TQ MB-COME10-1 User manual

User's Manual l MB-COME10-1 UM 0101 l © 2016 TQ-Group Page i
MB
-
COME10
-
1
User's Manual
MB-COME10-1 UM 0101
2016-01-29

User's Manual l MB-COME10-1 UM 0101 l © 2016 TQ-Group Page i
TAB E OF CONTENTS
1. ABOUT THIS MANUA ................................................................................................................................................................................1
1.1 Copyright and icence Expenses ...........................................................................................................................................................1
1.2 Registered Trademarks..............................................................................................................................................................................1
1.3 Disclaimer......................................................................................................................................................................................................1
1.4 Imprint............................................................................................................................................................................................................1
1.5 Service and Support...................................................................................................................................................................................1
1.6 Tips on Safety ...............................................................................................................................................................................................2
1.7 Symbols and Typographic Conventions..............................................................................................................................................2
1.8 Handling and ESD Tips ..............................................................................................................................................................................2
1.9 Naming of Signals.......................................................................................................................................................................................3
1.10 Further Applicable Documents / Presumed Knowledge................................................................................................................3
2. INTRODUCTION ...........................................................................................................................................................................................4
2.1 Functional Overview..................................................................................................................................................................................4
2.2 Specification Compliance.........................................................................................................................................................................4
2.3 Versions..........................................................................................................................................................................................................5
2.4 Accessories....................................................................................................................................................................................................5
3. FUNCTIONA SPECIFICATION..................................................................................................................................................................6
3.1 Block Diagram..............................................................................................................................................................................................6
3.2 Electrical Specification...............................................................................................................................................................................6
3.2.1 Supply Voltage Characteristics ...............................................................................................................................................................6
3.2.2 Power Consumption Specification........................................................................................................................................................6
3.3 Environmental Specification ...................................................................................................................................................................7
3.4 System Components..................................................................................................................................................................................7
3.4.1 Gigabit Ethernet Controller......................................................................................................................................................................7
3.4.2 DP- VDS Bridge ...........................................................................................................................................................................................7
3.4.3 Dual UART......................................................................................................................................................................................................7
3.4.4 USB Hub .........................................................................................................................................................................................................7
3.4.5 HD-Audio Codec..........................................................................................................................................................................................7
3.4.6 IC Test Devices............................................................................................................................................................................................7
3.5 Connectors and Interfaces .......................................................................................................................................................................8
3.5.1 Power Supply ............................................................................................................................................................................................ 10
3.5.2 DisplayPort................................................................................................................................................................................................. 10
3.5.3 USB Host / Device Interfaces ................................................................................................................................................................ 10
3.5.4 Gigabit Ethernet ....................................................................................................................................................................................... 11
3.5.5 Serial Interfaces (RS232/RS422) ........................................................................................................................................................... 11
3.5.6 Embedded Display Port ......................................................................................................................................................................... 13
3.5.7 VDS............................................................................................................................................................................................................. 14
3.5.8 Mini PCIe Socket....................................................................................................................................................................................... 15
3.5.9 SATA Interfaces......................................................................................................................................................................................... 16
3.5.10 SD Card Socket.......................................................................................................................................................................................... 17
3.5.11 Audio............................................................................................................................................................................................................ 17
3.5.12 Fan Connectors......................................................................................................................................................................................... 18
3.5.13 Riser Interface............................................................................................................................................................................................ 18
3.5.14 Front Panel Connector ........................................................................................................................................................................... 19
3.5.15 Debug EDs................................................................................................................................................................................................ 19
3.5.16 SMBus and IC Header ............................................................................................................................................................................ 19
3.5.17 SPI Flash Socket ........................................................................................................................................................................................ 20
3.5.18 COM Express™ GPIO Header................................................................................................................................................................. 20
3.5.19 Smart Battery Management Header .................................................................................................................................................. 20
3.5.20 COM Express™ Connector ..................................................................................................................................................................... 20

