Vertiv NetSure 48 Series User manual

NetSure™ -48 VDC
Battery Rack System
Installation and User Manual
Specification Number: 588820400100, 588820400150, 588820400200
Model Number: 48BA800-23

Vertiv™ NetSure™ -48 VDC Battery Rack System Installation and User Manual
Vertiv™ NetSure™ -48 VDC Battery Rack System Installation and User Manual
The information contained in this document is subject to change without
notice and may not be suitable for all applications. While every precaution has
been taken to ensure the accuracy and completeness of this document, Vertiv
assumes no responsibility and disclaims all liability for damages resulting from
use of this information or for any errors or omissions. Refer to other local
practices or building codes as applicable for the correct methods, tools, and
materials to be used in performing procedures not specifically described in
this document.
The products covered by this instruction manual are manufactured and/or
sold by Vertiv. This document is the property of Vertiv and contains
confidential and proprietary information owned by Vertiv. Any copying, use or
disclosure of it without the written permission of Vertiv is strictly prohibited.
Names of companies and products are trademarks or registered trademarks of
the respective companies. Any questions regarding usage of trademark
names should be directed to the original manufacturer.
Technical Support Site
If you encounter any installation or operational issues with your product, check the pertinent section of this
manual to see if the issue can be resolved by following outlined procedures.
Visit https://www.vertiv.com/en-us/support/ for additional assistance.

Vertiv™ NetSure™ -48 VDC Battery Rack System Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
iii
TABLE OF CONTENTS
Admonishments Used in this Document.............................................................................................................................iv
Important Safety Instructions..................................................................................................................................................v
Safety Admonishments Definitions ..........................................................................................................................................................................................................................v
Safety and Regulatory Statements...........................................................................................................................................................................................................................v
Déclarations de Sécurité et de Réglementation...........................................................................................................................................................................................v
1Customer Documentation Package..................................................................................................................................1
2System Description ................................................................................................................................................................1
3Installation Acceptance Checklist ....................................................................................................................................1
4Installing the System ............................................................................................................................................................2
4.1 General Requirements..............................................................................................................................................................................................................................................2
4.2 Securing the System’s Box Framework(s) to the Floor.............................................................................................................................................................3
5Making Electrical Connections .........................................................................................................................................5
5.1 Important Safety Instructions............................................................................................................................................................................................................................5
5.2 Wiring Considerations...............................................................................................................................................................................................................................................5
5.3 Access Covers .................................................................................................................................................................................................................................................................5
5.4 Battery Rack Box Framework Grounding Connection (Frame Ground)....................................................................................................................5
5.5 Battery Disconnect Circuit Breakers External Alarm Connections................................................................................................................................6
5.6 Battery Connections to Associated Power System ......................................................................................................................................................................7
6Installing Batteries.................................................................................................................................................................8
6.1 Important Safety Instructions............................................................................................................................................................................................................................8
6.2 Battery Manufacturer Information.................................................................................................................................................................................................................8
6.3 Installing Batteries into the Battery Trays.............................................................................................................................................................................................8
7Initially Starting the System ............................................................................................................................................13
8Maintenance...........................................................................................................................................................................13
8.1 Batteries...............................................................................................................................................................................................................................................................................13
8.2 System Maintenance Procedures................................................................................................................................................................................................................13
9Troubleshooting and Repair ............................................................................................................................................13
9.1 Contact Information..................................................................................................................................................................................................................................................13
9.2 Batteries...............................................................................................................................................................................................................................................................................13

Vertiv™ NetSure™ -48 VDC Battery Rack System Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
iv
Admonishments Used in this Document
DANGER!
Warns of a hazard the reader will be exposed to that will likely result
in death or serious injury if not avoided. (ANSI, OSHA)
WARNING!
Warns of a potential hazard the reader may be exposed to that could
result in
death or serious injury if not avoided. This admonition is not used for situations that pose a
risk only to equipment, software, data, or service. (ANSI)
CAUTION!
Warns of a potential hazard the reader may be exposed to that could
result in minor or moderate injury if not avoided. (ANSI, OSHA) This admonition is not
used for situations that pose a risk only to equipment, data, or service, even if such use
appears to be permitted in some of the applicable standards. (OSHA)
ALERT!
Alerts the reader to an action that must be avoided in order to protect
equipment, software, data, or service. (ISO)
ALERT!
Alerts the reader to an action that must be performed in order to prevent
equipment damage, software corruption, data loss, or service interruption. (ISO)
FIRE SAFETY!
Informs the reader of fire safety information, reminders, precautions,
or policies, or of the locations of fire
-fighting and fire-safety equipment. (ISO)
SAFETY!
Informs the reader of general safety information, reminders, precautions, or
policies not related to a particular source of hazard or to fire safety. (ISO, ANSI, OSHA)

