Trinity TBFPRA-2706 User manual

OWNER’S MANUAL
TRINITY 30" X 20" X 72” BAMBOO GARMENT RACK
- BRONZE ANTHRACITE
Model # TBFPRA-2706

© 2018 TRINITY - 800.985.5506 1
Your TRINITY 30" x 20" x 72” Bamboo Garment Rack should include the following parts. Please inspect
box contents to ensure you have received all components.
If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY
Customer Service: 800.985.5506 or [email protected]om. Parts can also be requested online at
www.trinityii.com (Help & More, Contact Us).
ABC
HANGING ROD (3)
FIXED SHELF (2)TOP SIDE
FRAME (2)
BOTTOM SIDE
FRAME (2)
PARTS LIST
D
SCREW (14) FRAME CONNECTING
SCREW (4)
FEET
LEVELER (4)
HEX KEY (1)
G
E F
H
ANTI-TIPPING
KIT (2)
I

STEP 2
Screw FEET LEVELERS (G) into the bottoms
of each BOTTOM SIDE FRAME (B). Turn
clockwise to screw in place.
G (4)B (2)
F (4) H (1)
Connect TOP SIDE FRAME (A) with BOTTOM
SIDE FRAME (B). Using the included HEX
KEY (H), screw 1 FRAME CONNECTING
SCREW (F) into each hole where BOTTOM
SIDE FRAME (B) is connected with TOP SIDE
FRAME (A). Repeat for remaining FRAME
CONNECTING SCREWS (F).
ASSEMBLY INSTRUCTIONS
STEP 1
B
B (2)
A (2)
B
A
FH
G
© 2018 TRINITY - 800.985.5506
2

© 2018 TRINITY - 800.985.5506 3
STEP 4
Place FIXED SHELVES (C) on their sides and connect
them to TOP & BOTTOM SIDE FRAMES (A & B)
assembled at STEP 2, fasten SCREWS (E) into frame
screw holes by HEX KEY (H).
Stand the unit upright.
Place 1 HANGING ROD (D) between
2 hanger sticks on TOP SIDE FRAME
(A), fasten SCEWS (E) into screw
holes by HEX KEY (H).
Place 1 HANGING ROD (D) on ¼ of
frame height from shelf top, fasten
SCEWS (E) into screw holes by HEX
KEY (H).
Place 1 HANGING ROD (D) on ¼ of
frame height from shelf bottom,
fasten SCEWS (E) into screw holes
by HEX KEY (H).
ASSEMBLY INSTRUCTIONS
STEP 3
E (8) H (1)C (2)
E (6) H (1)D (3)
D
D
D
CC
H
EE
H
E
B
A

© 2018 TRINITY - 800.985.5506
4
ASSEMBLY INSTRUCTIONS
STEP 5
I (2)
To install the ANTI-TIPPING KIT (I), place
BAMBOO GARMENT RACK against the wall.
Mount bracket to the wall, next to outer TOP
SIDE FRAME (A) just below the top FIXED
SHELF (C).
First, fully secure ANTI-TIPPING KIT (I) to the
wall.
Next, close cable loop through TOP SIDE
FRAME (A) as shown. Wall
I
C
AA

© 2018 TRINITY - 800.985.5506 5
PRODUCT EXTRA SHELF OPTIONS
There are extra screw holes in this product for more ADJUSTABLE SHELVES. You will need 1
ADJUSTABLE SHELF and 4 ADJUSTABLE SHELF RESTS to add one extra shelf to the product.
Extra ADJUSTABLE SHELF (PRA-03-046-2820) and ADJUSTABLE SHELF REST (ZBK-01-031-0620) are
available for purchasing. Please visit our website www.trinityii.com or contact our Customer Service
(see last page of the manual) to place your order.
ADJUSTABLE
SHELF REST (4)
ADJUSTABLE SHELF (1)
+
PRA-03-046-2820
ZBK-01-031-0620

© 2018 TRINITY - 800.985.5506
6
SERVICE PARTS LIST –TBFPRA-2706
TRINITY Customer Service provides the following replacement parts:
3
8
4
5
2
7
6
1
Part Number Description Part Number Description
1)
XSV
-02-011-0007
Anti
-tipping kit 6)
ZBK
-01-002-0635
Screw
2)
PRA
-14-021-2036
Top Side Frame
7)
PRA
-13-007-2850
Hanging Rod
3)
ZBK
-01-002-0615
Frame Connecting Screw
8)
PRA
-03-045-2820
Fixed Shelf
4)
PRA
-14-022-2036
Bottom Side Frame
9)
XXX
-97-001-0001
Hex Key
5)
XBK
-98-006-2525
Feet Leveler
9

© 2018 TRINITY - 800.985.5506 7
1. Read and understand all instructions. Failure to follow all instructions may result in injury
and/or damage.
2. Use the provided anti-tipping kits to secure the product to the wall to prevent the
product from tipping over.
3. The warnings, cautions, and instructions discussed in this manual cannot cover all
possible conditions or situations that may occur. The user must always be aware of their
environment and ensure that they use the product in a safe and responsible manner.
4. Do NOT modify the product in any way. Unauthorized modification may impair the
function and/or safety of the product, and may affect the life of the product.
5. Check for damaged parts.Before using this product, carefully check that all parts are in
good condition, and that the product will operate properly and perform its intended
function. Check for damaged parts and any other conditions that may affect the operation
of this product. Replace damaged or worn parts, and never use this product with a damaged
part.
6. Do NOT overload the product.
7. Do NOT allow children to climb or play around the product.
WARNINGS
CARE AND MAINTENANCE
Weight capacity of Hanging Rod (evenly distributed) 50 lb
Weight capacity per shelf (evenly distributed) 75 lb
•Bamboo can be maintained with mineral oil for best results.
•Avoid harsh, abrasive cleaners, and other corrosive chemicals.
•The product is designed for indoor use. Wipe dry and keep out of direct sunlight.

© 2018 TRINITY - 800.985.5506
8
Thank you for purchasing a TRINITY 30" x 20" x 72” Bamboo Garment Rack. In order to register your
product and receive streamlined customer service, please fill out the following Product Registration
Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at
www.trinityii.com or (3) scan and email the form to [e-mail]. Include a copy of
your original receipt with your submission.
First Name: Last Name:
Address:
City: State: Zip Code:
Email Address: Phone:
Product Model #: TBFPRA-2706 Purchase Date: / /
Location of Purchase:
Please rate the importance of each feature (1=least important; 10=most important)
Quality Price Size/Capacity Appearance Other
How did you hear about our product?
Magazine Ad Catalog Salesperson Word of Mouth
Internet Store Display Other
Marital Status: Single Married
Household Income: Below $50,000 $50,000-$150,000 $150,000+
Education: High School College Graduate School
Primary Residence: Own Rent
Comments/Suggestions:
PRODUCT REGISTRATION
