Ubiquiti airFiber AF-24HD User manual

24 GHz Full Duplex
Point-to-Point 2 Gbps Radio
Model: AF-24HD

1
Introduction
Thank you for purchasing the Ubiquiti Networks® airFiber® 24GHz
Full Duplex Point-to-Point 2 Gbps Radio. This Quick Start Guide
is designed to guide you through installation, show you how to
access the airFiber Configuration Interface, and explain how to
set up an airFiber link. This Quick Start Guide also includes the
warranty terms and is for use with the model AF-24HD.
Package Contents
airFiber AF-24HD Pole Mount Bracket Pole Clamps
(Qty. 2)
GPS Antenna
Mount
Carriage Bolts
(M10x150, Qty. 4)
Flat Washers
(M10, Qty. 4)
Split Lock
Washers
(M10, Qty. 4)
Hex Nuts
(M10, Qty. 4)
Metal Strap
24 GHz Full Duplex
Point-to-Point 2 Gbps Radio
Model: AF-24HD
External GPS
Antenna
Cable Ties
(Qty. 3)
Gigabit PoE
Adapter
(50V, 1.2A)
Power Cord Quick Start
Guide
TERMS OF USE: Ubiquiti radio devices must be professionally installed. Shielded Ethernet cable and
earth grounding must be used as conditions of product warranty. TOUGHCable™is designed for
outdoor installations. It is the customer’s responsibility to follow local country regulations, including
operation within legal frequency channels, output power, and Dynamic Frequency Selection (DFS)
requirements.
Introduction

2
Hardware Overview
Side
0
5
10
5
10
Alignment Bracket
Elevation
Adjustment
Azimuth
Adjustment
Ground
Bonding Point
Lock Bolts
Lock Bolts
airFiber® AF-24HD Quick Start Guide

3
Back
Lock Bolts
Lock Bolts
Lanyard Loop
Lanyard Loop
Azimuth
Adjustment
Lock Bolts
Lock Bolts
Cover LockPort Cover
Elevation
Adjustment
Hardware Overview

4
Interfaces
RESETGPS DATA AUX CONFIGLED Display
Interface Description
GPS Connect the External GPS Antenna to this SMA connector.
RESET
To reset to factory defaults, press and hold the Reset
button for more than five seconds while the unit is
already powered on.
DATA 10/100/1000 Mbps port handles all user traffic.
AUX Port for audio tone aiming.
LED Display Digital display used for power, status, and mode
information.
CONFIG
10/100 Mbps, secured port for configuration. By default,
this is the only port that can monitor, configure, and/or
update firmware.
LEDs
Link/Act
Speed GPS
Modulation Link/Act
SpeedRX Power
Master/Slave RF Link Status
airFiber® AF-24HD Quick Start Guide

5
LED State Status
DATA
Speed Off 10/100 Mbps
On 1000 Mbps
Link/Act
Off No Ethernet Link
On Ethernet Link Established
Random Flashing Ethernet Activity
AUX
GPS
Off No GPS Synchronization
On Operational (Strong Signal)
Normal Flash* Operational (Weak Signal)
Modulation
Off ¼x or 1x (QPSK SISO)
Short Flash* 2x (QPSK MIMO)
Normal Flash* 4x (16QAM MIMO)
Long Flash* 6x (64QAM MIMO)
On 8x (256QAM MIMO)
LED Display
RX Power
(-dBm)
Number Decodable RX Signal
Flashing Number Undecodable RX Signal
Overload Condition
Master/
Slave
Off Slave Mode
On Master Mode
RF Link
Status
Off RF Off
Short Flash* Syncing
Normal Flash* Beaconing
Long Flash* Registering
On Operational
CONFIG
Speed Off 10 Mbps
On 100 Mbps
Link/Act
Off No Ethernet Link
On Ethernet Link Established
Random Flashing Ethernet Activity
* Short Flash (1:3 on/off cycle)
Normal Flash (1:1 on/off cycle)
Long Flash (3:1 on/off cycle)
Hardware Overview

