VeEX FX20 User manual

The Verification Experts
FX20
Optical Power Meter
QUICK GUIDE
Backlight
icon
ON/OFF
LIGHT
ZERO
λ
LCD
AUTO OFF
dB
Set the reference value
1. Install the opcal patch cord to the FX20.
2. Turn on the power.
3. Press the dB buon to change the display to dB.
4. Press the ZERO buon to set dB to zero as the reference value.

FX20
Optical Power Meter
VeEX Inc.
2827 Lakeview Court
Fremont, CA 94538 USA
Tel: [phone]
Fax: [phone]
www.veexinc.com
[email protected]
© 2014 VeEX Inc. All rights reserved.
VeEX is a registered trademark of VeEX Inc. The information con-
tained in this document is accurate. However, we reserve the right
to change any contents at any time without notice. We accept no
responsibility for any errors or omissions. In case of discrepancy,
the web version takes precedence over any printed literature.
D02-00-036P A00 2014/08
Functional descriptions
1. LCD This displays the current informaon of the device. It displays
the opcal power measurement results in units of dB, dBm, mW, μW, and
nW, the set wavelength in units of nm, and the state of AUTO OFF seng.
2. ON/OFF This is the power buon that turns the device on and o.
To power on the meter, press and hold the power buon unl informaon
appears on the LCD. Press and hold the power buon again to turn it o.
3. AUTO OFF While the device is on, press the AUTO OFF buon
to enable or disable the AUTO OFF funcon. If AUTO OFF is enabled, a
power icon will appear in the top le corner of the LCD. When AUTO OFF
is enabled, the device will automacally turn o if there are no operaons
performed within 10 minutes.
4. ZERO Press this buon to zero the relave opcal power value.
5. LIGHT Press this buon to turn on the backlight for the LCD. While
the LCD backlight is on, press the buon again to turn it o.
6. dB Press this buon to change the units of the relave opcal power
between μW and dB.
7. λPress this buon to select the wavelength to be measured. The
seven precalibrated wavelengths include 850 nm, 980 nm, 1300 nm, 1310
nm, 1490 nm, 1550 nm, and 1625 nm.
