urmet domus IPerCom VOG 7 1761 Series Installation and operation manual

DS 1761-024 LBT 21039
Mod.
1761
OOOOOOOOOOO
IP 7’’ VIDEO DOOR PHONE
Ref. 1761/31 (White)
Ref. 1761/33 (Black)
USER BOOKLET
Interactive Links

2DS1761-024
The information contained in this booklet has been carefully collected and checked; however, the
manufacturer may not be held responsible for any errors or omissions. The manufacturer reserves
the right to introduce at any time and without notice improvements or changes in the products and
services described in the booklet.
(Note: the Android apps may be subject to changes according to the product version).
This manual may also contain references to or information on products or services not yet available
commercially. Such references or information will not in any way imply that the company intends to
market such products or services.
All the trademarks mentioned in this document are the property of their respective owners.
All rights reserved. We hereby authorise the partial or total reproduction of this document for the
exclusive purpose of using the IP 1761/31 or /33 Video door phone.

DS1761-024 3
The features described in the following booklet refer to version: 2.1.0_49_VER_7_8_0_R7 of the IP 1761/31
or /33 Video door phone.
INDEX
1. DEVICE GENERAL DESCRIPTION .......................................................................................................5
1.1 In a nutshell .................................................................................................................................5
1.2 How to turn on the screen and access the various functions .....................................................5
1.3 How to navigate between applications .......................................................................................6
1.4 How to interpret the reports ........................................................................................................8
1.5 Howtoturnothescreen(Stand-by) .........................................................................................8
1.6 How to send a panic alarm..........................................................................................................8
1.7 Screen lock function....................................................................................................................9
1.8 How to control a Video door phone hardware reset ...................................................................9
2. USING THE DEVICE AS VIDEO DOOR PHONE TERMINAL ..............................................................10
2.1 How to answer an external call .................................................................................................10
2.1.1 How to answer a call with the “Remote” option enabled ................................................11
2.2 How to answer a call from the switchboard..............................................................................11
2.3 How to answer an intercom call ................................................................................................12
2.4 Receiving and answering a call from your smartphone via CallMe App ...................................13
2.5 How to access Video Door Phone functions.............................................................................14
2.6 Howtouseaudiomessages(Voice“Post-its”).........................................................................14
2.6.1 How to record an audio message....................................................................................14
2.6.2 How to listen to an audio message..................................................................................15
2.7 How to call the switchboard......................................................................................................15
2.8 How to activate an auxiliary function.........................................................................................16
2.9 How to open the entrance door without having been called.....................................................16
2.10 How to open the garage/driveway gate without having been called ........................................16
2.11 How to activate the Video Door Phone Voicemail.....................................................................17
2.12 HowtoturnotheVideoDoorPhoneVoicemail......................................................................17
2.13 Activating the “Remote” mode ..................................................................................................17
2.14 Deactivating the “Remote” mode..............................................................................................17
2.15 Activating the “Divert” mode .....................................................................................................18
2.16 Deactivating the “Divert” mode .................................................................................................18
2.17 How to view voicemail calls.......................................................................................................18
2.17.1 How to delete one or more voicemail recordings...........................................................19
2.18 MUTE function...........................................................................................................................19
2.19 Door open indication .................................................................................................................19
2.20 How to make an intercom call...................................................................................................20
2.21 How to check the call log ..........................................................................................................21
2.22 How to send a text message.....................................................................................................22
2.23 How to search for a name in the address book ........................................................................24
2.24 How to add new contacts to your address book ......................................................................24
2.24.1 How to resend a contact request ...................................................................................26
2.25 How to accept contact requests ...............................................................................................26
2.26 How to delete contact requests ................................................................................................27
The document contains INTERACTIVE LINKS for faster and more ecient consultation.
Interactive Links

