Tyco Fire Product CENTRAL BV-QR User manual

should be considered, as a minimum,
along with the corrosive nature of the
chemical to which the sprinklers will be
exposed.
Operation: The glass bulb contains a fluid
which expands when exposed to heat.
When the rated temperature is reached,
the fluid expands sufficiently to shatter the
glass bulb, which then allows the sprinkler
to activate & flow water.
WARNING
The Model BV-QR & BVLO-QR Upright,
Pendent & Rec. Pendent Sprinklers
described herein must be installed and
maintained in compliance with this
document, as well as with the applicable
standards of the National Fire Protection
Association, in addition to the standards of
any other authorities having jurisdiction.
Failure to do so may impair the integrity of
these devices.
The owner is responsible for maintaining
their fire protection system and devices in
proper operating condition. The installing
contractor or sprinkler manufacturer
should be contacted relative to any
questions.
Model BV-QR & BVLO-QR
4.2, 5.6 & 8.0 K-factor
Quick Response
Standard Coverage
Upright, Pendent & Rec. Pendent Glass Bulb Automatic Sprinkler
No. 1-7.0
General
Description
The Central Model BV-QR, 4.2 & 5.6
K-factor (7/16" & 1/2" orifice) & Model
BVLO-QR, 8.0 K-factor (17/32" orifice),
Upright, Pendent, and Rec. Pendent
Sprinklers are quick response - standard
coverage, decorative glass bulb type
spray sprinklers designed for use in light &
ordinary hazard, commercial occupancies
such as banks, hotels, shopping malls etc.
The recessed version of the Central Model
BV-QR, intended for use in areas with a
finished ceiling, uses a two-piece Model
BV Res/QR Recessed Escutcheon
(Vented or Unvented). The Model BV
Res/QR Recessed Escutcheon provides
up to 3/8 inch (9,5 mm) of total adjustment
from the flush pendent position. The
recessed version of the Central Model
BVLO-QR, also intended for use in areas
with a finished ceiling, uses a two-piece
Model ELO Recessed Escutcheon. The
Model ELO Recessed Escutcheon
provides up to 3/4 inch (19,1 mm) of total
adjustment from the flush pendent
position. The adjustment provided by
these Recessed Escutcheons reduces the
accuracy to which the fixed pipe drops to
the sprinklers must be cut.
These sprinklers are available with a
polyester coating that may be utilized to
extend the life of copper alloy sprinklers
beyond that which would otherwise be
obtained when exposed to corrosive
atmospheres.
Although polyester coated sprinklers have
passed the standard corrosion tests of the
applicable approval agencies, the testing
is not representative of all possible
corrosive atmospheres. Consequently, it is
recommended that the end user be
consulted with respect to the suitability of
this corrosion resistant coating for any
given corrosive environment. The effects
of ambient temperature, concentration of
chemicals, and gas/chemical velocity,
CENTRAL BV-QR & BVLO-QR 5-01
Standard Spray
Upright, Pendent
& Rec. Pendent
Sprinklers
Tyco Fire Products --- www.centralsprinkler.com
451 North Cannon Avenue, Lansdale, Pennsylvania 19446 --- USA
Customer Service/Sales: Tel: [phone] / Fax: [phone]
Technical Services: Tel: [phone] / Fax: [phone]
SPRINKLER
FRAME
DEFLECTOR
GLASS BULB
OPERATING
ELEMENT
GASKETED SPRING
PLATE
(BELLEVILLE
SEAL)
BUTTON
ASSEMBLY
COMPRESSION
SCREW
Figure 1 - Cross Section
Model BVLO-QR,
Upright Sprinkler
OBSOLETE

Figure 2 - Model BV-QR, Upright, Pendent & Rec. Pendent Sprinkler
1. Listed by Underwriters Laboratories, Inc. - (K = 4.2 & 5.6)
2. Listed by Underwriters' Laboratories of Canada. - (K = 4.2 & 5.6)
3. Approved by Factory Mutual Research Corporation. - (K = 5.6)
4. Approved by the City of New York under MEA 466-92-E Vol. III. - (K = 4.2 & 5.6)
* Pendent Only.
