Vision ZD2102IN-5 User manual

Installation & Operation Manual
ZD2102IN-5
ZD2102MY-5
ZD2102EU-5
ZD2102RU-5
ZD2102US-5
ZD2102IL-5
ZD2102HK-5
ZD2102KR-5
ZD2102BR-5
ZD2102JP-5
Wireless Door/ Window Sensor
ZD 2102-5
V3
1050427
6B1Z-21005
Introduction
Thanks for choosing the Vision’s wireless door/window sensor of the home security device. This
sensor is a Z-Wave™ enabled device (interoperable, two-way RF mesh networking technology)
and is fully compatible with any Z-Wave™ enabled network and it’s security framework. Every
mains powered Z-Wave enabled device acts as a signal repeater and multiple devices result in
more possible transmission routes which helps eliminate “RF dead-sports”
Z-Wave™ enabled devices displaying the Z-Wave™ logo can also be used with it regardless of
the manufacturer, and ours can also be used in other manufacturer’s Z-Wave™ enabled
networks. This sensor monitors door/window and send Z-Wave™ signal when door or window
is opened and closed. When the device is secure included into Z-Wave network, above
communication will be encrypted.
Product Description and Specification
*** For indoor use only***
Specification:
Package
Content:
Protocol: Z-Wave™ (ZM5202)
Frequency Range:
865.22MHz (ZD2102IN-5)
868.10MHz (ZD2102MY-5)
868.42MHz (ZD2102EU-5)
869.00MHz (ZD2102RU-5)
908.42MHz (ZD2102US-5)
916.00MHz (ZD2102IL-5)
919.80MHz (ZD2102HK-5)
920.00~923.00MHz (ZD2102KR-5)
921.42MHz (ZD2102BR-5)
922.00MHz~926.00MHz (ZD2102JP-5)
Operating Range: Up to 100 feet line of sight
Operating Temp.: -15°C~ 60°C (5°F ~140°F)
Battery: Panasonic CR123A * 1PC
1pc
1pc
1pc
2pcs
1pc
4pcs
1pc
ZD 2012-5 sensor
Bracket for Contact Magnet
Magnet
Adhesive tape for Magnet /
sensor
CR123A Lithium Battery
Screws for bracket/ sensor
Installation & Operation manual
Z-Wave Command Classes:
COMMAND_CLASS_ASSOCIATION_GRP_INFO
COMMAND_CLASS_ASSOCIATION_V2
COMMAND_CLASS_BATTERY
COMMAND_CLASS_CONFIGURATION
COMMAND_CLASS_DEVICE_RESET_LOCALLY
COMMAND_CLASS_FIRMWARE_UPDATE_MD_V2
COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2
COMMAND_CLASS_NOTIFICATION_V4 (Mapping COMMAND_CLASS_BASIC)
COMMAND_CLASS_POWERLEVEL
COMMAND_CALSS_SECURITY
COMMAND_CLASS_VERSION_V2
COMMAND_CLASS_WAKE_UP_V2
COMMAND_CLASS_ZWAVEPLUS_INFO_V2
Notification V4 Type
SWITCH TYPE STATUS
Notification
Type
Reed Switch
External Switch (When Enable)
0x06
Tamper Switch 0x07
Event
Reed Switch
External Switch (When Enable)
Close: 0x17, Open: 0x16
Tamper Switch Close:0x00; Open:0x03
V1 Alarm:
Switch Type Status
Alarm Type Reed Switch &
External Switch (When Enable)
0x06
Tamper Switch 0x07
Alarm Level Close: 0x00; Open 0xFF
Configuration - External Switch
Parameter Number: 0x01
Size: 1
VALUE
ENABLE
0xFF
DISABLE
(Default)
0x00
Installation
Notice: If you are installing the entire Z-Wave™ system for the first time, please refer to
the installation guide of Z-Wave™ Interface Controller before installing ZD2102.
1. Unscrew the screw fastening the rear cover and slide the rear cover down.
2. Using the screws or adhesive tape to affix the rear cover on the frame along the
opening edge of door / window.
3. Insert a CR123A battery into the battery compartment, LED will start to flash slowly
and ZD2102 will go to sleep if user didn’t press the tamper switch within 10 seconds or
ZD2102 will send the NIF.
-1- -2-
LED Status for Z-Wave Network:
* After power on, the red LED will flash if the ZD2102 has not been included yet.
* After power on, the red LED will go on if the ZD2102 has been included. (The LED
will turn on lasting 10 seconds then go off and go to sleep mode.)
