Totally Wicked INTU Mini User manual

USER MANUAL / BEDIENUNGSANLEITUNG
TW_Intu_Mini_Kit_Compliant_Manual.indd 1 22/03/2017 12:46

2
Congratulations on purchasing your
Totally Wicked INTU Mini Electronic Cigarette Kit.
The Totally Wicked INTU Mini is an exceptionally compact, yet highly functional
device incorporating an intelligent temperature control system, allowing you
to finely tune to suit your vaping style. Paired with the INTU Mini is the SubAir
III Nano Tank, providing top filling capability, adjustable airflow and the use of
the popular EC/ML atomizer heads. The user is provided with seven modes of
vaping operation; Variable Power (W); Bypass; Smart Mode; Variable Temperature
with Nickel Coils (Ni); Variable Temperature with Titanium Coils (Ti); Variable
Temperature with Stainless Steel Coils (SS316) and Temperature Coefficient of
Resistance (TCR). The adjustable modes allow for incremental settings in terms
of watts or temperature. The INTU Mini Kit combines all of its functionality and
1100mAh battery in a sleek and ergonomic, yet simple to use package.
TW_Intu_Mini_Kit_Compliant_Manual.indd 2 22/03/2017 12:46

3
INTU Mini Battery
Power Button
OLED Screen
Up Button
Mode Button
Down Button
Adjustment
Buttons
510 Connector
Micro USB Port
TW_Intu_Mini_Kit_Compliant_Manual.indd 3 22/03/2017 12:46

4
SubAir III Nano Tank
Airflow Ring
Atomizer Base
Atomizer Head
Glass Tube
Top Cap
Mouthpiece
TW_Intu_Mini_Kit_Compliant_Manual.indd 4 22/03/2017 12:46

5
Using your INTU Mini Kit
Using your Tank for the First Time:
Remove the top cap from the
atomizer head by unscrewing in
the anticlockwise direction and
drip a few drops of e-liquid into
the atomizer head, this will ensure
optimum operation and longevity of
the atomizer.
Filling the SubAir III Nano Tank:
To fill the tank, turn the cap
anticlockwise until it is fully
unscrewed from the atomizer head.
Fill the tank with e-liquid by inserting
the nozzle between the glass tube
and the atomizer head. Replace the
top cap onto the atomizer head by
turning it clockwise until it is firmly
seated.
Maximum refill nozzle diameter:
4.0mm
TW_Intu_Mini_Kit_Compliant_Manual.indd 5 22/03/2017 12:46

6
Replacing the Atomizer Head
To replace the atomizer head,
turn the top cap anticlockwise
until it is fully unscrewed from
the atomizer head. Remove the
glass by pulling it away from the
sealing ring on the atomizer base,
the atomizer head can now be
unscrewed from the atomizer base
by turning it anticlockwise. Screw
the replacement atomizer into the
base by turning it clockwise until
firmly seated. Reassemble the tank
and the new atomizer head is ready
for use.
Note: Please drip a few drops of
e-liquid into a new atomizer head
before use.
Using your INTU Mini Kit
TW_Intu_Mini_Kit_Compliant_Manual.indd 6 22/03/2017 12:46

7
Using your INTU Mini Kit
Power On and Off:
The INTU Mini uses a 5-click on/
off function. To switch the device
on, press the power button 5 times
in quick succession. The OLED
screen will illuminate, signifying that
the device is powered on. Press
the button 5 times to switch the
device off.
Vaping:
Simply press the power button as
you inhale.
Adjusting the Airflow:
To adjust the airflow, simply twist
the Airflow ring in the clockwise
direction to loosen the draw and in
the anticlockwise direction to tighten
the draw.
Charging the Battery:
Charge the INTU Mini via the USB
cable when connected to a powered
USB port or suitable wall adapter.
The indicator on the display will
indicate the battery status.
TW_Intu_Mini_Kit_Compliant_Manual.indd 7 22/03/2017 12:46