4DS1761-024
2.27 Auto-onfunction........................................................................................................................27
2.28 How to view snapshots .............................................................................................................28
2.28.1 How to delete one or more snapshots ...........................................................................29
2.29 How to call the lift......................................................................................................................29
3. USE OF THE DEVICE AS TERMINAL FOR: HOME AUTOMATION, ACCESS CONTROL,
INTRUSION ALARM CONTROL UNIT, ANDROID AND MULTIMEDIA...............................................30
3.1 Yokis Home Automation............................................................................................................30
3.2 App My 1067+ ...........................................................................................................................31
3.3 Urmet Secure App .....................................................................................................................33
3.4 IPerHome Home Automation.....................................................................................................34
3.5 Android App...............................................................................................................................36
3.5.1 Preloaded Android Apps..................................................................................................38
3.6 MIFARE (Access control Application)........................................................................................38
3.6.1 How to change the access code for the administrator....................................................40
3.6.2 How to create, delete, or replace a key for the administrator..........................................41
3.6.3 How to manage users ......................................................................................................43
3.6.4 How to record accesses and exits...................................................................................47
3.6.5 How to view a user’s log..................................................................................................47
3.6.6 How to view all logs .........................................................................................................48
3.7 Media player ..............................................................................................................................49
3.8 Gallery........................................................................................................................................50
3.9 iUVS App ...................................................................................................................................52
3.10 Yokis YnO App ..........................................................................................................................53
3.11 CallMe App ................................................................................................................................55
3.11.1CallMeappcongurationasHomepage........................................................................56
3.11.2CallMeappcongurationanduse..................................................................................57
3.12 CongurationofvideodoorphoneparametersandVideoDoorPhoneapplication ................58

DS1761-024 5
1. DEVICE GENERAL DESCRIPTION
The following booklet describes how to use the video door phone.
1.1 IN A NUTSHELL
The Video door phone 1761/31 or /33 is an IP touchscreen device of the Ipercom system that can operate
as:
•Advanced IP Video Door Phone;
•Yokis Home Automation Terminal,
•Terminal for displaying the intrusion alarm control unit status,
•IPerHome Home Automation Terminal,
•MIFARE Access Control,
•Android Applications Manager,
•iUVS Applications Manager,
•YnO Applications Manager.
The Video door phone uses the Android operating system and is able to perform both the specic
functionsofUrmetsystemsandthegenericfunctionsofAndroiddevices.Tooptimiseuser-friendliness,
theVideodoorphonecomeswithcertainfactory-preloadedapplications.
1.2 HOW TO TURN ON THE SCREEN AND ACCESS THE VARIOUS FUNCTIONS
The1761/31or/33Videodoorphonescreenisnormallyoandautomaticallylightsupwhenitreceives
a video door phone call (see section How to answer an external call).
In this case, a screen page is displayed from which the user can answer the caller and open the entrance
door.
The screen can also be voluntarily turned on by the user, to access one of its many applications. To turn
on the screen simply:
•tap anywhere on the screen;
•press the Home button (at the bottom centre of the video door phone) to display the Homepage.
The default Home Page is the Video Door Phone application , from which you can access the
various video door phone functions (you can change this setting and choose another application as your
Home Page, for example one of the Home Automation ones).
Video Door Phone Home Page (default option)
The following information is displayed in the bottom right:
App 01: Indicates the name of the apartment where the video door phone is present.
Video door phone 1: This is the name assigned to the video door phone by the installer during
conguration.
010101020100: Video door phone ID code.

6DS1761-024
The video door phone functions are the following:
Recording short audio messages (Post.it)
Callingtheswitchboard(iftheIpercomsystemisadequatelypre-set)
Liftcontrol(iftheIpercomsystemisadequatelypre-set).
Activating an auxiliary function, e.g. turning on the stair lights (if the Ipercom system is
adequatelypre-set).
Opening a driveway or garage gate.
Opening the door
WARNING! The functions’ availability depends on how the video door phone system has
been designed and built. Some of the functions described below may not be available in
your system. You may want to check with your installer if a specic function is available
or can be implemented.
The other navigation icons in the top bar can be used to:
View footage from the cameras present in the system
Viewrecordedaudio-videomessages(videodoorphoneVoicemail)
Display the address book and the call log
Send text messages (Chat)
Change the video door phone settings and/or the operating language
To change the default application tap the icon , provided in the top left corner, to access the Top
Page,thentaptheSet-upicon andnally the Home Page menu.
1.3 HOW TO NAVIGATE BETWEEN APPLICATIONS
The various applications are accessible from the Top Page, by tapping the special icon.
Example of Top Page