User's Manual l MB-COME10-1 UM 0101 l © 2016 TQ-Group Page ii
TAB E OF CONTENTS (continued)
4. MECHANICS ............................................................................................................................................................................................... 21
4.1 Dimensions ................................................................................................................................................................................................ 21
4.2 Protection Against External Effects .................................................................................................................................................... 21
5. SOFTWARE.................................................................................................................................................................................................. 22
5.1 System Resources .................................................................................................................................................................................... 22
5.1.1 IC Bus.......................................................................................................................................................................................................... 22
5.1.2 SMBus .......................................................................................................................................................................................................... 22
5.2 Operating Systems .................................................................................................................................................................................. 22
5.2.1 Supported Operating Systems............................................................................................................................................................. 22
5.2.2 Driver Download...................................................................................................................................................................................... 22
6. SAFETY REQUIREMENTS AND PROTECTIVE REGU ATIONS......................................................................................................... 23
6.1 EMC............................................................................................................................................................................................................... 23
6.2 ESD................................................................................................................................................................................................................ 23
6.3 Operational Safety and Personal Security........................................................................................................................................ 23
6.4 Reliability and Service ife..................................................................................................................................................................... 23
6.4.1 RoHS Compliance..................................................................................................................................................................................... 23
6.4.2 WEEE Regulation ...................................................................................................................................................................................... 23
6.5 Other Entries.............................................................................................................................................................................................. 23
7. APPENDIX................................................................................................................................................................................................... 24
7.1 Acronyms and Definitions..................................................................................................................................................................... 24
7.2 References.................................................................................................................................................................................................. 26
TAB E DIRECTORY
Table 1: Terms and Conventions.....................................................................................................................................................................2
Table 2: Pinout Power-In Connector X10 .................................................................................................................................................. 10
Table 3: TQ-Specific Feature for DDI1......................................................................................................................................................... 10
Table 4: Pinout USB Host Extension Connector X26.............................................................................................................................. 10
Table 5: Ethernet EDs..................................................................................................................................................................................... 11
Table 6: Serial Port COM Express™ Port Mapping................................................................................................................................... 11
Table 7: RS232 D-Sub Connector X6........................................................................................................................................................... 12
Table 8: RS232 Header X24 ............................................................................................................................................................................ 12
Table 9: RS422 Header X25 ............................................................................................................................................................................ 12
Table 10: eDP Connector X30.......................................................................................................................................................................... 13
Table 11: VDS Connector X31........................................................................................................................................................................ 14
Table 12: Backlight Power Connector X11 .................................................................................................................................................. 15
Table 13: Backlight Connector X32................................................................................................................................................................ 15
Table 14: Headphone and Microphone Connector X12 ......................................................................................................................... 17
Table 15: Speaker Connector for Right Speaker X27................................................................................................................................ 17
Table 16: Speaker Connector for eft Speaker X28................................................................................................................................... 17
Table 17: 12 V Fan Connector X17 ................................................................................................................................................................. 18
Table 18: 5 V Fan Connector X18.................................................................................................................................................................... 18
Table 19: Debug EDs........................................................................................................................................................................................ 19
Table 20: IC Address Mapping COM Express™ IC Bus............................................................................................................................ 22
Table 21: IC Address Mapping COM Express™ SMBus Port................................................................................................................... 22
Table 22: Acronyms ............................................................................................................................................................................................ 24
Table 23: Further Applicable Documents and inks................................................................................................................................. 26

