Totally Wicked Corsa Mini User manual

1
ELECTRONIC
CIGARETTE
KIT
user manual
TW_Corsa_Mini_Manual_UK/GER.indd 1 30/03/2016 16:56

2
Congratulations on purchasing your
Totally Wicked Corsa Mini Electronic Cigarette.
The Totally Wicked Corsa Mini is a stylish, highly functional, and exceptionally
compact e-cigarette design incorporating an intelligent temperature control system,
allowing you to nely tune your device to suit your vaping style. Additionally,
upgradeable rmware means that you will always be up to date.
The user is provided with six modes of operation; Variable Power (W); Variable
Temperature with Nickel Coils (Ni); Variable Temperature with Titanium Coils (Ti);
Variable Temperature with Stainless Steel Coils (SS316); Temperature Coefcient of
Resistance (TCR) and Bypass. The adjustable modes allow for incremental settings in
terms of watts, temperature or temperature coefcient of resistance.
The Corsa Mini combines all of its functionality and a 2400mAh Li-battery in a sleek
and ergonomic, yet simple to use package, suitable for all electronic cigarette users.
TW_Corsa_Mini_Manual_UK/GER.indd 2 30/03/2016 16:56

3
Totally Wicked Corsa Mini
A. 510 Connector
B. Power Button
C. OLED Display Screen
D. Adjustment Buttons
A
B
C
D
TW_Corsa_Mini_Manual_UK/GER.indd 3 30/03/2016 16:56

4
Using your Corsa Mini
Power On and Off:
The Corsa Mini uses a 5-click on/
off function. To switch the device on,
press the power button 5 times in quick
succession. The OLED screen will
illuminate, signifying that the device
is powered on. If the Corsa Mini is
powered on the user can press the
button 5 times to switch the device off.
Vaping:
Simply press the power button as you
inhale.
Power Button
TW_Corsa_Mini_Manual_UK/GER.indd 4 30/03/2016 16:56

5
New Atomizer Installation:
When a new atomizer is connected, or
the existing atomizer is disconnected
and reconnected, a message prompt
may be displayed – ‘New Coil Right,
Same Coil Left’. Press the right
adjustment button to conrm that a new
atomizer has been connected, or the left
adjustment button to conrm that the
existing atomizer has been reconnected.
Selection of a new coil should only be
made when the atomizer and coil are at
room temperature.
Using your Corsa Mini
RIGHTLEFT
TW_Corsa_Mini_Manual_UK/GER.indd 5 30/03/2016 16:56

6
Using your Corsa Mini
Charging the Battery:
Simply charge the Corsa Mini via
the USB cable when connected to
a powered USB port or suitable wall
adapter. The indicator on the display will
indicate the battery status.
Battery Charge:
The battery charge for the internal
2400mAh Li-battery is displayed on the
fth row of the OLED display.
Shift between VW/VT-Ni/VT-Ti/VT-
SS316/TCR/Bypass Modes:
When powered on, press the power
button 3 times consecutively, the rst
row will ash indicating that the right
adjustment button may be used to cycle
through the VW/VT-Ni/VT-Ni /VT-SS316/
TCR/Bypass modes.
RIGHT
TW_Corsa_Mini_Manual_UK/GER.indd 6 30/03/2016 16:56

7
Using your Corsa Mini
VW Mode:
When in VW mode, use the left or
right adjustment buttons to decrease
or increase the level of wattage
respectively. The available wattage
range is 1W – 80W in increments of 1W.
VT Mode (Ni/Ti/SS316):
When in VT mode, use the left or right
adjustment buttons to decrease or
increase the temperature respectively.
The available temperature range is
100-315°C or 200-600°F and can be
adjusted in increments of 5°C and 10°F.
To adjust the wattage level whilst in VT
mode, press the power button 3 times
consecutively to activate the menu,
press the left adjustment button once
and the wattage (PWR) value will ash,
use the right adjustment button to adjust
the wattage level.
RIGHT
TW_Corsa_Mini_Manual_UK/GER.indd 7 30/03/2016 16:56

