VISIONARY DESIGNS MOD-1525 Manual

© 2016
www.classicexhibits.com
Order #XXXXX - MOD-1525 Backlit Reception Counter
SETUP INSTRUCTIONS
If you would like to tell us about your experience with your setup instructions please email us at [email protected]
2
3
3A
Center Reflective Infill
4
4A
5
5
5A
Side
Infill
Front Graphic Infill
Side Infill
Side Infill
Side
Infill
5A
6
6A
6A
Primary
Counter Top
Plex Counter Top
Internal Shelf
7A
6
7
2A
1
1A
Item
1/1A
2/2A
3/3A
4/4A
5/5A
6/6A
7/7A
Qty.
1/1
1/1
1/1
2/2
2/2
2/2
1/1
Description
36.4882”h Vertical Extrusion
42”h Vertical Extrusion
42”h Vertical Extrusion
40”w Z45 Horizontal Extrusion
13”w Z45 Horizontal Extrusion
5”w Z140 Horizontal Extrusion
40”w Z140 Horizontal Extrusion
Steps:
1) Connect horizontals [4] & [4A] between verticals [1] & [1A].
2) Attach horizontal [4] between verticals [2] & [2A].
3) Connect horizontals [5] between verticals [1 & 2] & [1A & 2A].
4) Attach horizontal [7] between verticals [3] & [3A].
5) Connect horizontals [6] between verticals [1 & 2] & [2A & 3A].
6) Slide Center Reflective Infill between verticals [2] & [2A];
secure with horizontal [4A].
7) Insert Side Infills between verticals [1 & 2] & [1A & 2A];
secure with horizontals [5A].
8) Insert Side Infills between verticals [2 & 3] & [2A & 3A];
secure with horizontals [6A].
9) Insert Front Graphic Infill between verticals [3 & 3A].
10) Place Internal Shelf on shelf pins.
11) Attach Primary Counter Top to top of assembled base.
12) Connect Plex Counter Top to top of verticals [2/3] & 2A/3A].
See Plex Counter Top Attachment detail.
4
4A
Plex Counter Attachment
*
Insert Connector
into groove.
Place Plex Counter
on top of pedestal
base.
Secure counter
with Screw Cap.
**DO NOT
OVER TIGHTEN.
PLEX WILL CRACK**
Screw Cap
Plex Counter
*
*

© 2016
www.classicexhibits.com
Order #XXXXX -
DO NOT USE POWER TOOLS
ALL CONNECTIONS MUST
BE TIGHTLY SECURED
Part Identification - Numbering
Spline Connection Base Plate & Extrusion Connection
General Setup Instructions
- Read entire setup instruction manual prior to
unpacking parts and pieces.
- The setup instructions are created specifically
for this configuration.
- Setup instructions are laid out sequentially in
steps, including exploded views with detailed
explanation for assembly.
WARNING
Cleaning & Packing
- For Cleaning Metal, Plex, & Laminate Parts:
Use a MILD NON-ABRASIVE cleanser and
soft cloth/paper towel to clean all surfaces.
- Keep exhibit components away from heat
and prolonged sun exposure.
Heat and UV exposure will warp and
fade components.
- Retain all provided Packing Materials.
All provided packing materials are for
ease of repacking & component protection.
Disassembly
- For loss prevention, tighten all setscrews
and locks during disassembly
7A
Hex Tool - Essential for Assembly
Extrusion & Lock Connection Engaged Lock
LADDERS OR LIFTS
MAY BE REQUIRED
General Information