Vertiv™ NetSure™ -48 VDC Battery Rack System Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
v
Important Safety Instructions
Safety Admonishments Definitions
Definitions of the safety admonishments used in this document are listed under “Admonishments Used in this Document” on page iv.
Safety and Regulatory Statements
Refer to Section 4154 (provided with your customer documentation) for Safety and Regulatory Statements.
Déclarations de Sécurité et de Réglementation
Reportez-vous à la Section 4154 (fourni avec les documents de votre client) pour les déclarations de sécurité et de réglementation.

Vertiv™ NetSure™ -48 VDC Battery Rack System Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
vi
This page intentionally left blank.

Vertiv™ NetSure™ -48 VDC Battery Rack System Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
1
1Customer Documentation Package
This document (IM588820400100) provides Installation and User Instructions for Vertiv™ NetSure™ -48 VDC Battery Rack System
Model 48BA800-23; Spec. No. 588820400100, 588820400150, and 588820400200.
The complete Customer Documentation Package consists of…
•Battery Rack System Installation and User Instructions: IM588820400100
•Battery Rack System “System Application Guide”: SAG588820400100, SAG588820400150, SAG588820400200
•Engineering Drawings
2System Description
Front access battery rack system consisting of a 27.5” wide x 22.8” deep x 84” tall free-standing box framework, five (5) battery trays,
and battery termination busbar assemblies. The battery trays accommodate a variety of front terminal -48V valve regulated lead acid
(VRLA) batteries. Includes factory routed and lugged cabling from each battery tray to the battery termination busbar assemblies.
Also equipped with left side mounted battery disconnect circuit breakers. Factory circuit breaker alarm wiring is provided to an alarm
card. The alarm card provides external relay contacts and resistive battery for connection to customer external alarm circuits.
3Installation Acceptance Checklist
Provided below is an Installation Acceptance Checklist. This checklist helps ensure proper installation and initial operation of the
system. As the procedures presented in this document are completed, check the appropriate box in this list. If the procedure is not
required for your installation site, also check the box in this list to indicate that the procedure was read. When installation is done,
ensure that each block in this list has been checked.
System’s Box Framework Mounted to Floor
System’s Box Framework Properly Grounded
Battery Disconnect Circuit Breakers External Alarm Connections Made
Battery Connections to Associated Power System Made
Batteries Installed
System Started

Vertiv™ NetSure™ -48 VDC Battery Rack System Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
2
4Installing the System
4.1 General Requirements
•This product is intended only for installation in a restricted access location on or above a non-combustible surface.
•This product must be located in a controlled environment with access to Crafts persons only.
•This product is intended for installation in network telecommunication facilities (CO, vault, hut, or other environmentally
controlled electronic equipment enclosure).
•This product is intended for connection to the common bonding network in a network telecommunication facility (CO, vault,
hut, or other environmentally controlled electronic equipment enclosure).
•The DC return connection to this system can remain isolated from system frame and chassis (DC-I).
•This system is suitable for installation as part of the Common Bonding Network (CBN).
•The installer should be familiar with the installation requirements and techniques to be used in securing the box framework to
the floor.
•Clearance requirements are:
a) Recommended minimum aisle space clearance for the front of the bay is 2' 6".
b) The battery rack is front accessed for installation, operation, and maintenance. Refer to your company’s standards for
recommended minimum aisle space clearance for the rear of each bay.

