VISIONARY DESIGNS MOD-1363 Manual

© 2018
Order #XXXXX
Plan View
SETUP INSTRUCTIONS
If you would like to tell us about your experience with your setup instructions please email us at [email protected]
MOD-1363 iPad Kiosk

© 2018
Order #XXXXX
DO NOT USE POWER TOOLS
ALL CONNECTIONS MUST
BE TIGHTLY SECURED
Part Identification - Numbering
Spline Connection Base Plate & Extrusion Connection
General Setup Instructions
- Read entire setup instruction manual prior to
unpacking parts and pieces.
- The setup instructions are created specifically
for this configuration.
- Setup instructions are laid out sequentially in
steps, including exploded views with detailed
explanation for assembly.
WARNING
Cleaning & Packing
- For Cleaning Metal, Plex, & Laminate Parts:
Use a MILD NON-ABRASIVE cleanser and
soft cloth/paper towel to clean all surfaces.
- Keep exhibit components away from heat
and prolonged sun exposure.
Heat and UV exposure will warp and
fade components.
- Retain all provided Packing Materials.
All provided packing materials are for
ease of repacking & component protection.
Disassembly
- For loss prevention, tighten all setscrews
and locks during disassembly
7A
Hex Tool - Essential for Assembly
Extrusion & Lock Connection Engaged Lock
LADDERS OR LIFTS
MAY BE REQUIRED
General Information

© 2018
Case 1 of 1
Order #XXXXX Case Packing
Level 1 Level 3
Setup Hardware
Brackets
Base
Partly
Assembled
Frame
Top View of Each Level
Graphic
Level 2
Partly
Assembled
Frame

© 2018
Step 1 of 2
Order #XXXXX MOD-1363 iPad Kiosk Assembly
1
2
3
4
Top View of Brackets
Bolts
BoltsBolts
5
7
6
Steps:
1) Connect curved extrusions [1] to [2] and [3] to [4].
2) Connect assemblies [1/2] and [2/3] to [5] and [6].
3) Attach assembled frame to base, using bolts.
4) Attach Support Brackets to back, using bolts.
5) Apply front SEG graphic. See SEG Graphic Installation detail.
6) Position horizontal [7], then lock in place.
7) Attach iPad mount. See iPad Mount Attachment detail.
-- Continued page 2 --
Base
Item
1
2
3
4
5
6
7
Qty.
1
1
1
1
1
1
1
Description
32.075” TSP49 Curved Extrusion
32.075” TSP49 Curved Extrusion
32.075” TSP49 Curved Extrusion
32.075” TSP49 Curved Extrusion
20” TSP49 Horizontal Extrusion
20” TSP49 Horizontal Extrusion
16.417” Z45 Horizontal Extrusion w/ 6” S10
TSP49
Z45
S10
7
S10
S10
V20
Do not remove bolts from V20’s.
Apply SEG graphic and position extrusion [7] by
loosening set screws, sliding into place, then
tightening set screws. S10 extrusion should poke
through hole in graphic. Loosen bolts on iPad
mount (Do Not Remove) then slide V20’s into
S10 groove. Tighten bolts to secure.
iPad Mount Attachment
Z45
Mount
Mount
Bolt
Bolt
V20
*
TSP49
TSP49
Lock
Tighten set screw
to secure extrusions.
TSV1 Lock Detail
*
*
*
*
*
*
Support
Bracket
Support
Bracket
Graphic Removal
To remove the graphic from
the frame, locate the fabric
pull tab.Gently pull up on the
tab to remove the fabric.
Step 1
Insert corner A. Turn edge of
graphic so silicon welt is
perpendicular to face of
graphic. Insert narrow side
of welt with fabric to outside
into the channel. Repeat for
other side of this corner.
Step 2
Repeat Step 1 for opposite
corner C, then insert corner
B, followed by corner D, to
complete the installation of
the corners.
Step 3
Once all corners are inserted,
press one silicon edge into
channel from corners and
work toward the center.
Make sure welt is fully inserted
into channel. Continue until
all sides are done. Smooth
out edges of graphic.
SEG Graphic Installation
It is important to first insert
graphic into each alternate
corner then to the sides of
the frame. If this is not done,
graphic will not fit into the
frame correctly.
Corner A
Corner D
Corner B
Corner C

© 2018
Step 2 of 2
Order #XXXXX MOD-1363 iPad Kiosk Assembly Cont’d
--Steps Continued---
9) Attach Clamshell with iPad and route cords. See Clamshell Attachment detail.
10) Attach Conduit for cord management. See Cord Management Attachment detail.
11) Install back SEG Graphic to assembled frame.
Completed Assembly
to power
Foam Lining
Removed
Home Button Shield
Optional Cover for Home Button
1) Remove foam lining from inside bottom of
Clamshell.
2) Attach Home Button Shield with double-sided
tape to inside of Clamshell, keeping top of
shield flush with Clamshell opening.
NOTE: This is a permanent fix and can’t be
easily removed.
Cord
Access
iPad
Lock Lock
Connect Clamshell to Mount Plate then secure with Hex Nuts. Insert iPad.
Hex
Nut
Clamshell
Clamshell
Mount
Plate
Clamshell Attachment
Run cords through plastic Conduit, then
attach Conduit by pinching the opening
and inserting into the groove of the TSP49.
Cord Management
pinch
Conduit
TSP49
