DSP1212C, DSP1224C, DSP2012C,
DSP2024C
Sine wave inverter with integrated
battery charger
Installation and Operating Manual. . . . . . . . 3
Sinus-Wechselrichter mit integiertem
Batterielader
Montage- und Bedienungsanleitung . . . . .33
Onduleur sinusoïdal avec chargeur de
batterie intégré
Instructions de montage
et de service . . . . . . . . . . . . . . . . . . . . . . . . .65
Inversor sinusoidal con cargador de
batería integrado
Instrucciones de montaje y de uso . . . . . . .96
Conversor sinusoidal com carregador
da bateria integrado
Instruções de montagem e manual de
instruções . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Inverter a onda sinusoidale pura con
caricabatterie integrato
Istruzioni di montaggio e d’uso . . . . . . . . 157
Sinusomvormer met geïntegreerde
acculader
Montagehandleiding en
gebruiksaanwijzing. . . . . . . . . . . . . . . . . . 188
Sinus inverter med integreret
batterilader
Monterings- og betjeningsvejledning. . . 219
Sinusväxelriktare med inbyggd
batteriladdare
Monterings- och bruksanvisning . . . . . . . 249
Sinus vekselretter med integrert
batterilader
Monterings- og bruksanvisning . . . . . . . . 279
Siniaaltoinvertteri, jossa integroitu
akkulaturi
Asennus- ja käyttöohje . . . . . . . . . . . . . . . 309
Синусоидальный инвертор со
встроенным зарядным устройством
для аккумуляторов
Инструкция по монтажу и эксплуатации 338
Przetwornica sinusoidalna z
wbudowaną ładowarką akumulatora
Instrukcja montażu i obsługi. . . . . . . . . . . 370
Sínusový menič s integrovanou
nabíjačkou batérií
Návod na montáž a uvedenie
do prevádzky. . . . . . . . . . . . . . . . . . . . . . . 401
Sinusový měnič s nabíječkou baterií
Návod k montáži a obsluze . . . . . . . . . . . 431
Szinuszos inverter integrált
akkumulátortöltővel
Szerelési és használati útmutató . . . . . . . 461
BREAKER
OUTPUT INPUT
EN
DE
FR
ES
PT
IT
NL
DA
SV
NO
FI
RU
PL
SK
CS
HU
ENERGY & LIGHTING
SINEPOWER
'63&&,2VERRN6HLWH'RQQHUVWDJ-XOL

'63&&,2VERRN6HLWH'RQQHUVWDJ-XOL

EN
SinePower
3
Please read this instruction manual carefully before installation and first
use, and store it in a safe place. If you pass on the product to another
person, hand over this instruction manual along with it.
Table of contents
1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
2 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
5 Target group for this manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
6 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
7 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
8 Fitting the device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
9 Connecting the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
10 Before initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
11 Using the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
12 Cleaning and caring for the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
13 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
14 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
15 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
16 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
'63&&,2VERRN6HLWH'RQQHUVWDJ-XOL

EN
Explanation of symbols SinePower
4
1 Explanation of symbols
D
!
A
I
2 General safety instructions
2.1 General safety
The manufacturer accepts no liability for damage in the following cases:
• Faulty assembly or connection
• Damage to the product resulting from mechanical influences and incorrect
connection voltage
• Alterations to the product without express permission from the manufacturer
• Use for purposes other than those described in the operating manual
Note the following basic safety information when using electrical devices to protect
against:
• Electric shock
•Firehazards
•Injury
DANGER!
Safety instruction: Failure to observe this instruction will cause fatal or
serious injury.
WARNING!
Safety instruction: Failure to observe this instruction can cause fatal or
serious injury.
NOTICE!
Failure to observe this instruction can cause material damage and impair
the function of the product.
NOTE
Supplementary information for operating the product.
'63&&,2VERRN6HLWH'RQQHUVWDJ-XOL

