turck BL ident TW-R16-B128-Ex User manual

Mobile data carrier
TW-R16-B128-Ex
Edition • 2013-07-12T17:44:31+02:00
1 / 4 Hans Turck GmbH & Co.KG ñ D-45472 Mülheim an der Ruhr ñ Witzlebenstraße 7 ñ Tel. [phone] ñ Fax [phone] ñ [email protected] ñ www.turck.com
Type code TW-R16-B128-Ex
Ident no. 7030241
Data transfer inductive coupling
Operating frequency 13.56 MHz
Memory type EEPROM
Chip NXP I-Code SLI/SL2
Memory 128 byte
Memory read/write
Freely usable memory 112 byte
Number of read operations unlimited
Number of write operations 105
Typical read time 2 ms/byte
Typical write time 3 ms/byte
Radio communication and protocol standards ISO 15693
Minimum distance to metal 10 mm
Ambient temperature -25…+85 °C
Storage temperature -25…+120 °C
160 °C, 1x35 h
220 °C, 1x30 s
in the explosion hazardous area see instruc-
tion leaflet
Device designation Ex II 2 G Ex ia IIC T4/T6 II 2D Ex iaD 21
T110°C
Approval acc. to BVS 09 ATEX E 036 X
Design R16
Diameter 16 mm
Housing material Plastic, PA
Material active face Plastic, Black, PA
Protection class IP69K
Packaged quantity 1
Special features Extended storage temperature, ATEX
■ATEX category II 2 G, Ex-zone 1
■ATEX category II 2 D, Ex-zone 21
■EEPROM, memory 128 byte
Functional principle
The HF read/write heads operating at a fre-
quency of 13.56 MHz, form a transmission
zone the size of which (0…500 mm) varies,
depending on the combination of read/write
head and data carrier.
The read/write distances mentioned here on-
ly represent standard values measured under
laboratory conditions and free from any influ-
ences caused by materials.
The read/write distances of data carriers suit-
able for mounting in/on metal were deter-
mined in/on metal.
Attainable distances may vary by up to 30 %
due to component tolerances, mounting con-
ditions, ambient conditions and material quali-
ties (especially when mounted in metal)
Testing of the application under real operat-
ing conditions is therefore essential, especial-
ly with read/write on-the-fly!

Mobile data carrier
TW-R16-B128-Ex
Edition • 2013-07-12T17:44:31+02:00
2 / 4 Hans Turck GmbH & Co.KG ñ D-45472 Mülheim an der Ruhr ñ Witzlebenstraße 7 ñ Tel. [phone] ñ Fax [phone] ñ [email protected] ñ www.turck.com
Read/write heads
Dimensions Type designation Read-write distance Transfer zone Minimum dis-
tance between two
read-write heads
Ident - no. Recommend-
ed (mm)
max. [mm] length
max. [mm]
width offset
max. [mm]
[mm]
TB-EM18WD-H1147-Ex
7030381
10 17 14 7 54
TB-EM18WD-H1147/S1126-EX
7030383
10 17 14 7 54
TN-EM18WD-H1147-Ex
7030382
10 17 14 7 54
TN-EM18WD-H1147/S1126-EX
7030384
12 23 26 13 54
TB-EM30WD-H1147-Ex
7030385
12 23 20 10 90
TB-EM30WD-H1147/S1126-EX
7030387
12 23 20 10 90
TN-EM30WD-H1147-Ex
7030386
20 38 44 22 90
TN-EM30WD-H1147/S1126-EX
7030388
20 38 44 22 90
TN-Q80-H1147-EX
7030302
20 52 60 30 240
TNLR-Q80-H1147-EX
7030303
50 85 90 45 240

Mobile data carrier
TW-R16-B128-Ex
Edition • 2013-07-12T17:44:31+02:00
3 / 4 Hans Turck GmbH & Co.KG ñ D-45472 Mülheim an der Ruhr ñ Witzlebenstraße 7 ñ Tel. [phone] ñ Fax [phone] ñ [email protected] ñ www.turck.com
Compatible handhelds
PD-IDENT
1542331
Handheld for mobile reading and writing on data carriers.
PDA-IDENT
1542344
The handheld can be used with two different antennas.
Internal antenna, PDA-IDENT-IA, 1542345
External antenna, PDA-IDENT-EA, 1542346

Mobile data carrier
TW-R16-B128-Ex
Edition • 2013-07-12T17:44:31+02:00
4 / 4 Hans Turck GmbH & Co.KG ñ D-45472 Mülheim an der Ruhr ñ Witzlebenstraße 7 ñ Tel. [phone] ñ Fax [phone] ñ [email protected] ñ www.turck.com
Operating manual
Intended use
This device fulfils the directive 94/9/EC and is suited for use in explosion hazardous areas as per EN60079-0, -11 and EN61241-0, -11
For use in explosion hazardous areas conform to classification
II 2 G and II 2 D (Group II, Category 2 G, electrical equipment for gaseous atmospheres and category 2 D, electrical equipment for dust atmo-
spheres)
Marking (see device or technical data sheet)
É II 2 G and Ex air IIC T4/T6 and EN60079-0:2006 and EN60079-11:2007 and É II 2 D Ex aid 21 T110°C and EN61241-0:2006 and
EN61241-11:2006
Local admissible ambient temperature
As ATEX category II 2 G electrical equipment -45…+55°C for T6, -45…+85°C for T4 and as category II 2 D -45…+85°C
Installation / Commissioning
These devices may only be installed, connected and operated by trained and qualified staff. Qualified staff must have knowledge of protection
classes, directives and regulations concerning electrical equipment designed for use in explosion hazardous areas and if necessary, of the regu-
lations applicable to safety-related systems.
Please verify that the classification and the marking on the device comply with the actual application conditions.
Installation and mounting instructions
Avoid static charging of cables and plastic devices. Please only clean the device with a damp cloth. Do not install the device in a dust flow and
avoid build-up of dust deposits on the device.
Special conditions for safe operation
Special conditions indicated with the X in the approval should be observed to ensure safe operation.
Data carriers applied in explosion hazardous area should only be read and written to with devices which are approved for this area.
In order to observe the admissible surface temperature of the data carriers, the strength of allowed electromagnetic fields should be limited.
Maximum values should comply with the safety and occupational health regulations. The regulation BGV B11 of the BGFE for electromagnetic
fields is applied in Germany.
The data carriers should not be damaged when mounted or dismounted. Please also ensure that the label is clearly visible for later inspection
when mounted. To avoid possible electrostatic discharge, 50 mm Ø data carriers should be mounted with only one freely accessible side. Due to
possible electrostatic discharge, all mounting screws and brackets for data carriers should be earthed safely when applied in the hazardous dust
explosive area. If this is not possible, because the data carrier is mobile for example, use plastic screws and brackets.
In hazardous dust explosive areas metal screws and brackets for data carriers have to be earthed safely. Static charge caused by cleaning, fric-
tion or other forms of charge separation has to be avoided.
Data carriers approved for temperature class T6 (-45°C … +55°C ) and T4 (-45°C … +85°C ) can be applied in hazardous gas explosive areas.
The data carriers can be applied in hazardous dust explosive areas at ambient temperatures of -45°C to +85°C
service / maintenance
Servicing is not required. Defective data carriers have to be replaced, repair is not possible. Mechanically damaged data carriers must be re-
moved.
