Vendo V21 User manual

Vendo V21
Manual
for
Identied Equipment
Vendo P/N 1124557
Rev. B
Chameleon
SandenVendo America, Inc.
10710 Sanden Drive • Dallas, Texas 75239 • [phone] • FAX [phone]

I
Part #1169256 09/2008
CHAMELEON
TABLE OF CONTENTS

II
Part #1169256 09/2008
SAFETY SECTION..................................................................................... Pages S-1 - S-16
A COMMITMENT TO SAFETY....................................................................Page S-2
VENDOR INSTALLATION........................................................................... Pages S-3 - S-6
ELECTRICAL HAZARDS ............................................................................ Pages S-7 - S-8
MECHANICAL HAZARDS........................................................................... Page S-9
REFRIGERATION HAZARDS.....................................................................Page S-10
SUBSTITUTIONS AND MODIFICATIONS..................................................Pages S-11 - S-12
CONSUMER SAFETY WARNING .............................................................. Page S-13
PARTS, SALES, AND SERVICE CENTERS OF VENDO/SANDEN CO..... Pages S-14 - S-15
GENERAL INFORMATION......................................................................... Pages G1 - G12
GENERAL INFORMATION.......................................................................... Page G-2
INITIAL SET-UP .......................................................................................... Pages G-3 - G-4
LABEL INSTALLATION ............................................................................... Page G-5
ALIGNMENT CHECKS................................................................................ Page G-6
LOADING INSTRUCTIONS ........................................................................ Page G-6 - G-7
VEND MECHANISM PARTS DESCRIPTION.............................................Pages G-8 - G-9
VEND CYCLE.............................................................................................. Pages G-10 - G-11
PROGRAMMING SECTION ....................................................................... Pages P-1 - P-12
12.4 PROGRAMMING................................................................................. Page P-2
SET-UP AND CODE DESCRIPTION.......................................................... Pages P-3 - P-12
12.4 WIRING DIAGRAMS........................................................................... Page P-12
TRADE CABINET SECTION...................................................................... Pages C-1 - C-17
READING A PARTS LIST............................................................................ Page C-2
HARDWARE LIST....................................................................................... Pages C-4 - C-5
CABINETASSEMBLY................................................................................. Pages C-6 - C-7
STACK ASSEMBLY.....................................................................................Pages C-8 - C-9
MECH PLATE ASSEMBLY..........................................................................Pages C-10 - C-11
REFRIGERATION ASSEMBLY ................................................................... Pages C-12 - C-13
POWER BOX ASSEMBLY ..........................................................................Pages C-14 - C-15
HARNESS QUICK REFERENCE GUIDE...................................................Pages C-16
TRADE DOOR SECTION ........................................................................... Pages TD-1 - TD-9
OUTER DOOR............................................................................................ Pages TD-2 - TD-5
LOCK ASSEMBLY....................................................................................... Pages TD-6
INNER DOOR ASSEMBLY.......................................................................... Pages TD-7 - TD-8
MAINTENANCE.......................................................................................... Pages M-1 - M-10
PREVENTATIVE MAINTENANCE SUGGESTIONS...................................Page M-2
LUBRICATION GUIDE................................................................................Page M-2
CARE AND CLEANING...............................................................................Page M-3
REFRIGERATION OPERATION ................................................................. Pages M-4 – M-6
REFRIGERATION PARTS DESCRIPTION................................................. Pages M-7 - M-9
V21 TRADE TABLE OF CONTENTS

III
Part #1169256 09/2008
TROUBLESHOOTING................................................................................ Pages T-1 - T-12
VENDO WARRANTY.................................................................................. Pages T-2
PARTS RETURN PROCEDURE................................................................. Page T-3
TROUBLESHOOTING GUIDE.................................................................... Pages T-4 - T-11

S-1
Part #1169256 09/2008
CHAMELEON
SAFETY SECTION

S-2
Part #1169256 09/2008
A COMMITMENT TO SAFETY
SandenVendo America, Inc. is committed to safety in every aspect of our product design.
SandenVendoAmerica, Inc. is committed to alerting every user to the possible dangers involved
in improper handling or maintenance of our equipment. The servicing of any electrical or
mechanicaldeviceinvolvespotentialhazards,bothtothoseservicingtheequipmentandtousers
of the equipment. These hazards can arise because of improper maintenance techniques. The
purpose of this manual is to alert everyone servicing SandenVendo America, Inc. equipment of
potentially hazardous areas, and to provide basic safety guidelines for proper maintenance.
This manual contains various warnings that should be carefully read to minimize the risk of
personal injury to service personnel. This manual also contains service information to insure
that proper methods are followed to avoid damaging the vendor or making it unsafe. It is also
important to understand these warnings are not exhaustive. SandenVendoAmerica, Inc. could
not possibly know, evaluate, or advise of all of the conceivable ways in which service might be
done. Nor can SandenVendo America, Inc. predict all of the possible hazardous results. The
safety precautions outlined in this manual provide the basis for an effective safety program. Use
these precautions, along with the service manual, when installing or servicing the vendor.
We strongly recommend a similar commitment to safety by every servicing organization. Only
properly-trained personnel should have access to the interior of the machine. This
will minimize the potential hazards that are inherent in electrical and mechanical devices.
SandenVendo America, Inc. has no control over the machine once it leaves the premises. It is
the owner or lessor’s responsibility to maintain the vendor in a safe condition. See Section I of
this manual for proper installation procedures and refer to the appropriate service manual for
recommendedmaintenanceprocedures. Ifyouhave anyquestions,pleasecontacttheTechnical
Services Department of the SandenVendo America, Inc. office nearest you.
SAFETY RULES
• Read the Safety Manual before installation or service.
• Test for proper grounding before installing to reduce the risk of electrical shock and fire.
• Turn off power switch or disconnect power cord from wall outlet before servicing or clearing
product jams. The vending mechanism can trap and pinch hands.
• Use only fully-trained service technicians for Power- On servicing.
• Remove any product prior to moving a vendor.
• Use adequate equipment when moving a vendor.
• Always wear eye protection, and protect your hands, face, and body when working near the
refrigeration system.
• Use only authorized replacement parts.
• Be aware of inherent dangers in rocking or tipping a vending machine.
• Always turn power off before plugging or unplugging vendor to wall outlet.

