Ulvac Vd30c User manual

YK15-0009-DI-002-04

INSTRUCTION MANUAL

OIL SEALED ROTARY VACUUM PUMP

VD30C

VD40C

VD60C

VD90C

Before using this product, be sure to read this operation manual.

Keep this manual with care to use at any time.

ULVAC, Inc.

Components Division

http://www.ulvac.co.jp/

YK15-0009-DI-002-04

0. Before Using This Product

We thank you very much for purchasing our product.

You are kindly requested, upon delivery of this product, to check that the delivered product is

exactly what you have ordered and it has no damage caused by transport or the like.

This manual gives description on operation and maintenance procedure appropriate to use

this product in safe and effective way. Please read this manual beforehand to correctly use the

Pump.

You are requested to install and operate this product in compliance with the laws and

regulations relating to the safety, e.g. Fire Defense Law, Electric wiring regulation and so on in

the country and region you use this product. Consequently you shall be requested to attend

general safety lectures officially effective in the area, such as electrical safety, Cargo handling

safety and so on. Note that any person not attended such lectures shall be restricted from

handling this product. Operators shall need to attend such kind of training and have special

knowledge, skill and title regarding the electricity, machinery, cargo, vacuum and so on.

This product is designed to conform to regulations valid at the time of issue of this manual and

its conformity is not ensured if any of regulations shall be changed in the future.

The performance and safety of this product might not be ensured if any of the devices put

together did not conform to same regulations or this product itself was modified. ULVAC shall be

not liable to guarantee performance and safety in such cases above. Any modification of this

product by the user is out of the scope of guarantee by us and not be guaranteed in any manner.

Be sure to clear any energy sources, e.g. electricity, coolant and so on of this product before

installing or removing this product.

Please note that any of the parts used in this product shall keep the performance at the time of

the shipment but shall not survive eternally. Any of the parts cannot, under any application

supposed under socially-accepted idea, help but inevitably deteriorate its performance and get

easily result in causing trouble of this product. You are kindly requested consequently to take

your application situation into consideration and help yourself to implement the protective

maintenance so as to avoid troubles.

Through implementation of the protective maintenance, you shall reduce occurrence of the

trouble due to wear and/or failure of the part and bring reducing the occurrence of the downtime

caused by this product trouble and fire as well as a risk of affecting the another process.

We would like to ask you again to establish the protective maintenance plan as well as

conduct the part replacement and overhaul in accordance with such a plan.

Please do not hesitate to contact our sales office or agency closest to you or the Components

Division if you had any question or unclear on the use.

YK15-0009-DI-002-04

IMPORTANT

①Author's copyright of this instruction manual belongs to

Components Division of ULVAC, Inc.

It is prohibited to copy a part and/or this entire manual without

authorization by Components Division of ULVAC, Inc.

②It is prohibited to use this instruction manual except for

explanation when using the VD30C, VD40C, VD60C and VD90C

and

other purpose Components Division of ULVAC, Inc. agreed.

③It is prohibited to hand over and disclose this instruction manual to third

parties without agreement by

Components Division of ULVAC, Inc.

0.1 Safety Symbol Marks

We display symbol marks regarding the safety in this manual and on this product to make

clear items to observe. Descriptions attached to the symbol are classified as illustrated below;

0.2 Meanings of Safety Symbol Marks

DANGER

If the user makes a mistake in handling, it indicates an imminent

possibility that the user is subject to death or heavy injury.

WARNING

If the user makes a mistake in handling, it indicates a possibility that

the user is subject to death or heavy injury.

CAUTION

If the user makes a mistake in handling, it indicates a possibility

that the user is subject to

moderate injury or it leads to significant

damage of the machine. It indicates a possibility that damage of the

machine is caused and the normal operation is impaired.

IMPORTANT

[IMPORTANT] description shall be given where there is particular

information to notice for the operation or maintenance work of

this

product

Training for the electrical safety is required as there is a risk of

electrical shock.

