BI1.5-HS865-Y1
Inductive sensor
Technical data
Type BI1.5-HS865-Y1
ID number 1004201
Rated switching distance 1.5mm
Mounting conditions Flush
Secured operating distance ≤(0,81 x Sn) mm
Correction factors St37 = 1; Al = 0.3; stainless steel = 0.7; Ms =
0.4
Repeat accuracy ≤2% of full scale
Temperature drift ≤ ± 10 %
Hysteresis 1…10%
Ambient temperature -25…+70°C
Output function 2-wire, NAMUR
Switching frequency 5kHz
Voltage Nom.8.2VDC
Non-actuated current consumption ≥2.1mA
Actuated current consumption ≤1.2mA
Approval acc. to KEMA 02 ATEX 1090X
Internal capacitance (Ci)/inductance (Li) 150 nF/150 µH
Device marking É II 2 G Ex ia IIC T6 Gb / II 1 D Ex ia IIIC T95
°C Da
(max. Ui = 20 V, Ii = 60 mA, Pi = 130 mW)
Design Smooth barrel, 6.5 mm
Dimensions 32mm
Housing material Metal, CuZn, Chrome-plated
Active area material Plastic, PA12-GF30
End cap Plastic, PP
Electrical connection Cable
Cable quality Ø4mm, Blue, Lif9YYW, PVC, 2m
Features
■ATEX category II 2 G, Ex zone 1
■ATEX category II 1 D, Ex zone 20
■SIL2 (Low Demand Mode) acc. to IEC 61508, PL
c acc. to ISO 13849-1 at HFT0
■SIL3 (All Demand Mode) acc. to IEC 61508, PL e
acc. to ISO 13849-1 with redundant configura-
tion HFT1
■Smooth barrel, Ø 6.5 mm
■Active face, lateral
■Chrome-plated brass
■DC 2-wire, nom. 8.2 VDC
■Output acc. to DIN EN 60947-5-6 (NAMUR)
■Cable connection
Wiring diagram
Inductive sensors detect metal objects
contactless and wear-free. For this, they use a
high-frequency electromagnetic AC field that
interacts with the target. Inductive sensors
generate this field via an RLC circuit with a ferrite
coil.

Hans Turck GmbH & Co. KG | 45466 Mülheim an der Ruhr, Germany | T [phone] | F [phone] | [email protected] | www.turck.com 2|3
Technical data
Cable cross section 2x0.25mm2
Vibration resistance 55Hz (1 mm)
Shock resistance 30g (11 ms)
Protection class IP67
MTTF 6198years acc. to SN 29500 (Ed. 99) 40 °C
Mounting instructions/Description
Mounting accessories
IMX12-DI01-2S-2T-0/
24VDC
7580020
Isolating switching amplifier, 2-channel;
SIL2 acc. to IEC 61508; Ex-proof version;
2 transistor outputs; input Namur signal;
ON/OFF switchable monitoring of
wire-break and short-circuit; toggle
between NO/NC mode; signal doubling;
removable screw terminals; 12.5 mm
wide; 24 VDC power supply

Hans Turck GmbH & Co. KG | 45466 Mülheim an der Ruhr, Germany | T [phone] | F [phone] | [email protected] | www.turck.com 3|3
Operating Instructions
Intended use
This device fulfills the directive 2014/34/EC and is suited for use in explosion hazardous areas according to EN 60079-0:2012 + A11 and
EN 60079-11:2012.Further it is suited for use in safety-related systems, including SIL2 as per IEC 61508.In order to ensure correct opera-
tion to the intended purpose it is required to observe the national regulations and directives.
For use in explosion hazardous areas conform to classification
II 2 G and II 1 D (Group II, Category 2 G, electrical equipment for gaseous atmospheres and category 1 D, electrical equipment for dust
atmospheres).
Marking (see device or technical data sheet)
É II 2 G and Ex ia IIC T6 Gb and É II 1 D Ex ia IIIC T95 °C Da acc. to EN 60079-0, -11
Local admissible ambient temperature
-25…+70 °C
Installation / Commissioning
These devices may only be installed, connected and operated by trained and qualified staff. Qualified staff must have knowledge of
protection classes, directives and regulations concerning electrical equipment designed for use in explosion hazardous areas.Please
verify that the classification and the marking on the device comply with the actual application conditions.
This device is only suited for connection to approved Exi circuits according to EN 60079-0 and EN 60079-11. Please observe the maxi-
mum admissible electrical values.After connection to other circuits the sensor may no longer be used in Exi installations. When inter-
connected to (associated) electrical equipment, it is required to perform the "Proof of intrinsic safety" (EN60079-14).Attention! When
used in safety systems, all content of the security manual must be observed.
Installation and mounting instructions
Avoid static charging of cables and plastic devices. Please only clean the device with a damp cloth. Do not install the device in a dust
flow and avoid build-up of dust deposits on the device.If the devices and the cable could be subject to mechanical damage, they must
be protected accordingly. They must also be shielded against strong electro-magnetic fields.The pin configuration and the electrical
specifications can be taken from the device marking or the technical data sheet.
service / maintenance
Repairs are not possible. The approval expires if the device is repaired or modified by a person other than the manufacturer. The most
important data from the approval are listed.
