Allen + Roth 1116VA-36-320-901 User manual

1
ATTACH YOUR RECEIPT HERE
Serial Number__________________ Purchase Date__________________
Questions, problems, missing parts? Before returning to your retailer, call our customer service
department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday.
36-IN VANITY WITH TOP
ITEM # 4767834; 4767833
MODEL # 1116VA-36-320-901; 1116VA-36-320-900
welcoming • sophisticated • inspiring
1116VA-36-320-901 Wrightsville 36-In Vanity Flaxen White Top
1116VA-36-320-900 Wrightsville 36-In Vanity Flaxen Carrara Top
MODEL NUMBER DESCRIPTION

2
TABLE OF CONTENTS
Package Contents...........................................................................................................................3
Hardware Contents..........................................................................................................................3
Safety Information............................................................................................................................3
Preparation....................................................................................................................................4
Assembly or Installation Instructions...............................................................................................4
Care and Maintenance...................................................................................................................10
Warranty.........................................................................................................................................10
Replacement Parts List..................................................................................................................11

3
HARDWARE CONTENTS (NOT SHOWN ACTUAL SIZE)
PACKAGE CONTENTS
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or install the
product.
WARNING
• Some steps are more easily handled with 2 adults.
CAUTION
• Use care when assembling the vanity, take your time and follow the assembly instructions closely.
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
FF
Touch Up Pen
Qty. 1
AA BB CC DD EE
Lock Washer
Qty. 4
Nut
Qty. 4
Wrench
Qty. 1
Bolt
Qty. 4
Sink Bracket
Qty. 4
A
B
C
D
E
F
PART DESCRIPTION QUANTITY
A Vanity 1
B Top 1
C Backsplash 1
D Sink 1
E
Left Door
(preassembled to
Vanity (A)) 1
F
Right Door
(preassembled to
Vanity (A)) 1
CARTON
Box 2 of 2
Box 2 of 2
Box 1 of 2

4
INSTALLATION INSTRUCTIONS
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list and hardware contents list. If any part is missing or damaged, do not attempt
to assemble the product.
Estimated Installation Time: 45 minutes (24 hours for silicone caulk to dry).
Tools Required for Installation (not included): Phillips screwdriver, utility knife or scissors, silicone
caulk, power drill with drill bit, measuring tape, level.
WARNING
Vanity (A) MUST be secured to the wall.
Note: Clean area where the vanity (A) will
be permanently located prior to beginning
installation, ensuring the vanity (A) will not
interfere with any water supply and drain
lines once mounted.
1. With two people, carefully place vanity (A)
against the wall in its final location. Find and
mark locations of wall studs behind the
permanent location of vanity (A).
From inside vanity (A), drill hole through
vanity mounting area into wall studs.
Using mounting hardware (not included)
appropriate for your installation site, secure
vanity (A) to wall stud. If possible, secure
vanity (A) to two wall studs for increased
stability.
Note: Use preassembled levelers on feet of
vanity (A) to level the item. Twisting the levelers
counterclockwise will increase the height of vanity
(A), twisting them clockwise will decrease it.
1
A
A

5
INSTALLATION INSTRUCTIONS
2
Remove the top foam sheet
Remove the foam sheet
Remove the cutout foam
sheet & hardware
Remove the top and place it
on a scratch free surface
Remove the backsplash and place
it on a scratch free surface
C
B
FRONT
B
FRONT
Hardware
Pack
12
B
BACK
FRONT
Foam sheet
Foam sheet
C
3
D
B
2
2
BACK
BACK
BACK
1
BACK
BACK
Top
Sink Lip
2. Take out the top (B) and backsplash (C)
according to the steps indicated by the
drawings on the right, and place them face
down onto a scratch free surface such as a
foam sheet that came in the packaging.
3. Apply silicone caulk (not included) to
the top edge of sink (D). With the help of
another adult, lower the sink onto the back
side of the stone top.
Make sure the sink over-flow hole is facing
the front of stone top.
Be sure to align the sink well with the stone top
cut out allowing for equal stone overhang on the
front, back and sides of the ceramic sink (D).
Note: To install the sink onto the top correctly,
ensure that the two "BACK" stamps on the sink
and the top are aligned on the same sides.
Use the guide lines marked on the sink and
bottom side of stone top to assist with sink
location.

6
INSTALLATION INSTRUCTIONS
Hardware Used
AA Bolt x 4
4. Screw bolts (AA) into the threaded holes of
stone top (B).
Hardware Used
Sink bracket x 4
Nut x 4
x 4Lock Washer
Wrench x 1
5. Lower the sink brackets (BB) over the bolts
(AA) and allow to rest on the sink lip. Adjust
location of bracket to firmly grasp sink lip.
Lower lock washers (DD) over bolts (AA) and
secure with nuts (CC). Hand tighten nuts (CC)
with included wrench (EE).
DO NOT OVER TIGHTEN!
Tip: Check that the sink placement is well
centered front to back and side to side of the
stone top cut out before allowing the silicone
caulk to dry. If the sink is not centered well
unscrew sink clamps, re-adjust the sink position
and re-tighten the sink brackets.
5
1
BB
D
B
BACK
BACK
EE
CC
DD
AA
3
2
4
D
B
BACK
BACK
AA
AA
BB
CC
DD
EE