8
Using your INTU Mini Kit
Shift between VW/Bypass/Smart/
VT-Ni/VT-Ti/VT-SS316/TCR Modes:
When powered on, hold the mode
button to cycle through the VW/
Bypass/Smart/VT-Ni/VT-Ti/VT-SS316/
TCR modes.
VW Mode and Smart Mode:
When in VW or smart mode, use
the up or down adjustment buttons
to increase or decrease the level of
wattage respectively. The available
wattage range is 1W – 40W in
increments of 1W. Smart mode
allows for wattage settings to be
saved to the device dependant on
the atomizer resistance which is
installed, 10 profiles can be saved
at one time and if this is exceeded
the first profile will be deleted. If the
wattage is changed for a particular
resistance, this will automatically be
saved to that resistance profile.
TW_Intu_Mini_Kit_Compliant_Manual.indd 8 22/03/2017 12:46

9
Using your INTU Mini Kit
Bypass Mode:
When in bypass mode there is
a direct output of the voltage of
the internal battery cell. The cells
operating voltage will be displayed
when the power button is pressed,
and will be dependent on the
resistance of the atomizer used.
VT Mode (Ni/Ti/SS316):
When in VT mode, use the up or
down adjustment buttons to increase
or decrease the temperature
respectively. The available
temperature range is 100-315°C
or 200-600°F and can be adjusted
in increments of 5°C and 10°F. To
adjust the wattage level whilst in
VT mode, hold the up adjustment
button and the mode button
simultaneously to increase the
wattage, conversely, hold the down
adjustment button and the mode
TW_Intu_Mini_Kit_Compliant_Manual.indd 9 22/03/2017 12:46

10
Using your INTU Mini Kit
button to decrease the wattage.
To lock the atomizer resistance, hold
the power button and up adjustment
button simultaneously until the
‘Ω’ symbol appears next to the
resistance. Repeat the process to
unlock the atomizer resistance, the
‘Ω’ symbol will disappear.
Note: Only lock the atomizer when
the coil is at room temperature.
Note: If a coil with a resistance
exceeding 1.5ohms is applied
in VT mode, the device will
automatically switch to VW mode.
Also, if a standard kanthal coil is
used under VT mode, the device
will automatically switch to VW
mode.
TCR Mode (M1, M2, M3):
When in TCR mode, use the up or
down adjustment buttons to increase
or decrease the temperature
respectively. The available
TW_Intu_Mini_Kit_Compliant_Manual.indd 10 22/03/2017 12:46

11
Using your INTU Mini Kit
temperature range is 100-315°C
or 200-600°F and can be adjusted
in increments of 5°C and 10°F. To
adjust the wattage level whilst in
TCR mode, hold the up adjustment
button and the mode button
simultaneously to increase the
wattage, conversely, hold the down
adjustment button and the mode
button to decrease the wattage.
Configuring TCR Mode:
To set the temperature coefficient
of resistance to match a particular
coil, when the device is powered
off simultaneously hold the power
button and the up adjustment button
to enter the TCR configuration
menu. Hold the Power Button for 1-2
seconds to select which to configure
from M1, M2 and M3 – this feature
allows the TCR values for 3 materials
to be stored to the device. Use the
up and down adjustment buttons to
increase or decrease the value to
your preference, leave the device for
5 seconds to confirm the selection.
TW_Intu_Mini_Kit_Compliant_Manual.indd 11 22/03/2017 12:46

12
Using your INTU Mini Kit
TCR Value Range:
Material TCR Value Range
Nickel 600-700
NiFe 300-400
Titanium 300-400
SS (303, 304, 316, 317) 80-200
Note: The TCR value displayed is 105(100,000) times greater than the actual
TCR value and is for INTU Mini usage only.
TW_Intu_Mini_Kit_Compliant_Manual.indd 12 22/03/2017 12:46

13
Using your INTU Mini Kit
Stealth Mode:
When powered on, simultaneously
hold the power button and the
left adjustment button to activate
stealth mode. Repeat the process to
deactivate stealth mode.
Temperature Protection:
When in VT mode, if the actual
temperature of the coil is above the
set temperature then ‘Protection’ will
be displayed on the screen. This is
normal operation of the device and
the user many continue to vape.
Temperature Alert:
If the temperature of the device
exceeds 70°C, the output will
cease and ‘Device Too Hot’ will
be displayed on the screen. If this
occurs, allow to device to cool to
room temperature before resuming
vaping.
TW_Intu_Mini_Kit_Compliant_Manual.indd 13 22/03/2017 12:46

