UfiSpace S9500-30XS Manual

Hardware Installation Guide
S9500-30XS
Disaggregated Cell Site
Gateway
R1.1

S9500-30XS Hardware Installation Guide | i
Table of Contents
1Overview.............................................................................................................................1
2Preparation.........................................................................................................................2
Installation Tools......................................................................................................................2
Installation Environment Requirements..................................................................................3
Preparation Check List.............................................................................................................4
3Package Contents................................................................................................................5
Accessory List...........................................................................................................................5
Component Physical Information............................................................................................6
4Identifying Your System.......................................................................................................7
S9500-30XS Overview..............................................................................................................7
DC Version PSU Overview........................................................................................................8
AC Version PSU Overview........................................................................................................8
Fan Overview ...........................................................................................................................9
Port Overview ..........................................................................................................................9
5Rack Mounting..................................................................................................................10
6Installing Fan Modules.......................................................................................................11
7Installing Power Supply Units ............................................................................................12
8Grounding the Router........................................................................................................14
9Connecting Power .............................................................................................................16
DC Version..............................................................................................................................16
AC Version..............................................................................................................................17
10 Verifying System Operation...............................................................................................18
Front Panel LED....................................................................................................................18
PSU FRU LED ........................................................................................................................19
Fan FRU LED.........................................................................................................................19
Management port LED.........................................................................................................19
11 Initial System Setup...........................................................................................................20
12 Cable Connections.............................................................................................................22
Connecting the USB Extender Cable....................................................................................22
Connecting a Cable to the ToD Interface.............................................................................22

S9500-30XS Hardware Installation Guide | ii
Connecting a Cable to the BITS Interface............................................................................23
Connecting the GNSS Interface ...........................................................................................23
Connecting the 1PPS Interface ............................................................................................24
Connecting the 10MHz Interface.........................................................................................24
Connecting the Transceiver.................................................................................................24
13 Cautions and Regulatory Compliance Statements ..............................................................26

S9500-30XS Hardware Installation Guide | 1
1Overview
The UfiSpace S9500-30XS is a high-performance, versatile open networking white box
router that is designed to address the changing needs of backhaul transport requirements
as Telecoms make the transition from legacy technologies towards 5G.
It enables telecoms and service providers to deploy disaggregated open network
infrastructure to lower costs and rapidly scale existing services for edge computing, mobile
backhaul, and broadband access applications.
The S9500-30XS is future-proofed with a powerful 4-core processor, 10GE/25GE/100GE
high-speed interfaces, and full timing features supporting IEEE 1588v2 and SyncE, which
enables service providers to easily migrate from 2G, 3G, 4G BBUs to 5G RAN. It is suitable
for both indoor and outdoor deployments with redundant, hot swappable components for
convenience, increased availability, reliabilityand lower costs of maintenance
This document describes the hardware installation process for S9500-30XS.

S9500-30XS Hardware Installation Guide | 2
2Preparation
Installation Tools
Phillips #2 Screw Driver
Crimping Tool
14-AWG wire with ring terminal for
DC power supply
6-AWG green-and-yellow wire for grounding
Wire-stripping tools for
stripping 6-AWG copper wire
Console cable
•PC with terminal emulation software. Refer to the "Initial System Setup" section for
details.
•Baud rate: 115200 bps
•Data bits: 8
•Parity: None
•Stop bits: 1
•Flow control: None