DS1761-024 7
For all details on the Apps present on the video door phone, see the relevant paragraphs in the following
manual.
The key can be used to scan a QR Code and access with your smartphone a page on the Urmet
website, where you can check the datasheet of the product in question.
To return to the Home Page from any screen page, tap the icon in the middle of the bottom bar.
The default Homepage is the Video Door Phone application, but it can be replaced with one of
theotherapplicationsusingtheTopPageCongurationmenu .
The other navigation icons in the top bar can be used to:
Return to the previous page.
Go to the page that lists the recently opened applications.
Send a panic alarm signal (function enabled if the Ipercom system includes
asuitablyconguredconciergeswitchboardservice).
Mutethecall(Mute)totheVideodoorphoneforauser-settableperiodof
time.
Change the call volume.
Set the following device states: At home / Recording / Divert / Remote
(only one active at a time).

8DS1761-024
1.4 HOW TO INTERPRET THE REPORTS
The bar at the top right of the screen shows status information:
Automatic door opening (if this feature is enabled).
Set the following device states: At home / Recording / Divert / Remote
(only one active at a time).
Bluetooth Connection active.
Active WiFi or second LAN connection (only one active at a time).
LAN connection to Ipercom network
The icon does not appear in Link Local
Time.
AnewnoticationissignalledbytheblueLEDashingontheHomebuttonoftheIPVideoDoorPhone
1761/31 or /33, the relevant icon in the upper left corner and the corresponding item in the scrolling menu.
Thepossiblenoticationsare:
Micro SD Card in.
Presence of an unread text message (Chat).
New contact request.
NewPost-itnotyetlistenedto.
Missed Call.
Video message not yet viewed.
Panic Alarm sent/cancelled.
Gesture or voice commands enabled
Door open detection
1.5 HOW TO TURN OFF THE SCREEN (STAND-BY)
Tomanuallyturnothescreen,presstheHomekeyontheIPvideodoorphone1761/31or/33.
Thescreenturnsoautomatically:
•when the user-programmable time-out delay has elapsed (see paragraph Congurations in the
Parameter conguration booklet”);
•attheendofanincomingcall,ifthescreenwaspreviouslyo.
1.6 HOW TO SEND A PANIC ALARM
WARNING! The Panic alarm function requires that:
•the video door phone system has a switchboard;
•the system has been properly set up (for more information, check the Ipercom
manual on www.urmet.com);
•there is a switchboard operator on duty;
•the switchboard operator has been properly trained on what to do in the event that
a panic alarm is received.

DS1761-024 9
How to send a panic alarm:
•Turnonthescreen,ifo,bytappingitatanypointorbypressingtheHomebuttonontheIPVideo
door phone.
•Touch the iconinthelowerleftcornerofthescreen,unlessitisdisabledintheconguration
parameters or there is no exchange in the system (for more information, refer to chapter Congurations
in the Parameter conguration booklet).
•Inthepop-uppagethatopens,presstheCONFIRM button to send the alarm.
ATTENTION! In any case, even in the absence of conrmation, the alarm message will
be sent at the end of the timeout (5 seconds), unless you cancel the sending by pressing
the CANCEL button.
On receiving the Panic Alarm message, the switchboard operator can listen to what is going on inside
the apartment, next to the Video door phone. Ambient listening can only be stopped by the switchboard
operator and can continue without any time limits. Ambient listening enabling in the apartment must be
done by the installer (for more information, refer to the Ipercom manual on www.urmet.com).
The panic alarm can also be activated via an external device, such as a button, connected to
the terminal block behind the Video door phone. In this case the Panic Alarm message will be
sentdirectlywithoutanyrequestforsendingconrmation.
1.7 SCREEN LOCK FUNCTION
To lock the video door phone screen, press and hold the Home key on the IP Video Door Phone until the
following screen is displayed.
The screen is inhibited for 20 seconds, after which it resumes operation.
It is possible to unlock the lock screen function early by pressing the Home key again or by following the
instructions shown on the screen.
The screen lock function is useful when you want to clean the screen, to avoid unintentional activation of
the Video Door Phone functions.
1.8 HOW TO CONTROL A VIDEO DOOR PHONE HARDWARE RESET
For a hardware reset of the Video door phone, press and hold the centre button of the Video door phone
until it restarts.