EN
SinePower General safety instructions
5
2.2 General safety
DDANGER!
• In the event of fire, use a fire extinguisher which is suitable for electrical
devices.
!WARNING!
• Only use the device as intended.
• Ensure that the red and black terminals never come into contact.
• Disconnect the device from the mains:
– Before cleaning and maintenance
–Afteruse
– Before changing a fuse
• If you disassemble the device:
– Detach all connections
– Make sure that no voltage is present at any of the inputs and out-
puts
• The device may not be used if the device itself or the connection cable
are visibly damaged.
• If this power cable for this device is damaged, it must be replaced by
the manufacturer, customer service or a similarly qualified person in
order to prevent safety hazards.
• This device may only be repaired by qualified personnel. Inadequate
repairs may cause serious hazards.
• This device can be used by children aged 8 years or over, as wellas by
persons with diminished physical, sensory or mental capacities or a
lack of experience and/or knowledge, providing they are supervised
or have been taught how to use the device safely and are aware of the
resulting risks.
•Electrical devices are not toys.
Always keep and use the appliance out of the reach of children.
• Children must be supervised to ensure that they do not play with the
device.
ANOTICE!
• Before start-up, check that the voltage specification on the type plate
is the same as that of the power supply.
• Ensure that other objects cannot cause a short circuit at the contacts
of the device.
• Never pull the plug out of the socket by the connection cable.
'63&&,2VERRN6HLWH'RQQHUVWDJ-XOL

EN
General safety instructions SinePower
6
• Store the device in a dry and cool place.
2.3 Safety when installing the device
DDANGER!
• Never mount the device anywhere where there is a risk of gas or dust
explosion.
!CAUTION!
• Ensure that the device is standing firmly.
The device must be set up and fastened in such a way that it cannot tip
over or fall down.
ANOTICE!
• Do not expose the device to a heat source (such as direct sunlight or
heating). Avoid additional heating of the device in this way.
• Set up the device in a dry location where it is protected against splash-
ing water.
2.4 Safety when connecting the device electronically
DDANGER! Danger of electrocution
•For installation on boats:
If electrical devices are incorrectly installed on boats, corrosion dam-
age might occur. Have the device installed by a specialist (marine)
electrician.
• If you are working on electrical systems, ensure that there is somebody
close at hand who can help you in emergencies.
!WARNING!
• Always use sockets which are grounded and secured by residual cur-
rent circuit breakers.
• Make sure that the lead has a sufficient cross-section.
• Lay the cables so that they cannot be damaged by the doors or the
bonnet.
Crushed cables can lead to serious injury.
!CAUTION!
• Lay the cables so that they cannot be tripped over or damaged.
'63&&,2VERRN6HLWH'RQQHUVWDJ-XOL

EN
SinePower General safety instructions
7
ANOTICE!
• Use ductwork or cable ducts if it is necessary to lay cables through
metal panels or other panels with sharp edges.
•Donot lay the 230 V mains cable and the 12 V DC cable in the same
duct.
•Donot lay the cable so that it is loose or heavily kinked.
• Fasten the cables securely.
• Do not pull on the cables.
2.5 Operating the device safely
DDANGER! Danger of electrocution
• Do not touch exposed cables with your bare hands. This applies espe-
cially when operating the device from the AC mains.
!WARNING!
• Only use the device in closed, well-ventilated rooms.
!CAUTION!
•Donot operate the device
– In salty, wet or damp environments
– In the vicinity of corrosive fumes
– In the vicinity of combustible materials
– In areas where there is a danger of explosions.
• Before starting the device, ensure that the power supply line and the
plug are dry.
• Always disconnect the power supply when working on the device.
• Please observe that parts of the device may still conduct voltage even
if the fuse has blown.
• Do not disconnect any cables when the device is still in use.
ANOTICE!
• Make sure the air inlets and outlets of the device are not covered.
• Ensure good ventilation.
'63&&,2VERRN6HLWH'RQQHUVWDJ-XOL

EN
Scope of delivery SinePower
8
3Scopeofdelivery
4Accessories
5 Target group for this manual
The electrical installation (chapter “Connecting the device” on page 16) is intended
for professionals who are familiar with the applicable regulations of the country in
which the equipment is to be installed and/or used.
All other chapters are intended for the users.
No. in
fig. 1Designation
1 Sine wave inverter with integrated battery charger
2DSP-EM
3 Connection cable DSP-EM
– Operating manual
Designation Ref. no.
Battery sensor MCA-HS1 9600000101
'63&&,2VERRN6HLWH'RQQHUVWDJ-XOL