User's Manual l MB-COME10-1 UM 0101 l © 2016 TQ-Group Page iii
I USTRATION DIRECTORY
Illustration 1: Block Diagram MB-COME10-1 .........................................................................................................................................................6
Illustration 2: MB-COME10-1, Top.............................................................................................................................................................................8
Illustration 3: MB-COME10-1, Bottom......................................................................................................................................................................9
Illustration 4: RJ45 Connectors X8, X9 .................................................................................................................................................................. 11
Illustration 5: RS232 D-SUB Connector X6........................................................................................................................................................... 12
Illustration 6: RS232 Header X24 ............................................................................................................................................................................ 12
Illustration 7: RS422 Header X25 ............................................................................................................................................................................ 12
Illustration 8: eDP Connector X30.......................................................................................................................................................................... 13
Illustration 9: VDS Connector X31........................................................................................................................................................................ 14
Illustration 10: Backlight Connector X32................................................................................................................................................................ 15
Illustration 11: 2.5” HDD/SSD Mounting ................................................................................................................................................................ 16
Illustration 12: Headphone / Microphone X12..................................................................................................................................................... 17
Illustration 13: Speaker Connector X27 .................................................................................................................................................................. 17
Illustration 14: Speaker Connector X28 .................................................................................................................................................................. 17
Illustration 15: 12 V Fan Connector X17 ................................................................................................................................................................. 18
Illustration 16: 5 V Fan Connector X18.................................................................................................................................................................... 18
Illustration 17: PCIe card Installation Configuration........................................................................................................................................... 18
Illustration 18: Front Panel Connector.................................................................................................................................................................... 19
Illustration 19: SMBus and IC Header..................................................................................................................................................................... 19
Illustration 20: COM Express™ GPIO Header.......................................................................................................................................................... 20
Illustration 21: Smart Battery Management Header........................................................................................................................................... 20
Illustration 22: MB-COME10-1 ................................................................................................................................................................................... 21
REVISION HISTORY
Rev. Date Name Pos. Modification
0100 2015-12-16 FP First edition
0101 2016-01-29 FP
2.4
3.5.4, Illustration 4
Illustration 12
Table 19
Accessories updated
“X10” replaced by “X8”
Corrected
“Function” and “Remark” of “SUS S3” to “SUS S5” corrected

User's Manual l MB-COME10-1 UM 0101 l © 2016 TQ-Group Page 1
1. ABOUT THIS MANUAL
1.1 Copyright and Licence Expenses
Copyright protected © 2016 by TQ-Systems GmbH.
This User's Manual may not be copied, reproduced, translated, changed or distributed, completely or partially
in electronic, machine readable, or in any other form without the written consent of TQ-Systems GmbH.
The drivers and utilities for the components used as well as the BIOS are subject to the copyrights of the respective
manufacturers. The licence conditions of the respective manufacturer are to be adhered to.
BIOS-licence expenses are paid by TQ-Systems GmbH and are included in the price.
icence expenses for the operating system and applications are not taken into consideration and must be separately
calculated / declared.
1. Registered Trademarks
TQ-Systems GmbH aims to adhere to the copyrights of all the graphics and texts used in all publications, and strives to use
original or license-free graphics and texts.
All the brand names and trademarks mentioned in the publication, including those protected by a third party, unless specified
otherwise in writing, are subjected to the specifications of the current copyright laws and the proprietary laws of the present
registered proprietor without any limitation. One should conclude that brand and trademarks are rightly protected by a third
party.
1.3 Disclaimer
TQ-Systems GmbH does not guarantee that the information in this User's Manual is up-to-date, correct, complete or of good
quality. Nor does TQ-Systems GmbH assume guarantee for further usage of the information. iability claims against TQ-Systems
GmbH, referring to material or non-material related damages caused, due to usage or non-usage of the information given in the
User's Manual, or due to usage of erroneous or incomplete information, are exempted, as long as there is no proven intentional
or negligent fault of TQ-Systems GmbH.
TQ-Systems GmbH explicitly reserves the rights to change or add to the contents of this User's Manual or parts of it without
special notification.
1.4 Imprint
TQ-Systems GmbH
Gut Delling, Mühlstraße 2
D-8 9 Seefeld
Tel: [phone]
Fax: [phone]
Email: [email protected]
Web: http://www.tq-group.com/
1.5 Service and Support
Please visit our website www.tq-group.com for latest product documentation, drivers, utilities and technical support.
You can register on our website www.tq-group.com to have access to restricted information and automatic update services.
For direct technical support you can contact our FAE team by email: [email protected].
Our FAE team can also support you with additional information like 3D-STEP files and confidential information, which is not
provided on our public website.
For service/RMA, please contact our service team by email ([email protected]) or your sales team at TQ.

