Trinity TLS-4804 User manual

TRINITY 56” ROLLING WORKBENCH – STAINLESS STEEL
Model # TLS-4804 (Stainless Body)
TLS-4805 (Black Body)
OWNER’S MANUAL
Everything in its place.®

Your TRINITY 56in Stainless Steel Workbench should include the following parts. Please
inspect box contents to ensure you have received all components.
If you are missing any parts, need assistance with assembly or have questions, please contact
TRINITY Customer Service: 800.985.5506 or [e-mail]. Parts can also be
requested online via our “Contact Us” section at www.trinityii.com.
You will need 10mm wrench (for handles) and 14mm wrench (for casters) for assembly. Not
included.
PARTS LIST
A
SIDE HANDLE (2)
B C
CASTER BOLT (16)
M10
D
LINER (7)
E
GH
HANDLE BOLT (12)
M6
LOCKING
CASTER (2)
F
NON-LOCKING
CASTER (2)
KEY (2)
© 2016 TRINITY - 800.985.5506
1
WORKBENCH (1)
I
SHELF (1)

ASSEMBLY INSTRUCTIONS
Position SIDE HANDLE (B) over pre-installed
nuts on the side of WORKBENCH (A). Insert
HANDLE BOLTS (C) through holes on SIDE
HANDLE (B). Use a 10mm wrench to tighten
HANDLE BOLTS (C) to WORKBENCH (A).
Repeat these instructions to install the other
SIDE HANDLE (B).
AB
C
© 2016 TRINITY - 800.985.5506 2
STEP 1
STEP 2
10mm
A (1) B (2) C (12)
Location of parts:
1) HANDLES (B) / FASTENERS (C/F) /
CASTER (D/E) / LINERS (G) / KEYS
(H) are all in accessory boxes inside
the lowest drawer. KEYS (H) are
taped outside the caster box.
NOTE: Drawer lock and cabinet
lock use different keys, please
match code on lock to the code
on the key
2) SHELF (I) is upside down at the
bottom inside the cabinet.
12

ASSEMBLY INSTRUCTIONS
© 2016 TRINITY - 800.985.5506
3
STEP 3
D (2) E (2) F (16)
Lay WORKBENCH (A) on its backside. Two
people are needed. Do NOT attempt this alone.
Position LOCKING CASTERS (D) on the side of
the WORKBENCH (A) of your choice and align
holes to pre-installed nuts on the underside of
WORKBENCH (A). Use a 14mm socket wrench
to fully tighten CASTER BOLT (F) to
WORKBENCH (A).
Repeat above step to install the NON-LOCKING
CASTERS (E).
Notes:
* Make sure to install both of the LOCKING
CASTERS (D) on the same side.
** For ease of use, place LOCKING CASTERS
(D) on the side you will regularly push or pull.
*** If you plan to push the Tool Chest against a
wall, place LOCKING CASTERS (D) on the front
long side for ease of access.
14mm
A
Carefully lift Workbench upright. Two people
are needed. Do NOT attempt this alone.
SHELF (I) is shipped upside down at the
bottom inside the cabinet. Tilt SHELF (I)
diagonally and remove from the cabinet. Flip
it over so the flat surface faces up and make
sure the tabs are on 2 sides.
Tilt SHELF (I) diagonally to move it to the
desired position. Once at the desired height,
secure SHELF (I) by pushing down on all 4
corners until SHELF (I) engages fully with the
tabs.
I (1)
STEP 4
ED
F
I
Position Tab

ASSEMBLY INSTRUCTIONS
STEP 5
Simply place LINERS (G) in each drawer
and on each shelf. G (7)
G
© 2016 TRINITY - 800.985.5506 4

