Vaxcel T0454 Instruction manual

ASSEMBLY AND INSTALLATION
INSTRUCTIONS
181029
1. Install a bulb (not included). See relamping label
at socket area or packaging for maximum allowed
wattage.
2. Pull out the wires and grounding wire from the post.
Make wire connections using the wire connectors (B):
---The hot wire (usually balck insulation) from the
fixture to the black wire from the post.
---The neutral wire (usually white insulation) from
the fixture to the white wire from the post.
---The grounding wire (usually green insulation or
bare wire from the fixture to the grounding wire
from the post.
Carefully put the wires back into the post.
3. Place the fitter on the top of the post, and then
secure it with fitter screws.
NOTE: With silicone caulking compound,
caulk completely around where the fitter
meets with the post surface to prevent water
from seeping into the post.
4. Attach the glass onto the glass holder, secure it
with four replacement ball nuts.
Bulb Type A Max.60W
(not included)
Glass
NOTES: 1. Before installing, consult local electrical codes for wiring and grounding requirements.
2. READ AND SAVE THESE INSTRUCTIONS.
T0454
Hardware Package (included):
Fitter Screw (A) Wire Connector (B)
Turn off the power at fuse or circuit box
Installation Steps
WARNING:
TO AVOID RISK OF ELECTRICAL SHOCK, BE SURE TO SHUT OFF
POWER BEFORE INSTALLING OR SERVICING THIS FIXTURE.
Turn on the power at fuse or circuit box
Post Grounding Wire
Fixture Wire
Wire Connector (B)
Post
Fitter
Fixture Grounding Wire
Fitter Screw (A)
Glass Holder
Replacement Ball Nut

181029
Assembly Kit
6004MM (1SET)
The following parts are available for re-order if damaged or missing.
Spare Parts List:
Glass 10037CS
B
A
A: 12-3/4"
B: 9-3/4"
Fitter Screw (A) Wire Connector (B)