User's Manual l MB-COME10-1 UM 0101 l © 2016 TQ-Group Page 2
1.6 Tips on Safety
Improper or incorrect handling of the product can substantially reduce its life span.
1.7 Symbols and Typographic Conventions
Table 1: Terms and Conventions
Symbol Meaning
This symbol represents the handling of electrostatic-sensitive modules and / or components. These
components are often damaged / destroyed by the transmission of a voltage higher than about 50 V.
A human body usually only experiences electrostatic discharges above approximately 3,000 V.
This symbol indicates the possible use of voltages higher than 24 V.
Please note the relevant statutory regulations in this regard.
Non-compliance with these regulations can lead to serious damage to your health and also cause
damage / destruction of the component.
This symbol indicates a possible source of danger. Acting against the procedure described can lead to
possible damage to your health and / or cause damage / destruction of the material used.
This symbol represents important details or aspects for working with TQ-products.
Command A font with fixed-width is used to denote commands, contents, file names, or menu items.
1.8 Handling and ESD Tips
General handling of your TQ-products
The TQ-product may only be used and serviced by certified personnel who have taken note of the
information, the safety regulations in this document and all related rules and regulations.
A general rule is: do not touch the TQ-product during operation. This is especially important when
switching on, changing jumper settings or connecting other devices without ensuring beforehand
that the power supply of the system has been switched off.
Violation of this guideline may result in damage / destruction of the MB-COME10-1 module and be
dangerous to your health.
Improper handling of your TQ-product would render the guarantee invalid.
Proper ESD handling
The electronic components of your TQ-product are sensitive to electrostatic discharge (ESD).
Always wear antistatic clothing, use ESD-safe tools, packing materials etc., and operate your TQ-
product in an ESD-safe environment. Especially when you switch modules on, change jumper settings,
or connect other devices.

User's Manual l MB-COME10-1 UM 0101 l © 2016 TQ-Group Page 3
1.9 Naming of Signals
A hash mark (#) at the end of the signal name indicates a low-active signal.
Example: RESET#
If a signal can switch between two functions and if this is noted in the name of the signal, the low-active function is marked with
a hash mark and shown at the end.
Example: C / D#
If a signal has multiple functions, the individual functions are separated by slashes when they are important for the wiring.
The identification of the individual functions follows the above conventions.
Example: WE2# / OE#
1.10 Further Applicable Documents / Presumed Knowledge
•Specifications and manual of the modules used:
These documents describe the service, functionality and special characteristics of the module used.
•Specifications of the components used:
The manufacturer's specifications of the components used, for example CompactFlash cards, are to be taken note of.
They contain, if applicable, additional information that must be taken note of for safe and reliable operation.
These documents are stored at TQ-Systems GmbH.
•Chip errata:
It is the user's responsibility to make sure all errata published by the manufacturer of each component are taken note of.
The manufacturer’s advice should be followed.
•Software behaviour:
No warranty can be given, nor responsibility taken for any unexpected software behaviour due to deficient components.
•General expertise:
Expertise in electrical engineering / computer engineering is required for the installation and the use of the device.
Implementation information for the carrier board design is provided in the COM Express™ Design Guide (2) maintained by the
PICMG®. This Carrier Design Guide includes a very good guideline to design a COM Express™ carrier board.
It includes detailed information with schematics and detailed layout guidelines.
Please refer to the official PICMG® documentation for additional information (1), (2).

User's Manual l MB-COME10-1 UM 0101 l © 2016 TQ-Group Page 4
. INTRODUCTION
The COM Express™ mainboard MB-COME10-1 is a carrier board for COM Express™ modules with Type 10 pinout. It can be used
for embedded computers or as evaluation platform for COM Express™ modules. In combination with a standard COM Express™
module it forms a very compact hardware kit that can be used for a freely scalable embedded PC platform thanks to its modular
design. Because of this – with uniform interfaces and mechanical dimensions – the PC system can be easily adjusted to suit the
requirements of the application. The many extension options and storage media that can be added offer a high level of flexibility
and allow functionalities and performance to be extended easily, quickly and inexpensively. Typical uses are found in embedded
server applications, PC systems for automation, visualisation and monitoring and all applications that place high demands on
quality, durability and long-term availability.
.1 Functional Overview
The following key functions are implemented on the MB-COME10-1:
Supported Modules:
•COM Express™ Mini Modules with Type 10 pinout
External Interfaces:
•2 × Gigabit Ethernet
•4 × USB2.0 (1 × USB3.0)
•Up to 2 × DisplayPort (2nd DP is optional)
•RS232
•Power Button / Reset
Internal Interfaces:
•Embedded Display Port (optional)
•VDS (optional)
•1 × USB (e.g. for touch applications)
•1 × USB 3.0 device
•Mini PCIe socket (with SIM Card support)
•mSATA socket
•SD card socket
•Socket for 2.5” HDD/SSD
•Audio: 1 × headphone out + 1 × microphone in + stereo speaker out
•RS232
•RS485/RS422
•Riser interface for PCIe add in cards
Power supply:
•Voltage: 12 V DC ±5 %
Environment:
•Extended temperature: –20 °C to +85 °C
Form factor / dimensions:
•170 × 170 mm (Mini ITX)
. Specification Compliance
The MB-COME10-1 supports modules compliant to the PICMG™ COM Express™ Module Base Specification (COM.0 R2.1) with
Type 10 pinout.