S-3
Part #1169256 09/2008
SECTION I: VENDOR INSTALLATION
A. Vendors are large, bulky machines of significant size and weight. Improper handling
can result in injury. When moving a vendor, carefully plan the route to be taken and the
people and equipment required to accomplish the task safely.
B. Remove all tape, shipping sealant, and Styrofoam from the vendor. Loosen any shipping
devices used to secure interior parts during shipping. Remove the wooden shipping base
attached to the vendor base by the vendor leveling screws. Make certain the leveling
screws are in place and functional.
C. Position the vendor three to four inches (7.6 cm to 10.2 cm) from a well-constructed wall
(of a building or otherwise) on a flat, smooth surface.
IMPORTANT: The vendor requires three inches (7.6 cm) of air space from the wall to
ensure proper air circulation to cool the refrigeration unit.
D. Adjust the leveling screws to compensate for any irregularities on the floor surface.
Ideally, no adjustment will be necessary and the leveling legs will be flush with the bottom
of the vendor. A spirit level is a useful aid to level the vendor. When the outer door is
open, it will remain stationary if the vendor is properly leveled. Vendors must be level to
ensure proper operation and to maintain stability characteristics. Do not add legs to the
vendor. The leveling legs shall not raise the vendor more than 1 1/8 inch above the
ground.
E. Check the manufacturer’s nameplate on the left or right side of the vendor’s outer door to
verify the main power supply requirements of the vendor. Be sure the main power supply
matches the requirements of the vendor. To ensure safe operation, plug the vendor only
into a properly grounded outlet.
DO NOT USE EXTENSION CORDS.
F. Recommended voltage specs = 115V ± 10%
G. Dedicated 15A service required for 1 machine.
NOTE: Any power supply variance more than + 10% may cause the vendor to malfunction.
* Power outlets must be properly grounded.
* Power outlets must be properly polarized, where applicable.
Test the outlets using the following information.
(Refer to Figure 1 on Page S-4.)

S-4
Part #1169256 09/2008

S-5
Part #1169256 09/2008
SECTION I: VENDOR INSTALLATION (CONTINUED)
For Type 1 and Type 2 outlets, test for Grounding and Polarization as follows:
1. With a test device (volt meter or test light), connect one probe to the receptacle’s
neutral contact and the other to the live contact. The test device should show a
reaction.
2. Connect one probe to the receptacle’s earth contact and the other to the live
contact. The test device should show a reaction.
For Type 3 through Type 5 outlets, test for Grounding as follows:
1. With a test device (volt meter or test light), determine which of the receptacle’s
power contacts is the live contact.
A. Connect one probe to the receptacle’s earth contact.
B. Connect the second probe to the left (or upper) power contact. If a
reaction occurs, this is the live power contact. If a reaction does not occur,
move the second probe to the right (or lower) contact. A reaction should
occur, indicating that this is the live power contact.
2. Connect one probe to the receptacle’s live power contact (as determined in step
1). Connect the second probe to the other power contact (neutral). The test
device should show a reaction.
IF THEABOVE CONDITIONS ARE NOT MET FOR THE GIVEN OUTLET
TYPE, CONTACT A LICENSED ELECTRICIAN AND HAVE THE
NECESSARY CORRECTIONS MADE.

S-6
Part #1169256 09/2008
SECTION I: VENDOR INSTALLATION (CONTINUED)
H. Door Support (Figure 2)
The door support is to ensure that the
outer door closes squarely to the cabinet.
Raising the door can also ensure proper
alignment of the door latch.
FIGURE 2
I. Door Latch Alignment (Figure 3)
After any door adjustment, the floating quicker lock
assembly should align itself automatically. The latch
assembly is adjustable. To adjust, loosen the latch
bracket mounting screws, raise or lower the latch
assembly into position, then tighten the mounting
screws.
FIGURE 3
WARNING:
KEEP FINGERS AND OTHER OBJECTS OUT OF LOCK CAVITY
NOTE: Refer to the appropriate parts and service manual for detailed
instructions, operating principles, and recommended maintenance intervals and
procedures.