14
Using your INTU Mini Kit
Short Circuit Protection:
If a short circuit occurs when the
power button is pressed, ‘atomizer
short’ will be displayed on the
screen. If this occurs, remove and
reinstall the tank and atomizer, if
this does not resolve the issue then
a new atomizer may be required.
If replacing the atomizer does not
resolve the issue, please contact
customer services.
Low Voltage Protection:
When the battery voltage is below
3.1V, ‘Battery Low’ will be displayed
on the screen. If following this
message, the button is continually
pressed, the message ‘Battery Low
Lock’ will be displayed and the
device will not operate. To unlock
and activate the device the battery
must be recharged.
TW_Intu_Mini_Kit_Compliant_Manual.indd 14 22/03/2017 12:46

15
Using your INTU Mini Kit
10 Second Protection:
If the power button is pressed for
longer than 10 seconds, the output
will automatically cease and the
message ‘Over 10s Protection’ will
be displayed.
Display Modes:
When powered off, hold both
adjustment buttons to turn the
display through 180°. Two display
states are available.
Key Lock Mode:
When powered on, simultaneously
hold both adjustment buttons for 3
seconds to activate key lock mode.
Repeat the process to deactivate the
key lock mode.
TW_Intu_Mini_Kit_Compliant_Manual.indd 15 22/03/2017 12:46

16
Kit Contents
1 x INTU Mini Body
1 x SubAir III Nano Tank (2ml)
1 x EC/ML atomizer head (0.3ohm fitted)
1 x EC/ML atomizer head (0.75ohm)
1 x Seal Ring
1 x USB Cable
1 x User Manual
TW_Intu_Mini_Kit_Compliant_Manual.indd 16 22/03/2017 12:46

17
Specications
INTU Mini Dimensions: 55mm x 38mm x 22.5mm
Display: 0.6” OLED
Wattage Range in VW Mode and VT Mode: 1W – 40W
Temperature Range in VT Mode: 100-315°C / 200-600°F
Temperature Coefficient of Resistance Range in TCR Mode: 1-1000
Resistance Range: 0.05-1.5ohm in VT Mode, 0.1-3.5ohm in VW/Bypass Mode
Tank Connector: 510 Connector
Battery: 1100mAh - Integrated
SubAir III Nano Dimensions: 51.5mm x 22mm
Tank Capacity: 2ml
Connector: 510 Connector
Atomizer Type: EC/ML
Maximum refill nozzle diameter: 4.0mm
TW_Intu_Mini_Kit_Compliant_Manual.indd 17 22/03/2017 12:46

18
Additional product information
There are no reported medical side effects with this product. If you believe you
experience a side effect, please contact the manufacturer.
TW_Intu_Mini_Kit_Compliant_Manual.indd 18 22/03/2017 12:46

19
Product storage and battery precautions
• Store the INTU Mini and its accessories away from children when not in use.
• Ensure the INTU Mini is powered off when not in use.
• Avoid accidentally pressing the INTU Mini power button when not in use.
• Please only use the charging cable provided.
• Please dispose of dead batteries in accordance with your country’s
appropriate legislation.
• Use only a maximum of 1.5ohm when in VT mode. The mode will
automatically be switched to VW mode when the coil is larger than 1.5ohm or
a normal coil is used.
• Do not charge the batteries in a damp environment.
• Do not use the device when temperatures are outside the range -10 - 60°C.
• Do not charge the battery when temperatures are outside the range 0 - 45°C.
• Do not attempt to repair a faulty INTU Mini as these are sealed units with no
serviceable parts. Attempted repairs will void the warranty.
TW_Intu_Mini_Kit_Compliant_Manual.indd 19 22/03/2017 12:46

20
The INTU Mini Kit components have a 28-day parts warranty with the exception
of the atomizer heads which are consumable items and covered by our ‘dead
on arrival’ warranty only. The USB cable supplied has a 12-month warranty. If
any parts are found to be faulty within this time please contact our customer
service team, whose details are on the back of this booklet and we will arrange
for a replacement. We may require the goods to be returned for further
inspection.
Warranty
TW_Intu_Mini_Kit_Compliant_Manual.indd 20 22/03/2017 12:46