Vertiv™ NetSure™ -48 VDC Battery Rack System Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
3
4.2 Securing the System’s Box Framework(s) to the Floor
Secure the box framework to the floor per site requirements. Refer to “General Requirements”on page 2.
Refer to Figure 4.1 for floor mounting hole dimensions.
Note! You must install a Floor Anchor Reinforcing Plate at each floor bolting position. Refer to System Application Guide
SAG588820400100 for part number.
Refer to Figure 4.2 when using the Optional Battery Rack Isolation Kit.
Figure 4.1 Box Framework Floor Mounting Hole Dimensions
Bottom View
Front
1.000 x 1.875 SLOT
(8 PLACES)
45°
45°
45°
45°
45°
45°
45°45°
10.296
18.296
22.812
22.434
22.934
27.470
2.268
2.518
2.258
6.258

Vertiv™ NetSure™ -48 VDC Battery Rack System Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
4
Figure 4.2 Optional Battery Rack Isolation Kit Mounting
Isolation Pad
Floor
Floor Anchors
(Customer Provided)
Battery Rack
Box Framework
1/2-inch Flat Washer
(inside box framework
at mounting locations)
(4-places)
1/2-inch Bushing
(inside box framework
at mounting locations)
(4-places)

Vertiv™ NetSure™ -48 VDC Battery Rack System Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
5
5Making Electrical Connections
5.1 Important Safety Instructions
DANGER! Adhere to the “Important Safety Instructions” presented at the front of this document.
5.2 Wiring Considerations
All wiring should follow the current edition of the American National Standards Institute (ANSI) approved National Fire Protection
Association's (NFPA) National Electrical Code (NEC), and applicable local codes. For operation in countries where the NEC is not
recognized, follow applicable codes.
For wire size, crimp lug, and general wiring recommendations; refer to System Application Guide SAG588820400100,
SAG588820400150, SAG588820400200.
5.3 Access Covers
You may remove the front access cover(s) from the battery rack system to facilitate wiring and battery installation. When electrical
connections and battery installation are complete, reinstall all covers that were removed before operating the battery rack system.
5.4 Battery Rack Box Framework Grounding Connection (Frame Ground)
The battery rack box framework must be properly grounded.
For grounding requirements, refer to the current edition of the American National Standards Institute (ANSI) approved National Fire
Protection Association's (NFPA) National Electrical Code (NEC), applicable local codes, and your specific site requirements.
A customer's grounding network lead can be attached to the top of each battery rack box framework. Provision is made for installing
a lead with a two-hole lug that has 1/4" bolt clearance holes on 5/8" centers. Refer to Figure 5.1 for locations. When using 1/4-inch
hardware, recommended torque is 84 in-lbs when a standard flat washer and lock washer are used.
Note! Remove any tape from hole locations before installing lug.
Figure 5.1 Battery Rack Box Framework Frame Grounding Connection Points
Top View
Frame Ground Connection Points
(1/4” clearance holes on 5/8” centers)

Vertiv™ NetSure™ -48 VDC Battery Rack System Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
6
5.5 Battery Disconnect Circuit Breakers External Alarm Connections
The battery disconnect circuit breakers are factory wired to an alarm card located at the top of the box framework. The alarm card
provides resistive battery and Form-C relay contacts for connection to external alarm circuits.
If any battery disconnect circuit breaker is in the OFF position, resistive battery is provided at terminal 1 of J3 on the alarm card. Also,
relay contacts open between terminals 2 and 3 of J3 and close between terminals 3 and 4 of J3 located on the alarm card. Refer to
Figure 5.2.
Figure 5.2 Battery Disconnect Circuit Breaker Alarm Card
Front shield and portion
of rack removed for
clarity only.
Front
Notes:
Relay shown in deenergized state.
Relay energizes during alarm condition.
N.O. (Normally Open Contact)
Com. (Common)
N.C. (Normally Closed Contact)
Terminal Block (J3) accepts a wire size in
the range of 26 AWG to 14 AWG (solid or
stranded). Recommended Torque (J3):
4.4 to 5.3 in-lbs.
Alarm Card
Resistive
Battery
N.C.N.O.
Com.
J3
1234