10 DS1761-024
2. USING THE DEVICE AS VIDEO DOOR PHONE TERMINAL
The Video Door Phone application is the main application of the IP 1761/31 or /33 Video door phone and
it is also the default Home Page. The application turns the device into an advanced video door phone
terminal.
Some of the following operations can also be performed using gesture or vocal commands. For further
information, refer to “Complete booklet for use of gesture commands” or “Complete booklet for use
of vocal commands”by pressing the relevant link or downloading the booklet from www.urmet.com in
the relevant product data sheet.
2.1 HOW TO ANSWER AN EXTERNAL CALL
When the Video door phone receives an outdoor door phone video call, it rings and the screen lights up
fromitsdefaultswitched-ostate. The video door phone will show the image of the caller on the display.
If there are more than one video door phone in the apartment, when a call is received, only the Master
video door phone will display the caller image. To display the caller image on a Slave video door phone,
press “Tap here to see who is calling you” on the video door phone display.
By tapping the various icons you can:
Reject the call. If the external calling station is a call module, a message is displayed informing
that the call has been rejected.
Answerthecallandbeginahands-freeconversation.
Open the door.
Open a driveway or garage gate.
Take a snapshot of the image displayed on the screen.
Enlarge or shrink the image, also changing its format from 4:3 to 16:9
TurntheVideodoorphonemicrophoneoandthenbackon,topreventthecallerhearingwhat
youaresaying.Whenthemicrophoneisturnedo,thecorrespondingiconiscrossedout.The
icon is only displayed after the call has been answered.
Activateanauxiliaryfunction,e.g.turningonthestairlights.Tappingtheiconopensapop-up
window that lists the possible controls. The icon is only displayed if the Ipercom system includes
a correctly programmed special decoding function (for more information see the Ipercom
technical manual on www.urmet.com).
Close the call. The icon will only be active after the call has been answered.
Changetheaudiovolumeintheoutdoorstation-to-Videodoorphonedirection(Videodoorphone
speaker).

DS1761-024 11
2.1.1 How to answer a call with the “Remote” option enabled
If the “Remote” option has been activated in the apartment, when a call is received the screen does not
show the caller image (see image below), even if there is only one IP Video Door Phone 1761/31 or /33;
(for more information see the Ipercom technical manual on www.urmet.com):
On the video door phone you want to use to answer, press “Tap here to see who is calling you”.
The video is displayed and you can then proceed as described here above for incoming calls from outside.
Ifthecallforwardingfunctionhasbeenconguredandactivated,withthe“Remote”status
activein addition to the video door phones, the smartphones on which the CallMe App has
been installed will also ring.
2.2 HOW TO ANSWER A CALL FROM THE SWITCHBOARD
When the Video door phone receives a call from the switchboard, it rings and the screen lights up
fromitsdefaultswitched-ostate.Theon-screenimageoftheswitchboardoperatorwillbedisplayed
already during the call (if the switchboard is equipped with a camera).
Toanswerthecallandbeginahands-freeconversationtaptheicon .

12 DS1761-024
After answering, by tapping the various icons you can then:
Show the operator your own picture taken by the Video door phone camera. If you do not tap
this icon, the operator will only receive voice input.
Store a snapshot of the switchboard operator displayed on the screen.
Enlarge or shrink the image, also changing its format from 4:3 to 16:9
TurntheVideodoorphonemicrophoneoandthenbackon,tostoptheswitchboardopera-
torhearingwhatyouaresaying.Whenthemicrophoneisturnedo,thecorrespondingiconis
crossed out. The icon is only displayed after the call has been answered.
Close the call.
Changetheaudiovolumeintheswitchboard-to-Videodoorphonedirection(Videodoorphone
speaker).
2.3 HOW TO ANSWER AN INTERCOM CALL
When the video door phone receives an intercom call, it rings and turns on the display, which is normally
o.Thedisplaydoesnotshowtheimageofthecallinguser.Itispossibletoseethecallerimageonly
after the call has been established and only if the caller has a video door phone with front camera and
enables display consent.
By tapping the various icons you can:
Reject the call. The message “Call rejected” is displayed on the calling device.
Answerthecallandbeginahands-freeintercomconversation.
Show the caller your own picture taken by the Video door phone camera. If you do not tap this
icon, the caller will only receive voice input. This function will only be active after the call has
been answered.
Store a snapshot of the caller displayed on the screen. This function will only be active after the
call has been answered.
Enlarge or shrink the image, also changing its format from 4:3 to 16:9.
TurntheVideodoorphonemicrophoneoandthenbackon,tostopthecallerfromhearing
whatyouaresaying.Whenthemicrophoneisturnedo,thecorrespondingiconiscrossedout.
The icon is only displayed after the call has been answered.
Close the call.
Change the RX audio volume.