EN
SinePower Intended use
9
6 Intended use
!
Thedevices withintegrated batterychargerconvert directcurrent intoa 230 – 240 V
AC supply of 50 Hz or 60 Hz:
•12 Vg:DSP1212C, DSP2012C
•24 Vg:DSP1224C, DSP2024C
Additionally the devices can charge the following batteries:
• Lead automotive batteries
• Lead gel batteries
• Maintenance-free batteries
• Absorbed glass mat (AGM) batteries
• Lithium ion batteries
Never use the devices to charge other battery types (such as NiCd or NiMH).
!
7 Technical description
The devices can be operated wherever a DC connection is available:
•12 Vg:DSP1212C, DSP2012C
•24 Vg:DSP1224C, DSP2024C
The device can be used as follows:
• As a sine wave inverter: the device produces a pure 230 V output voltage
• As a battery charger (4-stage charging characteristic)
• Power sharing: the device powers a connected load with 230 V and
simultaneously charges a battery
• Generator function (mains voltage function): the device supports a 230 V mains
voltage by supplementing it with energy from a battery (common power source)
WARNING!
Never use the device on vehicles where the positive terminal of the
battery is connected to the chassis.
WARNING! Danger of explosions
Do not charge batteries with a cell short circuit. The oxyhydrogen they
produce can cause explosions.
Do not charge nickel cadmium and non-rechargeable batteries with the
charger. The cases of these batteries can burst explosively.
'63&&,2VERRN6HLWH'RQQHUVWDJ-XOL

EN
Technical description SinePower
10
The light-weight and compact construction of this device allows for easy installation
in mobile homes, commercial vehicles or motor and sailing yachts.
The output voltage corresponds to the household voltage from the socket (pure sine
wave, THD <3 %).
Please observe the values for constant output power and peak output power as
indicated in chapter “Technical data” on page 29. Never connect devices that have
a higher power requirement.
I
The priority circuit reduces the load on a connected battery by switching the device
always to mains operation if AC power grid is connected. The device ensures that a
connected load is supplied with voltage:
• In case the AC grid power breaks down or is unstable
• In case the AC grid power does not suffice to supply the connected consumers
The device has various protective mechanisms.
•Overvoltage shutdown: The device shuts itself off when the voltage of the
connected DC source exceeds the cut-off value. It restarts when the voltage
returns to the restart value.
•Undervoltage shutdown: The device shuts itself off when the voltage of the
connected DC source sinks below the cut-off value. It restarts when the voltage
rises to the restart value.
•Excess temperature shutdown: The device switches off when the tempera-
ture inside the device or the temperature on the cooling element exceeds a cut-
off value. It restarts when the temperature falls to the restart value.
•Overloading and short circuit shutdown: The LED on the device indicates
an operating fault when an excess load is connected or a short circuit has
occurred.
I
NOTE
Note when connecting devices with an electrical drive (such as power
drills and refrigerators), that they often require more power than is
indicated on the type plate.
NOTE
The individual values are found in the chapter “Technical data” on
page 29.
'63&&,2VERRN6HLWH'RQQHUVWDJ-XOL

EN
SinePower Technical description
11
The device is operated in the following network configuration:
•TN network (fig. i):
The neutral conductor of the AC output is grounded. A safety switch (RCD)
must be installed at the device‘s AC output.
The softstart function allows the connection of loads with high starting current.
The device can be easily controlled using the DSP-EM.
7.1 Control elements device
7.2 Connections
Item in
fig. 2Description Explanation
1 Main switch
“ON/OFF/REMO.”
Switches the device on, off or to operation via
a remote control(accessory)
2 Status LED See chapter “Status indications” on page 20
3 Breaker Protects the device from overload.
The fuse can be pressed in again once it has
triggered.
Item in
fig. 2Description
4 AC PG fitting
5 AC PG fitting
6 Ground terminal (Earthing on the vehicle bodywork)
7 Positive terminal
8 Negative terminal
9 CI/LIN BUS connections (LNA)
Battery sensor or temperature sensor connection
10 DSP-EM connection (LNB)
11 Connection of remote switch
12 Fan
'63&&,2VERRN6HLWH'RQQHUVWDJ-XOL

