Uplift Desk CHR463 User manual

© UPLIFT Desk • 800-349-3839 • [email protected] • upliftdesk.com
NOTE
The Small brace’s outer edges are slightly out. Make sure the
ared side is facing the front of the chair assembly.
If you wish to assemble the kneeling chair so that the Barrel nuts
are hidden, simply insert the Small brace with the empty holes
facing the oor.
Step 3
Insert two (2) Barrel nuts into the holes on the Small brace. Make
sure the notch on each Barrel nut is facing up and perpendicular
to the Rockers.
Thread in the Long screws into the holes on the outside of the
Rockers, and begin tightening. Once all screws from Step 1 and
Step 3 are in place, you can tighten all of the screws all the way.
Step 1
Using the Large brace, connect the right and left Rockers. The
Large brace is wider on its bottom and narrower on the top.
Make sure it is properly aligned. Insert the Large brace’s metal
screw-pegs into the rear holes on the back curve of each Rocker.
Use four (4) Medium screws on these holes from the outside of
each Rocker, and begin tightening with the Allen wrench, but do
not fully tighten until Step 3. This gives you a little wiggle room
to help you install the Small brace more easily.
Step 2
Slide the Small brace between the Legs, lining up the Wood pegs
with the outer two holes.
Large brace
Small brace
Allen wrench
Long screws (qty 2)
Medium screws (qty 4)
Small screws (qty 6)
Wood pegs (qty 6)
Barrel nut (qty 2)
Knee cushions
(qty 2)
Seat cushion
front of
assembly
Rocker
(qty 2)
Package Contents
Ergonomic Kneeling Chair
SKU: CHR463

© UPLIFT Desk • 800-349-3839 • [email protected] • upliftdesk.com
Copyright Notice: These instructions are a component of the Kneeling Chair. These instructions are part of the scope of delivery, even if the item is resold. These instructions are also available on the UPLIFT Desk website:
upliftdesk.com. Excerpts or copies may not be forwarded to third parties or used in any other published form without the prior written consent of UPLIFT Desk. These instructions are subject to United States copyright law.
©
CAUTION: Read all instructions before assembly. Failure to assemble or operate properly may
result in damage or personal injury. Retain manual for future reference.
CAUTION: Use on a stable, level surface. Mount and dismount the chair carefully.
CAUTION: Do not play on this product. Keep ngers away from under the chair’s Rockers.
CAUTION: Maximum weight capacity is 200 lbs. (90.7 kg)
WARNING: Do not stand on the chair.
CAUTIONS & WARNINGS
!
!
!
!
!
!
Step 4
On the higher end of each Rocker, insert one (1) Wood peg into
the center of the three holes.
Line up the Seat cushion (curved end facing front, at end facing
back), and lower it onto the Wood pegs, using the center holes
on the seat.
Then insert four (4) Small screws, and tighten down all the way,
securing the seat in place.
Step 5
On the lower end of each Rocker, insert two (2) Wood pegs into
the outer two of the three holes.
Line up each Knee cushion (curved end facing front, at end fac-
ing back) and lower it onto the Wood pegs using the outer holes
on each.
Then insert the remaining two (2) Small screws, and tighten
down all the way, fastening each cushion in place.
AI-CHR463-1.1