Check and ensure that the Pump

is sufficiently cooled down as this

section keeps high temperature after having stopped the Pump.

YK15-0009-DI-002-04

iii

0.3 Safety Precautions

Descriptions are given as the method to keep away from danger and actions that must be

restricted on the use of this product.

Use of this product and this Instruction Manual.

IMPORTANT

Please read this Instruction Manual before starting installation, operation

check or maintenance of this product to use it in long term. You are

requested to fully understand the safety precautions, specifications and

operation methods of

this product

DANGER

Use of the toxic, combustible or combustion susceptible gas other than

inactive gas is not allowed as there is a risk of leakage of the gas from

the Pump unit if it was exhausted by the vacuum pump.

DANGER

Use of the toxic, combustible or combustion susceptible gas and

substance other than inactive gas is not allowed as there is a risk of

causing fire or explosion inside the Pump

unit if it was exhausted by the

vacuum pump.

DANGER

It is not allowed to use any corrosive gas other than inactive gas as it

might cause corrosion and/or give damage on pump parts when

discharged through vacuum pump.

YK15-0009-DI-002-04

DANGER

Pump oil as well as the Pump unit

becomes toxic should the toxic gas

was sucked in the vacuum pump. Pay attention to execute maintenance

work.

WARNING

We would be obliged to refrain from handling and/or executing

maintenance of this product

if the detail of used hazardous substance

was not disclosed or this product

has exhausted such substance that the

detoxification process is hardly conducted.

WARNING

This Instruction Manual shall absolutely need to be delivered to the last

user that uses this product.

WARNING

You are kindly requested to acknowledge that specifications and/or price

of this product and descr

iption of the Instruction Manual are subject to

change without prior notice for improvement.

Any change shall update the version number at the top right of the

Instruction Manual cover and issue the revised version.

If you need the latest manual, please

feel free to contact our Components

Division.

WARNING

To export this product abroad, you have to clear the examination in

accordance with the Foreign Exchange law, Foreign Trade law and

relevant decree, ordinance and order.

Please feel free to contact our sales office or agency closest to you or

our Components Division.

YK15-0009-DI-002-04

Installation and storage

WARNING

①

This product is packed with the wooden frame. Please ask the special

agency for dismantling it.

Advise the dismantling agent to wear leather gloves and use

appropriate tools such as pinch bar as they have a risk of cutting the

hand by nail or chip.

②Gi

ve the instruction them further to use the unloading machinery such

as crane to take out this product

of the wooded frame, lift it up with

its top eyebolt and transfer it on lifting.

Check the eyebolt whether it has no error before use.

③Only the technically entitled person should be in charge of

conducting the unloading operation and operating the unloading

machinery.

④There is a risk that the Pump

might drop or lay down when attempted

unreasonable operation or machinery setup was not sufficient. You

are strictly restricted to enter beneath

the Pump

Transfer

WARNING

①You have a risk of giving damage to your back as the load la

rger than

safety standard shall be required to transfer this product.

VD30C: 58kg

VD40C: 60kg

VD60C: 90kg

VD90C: 113kg

Be sure to use the loading machinery (such as mobile crane) to lift up

the Pump

or load it on the pallet and fix it and run the Pallet truck for

its transfer.

②Never try to enter beneath the Pump unit when lifted it up.

Use

its top eyebolt

to load/unloa

d the unit.

YK15-0009-DI-002-04

Countermeasure to the earthquake

WARNING

There is a risk that the Pump

lays down or slides and breaks peripheral

units if it was not correctly fixed. Be sure to give allowances to the

vacuum piping and electric cables so that they absorber vibrations to

prevent them from breaking and/or dismantling.

Inlet / outlet port piping <Mounting>

WARNING

Check and ensure that any of hazardous energy is blocked before

starting the operation.