EN
Technical description SinePower
12
7.3 Control elements DSP-EM
7.4 Description of functions
The device supports the functions described below.
Power sharing function
If the load from the connected consumer devices and the battery charging current is
higher than the connected 230 V power source, the fuse of the power source would
normally blow. In power sharing mode, the device reduces the battery charging
current and thus increases the power available for connected consumers.
The power sharing level (current at the 230 V input) can be configured using the
DSP-EM. If must be adapted to the fuse of the power source. For example, if it has a
10 A fuse, the power sharing level must also be 10 A.
Item in
fig. 3Description Explanation
1 Selector button Turn: Navigate through menus or change
values
Press: Select menu items or values
2 Deactivates the inverter function and thus the
power supply of the battery to the 230 V
consumers. The consumers are supplied
exclusively by an external AC power grid, the
battery is not discharged via the inverter.
3 Switches the device‘s night mode on or off.
The device‘s charging current is limited and
the fan operates at low speed.
4 Display Displays values and current statuses of the
connected devices.
'63&&,2VERRN6HLWH'RQQHUVWDJ-XOL

EN
SinePower Technical description
13
Example (values for illustration purpose only):
I
Generator function (external mains power supply)
A
If the load current is greater than the fuse of the connected 230 V power source, the
fuse would normally blow. The generator function enables the device to provide
additional power, which it takes from the battery.
If the required power falls below the power sharing level, the device recharges the
battery.
In generator mode, the 230 V power source and the battery act as a common power
source. While doing so, the battery is discharged.
The generator mode can manually be shut off via DSP-EM to ensure that the battery
will not be discharged.
If the battery‘s voltage or capacity does not suffice to support the grid the device is
disconnected from the grid and the inverter tries to work in isolated operation.
NOTE
Keep in mind that the device only measures the current which flows
through the device. If you connect more consumers in parallel, e. g.a
refridgerator or an separate charger, this additional load may trip the
fuse. In this case,set the power sharing level value below the fuse‘s value
accordingly.
NOTICE!
Observe the standards that apply in your country to the generator
function.
+-
12/24 V
2 A
8 A
10 A
230 V
AC INPUT
AC OUTPUT
BREAKER
OUTPUTINPUT
'63&&,2VERRN6HLWH'RQQHUVWDJ-XOL

EN
Technical description SinePower
14
Example (values for illustration purpose only):
Battery charging function
I
The battery is charging with IU0U characteristics (fig. g).
1: I phase (bulk)
At the beginning of the charging process, the flat battery is charged with a constant
current (100 % charge current) until the battery voltage reaches the charging end
voltage. The charging current decreases when the battery has reached this charging
level.
2: U0 phase (absorption)
Now the two-stage absorption charging process (U0-Phase) begins, where the
charge voltage and duration depend on the size and type of the battery. The voltage
remains constant until the minimum charging current (6 % of the set current) or the
maximum charging time (10 hours) is reached.
3: U Phase (floating)
The U phase serves to maintain the battery capacity (100 %).
If DC loads are connected, they are powered by the device. Only if the power
required exceeds the capacity of the device is this surplus power provided by the
battery. The battery is then discharged until the device re-enters the I phase and
charges the battery.
NOTE
If a battery sensor (accessory) is connected, the device adjusts the
voltage according to the measured values.
For this purpose the battery sensor has to be configured with DSP-EM.
+-
12/24 V
3 A
7 A
4 A
230 V
AC INPUT
AC OUTPUT
BREAKER
OUTPUT INPUT
'63&&,2VERRN6HLWH'RQQHUVWDJ-XOL

EN
SinePower Fitting the device
15
4: 12-day conditioning
Every 12 days, the battery charger switches back to phase 3 for 85 min in order to
revive the battery. This prevents any fatigue symptoms such as sulphation.
8 Fitting the device
8.1 Tools required
For the electrical connection you will need the following tools:
• DC connection: two flexible connection cables
Determine the necessary thickness from the table in chapter “Fitting the device”
on page 15.
• AC connection: two 3-phase cables (input and output)
• Housing ground: one cable
•Crimpingtool
• Cable lugs and conductor sleeves
For fastening you will require the following tools:
• Machine bolts (M4) with washers and self-locking nuts or
• self-tapping screws or wood screws.
8.2 Mounting instructions
When selecting the installation location, observe the following instructions:
• The device can be mounted horizontally or vertically.
• The device must be installed in a place that is protected from moisture.
• The device may not be installed in the presence of flammable materials.
• The device may not be installed in a dusty environment.
• The place of installation must be well ventilated. A ventilation system must be
available for installations in small, enclosed spaces. The minimum clearance
around the device must be at least 5 cm (fig. 4).
• The air intake on the underside or the air outlet on the back of the device must
remain clear.
'63&&,2VERRN6HLWH'RQQHUVWDJ-XOL