** Only Approved with the Series BV Res/QR (Vented) Recessed Escutcheon Assy.
SPRINKLER FINISH & STYLE
Temperature Bulb Natural Chrome Polyester Recessed
Rating Color Code Brass Plated Coated
135°F/57°C Orange
155°F/68°C Red
175°F/79°C Yellow
200°F/93°C Green
250°F/121°C Blue
1,2,3,4 1,2,3,4 1,2,3*,4 1,2,3**,4
1,2,3,4 1,2,3,4 1,2,3*,4 1,2,3**,4
1,2,3,4 1,2,3,4 1,2,3*,4 1,2,3**,4
1,2,3,4 1,2,3,4 1,2,3*,4 1,2,3**,4
1,2,3,4 1,2,3,4 1,2,3*,4 ----
Table 1 - Laboratory Listings and Approvals, Model BV-QR
CENTRAL
1-1/16
(27,0 mm)
WRENCH
FLAT
2-1/16"
(52,4 mm)
1/2" NPT
CENTRAL
2-1/16"
(52,4 mm)
1-1/16"
(27,0 mm)
1/2" NPT
CENTRAL
3/8" (9,5 mm)
Min.
3/4" (19,1 mm)
Max.
2-7/8" (73,0 mm)
2" (50,8 mm) Min.
2-1/4" (57,2 mm) Max.
FACE OF
REDUCING
COUPLING
FINISHED
CEILING LINE
MODEL BV Res/QR
RECESSED
ESCUTCHEON
ELEVATION VIEW
RECESSED
SUPPORT CUP
OUTER
ESCUTCHEON
RING
Sprinkler Identification Number
SIN C2201 - BV-QR Pend (K=4.2)
SIN C2101 - BV-QR UP (K=4.2)
SIN C3201 - BV-QR Pend (K=5.6)
SIN C3101 - BV-QR UP (K=5.6)
SIN C4201 - BVLO-QR Pend (K=8.0)
SIN C4101 - BVLO-QR UP (K=8.0)
Approvals
UL, ULC & C-UL Listed.
FM & NYC Approved
(Refer to Table 1 - 2. The approvals apply
only to the service conditions indicated in
the Design Criteria Section)
Maximum Working Pressure
175 psi (12,1 bar)
250 psi (17,3 bar) UL & ULC (K=5.6)
Pipe Thread Connection
1/2 inch NPT - (K=4.2 & 5.6)
3/4 inch NPT - (K=8.0)
Discharge Coefficient
K = 4.2 GPM/psi1/2 (60,5 LPM/bar1/2)
K = 5.6 GPM/psi1/2 (80,6 LPM/bar1/2)
K = 8.0 GPM/psi1/2 (115,2 LPM/bar1/2)
Temperature Ratings
135°F/57°C, 155°F/68°C, 175°F/79°C
200°F/93°C, 250°F/121°C
Finishes
Sprinkler: White Polyester, Chrome Plated,
or Natural Brass
Rec. Escutcheon: White Coated, Chrome
Plated, or Brass Plated
Corrosion Resistant Coatings
Sprinkler: White Polyester (UL only)
Head Guard & Water Shield:
G-3 (Guard) - (K=5.6) Up & Pend.
WSG-3 (Guard & Shield) - (K=5.6) Up
WS-3 (Shield) - (K=5.6) Pendent
(See Data Sheet 3-13.0 for details)
Physical Characteristics
The Model BV-QR & BVLO-QR Upright,
Pendent & Rec. Pendent Sprinklers utilize
a dezincification resistant (DZR) bronze
frame and a 3 mm bulb. The two-piece
button assembly is brass and copper. The
sprinkler frame orifice is sealed with a
gasketed spring plate (Belleville Seal)
consisting of a beryllium nickel disc spring
that is sealed on both its inside and outside
edges with a TeflonTM gasket. The
compression screw is bronze, & the
deflector is brass.