4. For “Inclusion” in (adding to) a network: Put the Z-Wave™ Interface Controller into
“inclusion” mode, and following its instruction to add the ZD2102 -5 to your controller.
To get in the “inclusion” mode. Press the program switch of ZD2102 for sending the
NIF. After sending NIF, Z-Wave will send the auto inclusion; otherwise, ZD2102 will go
to sleep after 15 seconds.
For “Exclusion” from (removing from) a network: Put the Z-Wave™ Interface
Controller into “exclusion” mode, and following its instruction to delete the ZD2102
from your controller. Press the program switch of ZD2102 for 1 second at least to be
excluded.
Note: All user and network settings will be cleared and the device reset to factory
defaults when the device is excluded.
6. Slide back the rear cover and screw fastening with the front cover, the LED should go
off.
7. Fix the Magnet by using the adhesive tape or fixing screws, locate the Magnet close to
the ZD2102 sensor the distance between these two devices should be in 1.9cm.
8. External Switch: If your window needs two sensors for fully monitoring. You could use
an external switch to connect with the ZD2102 for extending detection. The ZD2102
has 2 normally closed contact terminals. These can be used for additional external
switch wired contacts.
(Remark: Either reed switch or external switch has been opened means “open”, but,
both of them should be closed at the same time means “close”.)
9. Awake Mode:
It will be triggering after opening the rear cover, also the red LED will keep on lasting
10 seconds and ZD2102 will send “Wake Up Notification” after 10 seconds. If ZD2102
received “Wake Up No More Information” command then the red LED will go off or it
will wait 10 seconds then go off. It will proceed all the commands after sending the
“Wake Up Notification”
10. Auto Wake Up:
Use “Wake Up” command to set up the awaking time and send the wake up
notification to controller. User can use command to change the auto wake up from
10 minutes to 1 week, Interval increment is 3 minutes.
11.Battery Capacity Detection:
* Use “Battery Get” command to have the battery capacity back in %
* It will detect the battery capacity automatically
* Low Battery Auto Report (low battery is set as 2.6+/-0.1 Voltage, detects every 2
hours)
12.Association:
* Support one group with 5 nodes
* Support grouping identifier: 1
* All triggering reports & low voltage report will be sent to the associated nodes
13.Power Level Control:
* Use “Power Level Set” to set up the RF strength
* Use “Power Level Test Node Set” to test specific node’s RF sensitivity
14.Support Explorer Frame Function
15.Support OTA Firmware update from controller. Please refer to your controller manual.
Once OTA function success, please make sure to exclude the device & include
again before use the device.
16. All the rest commands depend on Z-Wave standard
17. Factory Default Reset: Trigger the rear cover switch to send the Alarm Report and
trigger the reed switch (close & open) 5 times in 10 seconds, ZD2102 will send the
“Device Reset Locally Notification” command and reset to the factory default.
(Remark: This is to be used only in the case of primary controller being inoperable or
otherwise unavailable.)
-3- -4-
Operation
1. Opening/Closing the door/window to separate the magnet from the sensor will send
signal to any association nodes accordding to the Status/Signal table on page 2 and
the LED will flash once.
2. Normal operation, the LED will not light.
3. If the cover of sensor is removed, the tamper switch will send signal according the
Status/Signal table, and the LED will go solid and ZD2102 will send “Wake Up
Notification” after 10 seconds. If ZD2102 received “Wake Up No More Information”
command, the red LED will go off. If ZD2102 did not receive”Wake Up No More
Information” command after 10 seconds the red LED will go off.
4. ZD2102 will send signal according the status / signal table after closing the rear
cover back 2 seconds..
5. Security enabled: Z-Wave controller must be used to fully utilize the product.
Federal Communications Commission Statement
This equipment has been followed to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try and
correct the interferene by one of the following measures:
Reorient or relocate the receiving antenna,
Increase the separation between the equipment and receiver,
Connect the equipment into and outlet on a circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undersired
operation.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
Limited Warranty
Vision Guarantees that every wireless door/window sensor is free from physical defects in
material and workmanship under normal use for one year from the date of purchase. If
the product proves defective during this one-year warranty period, Vision will replace it
free of charge. Vision does not issue any refunds. This warranty is extended to the
original end user purchase only and is not transferable. This warranty does not apply to:
(1) damage to units caused by accident, dropping or abuse in handling, or any negligent
use; (2) units which have been subject to unauthorized repair, taken apart, or otherwise
modified; (3) units not used in accordance with instruction; (4) damages exceeding the
cost of the product; (5) transit damage, initial installation costs, removal cost, or
reinstallation cost. For information on addional devices, plesae visit us at
www.visionsecurity.com.tw
-5-