6
Installation Requirements
• 17 mm wrench
• 13 mm socket wrench or driver
• Clear line of sight between airFiber radios
• Clear view of the sky for proper GPS operation
• Mounting location with < 0.5° displacement due to twist and
sway under wind loading
• Mounting point:
• At least 1 meter below the highest point on the structure
• For tower installations, at least 3 meters below the top of the
tower
• Ground wires – min. 8 AWG (10 mm2) and max. length: 1 meter.
As a safety precaution, ground the airFiber radios to grounded
masts, poles, towers, or grounding bars.
WARNING: Failure to properly ground your airFiber
units will void your warranty.
• (Recommended) 2 Outdoor Gigabit PoE surge protectors –
Ubiquiti Ethernet Surge Protector, model ETH-SP.
Note: For guidelines about grounding and lightning
protection, follow your local electrical regulatory codes.
• Outdoor, shielded Category 5e (or above) cabling and shielded
RJ-45 connectors should be used for all wired Ethernet
connections. Category 6 is required for installations with long
cable runs (up to 100 m).
We recommend that you protect your networks from the
most brutal environments and devastating ESD attacks with
industrial-grade shielded Ethernet cable and shielded RJ-45
connectors from Ubiquiti Networks. For more details, visit
www.ubnt.com/toughcable
airFiber® AF-24HD Quick Start Guide

7
Installation Overview
We recommend that you configure your paired airFiber radios
before mounting. Below is an overview of the installation with
specific details on the following pages:
• Connect Power over Ethernet to the DATA port, and connect an
Ethernet cable between your computer and the CONFIG port.
• Configure device settings in the airFiber Configuration Interface.
• Once configuration is complete, disconnect the cables to move
the airFiber radios.
• Reconnect at the site.
• After you have mounted the airFiber radios, establish and
optimize the RF link.
Connecting Power over Ethernet
1. Turn the Cover Lock to the Unlocked icon. Slide the Port Cover
down to remove it.
Installation Overview

8
2. Connect an Ethernet cable to the DATA port.
3. Connect the other end of the Ethernet cable from the DATA
port to the Ethernet port labeled POE on the Gigabit PoE
Adapter.
4. Connect the Power Cord to the power port on the Gigabit PoE
Adapter. Connect the other end of the Power Cord to a power
source.
airFiber® AF-24HD Quick Start Guide

9
airFiber Configuration
The instructions in this section explain how to access the airFiber
Configuration Interface and configure the following settings:
• Wireless Mode Configure one airFiber AF-24HD as the Master
and the other as the Slave.
• Duplex The airFiber AF-24HD supports both half-duplex and
full-duplex operation. Half-duplex operation provides more
frequency planning options at the cost of higher latency
and throughput. Full-duplex operation provides the highest
throughput and lowest latency; however, you have fewer
frequency management options.
- Half Duplex (default) The TX and RX Frequencies can be the
same or different to suit local interference.
TX
RX
TX
SlaveMaster
Frequency A
Frequency A
RX
Half-Duplex Diagram
- Full Duplex The TX and RX Frequencies should be different.
TX
RX
TX
RX
SlaveMaster
Frequency A
Frequency B
Full-Duplex Diagram
• TX and RX Frequencies The TX Frequency on the Master must
match the RX Frequency on the Slave, and vice versa.
airFiber Configuration

10
1. Connect an Ethernet cable from your computer to the CONFIG
port on the airFiber AF-24HD.
2. Configure the Ethernet adapter on your computer with a
static IP address on the 192.168.1.x subnet (for example,
192.168.1.100).
3. Launch your web browser. Type http://192.168.1.20 in the
address field and press enter (PC) or return (Mac).
4. The login screen will appear. Enter ubnt in the Username and
Password fields. Select your Country and Language. You must
agree to the Terms of Use to use the product. Click Login.
Note: U.S. product versions are locked to the U.S. Country
Code to ensure compliance with FCC regulations.
airFiber® AF-24HD Quick Start Guide