Technical
Data
OBSOLETE

1-3/8
(35,0 mm)
2-1/8"
(54,0 mm)
3/4" NPT
CENTRAL
CENTRAL
WRENCH
FLAT
3/4" NPT
2-1/8"
(54,0 mm)
1-3/16"
(30,2 mm)
CENTRAL
3/8" (9,5 mm)
Min.
1-1/8" (28,6 mm)
Max.
3-1/4" (82,6 mm)
2-1/4" (57,2 mm) Min.
2-3/4" (69,9 mm) Max.
FACE OF
REDUCING
COUPLING
FINISHED
CEILING LINE
MODEL ELO
RECESSED
ESCUTCHEON
ELEVATION VIEW
RECESSED
SUPPORT CUP
OUTER
ESCUTCHEON
RING WRENCH
FLAT
Figure 3 - Model BVLO-QR, Upright, Pendent &
Rec. Pendent Sprinkler
Design
Criteria
The Model BV-QR & BVLO-QR Upright,
Pendent & Rec. Pendent Sprinklers are
Quick Response, Standard Coverage,
Spray Sprinklers intended for fire
protection systems designed in
accordance with the standard installation
rules recognized by the applicable Listing
or Approval agency.
The 4.2 K-Factor, Model BV-QR
Sprinklers (Ref. Table 1) are UL & ULC
listed and NYC Approved for use in
accordance with current NFPA standards.
The 5.6 K-Factor, Model BV-QR
Sprinklers (Ref. Table 1) are UL & ULC
listed and NYC Approved for use in
accordance with current NFPA standards,
and FM Approved for use in accordance
with the FM Loss Prevention Data Sheets.
The 8.0 K-Factor, Model BVLO-QR
Sprinklers (Ref. Table 2) are UL & C-UL
listed for use in accordance with current
NFPA standards, and FM Approved for
use in accordance with the FM Loss
Prevention Data Sheets.
The Model BV-QR & BVLO-QR
Sprinklers can be used with any metalic
flush or extended escutcheon, provided
the maximum ceiling to top of sprinkler
deflector dimension specified in NFPA 13
is maintained. For recessed applications,
only the Model BV Res/QR Vented or
Unvented, (for 4.2 & 5.6 K-factor
sprinkers) and ELO (for 8.0 K-factor
sprinklers) Recessed Escutcheon
Assemblies may be used.
NOTE
Inquiries concerning the appropriateness
of polyester coated sprinklers for a given
corrosive environment should be
submitted to the attention of the Technical
Services Department. Polyester coated
sprinklers are not suitable for use in open
sprinkler applications.
Installation
The Model BV-QR & BVLO-QR Sprinklers
must be installed in accordance with the
following instructions:
NOTES
Do not install any bulb type sprinkler if the
bulb is cracked or there is a loss of liquid
from the bulb. With the sprinkler held
horizontally, a small air bubble should be
present. The diameter of the air bubble is
approximately 1/16 inch (1,6 mm) for the
135
° F/57 ° C to 3/32 inch (2,4 mm) for the
250
° F/121 ° C rating.