S9500-30XS Hardware Installation Guide | 3
Installation Environment Requirements
•Power Reserve: The S9500-30XS power supply is available with:
1. DC Version: 1+1 active-active -36 to -75V DC power supply field replaceable unit or;
2. AC Version: 1+1 active-active universal 100 to 240V AC power supply field replaceable unit.
To ensure the active-active feed power design functions properly, a field with dual power
circuit is recommend with a reserve of at least 400 watts on each power circuit.
•Space Clearance: The S9500-30XS width is 17.32 inches (44cm) and shipped with a rack
mount brackets suitable for 19 inch (48.3cm) wide racks and adjustable mounting rails are
provided for rack depths of 22 inches (55.9cm) to 33 inches (83.8cm). The depth of the
S9500-30XS chassis is 11.89 inches (30.2cm) without the field replaceable units (FRUs). The
handle for the fan units will extend outwards by 1 inch (2.5cm) and the handle for the power
supplies will extend outwards by 1.06 inches (2.7cm). To accommodate the air inlet and front
cabling, a recommended minimum space clearance of 6 inches (15.2cm) for the front of the
unit. To accommodate the fan handle, it is recommended that a minimum space clearance of
1 inch (2.5cm) for the back of the unit. A total minimum reserve depth of 18.89 inches
(47.9cm) is required.
Figure 1.
Figure 2.

S9500-30XS Hardware Installation Guide | 4
• Cooling: The S9500-30XS airflow direction is front-to-back. Make sure the equipmenton
the same rack have the same airflow direction.
Figure 3.
Figure 4.
Preparation Check List
Task
Check
Date
Power voltage and electric current requirement
DC version: -36 to -75V DC, 16A maximum x2 or;
AC version: 100 to 240V, 6A maximum x2
Installation spacing requirement
S9500-30XS spacing requires a height of 1RU (1.75”/4.5cm), a width
of 19” (48.3cm) in width, and a depth of 18.89 inches (47.9cm)
Thermal requirement
S9500-30XS working temperature is -40 to 65°C (-40°F to 149°F),
airflow direction is front-to-back
Installation tools required
#2 Philips Screwdriver, 6-AWG wire stripper, and crimping tool
Accessories required
PC with terminal emulation software, console cable, 14-AWG wire
with ring terminal for power, 6-AWG wire for grounding

S9500-30XS Hardware Installation Guide | 5
3Package Contents
Accessory List
Item
Description
Spec. & Dimensions
Qty.
Weight
1
Grounding Lug
1.97” x 0.44” x 0.3”
(#6 AWG)
(50 x 11.1 x 7.5mm)
1 pcs
0.022lb (10.0g)/pcs
2
Screw Kit
(for Grounding Lug)
2 x Screws M4*L8.0mm
4 x M4 Lock Washers
1 set
0.008lb (3.5g)/set
3
Rack Mount Bracket
1.98” x 1.69” x 0.79”
(19” width rack)
(50.4 x 43 x 20mm)
2 pcs
0.14lb (65.4g)/2pcs
(0.07lb (32.7g)/pcs)
4
Screw Kit (for Rack
Mount Bracket)
8 x Screws M4.0*L6.5mm
1 set
0.02lb (7g)/set
5
Adjustable Mounting
Rail (for 4 posts)
16.02” x 1.69” x 0.83”
(406.8 x 43 x 21mm)
(for 22” to 33” rack depth)
2 set
1.39lb (630g)/2 set
(0.69lb (315g)/set)
6
Screw Kit
(for Adjustable
Mounting Rail)
8 x Screws M4.0*L6.5mm
1 set
0.02lb (7g)/set
7
USB 2.0 Type A Cable
7.87” (200mm)
1 pcs
0.02lb (10.5g)/pcs
8
AC Power Cord
(AC version only)
72.05” (1830mm)
2 pcs
1.03lb (468g)/2 pcs
(0.52lb (234g)/pcs)
9
RJ45 to DB9 Female
Cable
95.98”(2438mm)
1 pcs
0.23lb (105g)/pcs

S9500-30XS Hardware Installation Guide | 6
Component Physical Information
Specification
Item
Description
Weight
Total package contents
22.58lb (10.24kg)
Chassis without FRU
10.49lb (4.76kg)
Power Supply Unit (PSU)
DC PSU : 1.48lb (672.2g)
AC PSU: 1.58lb (716g)
Fan
0.2lb (90g)
Ground lug
0.022lb (10g)
Rack mount bracket
0.07lb (32.7g)
Adjustable mounting rail
0.69lb (315g)
USB cable
0.02lb (10.5g)
AC Power cord (AC version only)
0.52lb (234g)
RJ45 to DB9 Female Cable
0.23lb (105g)
Screw kit for ground lug
0.008lb (3.5g)
Screw kit for rack mount bracket
and adjustable mounting rail
0.02lb (7g)
Dimension
S9500-30XS (W x D x H)
17.32” x 11.89” x 1.71” (440 x 302 x 43.5mm)
PSU (W x D x H)
1.99” x 8.31” x 1.58” (50.5 x 211 x 40.2mm)
Fan (W x D x H)
2.03” x 2.28”x 1.66” (51.5 x 57.8 x 42.2mm)

