URBAN OUTFITTERS SILAS BOOK SHELF User manual

URBAN OUTFITTERS
SILAS BOOK SHELF
Assembly Instructions
TOOLS REQUIRED BUT NOT INCUDED:
Screwdriver, Drill, Hammer, Level
WARNINGS:
Do not throw away packing materials and carton until after
assembly. Assemble all parts on a clean smooth surface
CARE INSTRUCTIONS:
Avoid direct exposure to sunlight. Do not place overheat or air
conditioning vents. Adjust levelers so that the furniture sits flat
on uneven floors. Blot spills do not rub, with a clean white cloth.
Do not use harsh chemicals.
Before cleaning any part test a small spot in a hidden area.
You may need to re-tighten all bolts after initial use.
PARTS INCLUDED:
1) Top Panel
(48 x 15 x 0.7") x1
or
(122 x 38 x 1.8cm)
4) Middle Shelf
(48x 15x0.7") x1
or
(122 x 38 x 1.8cm)
A) Bolt
(D 0.47 / 0.24 x 1.18") x 24
or
(D 12 / 6 x 30mm)
E) Bolt
(D 0.47 / 0.24 X 0.59") x25
or
(D12/6x15mm)
2) Shelf
(48x15x0.7") x2
or
(122 x 38 x 1.8cm)
5) Leg
(14x12x7") x4 1
or
(35.5 x 20.5 x 17cm)
@
B) Spring Washer
(D 0.47 / 0.24 x 0.08") x 25
or
(D 12 x 6x2mm)
F) L Shaped Metal
(2.76 X 0.7 9 X 0.08") x1
or
(70 x 20 x 2mm)
C) Flat Washer
(D 0.63 / 0.24 x 0.08") x 26
or
(D 16 x 6 x 2mm)
G) Plastic Anchor (D
0.35 X 1.38") x1
or
(D9x35mm)
EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC.@2017 UO, Inc.
All rights reserved, including all applicable copyright, design and patent rights. Any unauthorized
reproduction, adaptation, distribution or other infringement will be prosecuted.
3) Bottom
(48x 15x2.7") x1
or
(122x38x6.8cm)
6) Leg
(14x 12x7") x4
or
(35.5 x 20.5 x 17cm)
u
D) Allen Key
(D 0.16 X 2.32") x1
or
(D4x59mm)
H) Screw
(D 0.16 X 1.18") x1
or
(D4x30mm)
Page 1 of 3
SILAS BOOK SHELF
Assembly Instructions
STEP 1
A) Attach the top panel (1) to two legs (5) with bolt (E) and Allen key (D) as shown.
B) Attach one shelf (2) with bolts (A), flat washers (C), and spring washers (B) using Allen key (D) as shown.
STEP 3
A) Attach two legs (6) to the shelf (2) with bolt (E) and Allen key (D) as shown.
B) Attach the middle shelf (4) with bolts (A), flat washers (C), and spring washers (B) using Allen key (D) as shown.
C) Repeat STEP 3 (A) using two legs (5) instead of legs (6).
D) Repeat STEP 1 (B) using the last shelf (2).
E) Repeat STEP 3 (A) using the last two legs (6).
STEP 4
Attach the bottom (3) with bolts (A), flat washers (C), and spring washers (B) using Allen key (D) as shown. Then
attach the L shaped metal bracket (F) to the middle shelf (4) with bolts (E), flat washers (C), and spring washers (B)
using Allen key (D) as shown.
EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC.@2017 UO, Inc.
All rights reserved, including all applicable copyright, design and patent rights. Any unauthorized
reproduction, adaptation, distribution or other infringement will be prosecuted. Page 2 of 3
URBAN OUTFITTERS
STEP 5
Place the book shelf on the wall in its desired location. Ensure the book shelf is level and mark the location of the
mounting hole in the L shaped metal on the wall. Pre-drill hole for the plastic anchor (G) at the marked hole location
using a drill and use a hammer to tap it into the wall.
STEP 6
Place the shelf back over the plastic anchor (G) and insert screw (H) as shown. Tighten with a screwdriver
to complete the installation. If attaching directly to a stud, you do not need to use the plastic anchors, screw
through the bracket directly into the wall.
l
\
\
\,
@F C
Wl
SILAS BOOK SHELF
Assembly Instructions
URBAN OUTFITTERS
EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC.@2017 UO, Inc.
All rights reserved, including all applicable copyright, design and patent rights. Any unauthorized
reproduction, adaptation, distribution or other infringement will be prosecuted. Page 3 of 3
