Tranberg STAHL TEF 2457 User manual

Installation and operating manual
TEF 2457 Luminaire, watertight
Installation Manual
TEF 2457 Luminaire, Watertight
Safe Area
Document properties (TUM1011)
Revision
Comment
Revision date
Approved
-
First issue
-
***
A
Minor changes
17.07.2017
-
B
Removed 230V AC
25.06.2015
-
C
Removed lampholder B15d
11.05.2022
CKR
.

Installation and operating manual
TEF 2457 Luminaire, watertight
Installation and operating manual
Contents
Document properties (TUM1011) ............................................................................................................................ 1
Warnings and risk levels.......................................................................................................................................... 3
General information................................................................................................................................................. 3
Marking and intended use ....................................................................................................................................... 3
Technical data ......................................................................................................................................................... 4
Product description.................................................................................................................................................. 4
Transport and storage ............................................................................................................................................. 4
Safety precautions................................................................................................................................................... 4
Mounting and installation......................................................................................................................................... 5
Mounting ............................................................................................................................................................. 5
Electrical connections ......................................................................................................................................... 6
Maintenance and cleaning....................................................................................................................................... 6
Disposal................................................................................................................................................................... 6

Installation and operating manual
TEF 2457 Luminaire, watertight
Warnings and risk levels
DANGER
Non-compliance with the instruction results in risk of severe or fatal injuries to persons
WARNING
Non-compliance with the instruction may result in risk of severe or fatal injuries to persons
CAUTION
Non-compliance with the instruction may result in risk of injuries or damage to equipment
NOTICE
Non-compliance with the instruction may result in reduced lifetime of equipment, malfunctions etc.
General information
Before installation, make sure to read and understand this installation and operating manual.
Observe national assembly and installation regulations.
Always contact the manufacturer if anything is unclear, or if you notice any faults on the product or in this
document.
This installation and operating manual shall be available to anyone operating, installing, inspecting, modifying or
repairing the equipment.
Marking and intended use
CAUTION
Not intended for use in “these” conditions (Where mud may be present, on helidecks, underground, direct
sunlight, heavy vibrations, high risk of impact, harsh cleaning agents, high pressure washer etc.)
For use in Safe Areas

Installation and operating manual
TEF 2457 Luminaire, watertight
Technical data
Property
Value
Value
Input voltage
12V
24V
Ingress protection
IP56
Power consumption
Max. 25 Watt, dependent on light source
Weight
0,65 kg
Terminals
Screw terminals, 1-4mm²
Entries/Cable glands
1 x M20 Cable gland
2 x M20 stopping plug
Housing material
Cast brass
Other materials
Polycarbonate lexan
Product description
TEF 2457 is a luminaire to be used for various applications such as deck light, signal light, emergency light, life
boat light. It is intended for use I safe areas. The luminaire has a rugged and low profile is simple to install and
maintain. It is resistant to vibrations and salt-laden atmospheres. Tested according to IEC 60945:1996.
Transport and storage
•Transport and store the equipment only in the original packaging
•Store the equipment in a dry and vibration free place
•Do not drop!
Safety precautions
Note that changes made to the product and/or installation of components, which do not conform to the approval,
may be a safety violation. The manufacturer is in no circumstance responsible for such activity.
For your health and safety, always use safety gear suited for the task. Be certain to follow codes, regulations
and/or specific procedures related to the installation.

Installation and operating manual
TEF 2457 Luminaire, watertight
Mounting and installation
DANGER
Incorrect mounting and installation may lead to risk for falling objects, risk for electric shock or fire and risk for
equipment malfunction. In turn, this can lead to severe damage and/or injuries.
Mounting
Tools required for installation:
10 mm wrench - for assemble the luminaire.
3,5 mm flat screwdriver - for connecting the electricity on G-4
PH1 and 5,5 mm flat screwdriver –for connecting electricity on E27.
5,5 mm flat screwdriver –for tightening the globe and earth screw.
21 mm wrench –for tightening the pressure nut on the cable gland.
The lamp can be installed in any direction, but it is recommended that the cable glands face downwards.
Replace the cable gland gasket as required to match the cable diameter. Always replace any unused cable glands
with a blind plug.
When replacing the globe, take care not to overtighten the screws, while tightening them bit by bit.
Be sure to install the cable in a way, which prevents water to penetrate into the enclosure through the
cable gland
Mounting dimensions:

Installation and operating manual
TEF 2457 Luminaire, watertight
Electrical connections
Cable entries: 1xM20 cable gland, cable diameter 8-13mm and 1xM20 stopping plug.
Maintenance and cleaning
Inspection of the luminaire according to Company routines. The manufacturer suggests regular check for water
intrusion/condensation. If any water is inside the lamp, remove it immediately. Clean only with a damp cloth,
water and mild detergents. Avoid chemicals with high or low pH, abrasives, high pressure washer, strong
detergents, solvents, petroleum- or alcohol based cleaning agents and similar. Avoid any corrosive media.
Disposal
CAUTION
This equipment or part of this equipment is considered EE-Waste, and shall be handled accordingly
•Observe national and local regulations and statutory regulations regarding disposal
•Separate materials when sending it for recycling
•Ensure environmentally friendly disposal of all components
•No component or packaging shall end up in the ocean during any stage of the product’s lifetime