S9500-30XS Hardware Installation Guide | 7
4Identifying Your System
S9500-30XS Overview
Figure 5.

S9500-30XS Hardware Installation Guide | 8
DC Version PSU Overview
Power supply unit (PSU) with 1+1 redundancy. Hot swappable, field replaceable unit (FRU).
Figure 6.
AC Version PSU Overview
Power supply unit (PSU) with 1+1 redundancy. Hot swappable, field replaceable unit (FRU).
Figure 7.

S9500-30XS Hardware Installation Guide | 9
Fan Overview
4+1 Redundant, hot swappable, field replaceable unit (FRU).
Figure 8.
Port Overview
Port ID
Form Factor
Maximum Support Distance
Support Speed
0 ~ 1
QSFP28
24.85mi (40km)
40/100G
20 ~ 27
SFP28
24.85mi (40km)
10/25G
0 ~ 19
SFP+
49.7mi (80km)
1/10G
Figure 9.

S9500-30XS Hardware Installation Guide | 10
5Rack Mounting
It is recommended that installation be done by two trained professionals. One
individual should hold the equipment in position on the rack while the other
secures it in place.
1. Secure the rack mount brackets onto the router.
Align the rack mount brackets with the holes provided on the both sides of the case and
secure the brackets using the 8 M4.0*L6.5mm screws provided with the package.
Figure 10.
2. Secure the router onto the rack posts.
Mark the location on both posts to ensure it is leveled before securing the router onto
the rack. (See Figure 11). For a 4 post rack, first secure the adjustable mounting rail to the back
of the router using the M4.0*L6.5mm screws provided in the package. Then secure the
adjustable mounting rail to the rack posts. (See Figure 12).
Illustrations are for reference purposes only. Actual scenario may differ.
Screws for rack posts not included.
Figure 11.
Figure 12.

S9500-30XS Hardware Installation Guide | 11
6Installing Fan Modules
The fan modules are hot swappable field replaceable units (FRUs), which can be replaced while the
router is operating as long as all the remaining modules are installed and in operation. The fans
come pre-installed and the following steps are instructions on how to install a new fan module.
1. Loosen the captive screw located on the fan module.
Figure 13.
2. Grip the fan's handle and firmly pull it out of the fan bay.
Figure 14.
3. Align the new fan module with the fan bay.
4. Carefully slide the new fan module into the fan bay and gently push until it is flush with the
case.
5. Secure the captive screw on the fan module to lock the fan in place.
Figure 15.

S9500-30XS Hardware Installation Guide | 12
7Installing Power Supply Units
The power supply unit (PSU) is a hot swappable field replaceable unit (FRU) and can be replaced
while the router is operating as long as the remaining (second) PSU is installed and in operation.
The PSUs comes pre-installed and the following are instructions on how to install a new PSU.
DC Version:
AC Version:
Figure 16.
Shock hazard!
For safety, please disconnect all power inputs from the power supply unit before
servicing the router.
1. Locate the release tab on the PSU. Then press and hold down the release tab to unlock the PSU
from the power bay.
2. While holding down the release tab, grip the PSU's handle and firmly pull it out of the power
bay.
DC Version:
AC Version:
Figure 17.

S9500-30XS Hardware Installation Guide | 13
3. Align the new PSU with the power bay, ensuring the PSU’s power connector is in the correct
position.
4. Carefully slide the new PSU into the power bay and gently push until it is flush with the case.
5. An audible click will be heard when the PSU is installed correctly. The PSU will not go in all the
way if it is in the wrong direction.
Illustrations are for reference purposes only. Actual scenario may differ.
DC Version:
AC Version:
Figure 18.

