SARA-N2 / N3 series
Multi-band NB-IoT (LTE Cat NB1 / NB2) modules
System integration manual
Abstract
This document describes the features and the system integration of the SARA-N2 series and the
SARA-N3 series NB-IoT modules. These modules are a complete and cost efficient solution offering
from single-band up to multi-band data transmission for the Internet of Things technology in the
compact SARA form factor.
SARA-N2 / N3

SARA-N2 / N3 series - System integration manual
UBX-17005143 - R13 Document information Page 2 of 95
C1-Public
Document information
Title
SARA-N2 / N3 series
Subtitle
Multi-band NB-IoT (LTE Cat NB1 / NB2) modules
Document type
System integration manual
Document number
UBX-17005143
Revision and date
R13
14-Oct-2020
Disclosure restriction
C1-Public
Product status
Corresponding content status
Functional sample
Draft
For functional testing. Revised and supplementary data will be published later.
In development /
Prototype
Objective specification
Target values. Revised and supplementary data will be published later.
Engineering sample
Advance information
Data based on early testing. Revised and supplementary data will be published later.
Initial production
Early production information
Data from product verification. Revised and supplementary data may be published later.
Mass production /
End of life
Production information
Document contains the final product specification.
This document applies to the following products:
Product name
Type number
Modem version
Application version
PCN reference
Product status
SARA-N200
SARA-N200-02B-00
06.57
A07.03
UBX-18005015
End of life
SARA-N200-02B-01
06.57
A09.06
UBX-18048558
End of life
SARA-N200-02B-02
06.57
A10.08
UBX-19030865
End of life
SARA-N201
SARA-N201-02B-00
06.57
A07.03
UBX-18005015
End of life
SARA-N201-02B-01
06.57
A08.05
UBX-19030865
End of life
SARA-N210
SARA-N210-02B-00
06.57
A07.03
UBX-18005015
End of life
SARA-N210-02B-01
06.57
A09.06
UBX-18048558
End of life
SARA-N210-02B-02
06.57
A10.08
UBX-19030865
End of life
SARA-N211
SARA-N211-02X-00
06.57
A07.03
UBX-18005015
End of life
SARA-N211-02X-01
06.57
A09.06
UBX-18048558
End of life
SARA-N211-02X-02
06.57
A10.08
UBX-19030865
End of life
SARA-N280
SARA-N280-02B-00
06.57
A07.03
UBX-18005015
End of life
SARA-N280-02B-01
06.57
A09.06
UBX-19030865
End of life
SARA-N300
SARA-N300-00B-00
18.10
A01.04
UBX-20026729
Engineering sample
SARA-N310
SARA-N310-00X-00
18.13
A01.00
UBX-20033555
Initial production
u-blox or third parties may hold intellectual property rights in the products, names, logos and designs included in this document.
Copying, reproduction, modification or disclosure to third parties of this document or any part thereof is only permitted with the
express written permission of u-blox.
The information contained herein is provided “as is” and u-blox assumes no liability for its use. No warranty, either express or
implied, is given, including but not limited to, with respect to the accuracy, correctness, reliability and fitness for a particular
purpose of the information. This document may be revised by u-blox at any time without notice. For the most recent documents,
visit www.u-blox.com.
Copyright © u-blox AG.

SARA-N2 / N3 series - System integration manual
UBX-17005143 - R13 Contents Page 3 of 95
C1-Public
