TEF 2460 LED
PERIMETER LIGHT
LUMINAIRE ZONE 1 & 2
USER MANUAL
IMPORTANT
Read this instruction carefully before installing the
product
TUM 4524 REV. B 04.05.2016

TEF 2460 LED LUMINAIRE USER MANUAL
INTRODUCTION
Thank you for purchasing this product!
For installation, maintenance and assurance of a long life
of this product, please follow this manual.
CONTENT IN BOX
The product is fully assembled, and ready for installation.
TOOLS REQUIRED
Regular tools required for installation.
• Tools for mounting, e.g. 10 mm wrench – to fasten the
mounting bracket to the deck.
• 4 mm hexagon key (Unbraco/Allen key) for mounting
the top to the termination compartment, and for the ex-
ternal bonding connection. A long key, >80mm is rec-
ommended for easy installation.
• 3 mm hexagon key (Unbraco/Allen key) to loosen the
screws for the terminal assembly, if necessary.
• 32mm wrench to disassemble the blind plug and as-
semble the cable gland.
• Wrench for tightening the pressure nut on the cable
gland(s).
Do not use powertools when fastening globe!
SAFETY PRECAUTIONS
Note that changes to the product and /or installation of
components which do not conform to the approval, may
be a safety violation. The manufacturer will inn no cir-
cumstance be held responsible for such activity. For your
health and safety, always use safety gear suited for the
task. Be certain to follow codes, regulations and /or spe-
cific procedures that are related to the installation.
MAINTENANCE INSTRUCTIONS
The luminaire should be inspected according to Company
routines. The manufacturer suggests regular check for wa-
ter intrusion in the termination compartment. Due to the sili-
cone potting compound used in this product, some silicone
oil may condense on the inside of the glass. All electronics
are sealed, so this will have no technical concern.
When cleaning, use only mild detergents. Alcohol or petro-
leum based products may damage the gaskets.
APPLICATIONS
• Perimeter lights on helideck.
Green or red/green light (24V DC only).
• Zone 1, zone 2 and safe area
APPROVALS
IECEx / ATEX CERTIFIED
Ex e mb op is IIC T5 Gb
According to:
EN 60079-0:2012
EN 60079-7:2007
EN 60079-18:2009
EN 60079-28:2007
IEC 60079-0:2011
IEC 60079-7:2006
IEC 60079-18:2009
IEC 60079-28:2006
CE 0470

TEF 2460 LED LUMINAIRE USER MANUAL
INSTALLATION INSTRUCTIONS
Only qualified personnel are allowed to perform installation
and maintenance tasks to this product.
The equipment is ready for installation when leaving the
production facilities of Tranberg AS. Check the condition of
the equipment and the contents when unpacking. Any dam-
age done to the equipment during transportation is not the
responsibility of Tranberg AS. If the content is not complete,
file a claim to the manufacturer immediately.
The TEF 2460 is delivered with several mounting options.
A mounting bracket for flat surfaces is standard. For the
light output to be in accordance with any regulations listed
in this document, the perimeter light is to be mounted on a
horizontal surface coincident with the helideck.
The luminaire must always be installed in an upright posi-
tion. Any other mounting positions should not be used for
permanent installation, without a confirmation from Tran-
berg’s technical department. If the luminaire is mounted on
a vessel or a floating installation, movements such as roll
and pitch which moves the luminaire out of its original up-
right position, is not taken into account.
When mounting the top to the connection compartment,
make sure no cables or the safety wire are jammed between
the two parts. This will dramatically reduce the ingress pro-
tection, and impair the mode of protection regarding haz-
ardous areas. When mounted, there shall be no noticeable
gap between the top and the connection compartment. If
a gap is present after the screws are tightened, lift the top,
turn it 90° to help the cables and wires connecting the two
parts to form a coil and try again.
Not following these instructions may lead to a risk of water
ingress into the luminaire. The manufacturer assumes no
responsibility when these guidelines are not followed.
The terminals in this luminaire consist of a terminal block for
phase conductors and PE. Two M5 PE screws are fitted to
accept PE cables larger than 4mm2.
The terminal block is of the “Cage clamp” type, and there
is no need for a tool to connect or disconnect the phase
conductors. Nevertheless a large screwdriver, preferably
flathead, may be of good help.
Make sure to use IECEx /ATEX approved cable glands (IEC
60079-0:2007, IEC 60079-0:2009), approved for the spe-
cific cable diameter and type. These data can be found in
the cable gland datasheet.
Any damage caused by the use of an incorrect combination
of cable and cable gland is not the responsibility of Tranberg
AS and is not covered by warranty.
When used in areas under NEC regulations, an earth conti-
nuity test shall be performed after installation.
000A108346
The mounting bracket can be turned 90°

Tranberg AS | P.O. Box 8033 | N-4068 Stavanger | Norway | Tel.: [phone] | Fax.: [phone]
E-mail: [email protected] | www.tranberg.com
Tranberg Systems | Hjulmagervej 15C | 7100 Vejle | Denmark | Tel.: [phone]
E-mail: [email protected] | www.tranbergsystems.com
TEF 2460 LED LUMINAIRE USER MANUAL
TECHNICAL DATA
Material: Hot-forged and machined brass, Glass dome
Power consumtion: < 10 W
Input voltage: 100-254V AC 45-65Hz or 24V DC +/-30% depending on model
Permitted supply 50 A @ 24VDC +/- 30%
short-circuit current: 1500A @ 100-254V AC 45-65Hz
Expected lifetime: To be within specified light output for >50 000 h
Weight: 4 kg
IP rating: IP 66. (IP 67 without drain plug, according to IEC 60529)
Cable entries: 2 PCS. M25 x 1.5 entries for IECEx / ATEX approved cable glands
according to IEC 60079-0:2007, IEC 60079-0:2009. Delivered with
Tranberg cable glands.
Ex classification: Ex e mb op is IIC T5 Gb
Ex certificate no.: IECEx Pre 14.0009
Presafe 14ATEX4571
CE marking: CE 0470
Tamb: -55°C to +55°C
Manufacturer: Tranberg AS
SPARE PARTS
Description Part No.
Glass dome 50480032
Cable gland ATEX / IECEx Acc. to cable dim.