Power Supply wiring <Mounting>

WARNING

①Check and ensure that any of hazardous energy is

blocked before

starting the operation.

Entitled staff should conduct the wiring operation.

Erroneous wiring work might cause a fire.

②

Conduct the wiring operation correctly in compliance with laws and

rules concerning the safety (e.g. Fire Defense Law, Electric Equipment

Technology standard, Internal line cord) in the country and region you

use this product.

③Ensure to have a correct grounding.

You have a risk of getting electrical shock in case of failure or electric

leakage.

④You are recommended further to install a dedicated earth leakage

breaker.

⑤It is imperative to put the Overload protection device.

Otherwise it would cause the motor burn out and/or fire.

⑥

Wire size, please determined by considering the voltage drop of the

wire.

Typically, the voltage drop, please to be within 2% of the rated voltage

of the motor.

Voltage drop calculation：

√3 ×wire resistance (Ω/ km)×Wiring length (m) ×motor rated current (A) ×10-

※motor rated current, refer to "Table 4".

YK15-0009-DI-002-04

vii

Operation

WARNING

This pump is not pressure-proof.

Do not run the Pump

on blocking the exhaust outlet or putting any device

that might hamper gas passage onto the outlet. There is a risk that the

pressure inside the Vacuum pump rises up

to cause break or oil leak of

the casing or Oil level gauge resulting in overload of the motor.

This product is not made as the withstand pressure structure. Ensured

pressure value of the Pump shall be 0.03MPaG (0.3kg/cm2

G) (Gauge

pressure).

WARNING

Do not operate the Pump

in hazardous area (where there is a risk of

creating hazardous atmosphere by explosive gas). It might cause injury

and/or fire.

WARNING

①

Be sure to turn OFF the Power Supply to execute check and repair.

You have a risk of getting electrical shock or injury by accidental

sudden move.

②

Person other than Repair technician should not be in charge of

dismantling, repairing or remodeling this product

. You have a risk of

getting injured or electrical shock by a fire or erroneous move.

③Do not touch the Motor, vacuum pump or piping during the Pump

operation and just after stopped it while the Pump

unit keeps high

temperature. You have a risk of getting burned.

④

Should you found any malfunction or error, just turn OFF the Power

Supply to prevent accident and ask the agency or closest Service

Center for check and repair.

WARNING

①

Do not attempt to put your hand or article in the opening of the motor;

you have a risk of getting electrical shock, injury or casing a fire.

②

Do not touch any rotary section such as the motor, main spindle or

spindle joint during operation of the Vacuum pump;

it shall bring in injuries.

③

Strictly refrain from putting any combustible substance in and around

1m of the motor and Vacuum pump;

there is a risk of getting a fire.

④Do not put a wall or obstacle in and around 0.1m of the air in

let of the

motor (Motor edge face).

You have a risk of getting burned or fire caused by over heat.

YK15-0009-DI-002-04

viii

CAUTION

Be sure to lubricate the machine.

If the lubrication oil came down lower than limit level during operation, it

might give damage on the bearing, gear and shaft

sealing and result in

leak, noise, motor overload and operation stop.

Power Supply wiring <Dismantling>

WARNING

Be sure to cut off the electricity before starting install or dismantling

operation.

Inlet / outlet port piping <Dismantling>

WARNING

①Take off the piping following the Install Manual of the system.

②The Inlet and outlet piping remains very hot while

after having stopped

the Pump.

Be sure to take it off after the Pump has sufficiently cooled down.

③Make airtight completely the Pump exhaust outlet with a blank flange.

Transfer

WARNING

①

You have a risk of giving damage to your back as the load larger than

safety standard shall be required to transfer this product.

VD30C: 58kg

VD40C: 60kg

VD60C: 90kg

VD90C: 113kg

Be sure to use the loading machinery (such as mobile crane) to lift up

the Pump

or load it on the pallet and fix it and run the Pallet truck for

its transfer.