7
INSTALLATION INSTRUCTIONS
6
2
2
A
B
1
6. To install the stone top with assembled sink to
the vanity (A). Apply silicone caulk to the
top edge of the wood cabinet. With the help
of another adult, gently lower the stone top
with assembled sink onto the cabinet. Make
sure the stone top is flush with the back side
of the wood cabinet and the stone overhang is
equal on both sides over the wood cabinet left
and right side walls. Remove any excess
caulk before allowing to dry.
Helpful tip: it may be easier to install your
choice of faucet (not included) before securing
the vanity top (B) to vanity base (A).
7. Apply silicone caulk (not included) to unpolished
side and bottom of backsplash (C). Position
backsplash (C) on top (B) and against wall.
Clean any excess caulk before allowing
to dry.
7
1
B
C
22

8
INSTALLATION INSTRUCTIONS
8.
If you need to adjust the doors, do so in the following manner.
To adjust door up or down, loosen screws (a) on both hinges, adjust door, and retighten screws.
To adjust door left or right, turn screws (b) on both hinges, in and out.
To adjust door in or out, loosen screws (c) on both hinges, adjust door, and retighten screws.
8
2
2
2
2
2
2
a
1
a
3
b
1
1
c
1
c
3
9
2
1
A
9. To remove drawer from vanity base (A),
fully extend drawers and locate the plastic
levers on left and right sides of the metal glide
tracks. Push the plastic levers, on both sides,
at the same time, This will disengage the
drawer box from the glides. Gently lift up on
the drawer to remove it from the glide tracks.
Set aside as these will be re-installed.

9
INSTALLATION INSTRUCTIONS
Assembly is now complete. Install desired
faucet and drain assemblies (neither included)
if not already done at step 6. Per the manufacturers’
instructions to complete the installation.
10. To re-install drawer into vanity (A). Please fully
extend metal glide tracks, gently lower and slide
drawer box into rear glide catch, then, lower
drawer box down to completely rest on
extended glides, push plastic levers to
lock the drawer box in place.
Note: To Adjust the drawer box height. Please
spin the adjustment wheel to the left to raise the
drawer box or spin the adjustment wheel to
the right to lower the drawer box. You can
adjust the left and right side glide heights
independently in order to find the drawers best
alignment position.
CAUTION
DO NOT force drawer or damage to glide may
occur. If drawer does not slide in with ease,
remove and try again from the start.
10
3
2
A
1

10
CARE AND MAINTENANCE
WARRANTY
IMPORTANT
• Dust the vanity regularly with a soft, non-lint producing cloth or household dusting product.
• You can clean the vanity with a gentle, non-abrasive household cleaner.
• Make sure to dry the wood immediately with a soft cloth or towel.
• The ceramic sink can be cleaned using standard ceramic cleaning agents available at your local
supplier.
• Tips for using touch-up pen (FF): For scratches, stroke in direction of scratch; for worn areas,
stroke in direction of wood grain. Rub off excess colorant promptly with a soft cloth.
• Shade variations and patterns are an inherent characteristic of stone (e.g. granite, marble,
engineered stone). Stone tops will vary from product to product. Use caution placing items
such as soap or any fragranced material on the stone surface. Use a soap dish, coaster or
similar item to protect the surface if placing any soap or fragranced products on the stone.
• If soap or fragranced products come in contact with the stone top, rinse the surface with water
and dry using a soft non-abrasive cloth.
• WARNING: Must use cleaning agents safe for stone. Check your cleaning agents use
restrictions before using on any stone. Damage to the stone may result. Vanity Manufacturer not
responsible for damage caused by improper cleaning agents or soaps used. Warranty will not
cover damage caused by the use of improper soaps or cleaning agents.
• DO NOT use products to clean the stone top that contain acetone, lemon, vinegar or other
acids as these may cause damage to the stone surface.
• Periodically reseal the stone top using an appropriate stone sealer available from your local
home store. Follow the manufacturer’s directions on how to apply.
The manufacturer warrants this item against defects in materials and workmanship for a period of
one (1) year from the date of original retail purchase. This warranty applies only to the original
purchaser. This warranty does not apply to any damage on the product by accident, misuse, or
modified, improper installation or by affixing accessories not produced by the manufacturer. The
manufacturer will not be held liable for damages caused from cleaners or soaps that etch or stain
the stone top. The manufacturer is not accountable whatsoever for product installation during the
warranty period. There is no further expressed warranty. The manufacturer shall not be legally
responsible for incidental, consequential or special damages arising at or in connection with
product use or performance except as may otherwise be accorded by law. The manufacturer
disclaims any and all implied warranties.

11
REPLACEMENT PARTS LIST FOR 1116VA-36-320
For replacement parts, call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m.,
EST, Monday - Sunday.
H
E
I
B
C
G
D
F
FFAA BB CC DD EE GG HH II KKJJ
PART DESCRIPTION PART #
D Sink PU17-19x16-OVAL
C36" Engineered White Backsplash PU1116BS-36-901
36" Carrara Marble Backsplash PU1116BS-36-900
BComplete Set 36" Engineered White Top 1116VT-36-901
Complete Set 36" Carrara Marble Top 1116VT-36-900
E Left Door 1116VB-36-320-DOOR SET
F Right Door
G
Shelf 1116VB-36-320-002
H
Foot PU1116-320-FOOT
I Drawer Front 1116VB-36-320-003
AA Bolt
BB Sink Bracket
CC Nut GTC-SINK CLIPS
DD Lock Washer
EE Wrench
FF Touch-Up Pen P-3020
GG Shelf Pin PU17-SP-002
HH Knob (with screw) PU17-1116-BN
II Hinge PU1116-EU-SC
JJ Drawer Glide PUDTC-14x3-HANDLE
KK Leveler T-1007
