Uplift Desk SoCo User manual

For further info or assistance, visit upliftdesk.com
call 800-349-3839 or email [email protected]
©2020 UPLIFT Desk®. All Rights Reserved
355 lb
two person
assembly
SoCo Lounge Seating Collection
®

Thank you for choosing UPLIFT Desk.

© UPLIFT Desk • 800-349-3839 • 512-614-3152 • [e-mail] • upliftdesk.com 3
Before assembling or attaching any components:
We recommend that you sort your parts and plan
your space.
This will help you to understand where components
will go and in what order to assemble and attach them.
The options for conguring your SoCo furniture piec-
es are limited only by your imagination, but you can
visit our website for some typical conguration ideas.
The main components of the SoCo Collection are the
SoCo Seats (with and without back) and SoCo Table
shown to the left. We will refer to these components
as “modules” in these instructions. The modules can
be arranged in various congurations and joined to-
gether using the included Connectors. See the Mod-
ules section for instructions on connecting these com-
ponents.
Available accessories include the SoCo Wedge Table,
SoCo Circle Table, SoCo Privacy Screen, and SoCo
Armrest Bolster Cushion. Assembly and attachment
steps for these components will be covered rst in
these instructions.
SoCo Collection Components
Before you begin connecting modules together, it is
important to rst think about where your accessories
will be located within your planned conguration.
Armrest Bolster Cushions are used between two
SoCo Seat modules (with or without backs) and must
be placed before connecting the two modules to-
gether (see Armrest section).
The Wedge Table can be positioned between any
two SoCo Seat or Table modules. These require as-
sembly and attach the bottom of the modules (see
Wedge Table section).
The Circle Table will need to be attached to the un-
derside of one of the SoCo Seat modules. This should
be done prior to connecting the module to another
module (see Circle Table section).
Privacy Screens can only be attached to the backs or
sides of SoCo Seat or Table modules. They cannot be
attached between two modules that are going to be
joined together (see Privacy Screen section).
Wedge tableArmrest
bolster
cushion
Seat with back Seat without back Table
Circle table Privacy screen

© UPLIFT Desk • 800-349-3839 • 512-614-3152 • [e-mail] • upliftdesk.com
4
Wedge table Bracket
(qty 4)
M6x16 screw
(qty 12)
Package Contents for one Wedge Table
Wedge Table
Step 1
Wedge tables can only be attached to SoCo Seat or
Table modules.
After determining which modules will have Wedge
tables attached and which sides of the modules the
tables will be attached to, ip the modules over to ac-
cess the mounting holes.
Attach two Brackets (as shown) to each module on
the sides the Wedge table will be attached. Install two
M6x16 screws per bracket and tighten with a 4mm Al-
len wrench.
Step 2
Once the Brackets have been attached, ip the mod-
ules upright.
Next, align the modules so that the Wedge table can
rest on the tops of the Brackets. From the underside,
loosely install one M6x16 screw through each bracket
hole and into one of the threaded holes in the Wedge
table.
After all four screws have been started, tighten them
with a 4mm Allen wrench.
Continue this process until all Wedge tables and mod-
ules have been connected.

© UPLIFT Desk • 800-349-3839 • 512-614-3152 • [e-mail] • upliftdesk.com 5
Circle table M6x16 screw
(qty 6)
Package Contents
Circle Table
Step 1
The Circle table is designed to attach to the bottom of
a module on the front right hand side. When you have
picked a module to attach the table, ip it over and
align the six Circle table mounting points with the six
holes on the bottom of the module.
Attach the Circle table to the module using six M6x16
screws and tighten using a 4mm Allen wrench. Care-
fully ip the module with the attached Circle table up-
right and move it to the desired location.
See the Module section for details on connecting
modules together.
Privacy screen
(qty 2 per box)
M6x16 screw
(qty 8)
Corner
connector kit
Linear
connector kit
#8x1’’ screw
(qty 2 per kit)
#8x1’’ screw
(qty 2 per kit)
Package Contents - Screen Package Contents - Connector Kits (Ordered as needed)
Privacy Screen
Step 1
Attaching the Privacy screens to the modules is easi-
est if the modules are tipped onto their front face.
Swivel the brackets out from the bottom of each
screen towards the screen’s fabric seam (to hide the
seam after the panel is installed). Align the holes in
each bracket with the bracket holes at the bottom of
the module and attach using two M6x16 screws per
bracket. Tighten using a 4mm Allen wrench. Repeat
process for additional screens where needed.
Note: The Privacy screens should only be attached to the backs and outer sides of the modules.
They should not be attached to the fronts of modules. They can not be attached between two connected modules.