DS1761-024 13
2.4 RECEIVING AND ANSWERING A CALL FROM YOUR SMARTPHONE VIA CALLME APP
ATTENTION! It is possible to receive a call from a smartphone via CallMe App if:
•onthesmartphone,thereisanaccountproperlyregisteredandconguredontheUrmetCloud
•the call forwarding function has been activated on the video door phone (for more information, refer to
chapter “Call forwarding settings” in the Parameter conguration booklet).
When the video door phone receives a call from a smartphone via the CallMe App, it rings and turns on
thedisplay,whichisnormallyo.Thedisplayshowsthefollowingscreen:
ATTENTION! It is only possible to receive audio calls from a smartphone via the CallMe App.
By tapping the various icons you can:
Reject the call. The message “Call rejected” will be displayed on the calling device.
Answerthecallandbeginahands-freeintercomconversation.
Show the caller your own picture taken by the Video door phone camera. If you do not tap this
icon, the caller will only receive voice input. This function will only be active after the call has
been answered.
Store a snapshot of the caller displayed on the screen. This function will only be active after the
call has been answered.
Enlarge or shrink the image, also changing its format from 4:3 to 16:9.
TurntheVideodoorphonemicrophoneoandthenbackon,tostopthecallerfromhearing
whatyouaresaying.Whenthemicrophoneisturnedo,thecorrespondingiconiscrossedout.
The icon is only displayed after the call has been answered.
Close the call.
Change the RX audio volume.

14 DS1761-024
2.5 HOW TO ACCESS VIDEO DOOR PHONE FUNCTIONS
Turnonthescreen,ifo,bytappingitatanypointorbypressingtheHomebuttonontheIP1761/31or
/33 Video door phone. The Home Page, i.e. the Video Door Phone main page, is displayed if the default
congurationhasbeenmaintained.
IfadierentVideoDoorPhoneHomePagehasbeenselected,gototheTopPageandselecttheVideo
Door Phone application .
The Video Door Phone page shows the functions that can be used. Select your required Video Door
Phone function by tapping the corresponding icon.
2.6 HOW TO USE AUDIO MESSAGES (VOICE “POST-ITS”)
The IP 1761/31 or /33 Video door phone allows you to record short audio messages that can be
subsequentlylistenedtobytheirrecipientsaftertheyhavereturnedhomeortotheoce.
To record or listen to messages:
•Access the main page of the Video Door Phone application and press the Audio Messages icon
.
Apop-upwindowwillopenthatcanbeusedtorecordandlistentomessages.
Toclosethepop-upwindowtaptheXicon at the top right.
2.6.1 How to record an audio message

DS1761-024 15
Press the RECORD icon to start a new recording. The maximum permitted duration of the message
is 10 seconds. The time to the end of recording is shown on a scroll bar.
To stop recording before the end of the available time tap the STOP button.
At the end of the recording, the message is automatically saved, with recording date and time, the Home
keyLEDstartsashingandamessageappearsontherelevanticon.
The recorded message will be automatically deleted after 30 days.
2.6.2 How to listen to an audio message
The presence of new audio messages is signalled by:
•ashingtheHomekeyLED.
•a number in the bottom right corner in the icon of the Audio messages (the number refers to
how many new messages there are).
To listen to a message, press the icon. Messages are listed by date and time.
Select the desired message and press the PLAY icon to start playback. Message playing cannot be
stopped before it ends.
Tap the icon delete the message.
Whentherearenomorenewmessagestolistento,theHomekeyLEDturnsoandtheiconofAudio
Messages function returns to the default state .
2.7 HOW TO CALL THE SWITCHBOARD
If the Video Door Phone system has a switchboard, to call it:
•Access the main page of the Video Door Phone application.
•Tap the icon .
The call is forwarded only to the respective switchboard (for more information see the Ipercom handbook
on the www.urmet.com website). If the switchboard operator cannot answer, for example, because they
are not there, the call is stored as a missed call.