8
RIGHT
To lock/unlock the atomizer
resistance, press the power button 3
times in quick succession to activate
the menu, press the left adjustment
button twice and the atomizer value
will ash, use the right adjustment
button the lock/unlock the atomizer
resistance.
Note: Only lock the atomizer when the
coil is at room temperature.
Note: If a coil with a resistance
exceeding 1.5ohms is applied in VT
mode, the device will automatically
switch to VW mode. Also, if a standard
kanthal coil is used under VT mode,
the device will automatically switch to
VW mode.
Using your Corsa Mini
TW_Corsa_Mini_Manual_UK/GER.indd 8 30/03/2016 16:56

9
TCR Mode:
When in TCR mode and the title is
ashing indicating that the menu is
active, press the left adjustment button
once and the sub-menu (M1, M2 and
M3) will ash. Whilst the sub-menu is
ashing press the right button to shift
between M1, M2 and M3, then press
the power button to conrm. (Also see:
Conguring TCR Mode)
Conguring TCR Mode:
To set the temperature coefcient
of resistance to match a particular
coil, when the device is powered off
simultaneously hold the power button
and the right adjustment button to enter
the TCR conguration menu.
Use the right or left adjustment buttons
to select which to congure from M1,
M2 and M3 – this feature allows the
TCR values for 3 materials to be stored
to the device. Press the power button
to select the TCR value and then use
the adjustment buttons to increase or
decrease the value to your preference,
long press the power button or leave
the device for 10 seconds to conrm
the selection.
Using your Corsa Mini
RIGHT
Power Button
+
TW_Corsa_Mini_Manual_UK/GER.indd 9 30/03/2016 16:56

10
TCR Value Range
Material TCR Value Range
Nickel 600-700
NiFe 300-400
Titanium 300-400
SS
(303, 304, 316, 317) 80-200
Note: The TCR value displayed is 105 (100,000) times
greater than the actual TCR value and is for Corsa Mini
usage only.
TW_Corsa_Mini_Manual_UK/GER.indd 10 30/03/2016 16:56

11
Using your Corsa Mini
Current Display:
The real-time current (AMP) is displayed
on the screen on the fourth row whilst
the power button is pressed.
Charge Error:
If no charging current is detected when
the device is connected to the charging
lead, ‘Charge Error’ will be displayed.
Short Circuit Protection:
If a short circuit occurs when the power
button is pressed, ‘atomizer short’ will
be displayed on the screen.
TW_Corsa_Mini_Manual_UK/GER.indd 11 30/03/2016 16:56

12
Using your Corsa Mini
Low Voltage Protection:
When the battery voltage is below
3.1V, ‘Battery Low’ will be displayed on
the screen. If following this message,
the button is continually pressed, the
message ‘Battery Low Lock’ will be
displayed and the device will not re.
To unlock and activate the device the
battery must be recharged.
Weak Battery Alert:
Under VT/VW mode, if battery voltage
drops below 2.9V, the device will display
‘Weak Battery’. The output power will
automatically be reduced accordingly.
TW_Corsa_Mini_Manual_UK/GER.indd 12 30/03/2016 16:56

13
Using your Corsa Mini
10 Second Protection:
If the power button is pressed for
longer than 10 seconds, the output will
automatically cease and the message
‘Over 10s Protection’ will be displayed.
Upgrading Firmware:
To upgrade the rmware installed on the
device simply load the relevant product
page on the Totally Wicked website,
click on the link under ‘Firmware
Upgrade’ and follow the instructions
provided.
Display Modes:
When powered off, hold both
adjustment buttons to turn the display
through 180°. Two display states are
available.
Stealth Mode:
When powered on, simultaneously
hold the power button and the left
adjustment button to activate stealth
mode. Repeat the process to deactivate
stealth mode.
TW_Corsa_Mini_Manual_UK/GER.indd 13 30/03/2016 16:56