②Never try to enter beneath the Pump unit when lifted it up.

Use its top eyebolt to load/unloa

d the unit.

YK15-0009-DI-002-04

0.4 Types and Descriptions of Warning Labels Displayed on This Machine and

Displayed Positions

Warning labels are attached on the warning locations in this system.

Be sure to check them before starting operation of the Pump.

Before use, read through the instruction manual and fully

understand its contents.

・

You may get an electric shock in the area around a portion

with this warning label. Before maintenance or wiring, be sure

to turn off the primary power supply.

・

Be sure to close the lid of the terminal box before operating

this unit. Never open it during operation.

During operation or for a while after operation stops, do not

touch the unit as each portion is at a very high temperature. -

If a human body touches the unit, it may get burned.

・This product is not made as the withstand pressure

structure. Ensured pressure value of the Pump shall be

0.03MPaG (0.3kg/cm2G) (Gauge pressure).

・Do not run the Pump on blocking the Exhaust outlet or

putting any device that might hamper gas passage onto the

outlet. There is a risk that the pressure inside the vacuum

pump rises up to cause break the casing or Oil level gauge

resulting in overload of the motor.

・Following gases cannot be evacuated because these gases

may cause the

pump inner pressure to increase due to internal combustion.

1) explosive gas

2) flammable gas

3) gas which increases the susceptibility of substances to

burn.

Long term storage of the Vacuum pump without operation

might possibly cause trouble in operation caused by rust i

you kept the Pump

long time without operating it, ask a closest

Service Center for the check.

Indoor Use Only

Mount at least 100mm from side walls.

Before wiring, please confirm the power-

supply voltage you

use.

Please confirm the power-supply volta

ge you'll use and

change crossline in the terminal box.

Refer to “3.5 Electrical Connection”.

YK15-0009-DI-002-04

Fig. 1 Warning Label

This product can be used in compliance with the requirements of UL1450 "Standard for

Motor-Operated Air Compressors, Vacuum Pumps, and Painting Equipment" by replacing the

warning label according to the figure below.

Fig. 2 Warning Label replacement

①：Hazardous voltage.

②：Hot heating part present.

③：There is a risk of explosion.

④：Checkup after storage for a long period.

⑤：Installation location attention.

YK15-0009-DI-002-04

0.5 Acceptance and Storage of the Pump

0.5.1 Unpacking/Acceptance of the Pump

WARNING

①

This product is packed with the wooden frame. Please ask the special

agency for dismantling it.

Advise the dismantling agent to wear leather gloves and use

appropriate tools such as pinch bar as they have a risk of cutting the

hand by nail or chip.

②Giv

e the instruction them further to use the unloading machinery such

as crane to take out this product

of the wooded frame, lift it up with

its top eyebolt and transfer it on lifting.

Check the eyebolt whether it has no error before use.

③Only the technically entitled person should be in charge of

conducting the unloading operation and operating the unloading

machinery.

④There is a risk that the Pump

might drop or lay down when attempted

unreasonable operation or machinery setup was not sufficient. You

are strictly restricted to enter beneath

the Pump

Upon delivery of this product, check first that the delivered is exactly what you have ordered

and there is no break or damage through transport or the like. Claim after use of this product

might be resolved with a charge.

Although we pay full attention on shipping, you are kindly requested to check the following

upon unpacked this product.

IMPORTANT

①Whether the delivered is exactly the one you have ordered.

②Whether accessories (standard

accessories, optional parts) are

attached or not.

③Whether there is no break or damage through transport or not.

④

Whether any bolt or nut got loose or taken off through transport or

not.

Should you found any trouble, please do not hesitate to contact our Sales

division or your agency.

Table. 1 standard accessories

Part name Specification Quantity Remarks

Oil one time portion

ULVOIL R-72

1 set

For the consumed amount, refer to the specification table.

