Viega Prevista Dry Plus 8545.31 User manual

for WB with single-hole fitting
Model Year built:
8545.31 from 03/2019
en_INT
Prevista Dry Plus washbasin module, bar‐
rier-free
Instructions for Use

Prevista Dry Plus washbasin module, barrier-free 2 from 11

Table of contents
1About these instructions for use 4
1.1 Target groups 4
1.2 Labelling of notes 4
1.3 About this translated version 5
2Product information 6
2.1 Intended use 6
2.1.1 Areas of use 6
2.2 Product description 6
2.2.1 Overview 6
2.2.2 Compatible components 6
3Handling 7
3.1 Assembly information 7
3.1.1 Mounting conditions 7
3.1.2 Installation dimensions 7
3.2 Assembly 7
3.2.1 Mounting module 7
3.2.2 Set and clad the module 10
3.3 Disposal 11
Table of contents
Prevista Dry Plus washbasin module, barrier-free 3 from 11

1 About these instructions for use
Trade mark rights exist for this document; for further information, go to
viega.com/legal.
1.1 Target groups
The information in this instruction manual is directed at the following
groups of people:
nHeating and sanitary professionals and trained personnel
nDrywall builder
Individuals without the abovementioned training or qualification are not
permitted to mount, install and, if required, maintain this product. This
restriction does not extend to possible operating instructions.
The installation of Viega products must take place in accordance with
the general rules of engineering and the Viega instructions for use.
1.2 Labelling of notes
Warning and advisory texts are set aside from the remainder of the text
and are labelled with the relevant pictographs.
DANGER!
This symbol warns of possible life-threatening injury.
WARNING!
This symbol warns of possible serious injury.
CAUTION!
This symbol warns of possible injury.
NOTICE!
This symbol warns of possible damage to property.
This symbol gives additional information and hints.
About these instructions for use
Prevista Dry Plus washbasin module, barrier-free 4 from 11

1.3 About this translated version
This instruction for use contains important information about the choice
of product or system, assembly and commissioning as well as intended
use and, if required, maintenance measures. The information about the
products, their properties and application technology are based on the
current standards in Europe (e.g. EN) and/or in Germany
(e.g. DIN/DVGW).
Some passages in the text may refer to technical codes in Europe/
Germany. These should serve as recommendations in the absence of
corresponding national regulations. The relevant national laws, stand‐
ards, regulations, directives and other technical provisions take priority
over the German/European directives specified in this manual: The
information herein is not binding for other countries and regions; as said
above, they should be understood as a recommendation.
About these instructions for use
Prevista Dry Plus washbasin module, barrier-free 5 from 11

2 Product information
2.1 Intended use
2.1.1 Areas of use
The Prevista Dry Plus washbasin module is designed for mounting in a
Prevista Dry Plus pre-wall construction.
2.2 Product description
2.2.1 Overview
..

Fig. 1: Components and scope of delivery
1 Washbasin module
2 Wall bracket for concealed odour trap
3 Screws for fixing in support profile
4 Assembly accessories concealed odour trap
5 slot nuts
6 Assembly accessories wall plates
7 threaded rods for fixing sanitary objects
2.2.2 Compatible components
The washbasin module is compatible with all common washbasin
ceramics, even with larger projection (barrier-free).
Product information
Prevista Dry Plus washbasin module, barrier-free 6 from 11

3 Handling
3.1 Assembly information
3.1.1 Mounting conditions
nPrevista Dry Plus pre-wall constructions
The washbasin module may only be mounted on even wall surfaces.
With the construction height, the marked height of the upper edge of
the finished floor must be observed.
3.1.2 Installation dimensions
NBY
3.2 Assembly
3.2.1 Mounting module
Suitable walls
Construction height
Mounting in Prevista Dry Plus
Handling
Prevista Dry Plus washbasin module, barrier-free 7 from 11

The two vertical rails, which surround the module, must be
open towards the module and have an inner distance of
420 mm.
Secure the module onto the open mounting rail with the slot nuts
supplied.
Insert the slot nut into the opening of the module.
Push the slot nut in until it engages.
Set the height of the rail.
Handling
Prevista Dry Plus washbasin module, barrier-free 8 from 11

Fasten the slot nut.
Bend the sides of the metal bars of the rails.
Bend the sides of the metal bars of the fitting holder.
Set the height of the module according to the ceramic manufactur‐
er's instructions.
25 Nm

99
İ
Handling
Prevista Dry Plus washbasin module, barrier-free 9 from 11

3.2.2 Set and clad the module
Mount an odour trap.
Turn in the threaded rods by hand.
Tighten the nuts of the threaded rods with a fork spanner (size 17).
Place the protective caps on the threaded rods.
Make the water connections.
Cut the gypsum cardboard cladding panel to size.
.
W
J
F
H
B
.
ς
W
J
F
H
B
.
Handling
Prevista Dry Plus washbasin module, barrier-free 10 from 11

Clad the module with suitable gypsum cardboard cladding panels.
3.3 Disposal
Separate the product and packaging materials (e. g. paper, metal,
plastic or non-ferrous metals) and dispose of in accordance with valid
national legal requirements.
Handling