14
Using your Corsa Mini
Key Lock Mode:
When powered on, simultaneously
hold the two adjustment buttons for
3 seconds to activate key lock mode.
Repeat the process to deactivate the
key lock mode.
Check USB Adapter:
If the voltage of the USB adapter is 5.8V
or higher, ‘Check USB Adapter’ will be
displayed on the screen when either the
charging lead is connected or the re
button is pressed.
TW_Corsa_Mini_Manual_UK/GER.indd 14 30/03/2016 16:56

15
Wattage Range in VW Mode and VT Mode: 1W – 80W
Temperature Range in VT Mode: 100-315°C / 200-600°F
Temperature Coefcient of Resistance Range in TCR Mode: 1-1000
Resistance Range: 0.05-1.5ohm in VT Mode, 0.1-3.5ohm in VW Mode
Tank Connector: 510 Connector
Battery: Integrated 2400mAh Li-Battery
Firmware Type: Upgradable
Specifications
TW_Corsa_Mini_Manual_UK/GER.indd 15 30/03/2016 16:56

16
DO’s
• Store the Corsa Mini and its accessories away from children when not in use.
• Ensure the Corsa Mini is powered off when not in use.
• Avoid accidentally pressing the Corsa Mini power button when not in use.
• Please only use the charging cable provided.
• Please dispose of dead batteries in accordance with your country’s appropriate
legislation.
• Use only a maximum of 1.5ohm when in VT mode. The mode will automatically be
switched to VW mode when the coil is larger than 1.5ohm or a normal coil is used.
DON’Ts
• Do not charge the batteries in a damp environment.
• Do not use the device when temperatures are outside the range -10 - 60°C.
• Do not charge the battery when temperatures are outside the range 0 - 45°C.
• Do not attempt to repair a faulty Corsa Mini as these are sealed units with no
serviceable parts. Attempted repairs will void the warranty.
• Do not use temperature control coils under VW mode, damage will be caused.
Precautions
TW_Corsa_Mini_Manual_UK/GER.indd 16 30/03/2016 16:56

17
The Corsa Mini components have a 28-day parts warranty. The USB cable supplied
has a 12-month warranty. If any parts are found to be faulty within this time please
contact our customer service team, whose details are on the back page of this booklet
and we will arrange for a replacement. We may require the goods to be returned for
further investigation.
Warranty
TW_Corsa_Mini_Manual_UK/GER.indd 17 30/03/2016 16:56

18
Glückwunsch zum Kauf Ihrer Totally Wicked
Corsa Mini E-Zigarette.
Die Totally Wicked Corsa Mini ist eine elegante, funktionelle und eine kompakte
E-Zigarette einschließlich intelligenter Temperatursteuerung. Die Firmware kann
aktualisiert werden, daher ist man mit der Corsa Mini auch in Zukunft stets auf dem
neuesten Stand.
Der Nutzer kann aus sechs Betriebsmodi wählen; variable Leistung (W); variable
Temperatur mit Nickel-Heizwendeln (Ni); variable Temperatur mit Titan-Heizwendeln
(Ti); variable Temperatur mit Edelstahl-Heizwendeln (SS316); Temperaturkoefzient
(TCR) und Bypass.
Die Corsa Mini vereint all ihre Funktionalität - inkl. 2400mAh Li-Akku - in einem
ergonomischen und dennoch einfach zu bedienendem Paket.
TW_Corsa_Mini_Manual_UK/GER.indd 18 30/03/2016 16:56

19
Totally Wicked Corsa Mini
A. 510er Gewinde
B. Power-Taster
C. OLED -Display-Bildschirm
D. Einstelltasten
A
B
C
D
TW_Corsa_Mini_Manual_UK/GER.indd 19 30/03/2016 16:56

20
Bedienung Ihrer Corsa Mini
Power Ein/Aus:
Power-Taster 5-mal in Folge drücken;
das OLED-Display leuchtet auf und
signalisiert, dass die Corsa Mini an
und zur Nutzung bereit ist. Zum
Ausschalten, Taster ebenfalls 5-mal in
Folge drücken.
Dampfen:
Power-Taster drücken und inhalieren.
POWER-TASTER
TW_Corsa_Mini_Manual_UK/GER.indd 20 30/03/2016 16:56
