Trinity ECOSTORAGE TBFZ-0908 User manual

OWNER’S MANUAL
TRINITY ECOSTORAGE™4-TIER NSF WINE RACK
Model # TBFZ-0908
Important / Important / Importante
FOR QUICK & EASY 3D ASSEMBLY INSTRUCTIONS
POUR DES DIRECTIVES D’ASSEMBLAGE 3D RAPIDES ET FACILES
PARA INSTRUCCIONES DE ENSAMBLAJE RÁPIDAS Y SENCILLAS EN 3D
Intelligent Instructions
Directives intelligentes
Instrucciones Inteligentes
DOWNLOAD THE FREEAPP | TÉLÉCHARGERL’APPLICATION GRATUITE| DESCARGUE LA APLICACIÓN GRATUITA

PARTS LIST
Your TRINITY EcoStorage™4-Tier Wine Rack should include the following parts. Please inspect box
contents to ensure you have received all components.
If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY
Customer Service: 800.985.5506 or [e-mail]. Parts can also be requested online
via “Contact Us” section at www.trinityii.com.
You will NOT need additional tools for assembly.
A
POLE (4)
End Cap (4), Threaded
Insert (4) and Feet
Leveler (4) pre-installed
B
SHELF (4)
C
SLIP SLEEVE
(32) + (2) extra
D
POLE CONNECTOR (4)
Only use when connecting another unit
to make 8-Tier Wine Rack
Note: The black circular plastic spacers in between Shelves are used only for packaging
purposes. They are NOT needed. Please discard.
1© 2022 TRINITY - 800.985.5506

ASSEMBLY INSTRUCTIONS
STEP 1
Note that each POLE (A) has slight horizontal line
indentations at 1” intervals. Each SLIP SLEEVE (C) has raised
horizontal lines inside designed to lock them in place on
POLE (A).
On POLE (A), place one pair of SLIP SLEEVES (C) at desired
height no higher than 3rd indentation from bottom. Please
make sure arrow faces up and word “TOP” is right side up.
Slide pair of SLIP SLEEVES (C) until you hear a click to confirm
the pair is locked onto POLE (A). Do this for each POLE (A)
and make sure height is identical for each POLE (A). Do NOT
place more than one pair on each pole at a time.
Note: There will be a very small gap in-between two locked SLIP SLEEVES (C)—this is normal.
STEP 2
Place SHELF (B) on its side and slide each POLE (A) through each
corner cylinder on the SHELF (B). Make sure SHELF (B) corner
cylinders are positioned over SLIP SLEEVES (C).
Stand the unit upright.
Note:
•Level side of SHELF (B) is TOP side (TRINITY logo on corner
cylinders should be right-side up.)
•Use a rubber mallet, if needed, to secure SHELF (B).
© 2022 TRINITY - 800.985.5506 2

ASSEMBLY INSTRUCTIONS
STEP 3
On POLE (A), place 1 pair of SLIP SLEEVES (C) at the desired
distance between SHELVES (B). Please make sure the arrow
faces up and that the word “TOP” is right side up. Do this for
each POLE (A), and make sure height is identical for each
POLE (A).
Lower SHELF (B) over each POLE (A) so corner cylinders of
SHELF (B) are positioned over SLIP SLEEVES (C).
Repeat Step 3 to install other SHELVES (B) as desired.
Note: Use a rubber mallet, if needed, to secure SHELF (B).
NEED
HERE
STEP 4
Feet Levelers are already screwed into POLES (A), and
you can adjust as needed to ensure Shelving Rack is
level.
3© 2022 TRINITY - 800.985.5506

ASSEMBLY INSTRUCTIONS
STEP 5
Purchase another TRINITY 4-TIER WINE RACK.
Fully assemble one unit first. Remove black
END CAPS from all poles.
Screw POLE CONNECTORS (D) to second unit’s
loose POLES where END CAPS have been taken
off.
Screw POLES (A) with POLE CONNECTORS (D) to
top of POLES (A) of assembled unit.
Install remaining SHELVES (B) as desired.
© 2022 TRINITY - 800.985.5506 4

SERVICE PARTS LIST –TBFZ-0908 Chrome
TRINITY Customer Service provides the following replacement parts:
Part Number Description Part Number Description
1) ZSV-03-009-3614 Shelf 4) XBK-98-003-2538 Feet Leveler
2) XBK-01-011-2543 Slip Sleeve 5) XBK-23-004-2517 End Cap
3) ZSV-04-008-3400 Pole 6) ZSV-01-013-2523 Pole Connector
5© 2022 TRINITY - 800.985.5506

