4
inch)
5.Flangenut(5/16inch)
3.Frontuprightframe
bracket
4

9.Installthere-extinguishersupport or cup-cutter
brackettothesideuprightframebracketandfront
uprightframebracketwith2carriagebolts(5/16x3/4
inch)and2angenuts(5/16inch)asshowninFigure
9orFigure10.
Figure9
1.Flangenut(5/16inch)4.Carriagebolt(5/16x3/4
inch)
2.Sideuprightframebracket5.Frontuprightframe
bracket
3.Fire-extinguishersupport
Figure10
1.Frontuprightframe
bracket
4.Flangenut(5/16inch)
2.Cup-cutterbracket5.Carriagebolt(5/16x3/4
inch)
3.Sideuprightframebracket
10.Tightenthehex-headscrews(1/4x3/4inch)insteps
1and3to1,130N∙cm(100in-lb).
5

Whenyoucompleteinstallation,theBedRackKitappearsasfollows:
Leftsideinstallation—Figure11
Figure11
Rightsideinstallation(optionalconguration)—Figure
12
Figure12
Bothsidesinstallation(additionalparts
required)—Figure13
Figure13
6