User's Manual l MB-COME10-1 UM 0101 l © 2016 TQ-Group Page 5
.3 Versions
The MB-COME10-1 carrier is available in two standard configurations.
•MB-COME10-1-AA (“eDP/LVDS”)
Single Front Display Port
eDP/ VDS support (either eDP or VDS can be active at the same time, automatic switchover)
•MB-COME10-1-AB ("Dual DisplayPort")
Dual Front Display Port
No eDP/ VDS support
.4 Accessories
•COMSET-HDD
Mounting Set for 2.5” HDD/SSD on the MB-COME10-1
•RISER-COME-PCIE
Riser for 1 × PCIe; PCIe card is below mainboard
•RISER-COME- × PCIE
Riser for 2 × PCIe; PCIe cards are beside mainboard
•RISER-COME- × PCIE-
Riser for 2 × PCIe; PCIe cards are below mainboard
•DK-USB-TYPA-MOL5
Adapter cable from internal USB connector to an A-Type receptacle
•ADAP-Audio-Kit
Adapter for internal head-phone / microphone connector to dual 3.5 mm audio jack.
Please contact [email protected] for more details about Display Port cables and Display Port to DVI/HDMI adapters.

User's Manual l MB-COME10-1 UM 0101 l © 2016 TQ-Group Page 6
3. FUNCTIONAL SPECIFICATION
3.1 Block Diagram
The following illustration shows the block diagram of the MB-COME10-1:
Illustration 1: Block Diagram MB-COME10-1
3. Electrical Specification
3.2.1 Supply Voltage Characteristics
The MB-COME10-1 requires an input voltage of 12 V DC ±5 %.
The input voltages shall rise from 10 % of nominal to 90 % of nominal within 0.1 ms to 20 ms (0.1 ms ≤ Rise Time ≤ 20 ms).
There must be a smooth and continuous increase of each DC output voltage from 10 % to 90 % of its final set point within the
regulation range.
3.2.2 Power Consumption Specification
The power consumption of the system significantly depends on the connected devices (COM Express™ module, Mass storage
devices, USB devices, display backlight, speakers etc.).
The power consumption of the MB-COME10-1 itself is approximately 190 mA @ 12 V (COM Express™ module supplied externally;
UEFI-shell active; no keyboard, no mouse, no mass storage device, no Ethernet cable etc. connected).
The maximum input current of the MB-COME10-1 is limited to 5 A by a fuse. The devices connected to the carrier should not
exceed 50 W.
Note: Power requirement
The power supply for the MB-COME10-1 must be configured with enough reserve.
It should be calculated with the maximum power of all connected components.

User's Manual l MB-COME10-1 UM 0101 l © 2016 TQ-Group Page 7
3.3 Environmental Specification
•Temperature operating, Extended: –20 °C to +85 °C
•Temperature storage: –40 °C to +85 °C
•Relative humidity (operating / storage): 10 % to 90 % (not condensing)
3.4 System Components
3.4.1 Gigabit Ethernet Controller
The MB-COME10-1 is equipped with an Intel® i210IT Ethernet controller with 10/100/1000 Mbps speed and IEEE1588 support.
Please contact [email protected] for further information about the IEEE1588 support.
3.4.2 DP- VDS Bridge
The MB-COME10-1 is equipped with an NXP PTN3460IBS eDP to VDS bridge. If a display is connected to eDP the eDP to VDS
bridge will be deactivated automatically. There is also an EDID EEPROM on the MB-COME10-1 where display specific data can be
stored.
3.4.3 Dual UART
The MB-COME10-1 is equipped with an EXAR XR28V382 dual UART with its register set is based on the industry standard 16550
UART. The connected serial ports operate with standard serial port drivers.
3.4.4 USB Hub
The MB-COME10-1 is equipped with a Microchip USB2517 with 7 Hi-Speed downstream ports.
3.4.5 HD-Audio Codec
The MB-COME10-1 is equipped with a VIA VT1802P High Definition Audio Codec with a stereo Class D Amplifier with 2 W RMS
output power per channel.
3.4.6 IC Test Devices
The MB-COME10-1 is equipped with an EEPROM and an I/O Expander at the general purpose IC bus (COM Express™ pin names
I2C_DAT and I2C_CK) This devices can be used for software development and debug purposes. Further information can be found
in the chapter Software.

