Unify OpenScape CP600 User manual

OpenScape Desk Phone CP600/CP600E
OpenScape 4000
User Guide HFA
A31003-C1000-U114-3-7619

Provide feedback to further optimize this document to [e-mail].
As reseller please address further presales related questions to the responsible presales organization at Unify or at your
distributor. For specific technical inquiries you may use the support knowledgebase, raise - if a software support contract is in
place - a ticket via our partner portal or contact your distributor.
Our Quality and Environmental Management Systems are
implemented according to the requirements of the ISO9001 and
ISO14001 standards and are certified by an external certification
company.
Copyright © Unify Software and Solutions GmbH & Co. KG 08/2018
All rights reserved.
Reference No.: A31003-C1000-U114-3-7619
The information provided in this document contains merely general descriptions or
characteristics of performance which in case of actual use do not always apply as
described or which may change as a result of further development of the products.
An obligation to provide the respective characteristics shall only exist if expressly agreed in
the terms of contract.
Availability and technical specifications are subject to change without notice.
Unify, OpenScape, OpenStage and HiPath are registered trademarks of Unify Software and
Solutions GmbH & Co. KG. All other company, brand, product and service names are
trademarks or registered trademarks of their respective holders.
unify.com

Important Notes 3
Important Notes
Symbol
Software update
During a software update, the phone must not be disconnected from the power supply unit and/or
the LAN. An update action is indicated by messages on the display and/or by flashing LEDs.
Care and cleaning instructions
• Never spray the phone with liquids as the penetrating fluids can lead to malfunctions or may da-
mage the device.
• Do not use substances such as alcohol, chemicals, solvents or scouring agents, as these sub-
stances can lead to surface damage.
• Clean the phone with a soft and slightly damp cloth.
Online resources
This document along with additional information is available online at: http://www.unify.com/
Support.
Technical notes, current information about firmware updates, frequently asked questions, and lots
more can be found on the Internet at: http://wiki.unify.com/.
For safety reasons, the phone should only be supplied with power as follows:
• using the appropriate original power supply unit,
• over a LAN with PoE (Power over Ethernet), which complies with the IEEE
802.3af standard.
Never open the telephone! Should you encounter any problems, consult system
support.
Use only original accessories!
The use of other accessories is hazardous and will render the warranty, extended
manufacturer's liability, and the CE and other markings invalid.
The device conforms to the EU Directive as attested by the CE marking. The CE
Declaration of Conformity and, where applicable, other existing declarations of con-
formity as well as further information on regulations that restrict the usage of subs-
tances in products or affect the declaration of substances used in products can be
found in the Unify Expert WIKI at http://wiki.unify.com/ under the "Declarations of
Conformity" section.
The adjacent symbol indicates that any electrical and electronic products installed
and sold in countries of the European Union to which the WEEE2 Directive 2012/19/
EU applies should be disposed of separately from the municipal waste stream in
appropriate collection systems.
Information concerning the proper disposal of your Unify product in the business-to-
business market segment is available from your local sales representative in Unify or
partner sales.
7
7
7

4Important Notes
License information
• More information about the EULA and Open Source licenses you can find on the Web interface,
section ”Licenses”page 155.
Installation location information
• The telephone may only be operated using the LAN cabling internally in the building. The device
should be connected to the IP infrastructure using a shielded LAN cable: Cat-5 for 100 Mb/s or
Cat-6 for 1000 Mb/s. Make sure in the building installation that this cable shielding is earthed.
• The telephone is designed for operation in a sheltered environment within a temperature range
of 5 °C to 40 °C.
• Putting the telephone in a room with higher levels of dust can result in a reduced service life of
the device.
• Do not place the device in direct sunlight or other sources of direct heat. This is liable to damage
the electronic components and the casing.
• Do not install the phone in bath or shower rooms.