Vertiv™ NetSure™ -48 VDC Battery Rack System Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
7
5.6 Battery Connections to Associated Power System
Lug-terminated battery leads must extend from the termination busbars located at the top of the battery rack system to the battery
busbar and battery return busbar of the associated power system. Refer to the documentation provided with the power system for
connections to the power system. The termination busbars in the battery rack system are provided with 3/8” clearance holes for
installation of customer provided two-hole lugs with 1” centers. Customer must provide lug mounting bolts, washers, and additional
hardware. Refer to Figure 5.3.
Procedure
1. Remove front and rear protective covers.
WARNING! Observe correct polarity when making connections. Reversing polarity may result in damage to batteries, power
system, and loads.
2. Connect the positive (+) leads to the GROUND/RETURN termination busbar.
3. Connect the negative (-) leads to the -48V Battery (Supply) termination busbar.
4. Torque all connections. Recommended torque is 180 in-lbs when using 3/8” bolts with a Belleville lock washer and 300 in-lbs
when using 3/8” bolts with a standard flat washer and lock washer.
Figure 5.3 Customer Battery Cable Connections to Associated Power System
Front shield and portion
of rack removed for
clarity only.
Front
GND/RTN (+BAT)-48V (-BAT)
Customer Battery Cable
Connections to Power System
(See Detail A for Dimensions)
7.500
1.000
7.500
0.500
2.875 2.875 2.875 2.875
2.875
1.000
0.500
Note: Dimensions are in inches.
3/8” Bolt Clearance Holes on 1” Centers
(Customer must supply hardware)
See text for recommended
torque.
Detail A

Vertiv™ NetSure™ -48 VDC Battery Rack System Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
8
6Installing Batteries
6.1 Important Safety Instructions
DANGER! Adhere to the “Important Safety Instructions” presented at the front of this document.
DANGER! Batteries are heavy (up to 151 lbs.). Two people are recommended for lifting and placing batteries in lower battery
trays (trays below waist height). A battery lift is recommended for lifting and placing batteries in higher battery trays (trays
above waist height).
6.2 Battery Manufacturer Information
Refer to System Application Guide SAG588820400100 for specifications and manufacturers of the batteries to be installed in this
battery rack system.
6.3 Installing Batteries into the Battery Trays
Note! Spacers are provided on the rear wall and front cover of each tray to ensure separation between the batteries. Ensure
batteries are pushed against the rear wall with the spacers between them. For certain batteries of shorter length, shims are
required as shown in Figure 6.1. A battery spacer shim kit is available for this application. See SAG588820400100 for
ordering information.
Note! A battery retainer kit is required to accommodate batteries with a taller height or longer length. See SAG58820400100
for batteries that require this kit and for ordering information.
Procedure
1. Turn OFF all battery disconnect circuit breakers (located on the front of the box framework, adjacent to each battery tray).
2. Remove the front cover from each battery tray. To do so, remove the four (4) 3/8-16 x 1” bolts and two (2) 1/4-20 x 3/4” bolts
with associated washers.
3. Slide batteries into the tray, with the battery terminals toward the front as shown in Figure 6.1. Slide batteries into the tray as
far as they will go. Lower the battery retention bracket as required. See Figure 6.1. If a battery retainer kit is required, replace
the battery retention bracket with the battery retention bracket supplied in the battery retainer kit. See Figure 6.2.
4. Connect three links supplied by the battery manufacturer between pairs of battery terminals as shown in Figure 6.1. Use
hardware furnished by the battery manufacturer. Torque hardware to battery manufacturer’s recommendations.
5. Ensure the battery cable ends in all trays are insulated with sleeving before performing the next step.
DANGER! When batteries in one tray are connected, the battery cables in all trays will be energized. Remove sleeving from
and connect one cable at a time. Do not allow cable end to contact the battery tray or equipment rack.
WARNING! In the next step, observe correct polarity. Connect only cable labeled “+” to battery terminal labeled “+”.
Likewise, connect only cable labeled “–” to battery terminal labeled “–”.
6. Connect the cables found in the battery tray to the respective battery terminals, “+” to “+” and ”–“ to “– “. Observe correct
polarity. Refer to Figure 6.1. Torque battery connections to battery manufacturer’s recommendations.
7. Repeat steps 2 through 6 for any remaining battery trays.
8. Reinstall the front cover for each battery tray. See Figure 6.1. If a battery retainer kit is required, do not reuse the front
cover. Replace the front cover with the front cover supplied in the battery retainer kit. See Figure 6.2.