11
5. Click the Wireless tab.
6. Enter the Basic Wireless Settings:
a. For one airFiber AF-24HD, select Master from the Wireless
Mode drop-down. For the other airFiber AF-24HD, keep the
default, Slave.
b. Enter a name in the Link Name field. This should be the
same on both the Master and the Slave.
c. For the Duplex drop-down:
- Half Duplex The default mode. The TX and RX Frequencies
can be the same or different to suit local interference.
- Full Duplex The TX and RX Frequencies should be different.
d. Select a TX Frequency. This must match the RX Frequency on
your other airFiber AF-24HD.
e. Select a RX Frequency. This must match the TX Frequency of
your other airFiber AF-24HD.
f. If needed, change the Output Power, Maximum Modulation
Rate, and/or RX Gain settings.
airFiber Configuration

12
7. Configure the Wireless Security:
a. Select the AES Key Type, HEX or ASCII.
b. For the Key field:
- HEX Enter 16 bytes (eight, 16-bit HEX values: 0-9, A-F, or
a-f). You can omit zeroes and use colons, similar to the
IPv6 format.
Note: The airFiber Configuration Interface supports
IPv6 formats excluding dotted quad and "::"
(double-colon) notation.
- ASCII Enter a combination of alphanumeric characters (0-9,
A-Z, or a-z).
8. Click Change and then click Apply.
9. In-Band Management is enabled by default, so each airFiber
radio must have a unique IP Address. (If the airFiber radios use
the same IP Address, then you may lose access to the airFiber
radios via the DATA ports.) To change the networksettings:
a. Click the Network tab.
b. Change the IP Address, Netmask, and other settings to make
them compatible with your network.
c. Click Change and then click Apply.
Repeat the instructions in the airFiber Configuration section on
your other airFiber radio. After you have configured the airFiber
radios, disconnect them and move them to your installation site.
airFiber® AF-24HD Quick Start Guide

13
Hardware Installation
To install the airFiber AF-24HD:
1. Insert the four Carriage Bolts into the Pole Mount Bracket.
2. Attach the Pole Mount Bracket to a pole.
Note: The mounting assembly can accommodate a
Ø 51 - 101 mm (2.0" - 4.0") pole.
a. Orient the Pole Mount Bracket around the pole so it is aimed
in the direction of the other airFiber AF-24HD.
b. Insert the Carriage Bolts into the Pole Clamps.
c. Secure the clamps with the Flat Washers, Split Lock Washers,
and Hex Nuts.
Note orientation of slots
Aim towards link
Hardware Installation

14
3. Loosen, but do NOT remove the eight Lock Bolts located on the
Alignment Bracket.
4. Ensure that there is a 6 mm gap between the head of each
M8x14 Serrated Flange Screw and the Alignment Bracket.
0
5
10
5
10
6 mm
airFiber® AF-24HD Quick Start Guide

15
5. Lift the airFiber AF-24HD and align the four M8x14 Serrated
Flange Screws with the slots on the Pole Mount Bracket. Seat the
screws in the slots. Securely tighten the screws.
WARNING: To prevent injury, ensure that all four screws
are seated and fully tightened.
0
5
10
5
10
Hardware Installation

16
6. Attach a ground wire:
a. Remove the nut from the Ground Bonding Point.
b. Attach a ground wire (min. 8 AWG or 10 mm2) to the lug and
replace the nut to secure the wire.
c. Secure the other end of the ground wire to a grounded
mast, pole, tower, or grounding bar.
WARNING: Failure to properly ground your airFiber
units will void your warranty.
Note: The ground wire should be as short as possible
and no longer than one meter in length.
airFiber® AF-24HD Quick Start Guide

17
Connecting the GPS Antenna
Locate a mounting point for the External GPS Antenna that has a
clear view to the sky, and is above and as far away as possible from
the AF-24HD.
1. Attach the GPS Antenna Mount to a pole using the included
Metal Strap, or attach it to a wall using the appropriate
fasteners (not included).
2. Place the magnetic External GPS Antenna on the mount.
Hardware Installation

18
3. Secure the cable of the External GPS Antenna to the mount with
a Cable Tie.
4. Turn the Cover Lock counterclockwise to the Unlocked icon.
Slide the Port Cover down to remove it.
5. Connect the External GPS Antenna to the GPS SMA connector.
airFiber® AF-24HD Quick Start Guide