A leak tight 1/2 inch NPT sprinkler joint
should be obtained with a torque of 7 to 14
ft.lbs. (9,5 to 19,0 Nm). A maximum of
(Continued on Page 4)
1. Listed by Underwriters Laboratories, Inc.
2. Listed by Underwriters Laboratories for use in Canada (C-UL).
3. Approved by Factory Mutual Research Corporation.
SPRINKLER FINISH & STYLE
Temperature Bulb Natural Chrome Polyester Recessed
Rating Color Code Brass Plated Coated
135°F/57°C Orange
155°F/68°C Red
175°F/79°C Yellow
200°F/93°C Green
250°F/121°C Blue
1,2,3 1,2,3 1,2,3 1,2,3
1,2,3 1,2,3 1,2,3 1,2,3
1,2,3 1,2,3 1,2,3 1,2,3
1,2,3 1,2,3 1,2,3 1,2,3
1,2,3 1,2,3 1,2,3 ----
Table 2 - Laboratory Listings and Approvals, Model BVLO-QR
OBSOLETE

Printed in U.S.A. 5-01
Flow Control
Tyco Fire

Products
Care &
Maintenance Products manufactured by Tyco Fire
Products are warranted solely to the
original Buyer for ten (10) years against
defects in material and workmanship
when paid for and properly installed and
maintained under normal use and service.
This warranty will expire ten (10) years
from date of shipment by Tyco Fire
Products. No warranty is given for
products or components manufactured by
companies not affiliated by ownership with
Tyco Fire Products or for products and
components which have been subject to
misuse, improper installation, corrosion, or
which have not been installed, maintained,
modified or repaired in accordance with
applicable Standards of the National Fire
Protection Association, and/or the
standards of any other Authorities Having
Jurisdiction. Materials found by Tyco Fire
Products to be defective shall be either
repaired or replaced, at Tyco Fire
Products' sole option. Tyco Fire Products
neither assumes, nor authorizes any
person to assume for it, any other
obligation in connection with the sale of
products or parts of products. Tyco Fire
Products shall not be responsible for
sprinkler system design errors or inaccu-
rate or incomplete information supplied by
Buyer or Buyer's representatives.
IN NO EVENT SHALL TYCO FIRE
PRODUCTS BE LIABLE, IN CON-
TRACT, TORT, STRICT LIABILITY OR
UNDER ANY OTHER LEGAL THEORY,
FOR INCIDENTAL, INDIRECT, SPECIAL
OR CONSEQUENTIAL DAMAGES,
INCLUDING BUT NOT LIMITED TO
LABOR CHARGES, REGARDLESS OF
WHETHER TYCO FIRE PRODUCTS
WAS INFORMED ABOUT THE POSSI-
BILITY OF SUCH DAMAGES, AND IN
NO EVENT SHALL TYCO FIRE PROD-
UCTS' LIABILITY EXCEED AN AMOUNT
EQUAL TO THE SALES PRICE.
THE FOREGOING WARRANTY IS
MADE IN LIEU OF ANY AND ALL
OTHER WARRANTIES EXPRESS OR
IMPLIED, INCLUDING WARRANTIES
OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE.
Limited
Warranty
Ordering Information: When placing an
order, indicate the full product name.
Please specify the quantity, model, style,
orifice size, temperature rating, type of
finish or coating, and sprinkler wrench.
Refer to price list for complete listing of
Part Numbers.
Teflon is a trademark of the DuPont Corp.
Ordering
Information
The Model BV-QR & BVLO-QR Sprinklers
must be maintained and serviced in
accordance with the following instructions.
NOTES
Absence of an escutcheon which is used
to cover a clearance hole, may delay the
time to operation in a fire situation.
Before closing a fire protection system
main control valve for maintenance work
on the fire protection system it controls,
permission to shut down the affected fire
protection systems must be obtained from
the proper authorities. All personnel who
may be affected by this action must be
notified.
Sprinklers which are found to be leaking or
exhibiting visible signs of corrosion must
be replaced.
Automatic sprinklers must never be
shipped or stored where their tempera-
tures will exceed 100°F/38°C and they
must never be painted, plated, coated or
otherwise altered after leaving the factory.
Modified sprinklers must be replaced.
Sprinklers that have been exposed to
corrosive products of combustion, but
have not operated, should be replaced if
they cannot be completely cleaned by
wiping the sprinkler with a cloth or by
brushing it with a soft bristle brush.