© UPLIFT Desk • 800-349-3839 • 512-614-3152 • [e-mail] • upliftdesk.com
6
Note
If your desired furniture conguration requires con-
necting modules together, you can skip to the Mod-
ules section on page 7.
See Armrest section below if you are adding an Arm-
rest between two modules.
Step 2
If two Privacy screens form a corner, use a Corner
connector kit to hold the screens together. First re-
move the hook from the smaller piece of the kit by
sliding it up and out. Then position the larger piece
on the outside of the corner and the smaller piece on
the inside of the corner and install the two included
screws to hold the pieces together. Note: Be sure to
tighten the screws so it won’t slip later on when the
hook is holding weight.
Finish by reinserting the hook. You can use the hook
to hang a coat, hat, bag, etc. The weight capacity of
the hook is 10 lbs.
Step 3
If two Privacy screens meet side by side, follow the
same steps as the corner screen assembly, but use the
Linear connector kit.
You can use the hook to hang a coat, hat, bag, etc.
The weight capacity of the hook is 10 lbs.
Armrest Bolster Cushion
Step 1
Place the Armrest between two Seat modules (with
or without backs) with the Armrest ap and metal bar
hanging down towards the oor. Hold the Armrest in
place while sliding the Seat modules against each oth-
er.
See step 2 in the Modules section for instructions on
how to connect the modules together.
Package Contents
Armrest Bolster Cushion

© UPLIFT Desk • 800-349-3839 • 512-614-3152 • [e-mail] • upliftdesk.com 7
(qty 2)
Step 1
SoCo Collection modules can be placed individu-
ally where desired (as shown in gure 1) but also
offer the exibility to be joined in various cong-
urations. If your desired conguration requires
joining some or all of your modules together, read
on. When preparing to join two modules, we rec-
ommend lining them up by the notches (gure 2)
on the side of each module where possible.
Step 2
Modules can be connected in their upright position,
but will be easier if the modules are tipped up onto
their front or back faces.
First, align one end of the Connectors as shown over
the sockets in the bottom of the rst module on the
side you are connecting to the next module. Then
press to snap the Connectors into place. Next, align
the second module with the opposite ends of the
Connectors and snap them into place.
Step 3
Continue connecting your modules together accord-
ing to your desired conguration. Refer back to the
Wedge Table, Circle Table, Privacy Screen, and Arm-
rest Bolster Cushion sections if you are including those
accessories.
Armrest reminder: Be sure to hold the Armrest in
place with the ap and metal bar hanging between
the modules before connecting.
Privacy Screen reminder: After connecting two mod-
ules with adjacent Privacy Screens, install the Linear
connector kit to keep the panels aligned.
Modules
Connector
(qty 4)
g. 1 g. 2
Package Contents Package Contents Package Contents
Seat with back Seat without back Table
(qty 1)
Connector
(qty 2) (qty 1)
Connector
(qty 2)

512-614-3152
800-349-3839
[email protected]
upliftdesk.com
Copyright Notice: This guide is a component of this UPLIFT Desk Acoustics Product. This guide is a part of the scope of delivery, even if the item is
resold. This guide is also available on the UPLIFT Desk website: upliftdesk.com. Excerpts or copies may not be forwarded to third parties or used in
any other published form without the prior written consent of UPLIFT Desk. These instructions are subject to United States copyright law.
©
SAVE THESE INSTRUCTIONS
Study this manual carefully. If this product is sold, please provide this
manual to the buyer, installers, or support personnel operating the product.
INS-CHR110 - AI-CHR110-1.0
