VeEX FX15 User manual

Quick Guide
©2019 VeEX Inc. –All Rights Reserved www.veexinc.com
FX15
Optical Fiber Identifier
Product Contents
•FX15 Optical Fiber Identifier
•2 mm, 3 mm and 900 fiber alignment chucks
•Sunlight shade cover
•9V alkaline battery
•Softbag with zipper storage area for chucks
Product Layout

FX15 OPTICAL IDENTIFIER P a g e | 2
Operation
1. Slide down battery cover and install 9V battery
2. Remove Sun Shade cover.
3. With Test button down/open, slide one of the three available fiber chucks into place.
•2mm cable
•3mm cable
•900 for bare fiber and/or ribbon cable
4. Install test fiber into alignment chuck. Push up and lock button into place.
Note: Make sure fiber is seated properly before you shut/lock the button to avoid damage to test fiber.