USAGE INSTRUCTIONS
DRAWER REMOVAL
DRAWER REPLACEMENT
Pull the drawer out so that it is almost fully extended. On the RIGHT-hand side, push the black
release lever DOWN. On the LEFT-hand side, pull the black release lever UP. While holding
the levers as instructed, pull the drawer forward until released from the slides attached to the
Workbench (“Workbench Slides”).
Note: The slides attached to the drawer (“Drawer Slides”) are an integral part of the drawer and
must be removed along with the drawer itself.
To replace the drawer, pull the slides out completely. Insert the brackets on each side of the
Drawer Slides into the corresponding slots on the Workbench Slides, making sure they are
properly positioned. Once the brackets are inserted into the slots, completely close the drawer
to set all slides in their proper positions.
© 2016 TRINITY - 800.985.5506
5

SERVICE PARTS LIST –TLS-4804 / TLS-4805
Part Number Description Part Number Description
1) PBK-03-001-1617 Inner Shelf 11) XBK-22-001-3316 Drawer Liner
2) LNA-06-001-5619 Wood Top 12) XBK-22-001-1617 Shelf Liner
3) ZSV-01-001-0612 Handle Bolt 13) ZSV-99-002-5020 Non-locking Caster
4) XSV-05-001-0900 Side Handle 14) XBS-07-001-3511 Large Drawer
5) AMA-05-002-2350 Door Handle 15) XBS-07-001-3505 Medium Drawer
6) XBS-08-001-1726 Door 16) XBK-23-001-2505 End Cap
7) ZSV-12-002-1575 Slide (workbench side) 17) AMA-05-002-3325 Drawer Handle
8) ZSV-12-001-1575 Slide (drawer side) 18) XBS-07-001-3503 Small Drawer
9) ZSV-01-001-1020 Caster Bolt 19) CSV-11-001-0XXX Lock
10) ZSV-99-001-5020 Locking Caster 20) XBK-10-001-0XXX Key
TRINITY Customer Service provides the following replacement parts:
5
2
6
3
8
7
1
4
11
12
15
16
13
10
17
14
18
NOTE: Replacement keys may be ordered using the code shown on the face of
the lock. The Drawer and Door Lock may have different key codes.
9
19
20
© 2016 TRINITY - 800.985.5506 6

WARNINGS
1. Read and understand all instructions. Failure to follow all instructions may
result in injury and/or damage.
2. The warnings, cautions, and instructions discussed in this manual cannot
cover all possible conditions or situations that may occur. The user must
always be aware of their environment and ensure that they use the product in a
safe and responsible manner.
3. Use the appropriate wrenches to tighten casters completely. Failure to do as
instructed could result in the caster stem(s) to break thereby causing the
workbench to collapse.
4. Do NOT modify the product in any way. Unauthorized modification may impair
the function and/or safety of the product, and may affect the life of the product.
5. Check for damaged parts. Before using this product, carefully check that all parts
are in good condition, and that the product will operate properly and perform its
intended function. Check for damaged parts and any other conditions that may
affect the operation of this product. Replace damaged or worn parts, and never
use this product with a damaged part.
6. Do NOT overload the product.
7. Lock the casters when leaving workbench in stationary position.
8. Lock the drawers and door before moving the workbench.
9. Do NOT open more than one drawer at a time. Tipping can occur.
10. Do NOT step on open drawers.
11. Do NOT let children play near workbench.
Weight capacity per drawer 100 lb
Weight capacity per shelf 75 lb
Total weight capacity of tool chest 2200 lb
© 2016 TRINITY - 800.985.5506
7

© 2016 TRINITY - 800.985.5506 8
CARE AND MAINTENANCE
•Avoid harsh, abrasive cleaners, and other corrosive chemicals.
•Do not use scouring pad for cleaning.
•Keep dry and avoid damp environments.
•Use a quality stainless steel cleaner and follow instructions that come with the
cleaner. WipeALONG the grain (NOT against).
•Wood top can be cleaned with damp cloth and wiped dry immediately with dry cloth.
If needed, solvent-based wood furniture cleaner can be used.
•Clean up any spills immediately to prevent stains from forming on the wood top.

© 2016 TRINITY - 800.985.5506
9