Vertiv™ NetSure™ -48 VDC Battery Rack System Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
9
Note! Ensure the spacers provided on each front cover slide between the batteries.
9. To connect the batteries to the power system, turn ON the battery disconnect circuit breakers (located on the front of the
box framework, adjacent to each battery tray).
Figure 6.1 Installing Batteries into a Battery Tray (cont’d on next page)
Connect link furnished
with battery to these
two terminals.
Connect NEG (-)
battery cable
to this terminal.
Connect POS (+)
battery cable
to this terminal.
Connect link furnished
with battery to these
two terminals. Connect link furnished
with battery to these
two terminals.
Spacers separate
batteries (3 front &
3 back per tray).
Note: One tray
shown as example.
Turn off all battery
circuit breakers before
installing and
connecting batteries.
Install and Connect Batteries
See Also Next Page
See Detail A
Detail A
Torque to 31 in-lbs.
Lower Battery Retention Bracket as Required

Vertiv™ NetSure™ -48 VDC Battery Rack System Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
10
Figure 6.1 Installing Batteries into a Battery Tray (cont’d from previous page)
Installing Optional Spacer Shims
Optional Shim
P/N 564337
(installed at top)
Factory Installed
Bottom Bracket
Optional Shim
P/N 564337
(installed
at bottom)
To install shims, remove spacers and hardware
then re-install with shims. Use multiple shims
as required. Torque to 31 in-lbs.
Spacers separate
batteries (3 front &
3 back per tray).
3/8” Ground Washer
3/8-16 x 1” Bolt
(4 places)
Torque to 180 in-lbs.
1/4-20 x 3/4” Bolt
(2 places)
Torque to 84 in-lbs. 1/4” Ground Washer
Mount Covers to Rack
3/8” Flat Washer
3/8” Ground Washer
3/8” Flat Washer
1/4” Flat Washer
Installing Front Covers

Vertiv™ NetSure™ -48 VDC Battery Rack System Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
11
Figure 6.2 Installing Battery Retainer Kit (cont’d on next page)
Higher Battery Retention Bracket as Required
Detail A
See Detail A
Torque to 31 in-lbs.
Front Retainer
Bracket
Top Retainer
Bracket
Battery Retainer Kit

Vertiv™ NetSure™ -48 VDC Battery Rack System Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
12
Figure 6.2 Installing Battery Retainer Kit (cont’d from next page)
3/8” Ground Washer
3/8” Flat Washer
3/8-16 x 1” Bolt
(4 places)
Torque to 180 in-lbs
1/4-20 x 1/2” Bolt
(2 places)
Torque to 84 in-lbs
1/4” Flat Washer
3/8” Ground Washer
3/8” FlatWasher
1/4” Ground Washer
Installing Front Brackets

Vertiv™ NetSure™ -48 VDC Battery Rack System Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
13
7Initially Starting the System
Procedure
1. Ensure all furnished protective covers are installed.
2. Turn ON the battery disconnect circuit breakers (located on the front of the box framework, adjacent to each battery tray).
NOTE! Circuit breakers are provided with lockout/tagout capability.
3. Refer to any initial startup procedure in the documentation supplied with the associated power system.
8Maintenance
8.1 Batteries
For battery maintenance procedures, refer to the manual provided with the batteries.
8.2 System Maintenance Procedures
It is recommended to perform the maintenance procedures listed in Table 8.1 every 6-months to ensure continual system operation.
Table 8.1 Maintenance Procedures to be performed at 6-Month Intervals
PROCEDURE REFERENCED IN
Inspect and tighten all installer's connections. “Making Electrical Connections” section on page 5.
9Troubleshooting and Repair
9.1 Contact Information
Refer to Section 4154 (provided with your customer documentation) for support contact information.
9.2 Batteries
For battery troubleshooting and repair procedures, refer to the manual provided with the batteries.

Vertiv™ NetSure™ -48 VDC Battery Rack System Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
14
This page intentionally left blank.