Quick Start Manual

Japanese

／

English

1 copy －

※Fluorine oil is not included in the shipment for F specifications. If fluorine oil is required, it must be ordered

separately.

YK15-0009-DI-002-04

xii

0.5.2 Transfer

WARNING

①

You have a risk of giving damage to your back as the load larger than

safety standard shall be required to transfer this product.

VD30C: 58kg

VD40C: 60kg

VD60C: 90kg

VD90C: 113kg

Be sure to use the loading machinery (such as mo

bile crane) to lift up

the Pump

or load it on the pallet and fix it and run the Pallet truck for

its transfer.

②Never try to enter beneath the Pump unit when lifted it up.

Use its top eyebolt to load/unload the unit.

YK15-0009-DI-002-04

xiii

0.5.3 Ambient Condition for Storage, Install and Operation

As precise clearances are provided with this machine, be sure to fulfill the following for its storage,

install and operation;

①Ambient temperature and humidity for storage : -10°C to 50°C, less than 95%RH

②Ambient temperature and humidity for operation : 4°C to 40°C, less than 80%RH

※However, use pump oil "ULVOIL R-42" for operation at 4-10°C,

and pump oil "ULVOIL R-72" for operation at 10-40°C.

③Height (for both storage and operation) : Lower than 1,000 meters altitude

④External vibration (for both storage and operation) : Vibration acceleration less

than114dB (0.5G)

⑤Miscellaneous (for both storage and operation)

a. There shall be no corrosion behavior or explosive gas.

b. There shall be no freeze or dew formation.

c. There shall be no dust.

d. It shall be in house.

e. Another pump shall not be put on the Pump.

The Pump shall not be laid down nor put touching its motor edge face or oil gauge edge

face with the ground.

f. There shall be no direct sun beam.

g. Heat source shall be put away from the Pump.

CAUTION

①Do not give the Pump a shock or lay it down. It might impair

the

Pump operation.

②

Strictly refrain from putting any combustible substance in and

around 1m of the motor and Vacuum pump;

there is a risk of getting a fire.

③Do not put a wall or obstacle in and around 0.1m of the air in

let of

the motor (Motor edge face).

You have a risk of getting burned or fire caused by over heat.

④Indoor use only

YK15-0009-DI-002-04

xiv

Install the machine horizontal to a place where there are less dust and humidity.

In case you fix the Pump to floor, fix the Pump to the floor with bolts at four places.

Fix the Pump horizontally so that there is not a wobble.

Refer to “3.1 Storage/ Installation”, too.

Model

Foot print Bolt Anti-vibration

Rubber mount

VD30C

VD40C

VD60C

The Pump has four holes.

The Pump is fixed with four bolts.

More than

“M8 x 20mm”

Kurashiki Kako., Ltd.

Model：

KLB-3560(Recommended)

* NOT included

VD90C

The Pump has eight holes.

The Pump is fixed with four bolts:

Four places of outside

center side of the Pump.

The detail of the holes position: Refer to the Fig. 3 ~ Fig. 10.

0.6 Protective Device

This machine is equipped with the Three-phase AC motor.

This motor is not equipped with the protective device. Put an overload protective device to

connect through the motor with the Power Supply.

Refer to “3.5 Electrical Connection” to select the overload protective device. It is

recommended to put together another protective device such as a earth leakage breaker.

WARNING

It is imperative to put the Overload protection device.

Otherwise it would cause the motor burn out and/or fire.

