TRENDnet TEW-310APBX User manual

TRENDnet’s TEW-310APBX WirelessAccess Point is today’s
link to Wireless Technology. Compliant with the most
advanced IEEE Wireless Networking Standard 802.11b, it
provides Direct Sequence Spread Spectrum (DSSS)
operation for transparent bridging and roaming capabilities for
wireless nodes. The TEW-310APBX also provides AP-to-AP
bridging functions, allowing users to connect two or more
Access Points together, wirelessly. With TRENDnet’s
Wireless Access Point and Wireless Network Adapters, users
can connect to Ethernet/Fast Ethernet LAN at home or office
to access network resources such as hard drives, CD-
ROM/DVD drives, network printers, and Internet connection -
with coverage up to 300 meters.
TEW-310APBX
11/22Mbps Wireless Access Point + Bridge (with detachable Antennas)
BENEFITSFEATURES
Operates as Access Point, Wireless Bridge, or Access Point
Client
Uses 2.4GHz frequency band, which complies with worldwide
requirement
Direct Sequence Spread Spectrum (DSSS) wireless technology
Provides data rate bandwidth up to 22Mbps with automatic
fallback
Provides 64/128/256-bit Wired Equivalent Privacy (WEP)
encryption
Easy configuration with Web Browser and Windows
Configuration Software
Access Control with wireless client’s MAC Address
Detachable 2dBi Dual Dipole Antennas. Replace either one with
optional high gain antenna to extend the range/coverage area.
DHCP Server supports up to 100 clients
10/100Mbps auto-sense Fast Ethernet port
Wall-Mountable
Distance coverage 35 to100 meters indoor, 100 to 300 meters
outdoors
3-Year Warranty
Integration Friendly:
Economical:
Flexible:
Security:
Cost Effective:
Supports both Ethernet and Fast
Ethernet, with Web Browser
configuration for fast and easy setup.
Attaches to Ethernet network at
anytime to add wireless users on the
network. Save time, labor, and
material for network cable installation.
Works as stand-alone Access Point,
Single/Multiple Access Point(s)
Bridge, or Ethernet Access Point
Client.
Provides 64/128/256-bit WEP
Encryption and MAC address access
control.
One unit provides multiple wireless
connections to wired LAN.
TEW-310APBX (03-25-2002)
TRENDnet
TRENDware, USA
What's Next in Networking

PRODUCT INFORMATION
To Order Please Call:
1-888-326-6061
SPECIFICATIONS
NETWORKING SOLUTIONS
TEW-310APBX
11/22Mbps Wireless Access Point + Bridge (with detachable Antennas)
TEW-310APBX
11/22Mbps Wireless Access Point + Bridge (with detachable Antennas)
Wireless LAN Interface
Standards:
• IEEE 802.11b Wireless LAN
Modulation Technology:
• Direct Sequence Spread Spectrum (DSSS),
PBCC (Packet Binary Convolutional Coding),
11-chip Barker Sequence
Channels:
• 11 Channels (US & Canada)
Data Rate:
• 22Mbps, 11Mbps, 5.5Mbps, 2Mbps,
and 1Mbps (auto-fallback)
Operating Mode:
• AP, AP-to-AP, AP-to-Multiple AP,
or AP Client
Frequency Range:
• 2.4 ~ 2.4835 GHz
Security:
• 64/128/256-bit WEP Encryption
Antenna:
• 2 x 2dBi Detachable Dipole Antenna with
female Reverse SMA connector
(90° elbow, length = 137 mm / 5.39 inches)
Output Power:
• 16 ~ 18 dBm (max.)
Receiving Sensitivity:
• - 82 dBm (Typical)
Wired LAN Interface
Standards:
• IEEE 802.3 (10Base-T) and
IEEE 802.3u (100Base-TX)
Data Rate Transmission:
• 10/100Mbps, Half/Full duplex
auto-negotiation
Media Connector:
• 1 x UTP/STP RJ-45
Cabling:
• Cat. 5 UTP/STP RJ-45 Cable
(100 meters max.)
LED Indicators:
• Power, TX/RX, Link
Power:
• External Power Adapter,
Input: 100~240VAC, 1A, 50~60Hz.
Output: 5VDC, 2A
Dimensions:
• 140 x 113 x 38 mm
(5.51 x 4.45 x 1.5 inches) (antenna folded)
Weight:
• 213 g. (7.5 Oz.)
Temperature:
• Operating: -10° ~ 55°C (14°F ~ 131°F)
• Storage: -20° ~ 65°C (-4°F ~ 149°F)
Humidity:
• Max. 95% (non-condensing)
Certification:
• CE, FCC Class B
TEW-310APBX: 11/22Mbps Wireless Access Point + Bridge
(with detachable antennas)
TEW-310APB: 11/22Mbps Wireless Access Point + Bridge
TEW-311BRP: 11/22Mbps Wireless AP Router with 4-Port Switch
TEW-PS3: 3-port Wireless Ethernet Print Server
TEW-IA04O: 4dBi Omni Antenna (indoor) for IEEE 802.11b
2.4GHz ISM Band
TEW-IA06D: 6dBi Directional Antenna (indoor) for IEEE 802.11b
2.4GHz ISM Band
TEW-OA14DK: 14dBi Directional Antenna (outdoor) for IEEE 802.11b 2.4
GHz ISM Band with Mounting Hardware and 2 Meters Antenna Cable
(TEW-2000F; Female N-Type to Female Reverse SMA Connector)