EN
Connecting the device SinePower
16
• For ambient temperatures higher than 40 °C (such as in engine or heating
compartments, or direct sunlight), the device may shut down although the
connected load is below the rated load (derating).
• The device must be installed on a level and sufficiently sturdy surface.
A
8.3 Mounting the device
➤Mount the device as shown (fig. 5).
8.4 Mounting the DSP-EM
➤Mount the DSP-EM as shown (fig. 6).
9 Connecting the device
9.1 General instructions
!
• When installed in vehicles or boats, the device must be connected to the chassis
or earth.
• When setting up a socket distribution circuit (mains setup), comply with the
applicable regulations.
• Only use copper cables.
• Keep the cables for the DC connection as short as possible (<1 m).
NOTICE!
Before drilling any holes, make sure that no electrical cables or other
parts of the vehicle can be damaged by drilling, sawing and filing.
WARNING!
• The device may only be connected by a qualified workshop. The
following information is intended for technicians who are familiar
with the guidelines and safety precautions to be applied.
•Never use the device on vehicles where the positive terminal of the
battery is connected to the chassis.
• If you do not fit a fuse to the positive cable, the cables can over-
load, which might result in a fire.
'63&&,2VERRN6HLWH'RQQHUVWDJ-XOL

EN
SinePower Connecting the device
17
• Keep to the specified cable cross section and fit a cable fuse (fig. 81, page 1) as
close to the battery as possible on the positive cable (see the table).
9.2 Connecting the device
!
A
I
➤Connect the device as shown:
– Connecting the battery: fig. 7and fig. 8
– Connecting the ground terminal fig. 9
– Connecting the 230 V power cable: fig. 0
– Connecting the 230 V output cable: fig. 0
9.3 Connecting the DSP-EM
A
➤Connect the DSP-EM as shown (fig. a).
Device Required cable
cross section Cable fuse
DSP1212C 25 mm² ≥200 A
DSP1224C 16 mm² ≥100 A
DSP2012C 50 mm² ≥400 A
DSP2024C 25 mm² ≥200 A
WARNING!
Before connecting the AC output cable, make sure the device is
switched off at the main switch.
NOTICE!
Make sure that you do not reverse the polarity. Incorrect polarity can
damage the device.
NOTE
Tighten the nuts and bolts to a maximum torque of 15 Nm. Loose
connections may cause overheating.
NOTICE!
Only plug in the connection to the DSP-EM in the remote port. The
device can be damaged by connecting it incorrectly.
'63&&,2VERRN6HLWH'RQQHUVWDJ-XOL

EN
Connecting the device SinePower
18
9.4 Connecting external switch to turn device on and off
I
You can use the following as an external switch:
• external switch, voltage supply from the device: fig. bA
• Control unit with relay or transistor circuit (TR): fig. bB
• external switch with voltage supply from the battery (BAT) of the vehicle:
fig. bC
• external switch with its own voltage supply (DC POWER) e.g. from the ignition:
fig. bD
➤Set the main switch (fig. 21, page 1) to “OFF”.
➤Make sure that the connection for the DSP-EM (fig. 210, page 1) is not
assigned.
➤Set the main switch (fig. 21, page 1) to “REMO.”.
➤Connect the external on/off switch with the connection cable to the terminal
(fig. 211, page 1).
9.5 Connecting a relay
You can install a relay which monitors whether the 230 V input is connected.
Thereby you can, for example, implement an immobiliser so that the vehicle cannot
be started when the 230 V input is connected.
➤Connect the relay as shown (fig. c):
– NO: normally open contact
– COM: common contact
– NC: normally closed contact
Relay specification:
NOTE
Use cables with a cable cross section of 0.25 – 0.75 mm².
Maximum voltage Load Current consumption
NO NC
250 VwOhmic 0.5A 0.5A
12 V/24 VgOhmic 1A 1A