16 DS1761-024
2.8 HOW TO ACTIVATE AN AUXILIARY FUNCTION
IftheVideoDoorPhonesystemisequippedwithaspecialdecoderthatisproperlycongured (for further
information, see the Ipercom technical manual on www.urmet.com), you can activate an auxiliary function
(staircase lights, garden lights, etc. ) in the following manner:
•Access the main page of the Video Door Phone application.
•Tap the icon .
•Tappingtheiconopensapop-upwindowthatliststhepossiblefunctions.Tapyourrequiredfunction
to activate it.
•Toclosethepop-upwindowtaptheXicon at the top right.
The same auxiliary functions can also be activated by tapping the corresponding icon present in the
screen page that is displayed when you answer an incoming external call (see section “How to answer
an external call”).
2.9 HOW TO OPEN THE ENTRANCE DOOR WITHOUT HAVING BEEN CALLED
Ifproperlycongured,yourentrancedoorcanbeopenedevenwhenyouhavenotbeencalledfroman
outdoor station (for more information see the Ipercom handbook on the www.urmet.com website).
•Access the main page of the Video Door Phone application.
•Tap the icon .Sendingthiscontrol,andnotitsperformance,isconrmedbyapopupmessage.
2.10 HOW TO OPEN THE GARAGE/DRIVEWAY GATE WITHOUT HAVING BEEN CALLED
Ifproperlycongured,yourgarageordrivewaygatecanbeopenedevenwhenyouhavenotbeencalled
from an outdoor station (for more information, check the Ipercom manual on www.urmet.com).
•Access the main page of the Video Door Phone application.
•Tap the icon . Sendingthiscontrol,andnotitsperformance,isconrmedbyapopupmessage.

DS1761-024 17
2.11 HOW TO ACTIVATE THE VIDEO DOOR PHONE VOICEMAIL
To activate the Video Door Phone Voicemail:
•Tap the icon in the bottom right corner.
•Select the RECORDING button.
•The icon displayed switches from to .
From this moment onwards, all calls from the outdoor station will ring the Video door phone and will be
recorded. The user may choose to answer the call while the voicemail message is being recorded. In this
case, the recorded message will not be stored.
TheVideoDoorPhoneVoicemailcanbesetupaccordingtothe3dierentoperationmodes:
•in the calling phase recording is immediately activated on the Video door phone;
•in the calling phase a customised audio message is played at the outdoor calling station;
•in the calling phase a customised audio message is played at the outdoor calling station and a beep
is heard after which to leave a message.
For more details refer to chapter “Congurations” in the Parameter conguration booklet).
2.12 HOW TO TURN OFF THE VIDEO DOOR PHONE VOICEMAIL
ToturnotheVideoDoorPhoneVoicemail:
•Press the icon in the lower right corner.
•Select the AT HOME icon.
•The icon displayed switches from to .
From this moment onwards, all calls from the outdoor calling station will not be recorded.
2.13 ACTIVATING THE “REMOTE” MODE
The “Remote” mode allows forwarding an audio/video or audio only call to a smartphone with Android or
iOS operating system.
ATTENTION!Thecallforwardingfunctionmustbeconguredandactivatedonthevideodoorphone
in order to enable this mode (for more information, refer to chapter “Call forwarding settings” in the
Parameter conguration booklet).
To activate the “Remote” mode:
•Press the icon in the lower right corner.
•Select the REMOTE icon.
•The icon displayed switches from to .
From now on, in addition to the video door phones, smartphones on which the CallMe App has been
installedandconguredwillalsoring.
2.14 DEACTIVATING THE “REMOTE” MODE
To deactivate the “Remote” mode.
•Press the icon in the lower right corner.
•Select the AT HOME icon.
•The icon displayed switches from to .