User's Manual l MB-COME10-1 UM 0101 l © 2016 TQ-Group Page 8
3.5 Connectors and Interfaces
Illustration 2: MB-COME10-1, Top
X8
/
X
9:
Gigabit
Ethernet
Reset
Button
X10: Power In
12 V DC
X11: Display
Backlight
X4
/
X
5:
Display Ports
X6: Serial0:
RS232
Power
Button
X7:
USB 2.0/
USB 3.0
X26: USB 2.0
Touch
X17: 12 V Fan
X18: 5 V Fan
X20: Front panel
connector
X15: SIM
card
socket
X13: USB 3.0
Device
X24: Serial1/2:
RS232
X25: Serial3:
RS422
X12: headphone /
microphone
X14: SD card
socket
X1:
COM Express™
connector
Debug EDs
X16
: Riser interface
X23: SMBus
/
IC header
X19: SPI
f
lash
socket
X21: Power
enable jumper
X3:
2x USB 2.0

User's Manual l MB-COME10-1 UM 0101 l © 2016 TQ-Group Page 9
Illustration 3: MB-COME10-1, Bottom
X32:
Display Backlight
X31:
VDS
X29:
Mini PCIe
socket
X30:
eDP (embedded
Display Port)
X36:
2.5“ SATA HDD
X27 / 28:
Speaker out
right and left
X35:
mSATA socket
X16:
Riser interface
X33:
COM Express™
GPIO header
X34:
Smart battery
management
header
IC
Test devices

User's Manual l MB-COME10-1 UM 0101 l © 2016 TQ-Group Page 10
3.5.1 Power Supply
The MB-COME10-1 requires a single 12 V DC power supply. The voltage should not vary more than ±5 %.
X10: Power-In Connector
- Connector type: Phoenix MSTBA 2,5/ 2-G-5,08
- Mating connector: e.g. Phoenix MSTBA 2,5/ 2-ST-5,08
Table 2: Pinout Power-In Connector X10
Pin Signal Remark
1 12 V fused @ 5 A
2 GND
3.5.2 DisplayPort
The MB-COME10-1 supports up to two DisplayPort interfaces. The support of adapters from DP to HDMI, DVI or VGA depends on
the combination of the COM Express™ module and the adapter used. The combination of some modules with some adapters
might not work.
The COM Express™ Specification does not provide signal definitions for the DDI1 port to support dual mode (DP++) passive
adapter to convert the DP to HDMI/DVI. There is a missing select signal (DDI1_DDC_AUX_SE ) to switch between the DP
Aux+/- signals and the HDMI/DVI DDC signals.
The combination of TQMxE38M module and MB-COME10-1 supports the missing DDI1_DDC_AUX_SE signal to the COM
Express™ connector, to solve this limitation.
Table 3: TQ-Specific Feature for DDI1
COM Express™ Signal COM Express™ Pin TQMxE38M / MB-COME10-1 Remark
RSVD9 A86 DDI1_DDC_AUX_SE 3.3 V input
3.5.3 USB Host / Device Interfaces
The MB-COME10-1 supports several USB Hosts and one USB device interface.
X7: Double A-Type (USB3.0) connector for direct usage of USB host ports
Dependent on the configuration USB1 Super Speed lines can be either used for an USB3.0 device or a 2nd USB3.0 Host.
If the COM Express™ module supports USB Super Speed on USB port 0 of COM Express™ connector, USB 3.0 devices are
supported on X7 Top.
If the COM Express™ module supports USB host Super Speed on USB port 1 of COM Express™ connector, MB-COME10-1
can be configured that USB 3.0 devices are supported on X7 Bottom.
X3: Double A-Type (USB2.0) connector for direct usage of USB host ports
X26: USB host extension connector for usage of an USB host port with an adapter cable (e.g. for touch display applications)
- Connector type: Molex 53398-0571
- Mating connector: Molex 51021-0500
Table 4: Pinout USB Host Extension Connector X26
Pin Signal Cable Colour Remark
1 +5 V Red Fused @ 0.9 A
2 D– White –
3 D+ Green –
4 GND Black –
5 GND – –
X13: USB B-Type (USB3.0) connector for direct usage of the COM Express™ module as USB device.
If the COM Express™ module supports USB device on USB port 7 of COM Express™ connector,
the interface can be connected to a USB3.0 Host.
If the COM Express™ module supports USB device Super Speed on USB port 1 of COM Express™ connector,
MB-COME10-1 can be configured that the interface can be connected to a USB3.0 Host.