WARNINGS
1. Read and understand all instructions. Failure to follow all instructions may result in injury
and/or damage.
2. The warnings, cautions, and instructions discussed in this manual cannot cover all
possible conditions or situations that may occur. The user must always be aware of their
environment and ensure that they use the product in a safe and responsible manner.
3. Do NOT modify the product in any way. Unauthorized modification may impair the
function and/or safety of the product, and may affect the life of the product. Any
modifications will void product warranty.
4. Check for damaged parts. Before using this product, carefully check that all parts are in
good condition, and that the product will operate properly and perform its intended
function. Check for damaged parts and any other conditions that may affect the operation
of this product. Replace damaged or worn parts, and never use this product with a damaged
part.
5. Do NOT overload the product.
Weight capacity per Shelf Up to (9) 750 mL wine bottles OR 150 lb (evenly
distributed)
Total weight capacity of Wine Rack 600 lb (evenly distributed)
CARE AND MAINTENANCE
•Avoid harsh, abrasive cleaners, and other corrosive chemicals.
•This product is for in door use only.
© 2022 TRINITY - 800.985.5506 6

7© 2022 TRINITY - 800.985.5506

PRODUCT REGISTRATION
Thank you for purchasing a TRINITY EcoStorage™4-Tier NSF Wine Rack. In order to register your
product and receive streamlined customer service, please fill out the following Product Registration
Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at
www.trinityii.com or (3) scan and email the form to [e-mail]. Include a copy of
your original receipt with your submission.
First Name: Last Name:
Address:
City: State: Zip Code:
Email Address: Phone:
Product Model #: TBFZ-0908 Purchase Date: / /
Location of Purchase:
Please rate the importance of each feature (1=least important; 10=most important)
Quality Price Size/Capacity Appearance Other
How did you hear about our product?
Magazine Ad Catalog Salesperson Word of Mouth
Internet Store Display Other
Marital Status: Single Married
Household Income: Below $50,000 $50,000-$150,000 $150,000+
Education: High School College Graduate School
Primary Residence: Own Rent
Comments/Suggestions:
© 2022 TRINITY - 800.985.5506 8

9© 2022 TRINITY - 800.985.5506

1 YEAR LIMITED WARRANTY
TRINITY EcoStorage™4-Tier NSF Wine Rack
Model # TBFZ-0908
Trinity International Industries (“Trinity”) warrants to the original consumer purchaser (“Purchaser”) of the
EcoStorage™4-Tier NSF Wine Rack (“Product”) that each Product shall be free from defects in workmanship
and materials for a period of 1 year from the date of original purchase. Trinity’s obligation under this
warranty shall be limited to repair or replacement of, or adequate compensation for the Product which shall
not be greater than the amount of the purchase price of the Product, at the option of Trinity, during the
warranty period. All replaced parts and Products become the property of Trinity and must be returned to
Trinity.
This warranty excludes normal wear and tear of the Product and its parts or components, and damage arising
from any of the following: negligent use or misuse of the Product, use contrary to this User’s Manual, or
alteration by any one other than Trinity. The warranty period of 1 year shall not be extended or renewed by
the repair or replacement of, or compensation for, the Product. Any warranty implied by applicable law is
limited in duration to one year from the date of purchase and is subject to the same conditions and
limitations as is provided for our express warranty.
Except as set forth herein, and to the extent of applicable there are no warranties on this Product either
express or implied, and Trinity disclaims all warranties including, but not limited to, any implied warranties of
merchantability, infringement or fitness for a particular purpose. No warranty or guarantee given by any
person, firm, or corporation with respect to this product shall be binding on Trinity.
If your Product is defective or otherwise requires service or parts, please call TRINITY Customer Service toll-
free at [phone], between 5:00 a.m. and 5:00 p.m., PST. Please tell us which model you purchased,
the date of the purchase, and the problem with your Product. A copy of your original purchase receipt must
accompany your service request.
LIMITATION OF REMEDIES AND LIABILITY
Trinity (and its employees, officers, members, managers, affiliates and assigns) shall not be liable for any
incidental, consequential, special, indirect, remote, special or punitive damages for breach of any warranty,
express or implied, including, but not limited to, lost profits, lost savings, loss of anticipated benefits and
attorneys’ fees, which arise out of the purchase, use or inability to use the Product, whether arising out of
contract, negligence, strict tort, product liability, or any other legal theory on which a claim is based. As
noted above, to the extent damages are allowed by our express warranty or by applicable law, those
damages may not exceed the purchase price paid for the Product. Without limiting the foregoing Purchaser
assumes all risk and liability for loss, damage or injury to Purchaser and Purchaser’s property and to others
and their property arising out of the use, misuse, or inability to use this Product. This limited warranty shall
not extend to anyone other than the original purchaser of this product, is nontransferable and states your
exclusive remedy.
Some states do not allow the exclusion or limitation of incidental, consequential, special, or punitive
damages, so the above limitation or exclusion may not apply to you. The above warranty gives you specific
legal rights, and you may have other rights which vary from state to state.
© 2022 TRINITY - 800.985.5506 10

TRINITY Customer Service
TEL: [phone]
FAX: [phone]
EMAIL: [e-mail]
Monday through Friday
5:00 AM –5:00 PM (PST)
www.trinityii.com
QUESTIONS? NEED PARTS?
WE ARE HERE TO HELP!
Please feel free to contact us. There are no questions too small, or
any problems too big. We’re committed to providing our customers
with the highest level of service.
CONTACT US