S9500-30XS Hardware Installation Guide | 14
8Grounding the Router
It is recommended that equipment changes be done on a grounded rack system. This will reduce
or prevent the risk of shock hazards, equipment damage, and potential of data corruption.
The router can be grounded from the router's case and/or the power supply units (PSUs). When
grounding the PSUs, ensure that both PSUs are grounded at the same time in case one of them is
removed. A grounding lug, M4 screws and washers are provided with the package contents,
however, the grounding wire is not included. For convenience, there are two locations on the case
in which the grounding lug may be fixed.
The following instructions are for grounding the router.
This equipment must be grounded. Do not defeat the ground conductor or
operate the equipment without correctly grounding the equipment. If there is any
uncertainty about the integrity of the equipment's grounding, please contact the
electrical inspection authority or a certified electrician.
1. Before grounding the router, ensure that the rack is properly grounded and in compliance with
local regulatory guidelines. Ensure that there is nothing that can obstruct the connection for
grounding and remove any paint or materials that may prevent good grounding contact.
2. Strip the insulation from a size #6 AWG grounding wire (not provided within the package
contents), leaving 0.5” +/-0.02” (12.7mm +/-0.5mm) of exposed grounding wire.
3. Insert the exposed grounding wire all the way into the hole of the grounding lug (provided with
package contents).
4. Using a crimping tool, firmly secure the grounding wire to the grounding lug.
Figure 19.

S9500-30XS Hardware Installation Guide | 15
5. Locate the designated location for securing the grounding lug, which is located on the side of
the router.
6. Using 2 M4 screws and 4 washers (provided with the package contents), firmly lock the
grounding lug to either of the designated grounding locations on the router.
Figure 20.
Figure 21.
Figure 22.

S9500-30XS Hardware Installation Guide | 16
9Connecting Power
DC Version
1. Ensure there is enough power to supply the system.
The maximum system power consumption is 224 watts. It is recommended to ensure that
enough power is reserved from the power distribution system before installation. Also, please
ensure that both PSUs have been properly installed before powering up the equipment, as the
S9500-30XS is designed to support 1 + 1 power redundancy.
2. Attach the power cable.
Locate the DC power screw-type terminal block on the DC PSU. Attach the UL 1015, 14 AWG DC
power cable (not provided within the package contents) to the DC inlet connector on the PSU.
Dangerous voltage!
•Must be powered off before removing!
•Verify that all electrical connections are grounded before powering on
•The DC power source must be reliably grounded
Figure 23.
3. Tighten the screws to the specified torque.
Tighten the screws to a torque value of 7.0+/-0.5kgf.cm. If the torque is not enough, the lug
will not be secure and may cause malfunctions. If the torque is too much, the terminal block or
lug may be damaged.
Figure 24.

S9500-30XS Hardware Installation Guide | 17
4. Feed DC power into the system.
The PSU will immediately output 12V and 5VSB to the system when a -36V to -75V DC power
source is applied. The PSU has a built in 20 amperes, fast acting fuse based on the PSU
maximum capacity, which will act as a second tier system protection in case the power
distribution unit’s fuse is not functioning.
5. Verify that the power supply is operating.
If connected correctly, when turned on, the LED on the PSU will light up with a Green color
designating normal operation.
AC Version
1. Ensure there is enough power to supply the system.
The maximum system power consumption is 224 watts with an input voltage of 100-240V AC. It
is recommended to ensure that enough power is reserved from the power distribution system
before installation. Also, please ensure that both PSUs have been properly installed before
powering up the equipment, as the S9500-30XS is designed to support 1 + 1 power
redundancy.
2. Attach the power cable.
Plug the power cord into the AC PSU and secure it tightly.
3. Verify that the power supply is operating.
If connected correctly, when turned on, the LED on the PSU will light up with a Green color
designating normal operation.
Figure 25.