User's Manual l MB-COME10-1 UM 0101 l © 2016 TQ-Group Page 11
3.5.4 Gigabit Ethernet
The MB-COME10-1 supports 2 common Gigabit Ethernet ports.
The Ethernet signals of the COM Express™ connector are routed to X9.
An Intel® i210IT Ethernet controller with 10/100/1000 Mbps speed implemented on the MB-COME10-1 is connected to X8.
Table 5: Ethernet EDs
Illustration 4: RJ45 Connectors X8, X9
3.5.5 Serial Interfaces (RS232/RS422)
The MB-COME10-1 supports up to 3 serial ports:
- 2 × RS232 port (D-Sub front connector and on-board header)
- 1 × RS422 (on-board header)
The COM Express™ Specification does only provide signal definitions for RX and TX lines for the serial interface. Due to the TQ-
flexiCFG feature the serial ports can be configured to route the handshake signals to free pins on the COM Express connector.
Table 6: Serial Port COM Express™ Port Mapping
COM Express Signal COM Express Pin MB-COME10-1 Remark
SER0_TX A98 SER0_TX 3.3 V input
SER0_RX A99 SER0_RX 3.3 V output
SER1_TX A101 SER1_TX 3.3 V input
SER1_RX A102 SER1_RX 3.3 V output
SER0_RTS# 1 B77 SER0_RTS# 3.3 V input
SER0_CTS# 1 B78 SER0_CTS# 3.3 V output
SER1_RTS# 1 A78 SER1_RTS# 3.3 V input
SER1_CTS# 1 A79 SER1_CTS# 3.3 V output
The four COM Express™ serial signals (RX/TX) are specified to provide a protection and level shifter circuit.
The implementation of this circuit would result in a lower transfer speed on the two serial ports of the COM Express™ module.
On the MB-COME10-1 the protection circuit is removed and the serial ports provide a transfer rate of up to 115 kbaud.
The MB-COME10-1 can only be used in combination with COM Express™ modules Type 10 pinout.
1: These signals are not specified in COM Express™ specification.
These signals are only available when the TQ flexiCFG feature is available on the COM Express™ module. TQMxE38M modules support this feature.
ED Colour/ State Description
eft (ACT) off No link
eft (ACT) yellow on ink (no activity)
eft (ACT) yellow blinking ink and activity
Right (speed) off No link or 10 Mbit/s
Right (speed) green 100 Mbit/s
Right (speed) orange/yellow 1000 Mbit/s