18 DS1761-024
From now on, calls will no longer be forwarded to smartphones on which the CallMe App has been
installedandcongured,onlypanicalarmnoticationssentbythevideodoorphoneintheapartmentwill
be forwarded.
2.15 ACTIVATING THE “DIVERT” MODE
The “Divert” mode allows diverting the call to the relevant exchange, to all the exchanges in the system
or to a contact in the directory.
ATTENTION! Thecalldiversionfunctionmustbeconguredandactivatedonthevideodoorphone(for
more details on the procedure, refer to the chapter “Call divert settings” in the Parameter conguration
booklet).
To activate the “Divert” mode:
•Press the icon in the lower right corner.
•Select the DIVERT icon.
•The icon displayed switches from to .
From now on, calls will be diverted to the devices selected to receive the call.
2.16 DEACTIVATING THE “DIVERT” MODE
To deactivate the “Divert” mode:
•Press the icon in the lower right corner.
•Select the AT HOME button.
•The icon displayed switches from to .
From now on, calls will no longer be diverted.
2.17 HOW TO VIEW VOICEMAIL CALLS
How to view calls stored as voicemail:
•Access the main page of the Video Door Phone application .
•Press the icon. If there are new calls in the messaging service, their number is displayed in a red
circle next to the icon.
•Alistofvoicemailcallsopens;eachcallisidentiedbythenameoftheoutdoorcallingstationandby
the call date and time.

DS1761-024 19
•Selectthecallthatyouwishtoviewdetails.Apop-upwindowopens.Tapthebutton to listen to
the recorded message, the button to close the window.
2.17.1 How to delete one or more voicemail recordings
How to delete one or more recorded messages:
•Open the list of voicemail calls (see previous section)
•Tap the button .
•Select the recorded message(s) that you want to delete (the SELECT ALL button selects all recorded
messages).
•Tap the DELETE button to delete the recordings or CANCEL to cancel the operation without deleting
the recordings.
2.18 MUTE FUNCTION
This function allows excluding the call ringer on the video door phone and any additional connected
ringers.
•Press the icon in the lower right corner.
•A pop-up window opens with the available MUTE duration times:
– 15 minutes;
– 30 minutes;
– 1 hour;
– 2 hours;
– 4 hours;
– 8 hours;
– 24 hours;
– Permanent.
•Tap the icon corresponding to the time that you wish to set.
•Thepop-upwindowclosesandtheiconchanges from to , to indicate that the MUTE
mode is active.
From now on, all calls will be received but the video door phone will not ring.
When the MUTE time expires, the video door phone will return to ringing normally to calls, without the
need for any intervention.
The MUTE function can be stopped prematurely, as follows:
•Press the icon in the lower right corner.
•A pop-up window opens showing the remaining time of MUTE function
•To stop the MUTE function and reactivate the ringer, press the YES button.
2.19 DOOR OPEN INDICATION
The video door phone has the icon in the upper bar of the display, which indicates whether the
door has remained open on one or more entries. The door open condition is signalled by the call stations
only if the duration of this event is at least 30 seconds.
The function must be enabled by the installer when conguring the Ipercom system.
The function is related to the status of the SP terminal of call stations and requires a door open sensor.

20 DS1761-024
ATTENTION! The door open indication is displayed only on video door phones on which door opening
was carried out following the last call received.
In addition to the icon on the display, the LED of the Home key ashes on the video door phone.
When the door or any doors left open are closed, the icon will no longer be visible on the display and the
HomebuttonLEDwillstopashing.
2.20 HOW TO MAKE AN INTERCOM CALL
To make an intercom call with another Video door phone:
•Access the main page of the Video Door Phone application .
•Tap the icon .
•The address book opens, it contains:
– thecontactsuploadedbytheinstalleridentiedbythewordSystem (for more information see the
Ipercom handbook on the www.urmet.com) website,
– the contacts added later by the user (directly from a Max video door phone).
– Video door phones present in the same apartment.
To add a new contact directly from a Max video door phone follow the procedure described in section
“How to add new contacts to your address book”.
•To call a contact tap the icon located next to it.
•The following window will display and the contact is called.