YK15-0009-DI-002-04

Contents-1

Table of Contents

0. Before Using This Product .......................................................................................................................i

0.1 Safety Symbol Marks.........................................................................................................................ii

0.2 Meanings of Safety Symbol Marks....................................................................................................ii

0.3 Safety Precautions............................................................................................................................iii

0.4 Types and Descriptions of Warning Labels Displayed on This Machine and Displayed Positions .ix

0.5 Acceptance and Storage of the Pump..............................................................................................xi

0.5.1 Unpacking/Acceptance of the Pump..........................................................................................xi

0.5.2 Transfer .....................................................................................................................................xii

0.5.3 Ambient Condition for Storage, Install and Operation ............................................................. xiii

0.6 Protective Device............................................................................................................................xiv

1. For Your Safety Use ............................................................................................................................ 1

1.1 This Product Intrinsic Hazardous Nature and Safety Measures ...................................................... 1

1.1.1 ! Danger Leakage of dangerous gas and dangerous materials......................................... 1

1.1.2 ! Warning Transfer of heavy material ................................................................................. 1

1.1.3 ! Warning Electric shock ................................................................................................... 2

1.1.4 ! Warning Explosion............................................................................................................ 2

1.1.5 ! Caution High temperature ................................................................................................ 2

1.2 Safety Data Sheet（SDS）................................................................................................................. 3

2. Pump Outline....................................................................................................................................... 4

2.1 Characteristics.................................................................................................................................. 4

2.2 Performance Specifications.............................................................................................................. 7

2.3 System Flow ..................................................................................................................................... 8

2.4 Dimensional drawing ........................................................................................................................ 9

2.5 Pump Performance..................................................................................................................... 13

2.5.1 Ultimate Pressure..................................................................................................................... 13

2.5.2 Pumping Speed........................................................................................................................ 13

2.5.3 Power Requirements................................................................................................................ 15

3. Mounting............................................................................................................................................... 16

3.1 Storage/ Installation........................................................................................................................ 16

3.2 Lubrication ...................................................................................................................................... 17

3.3 Inlet port Piping............................................................................................................................... 18

3.4 Outlet port Piping............................................................................................................................ 19

3.5 Electrical Connection...................................................................................................................... 20

4. Operation.............................................................................................................................................. 24

4.1 Caution on Operation ..................................................................................................................... 24

4.2 Operation Start ............................................................................................................................... 26

YK15-0009-DI-002-04

Contents-2

4.3 Operation Stop................................................................................................................................ 27

4. 4 Gas Ballast Function ..................................................................................................................... 28

The............................................................................................................................................................ 29

4. 5 Vacuum Pump Oil For cold district ................................................................................................ 29

4.6 Oil mist trap (Optional).................................................................................................................... 30

5. Maintenance and Check ...................................................................................................................... 31

5.1 Maintenance ................................................................................................................................... 31

5.2 Regular Check................................................................................................................................ 32

5.2.1 Pump Oil Level Check.............................................................................................................. 33

5.2.2 Vacuum Pump Oil Check ......................................................................................................... 33

5.2.3 Replace Vacuum Pump Oil ...................................................................................................... 35

5.2.4 Oil Leak Check ......................................................................................................................... 36

5.2.5 Checking Gas Ballast Function................................................................................................ 36

5.2.6 Checking Metal Mesh at the Suction Inlet ............................................................................... 36

5.2.7 Checking Noise and Abnormal Vibration ................................................................................. 36

5.2.8 Checking Coupling and Spider................................................................................................. 37

5.2.9 Checking Oil Mist Trap (option)................................................................................................ 38

5.2.10 Checking drain valve.............................................................................................................. 38

5.3 Checkup after storage for a long period......................................................................................... 39

5.4 Overhaul ......................................................................................................................................... 39

5.5 Trouble shooting ............................................................................................................................. 40

6. Removal / transport.............................................................................................................................. 47

6.1 Operation procedure....................................................................................................................... 47

7. Disposal................................................................................................................................................ 48

8. Warranty Clauses................................................................................................................................. 49

8.1 Warrantable Items .......................................................................................................................... 49

8.2 Duration of guarantee..................................................................................................................... 49

8.3 Warrantee scope ............................................................................................................................ 49

8.4 Response procedure ...................................................................................................................... 49

8.5 Disclaimer ....................................................................................................................................... 50

8.6 Others ............................................................................................................................................. 50