User's Manual l MB-COME10-1 UM 0101 l © 2016 TQ-Group Page 12
Table 7: RS232 D-Sub Connector X6
Illustration 5: RS232 D-SUB Connector X6
Table 8: RS232 Header X24
Illustration 6: RS232 Header X24
Table 9: RS422 Header X25
Illustration 7: RS422 Header X25
2: Not available since signal is not defined in COM Express™ specification.
3: Only available when the TQ flexiCFG feature is available on the COM Express™ module.
Pin RS232 Signal
(all signals) MB-COME10-1
1 DCD NC 2
2 RXD RXD
3 TXD TXD
4 DTR NC 2
5 GND GND
6 DSR NC 2
7 RTS RTS 3
8 CTS CTS 3
9 RI NC 2
Pin RS232 Signal
(all signals) MB-COME10-1 D-Sub connector (with standard adapter)
1 DCD NC 2 –
2 DSR NC 2 RXD
3 RXD RXD TXD
4 RTS RTS 3 –
5 TXD TXD GND
6 CTS CTS 3 –
7 DTR NC 2 RTS
8 RI NC 2 CTS
9 GND GND –
10 NC NC –
Pin MB-COME10-1 D-Sub connector
(with standard adapter)
1 NC –
2 NC RS422 RX–
3 RS422 RX– RS422 TX+
4 RS422 TX– –
5 RS422 TX+ GND
6 RS422 RX+ –
7 NC RS422 TX–
8 NC RS422 RX+
9 GND –
10 NC –

User's Manual l MB-COME10-1 UM 0101 l © 2016 TQ-Group Page 13
3.5.6 Embedded Display Port
The MB-COME10-1 supports an embedded DisplayPort (eDP) interface where suitable displays can be connected directly. This
functionality is only available for the eDP/ VDS variant.
Either eDP or VDS can be used at the same time. VDS is only working if there is no display connected to the eDP interface.
X30: eDP connector
- Connector type: JAE HD1S040HA1
- Mating connector: e.g. JAE HD1P040MA1
Table 10: eDP Connector X30
Illustration 8: eDP Connector X30
Pin Signal Remark
1 NC
2 GND
3 TX3–
4 TX3+ ane 3 differential pair
5 GND
6 TX2–
7 TX2+ ane 2 differential pair
8 GND
9 TX1–
10 TX1+ ane 1 differential pair
11 GND
12 TX0–
13 TX0+ ane 0 differential pair
14 GND
15 AUX+
16 AUX– AUX - channel
17 GND
18 3V3
19 3V3
20 3V3
21 3V3
3.3 V supply voltage
22 NC
23 GND
24 GND
25 GND
26 GND
27 HPD Hot Plug Detect
28 GND
29 GND
30 GND
31 GND
32 B KT_EN Backlight enable
33 B KT_CTR Backlight (brightness) control
34 VDD_EN Panel power enable
35 AUX_SE ow  AUX; High  IC
36 V_B KT
37 V_B KT
38 V_B KT
39 V_B KT
12 V Backlight supply voltage
40 NC

User's Manual l MB-COME10-1 UM 0101 l © 2016 TQ-Group Page 14
3.5.7 VDS
The MB-COME10-1 supports an embedded DisplayPort (eDP) and an VDS interface where suitable displays can be connected
directly. This functionality is only available for the eDP/ VDS variant.
Either eDP or VDS can be used at the same time. VDS is only working if there is no display connected to the eDP interface.
There are also connectors for powering the backlight of the connected display.
The MB-COME10-1 has an on-board EDID EEPROM to store display specific timing information. This EEPROM can be programmed
with an external IC programmer. If the programmer supports a 3.3 V output voltage the MB-COME10-1 can be programmed
without any additional power supply. In this case no COM Express™ module should be connected to the carrier.
X31: VDS connector
- Connector type: Hirose DF19G-30P-1H
- Mating connector: e.g. Hirose DF19-30S-1C
Table 11: VDS Connector X31
Illustration 9: VDS Connector X31
Pin Signal Remark
1 A0– Odd bus
2 A0+ Odd bus
3 A1– Odd bus
4 A1+ Odd bus
5 A2– Odd bus
6 A2+ Odd bus
7 GND
8 AC K– Odd bus
9 AC K+ Odd bus
10 A3– Odd bus
11 A3+ Odd bus
12 B0– Even bus
13 B0+ Even bus
14 GND
15 B1– Even bus
16 B1+ Even bus
17 GND
18 B2– Even bus
19 B2+ Even bus
20 BC K– Even bus
21 BC K+ Even bus
22 B3– Even bus
23 B3+ Even bus
24 GND
25 5V_PANE
26 5V_PANE
27 5V_PANE
5 V Panel supply voltage
28 3V3_PANE
29 3V3_PANE
30 3V3_PANE
3.3 V Panel supply voltage
