VISIONARY DESIGNS MOD-1567 User manual

© 2019
Order #XXXXX
*
Completed Front View Completed Back View
5
Counter Top
Shelf
12
6
5
4
8
7
8
Shelf Support
Shelf Support
Shelf Support
Shelf Support
Shelf Support
7
3
Item
1
2
3
4
5
6,6A
7
8
Qty.
1
1
1
1
2
1,1
2
2
Description
38” GS220 Extrusion w/ 34.417” L-Channel
38” GS220 Extrusion w/ Door Hinges
38” GS220 Extrusion
38” GS220 Extrusion
33.026” Z45 Curved Extrusion
74.815” Z45 Curved Extrusion
24.813” Z45 Extrusion
24.813” Z45 Extrusion
Steps:
1) Attach lower extrusions [5] [6] and [7] between
vertical extrusions [1] [2] [3] and [4].
2) Slide infills between [1] [2] [3] and [4], making
sure Velcro is facing inward.
3) Secure infills with upper extrusions [5] [6A] and [8].
4) Attach door to vertical [2]. See Door Connection detail.
5) Connect shelf supports to Velcro on infills.
6) Place shelf on top of supports.
7) Lock counter top to extrusions [6A] and [8]. See
Counter Top Lock detail.
*
*
6A
D
o
o
r
I
n
fi
l
l
Infill
Infill
Keep L-channel attached to extrusion [1].
Door
Hinge
Hinge
Pin
Slide pin into
hinge attached
to vertical.
Slide door
hinge over pin.
Door Connection
*
Align hole with pin Rotate pin. Spring
will push pin into hole.
Counter Top Lock
12
*
Pin
Hole
**
MOD-1567 Counter
If you would like to tell us about your experience with your setup instructions please email us at [email protected]
SETUP INSTRUCTIONS

© 2019
Order #XXXXX
DO NOT USE POWER TOOLS
ALL CONNECTIONS MUST
BE TIGHTLY SECURED
Part Identification - Numbering
Spline Connection Base Plate & Extrusion Connection
General Setup Instructions
- Read entire setup instruction manual prior to
unpacking parts and pieces.
- The setup instructions are created specifically
for this configuration.
- Setup instructions are laid out sequentially in
steps, including exploded views with detailed
explanation for assembly.
WARNING
Cleaning & Packing
- For Cleaning Metal, Plex, & Laminate Parts:
Use a MILD NON-ABRASIVE cleanser and
soft cloth/paper towel to clean all surfaces.
- Keep exhibit components away from heat
and prolonged sun exposure.
Heat and UV exposure will warp and
fade components.
- Retain all provided Packing Materials.
All provided packing materials are for
ease of repacking & component protection.
Disassembly
- For loss prevention, tighten all set screws
and locks during disassembly.
7A
Hex Tool - Essential for Assembly
Extrusion & Lock Connection Engaged Lock
LADDERS OR LIFTS
MAY BE REQUIRED
General Information