Care must be exercised to avoid damage
- before, during, and after installation.
Sprinklers damaged by dropping, striking,
wrench twist/slippage, or the like, must be
replaced. Also, replace any sprinkler that
has a cracked bulb or that has lost liquid
from its bulb (Ref. Installation Section).
Frequent visual inspections are recom-
mended to be initially performed for
polyester coated sprinklers installed in
corrosive environments, after the
installation has been completed, to verify
the integrity of the polyester coating.
Thereafter, annual inspections per NFPA
25 should suffice; however, instead of
inspecting from the floor level, a random
sampling of close-up visual inspections
should be made, so as to better determine
the exact sprinkler condition and the long
term integrity of the polyester coating, as it
may be affected by the corrosive condi-
tions present.
The owner is responsible for the inspec-
tion, testing, and maintenance of their fire
protection system and devices in compli-
ance with this document, as well as with
the applicable standards of the National
Fire Protection Association (e.g., NFPA
25), in addition to the standards of any
other authorities having jurisdiction. The
installing contractor or sprinkler manufac-
turer should be contacted relative to any
questions.
It is recommended that automatic sprinkler
systems be inspected, tested, and
maintained by a qualified Inspection
Service.
Installation
(Cont.)
21 ft.lbs. (28,5 Nm) of torque is to be used
to install 1/2 inch NPT sprinklers. A leak
tight 3/4 inch NPT sprinkler joint should be
obtained with a torque of 10 to 20 ft.lbs.
(13,4 to 26,8 Nm). A maximum of 30
ft.lbs. (40,7 Nm) of torque is to be used to
install 3/4 inch NPT sprinklers. Higher
levels of torque may distort the sprinkler
inlet with consequent leakage or impair-
ment of the sprinkler.
Do not attempt to compensate for
insufficient adjustment in an Escutcheon
Plate by under- or over-tightening the
Sprinkler. Readjust the position of the
sprinkler fitting to suit.
Step 1. Upright sprinklers must be
installed only in the upright position &
pendent sprinklers must be installed only
in the pendent position. The deflector is to
be parallel to the ceiling, roof, or mounting
surface, as applicable.
Step 2. After installing the BV Res/QR or
ELO support cup (or other escutcheon, as
applicable) over the sprinkler pipe threads
& with pipe thread sealant applied to the
pipe threads, hand tighten the sprinkler
into the sprinkler fitting.
Step 3. Wrench tighten the sprinkler using
only the following wrenches:
BV-QR Up/Pend - Comb. Wrench (1106)
BV-QR Rec. Pend - BV Wrench (1099)
BVLO-QR Up & Pend - W-Type 3 (1073)
BVLO-QR Rec. Pend - ELO Offset (1093)
Wrenches are to be applied to the
sprinkler wrench flats (Ref. Fig 2 & 3) only.
Step 4. For applications using the BV-QR
Rec. Pendent Sprinklers, a Protective Cap
is available which helps to prevent
damage to the sprinkler during ceiling
installation or during application of the
finish coating of the ceiling. Place the
Protective Cap over the Recessed
Support Cup and push it upwards until it
bottoms out against the sprinkler deflector.
NOTE
As long as the Protective Cap remains in
place, the system is considered "Out of
Service."
Step 5. After the ceiling has been
completed, remove and discard the
Protective Cap. If the sprinkler has been
damaged, replace the entire sprinkler
assembly. Do not attempt to modify or
repair a damaged sprinkler.
Step 6. Push the outer ring of the
Recessed Escutcheon over the Recessed
Support Cup. Do not continue to push on
the Recessed Escutcheon such that it lifts
a ceiling panel out of its normal position. If
the Outer Recessed Escutcheon Ring
cannot be engaged with the Recessed
Support Cup or the Outer Recessed
Escutcheon Ring cannot be engaged
sufficiently to contact the ceiling, the
sprinkler fitting must be repositioned.
OBSOLETE
