11.8"
42.4"
Left Side View
30.1"
Front View
TITLE
DRAWING NO. REV.
NOTES
A B C D E F G H I J
1
2
3
4
5
6
7
8
9
10
1
2
3
4
5
6
7
8
9
10
150kVA G8000 Series UPS
3-Breaker Maintenance Bypass Panel
MBSB80-225-43 1.0
52C
52M
52L
Maintenance
Bypass Breaker
225 Amp M.L.O.
w/ (1) #6-250kcmil
Lug per Phase (typ)
Front View
(Door Removed)
27.0"
39.3"
Utility Feed
UPS Bypass
Input Breaker
UPS Output
Breaker
225 Amp Box-
Mounted Neutral w/
(2) #6-250kcmil Lugs
0.5" Dia.
Mounting Hole (4)
To Critical Load
ABC
N
Part No. UPS
KVA
Breaker
Type Voltage kAIC rating at 480/600V
UPS Output
Amp Rating
150MBSB80-225-43 FD 480/600 25/14180
Enclosure
Box/Trim
Finish
Breakers
Weight
- NEMA 1, Surface-Mount (UL Listed).
- 12-Gauge painted steel, trim held with adjustable clamps; Door equiped
with one 3x5 directory cardholder and Corbin type 15767 Snaplock.
- Beige polyester powdercoat on all surfaces, treated with sealer.
- Cutler-Hammer thermal-magnetic type, 225A frame, 3-pole, trip settings as
shown, supplied with (1) #4-4/0 terminal lug per phase.
- Approximately 190 lbs total.
Feed From Utility
Feed To Critical Load
52C
225AT
52M
225AT
52L
225AT
ST
ABC
A
B
C
A
B
C
A B C
Feed
from
UPS
Output
Feed to
UPS
Input
N
1) This drawing is for illustration purposes only and is subject to change without notice. TIC
is not responsible for any errors or omissions.
TOSHIBA
INTERNATIONAL CORPORATION
Houston Texas, USA
THIS MATERIAL IS THE EXCLUSIVE PROPERTY OF
TOSHIBA INTERNATIONAL CORPORATION AND SHALL NOT
BE REPRODUCED, USED, OR DISCLOSED TO OTHERS
UNLESS PRIOR WRITTEN AUTHORIZATION IS OBTAINED.
Drawn by
EO
Date 07/07/04
Approved by
JIS
Date 07/07/04
