VISIONARY DESIGNS MOD-1206 User manual

© 2022
Order #XXXXX
Locked layer contains
placeholder marks.
Completed Assembly
Item
1
2
3
4
5,5A
6,6A
7,7A
8,8A
9
10
11
Qty.
1
1
1
1
2,2
2,2
1,1
1,1
2
1
1
Description
37.5” S39 Vertical Extrusion
37.5” S39 Vertical Extrusion
37.5” S39 Vertical Extrusion
37.5” S39 Vertical Extrusion
10.5” Z45 Horizontal Extrusion
18” Z45 Horizontal Extrusion
22.811” Z45 Horizontal Extrusion
42“h S44 Vertical Extrusion
10” Z41 Horizontal Extrusion w/ Caps
20” Z41 Horizontal Extrusion w/ Cap
22” Z41 Horizontal Extrusion w/ Cap
Steps:
1) Attach horizontal extrusions [5] to the base of vertical extrusion [8].
2) Attach vertical extrusions [1] & [2] to horizontal extrusions [5].
3) Insert infill panels,then secure with horizontal extrusions [5A].
4) Attach horizontal extrusions [6] to the base of vertical extrusions [1] & [2].
5) Attach vertical extrusions [3] & [4] to horizontal extrusions [6].
6) Insert infill panels, then secure with horizontal extrusions [6A].
7) Connect horizontal extrusion [7] & [7A] between vertical extrusions [3] & [4].
8) Connect assembled door to vertical [3]. See Door Attachment detail.
9) Affix Shelf Supports to inside of counter assembly, using Velcro;
place internal Shelf onto shelf supports.
10) Lock counter top to horizontals [6A].
See Counter Top Attachment detail.
11) Attach vertical extrusion [8A] to vertical extrusion [8].
See Vertical Connector detail.
12) Connect horizontal extrusions [9] to base
of vertical extrusion [1A].
13) Insert wing panels, then secure with horizontal
extrusions [10] & [11].
14) Connect monitor mount to vertical extrusion [8A].
See Monitor Mount detail.
Keep connector
attached to [8]
when packing.
99
11
10
*
*
8A
8
Wing Wing
6A
6A
Counter Top
**
Door
Hinge
Hinge
Slide pin into
hinge attached
to vertical.
Slide door
hinge over pin.
Door Attachment
*
Pin
12
Counter Top Attachment
*
Align hole with pin. Rotate pin. Spring
will push pin into hole.
Monitor Mount Attachment
*
Slide V4 Connectors into groove
of Extrusion. Tighten Set Screws
to secure connectors in place.
Attach Monitor Mount back
piece to Extrusion, using bolts.
Then slide monitor mount into
back piece.
Connectors
V4
Connectors
Bolts
Monitor
Mount
Back
Piece
Door
Hinge
Infill
Infill
Infill
Shelf
3
8
2
4
1
6A 5A
5A
6
6A
7
5
5
6
7A
PR53
Connector
Vertical Connector
Slide upper extrusion
over connector and
rest on lower extrusion.
Secure with set screws.
*
To prevent product loss,
keep all screws attached
to connector after
disassembling.
Set Screw
MOD-1206 Monitor Stand
If you would like to tell us about your experience with your setup instructions please email us at [email protected]
SETUP INSTRUCTIONS

© 2022
Order #XXXXX
DO NOT USE POWER TOOLS
ALL CONNECTIONS MUST
BE TIGHTLY SECURED
Part Identification - Numbering
Spline Connection Base Plate & Extrusion Connection
General Setup Instructions
- Read entire setup instruction manual prior to
unpacking parts and pieces.
- The setup instructions are created specifically
for this configuration.
- Setup instructions are laid out sequentially in
steps, including exploded views with detailed
explanation for assembly.
WARNING
Cleaning & Packing
- For Cleaning Metal, Plex, & Laminate Parts:
Use a MILD NON-ABRASIVE cleanser and
soft cloth/paper towel to clean all surfaces.
- Keep exhibit components away from heat
and prolonged sun exposure.
Heat and UV exposure will warp and
fade components.
- Retain all provided Packing Materials.
All provided packing materials are for
ease of repacking & component protection.
Disassembly
- For loss prevention, tighten all set screws
and locks during disassembly.
7A
Hex Tool - Essential for Assembly
Extrusion & Lock Connection Engaged Lock
LADDERS OR LIFTS
MAY BE REQUIRED
General Information
