VISIONARY DESIGNS MOD-1185 Manual

© 2018
Order #XXXXX
*
Completed Counter Assembly
Steps:
1) Attach lower extrusions [2] [3] and [4] between verticals [1].
2) Attach verticals [5] and [6] to lower extrusion [2], with door between.
3) Insert infills between verticals [1] [5] and [6], making sure Velcro is facing inward.
4) Connect door to vertical [6]. See Door Connection detail.
5) Attach upper extrusions [2A] [3A] and [4A] between verticals [1], to secure infills.
6) Attach shelf supports to Velcro on inside of assembled counter then place shelf
on top of supports.
8) Place counter top on assembled counter base. See Counter Top Lock detail.
1
1
1
1
2
3
44
5 6
4A 4A
Door
Infill
Infill
Infill
Infill
Infill
2A
3A Counter Top
Shelf
*
*
*
Align hole with pin Rotate pin. Spring
will push pin into hole.
Counter Top Lock
12
*
Pin
Hole
Door
Hinge
Hinge
Pin
Slide pin into
hinge attached
to vertical.
Slide door
hinge over pin.
Door Connection
*
Item
1
2,2A
3,3A
4,4A
5
6
Description
38” GS220 Corner Extrusion
57.381“ Z45 Curved Horizontal Extrusion
68.449“ Z45 Curved Horizontal Extrusion
13.5” Z45 Horizontal Extrusion
34.418” Z45 Vertical Extrusion
34.418” Z45 Vertical Extrusion
Qty.
4
1,1
1,1
2,2
1
1
MOD-1185 Reception Counter
SETUP INSTRUCTIONS
If you would like to tell us about your experience with your setup instructions please email us at [email protected]
SETUP INSTRUCTIONS
If you would like to tell us about your experience with your setup instructions please email us at [email protected]

© 2018
Order #XXXXX
DO NOT USE POWER TOOLS
ALL CONNECTIONS MUST
BE TIGHTLY SECURED
Part Identification - Numbering
Spline Connection Base Plate & Extrusion Connection
General Setup Instructions
- Read entire setup instruction manual prior to
unpacking parts and pieces.
- The setup instructions are created specifically
for this configuration.
- Setup instructions are laid out sequentially in
steps, including exploded views with detailed
explanation for assembly.
WARNING
Cleaning & Packing
- For Cleaning Metal, Plex, & Laminate Parts:
Use a MILD NON-ABRASIVE cleanser and
soft cloth/paper towel to clean all surfaces.
- Keep exhibit components away from heat
and prolonged sun exposure.
Heat and UV exposure will warp and
fade components.
- Retain all provided Packing Materials.
All provided packing materials are for
ease of repacking & component protection.
Disassembly
- For loss prevention, tighten all set screws
and locks during disassembly
7A
Hex Tool - Essential for Assembly
Extrusion & Lock Connection Engaged Lock
LADDERS OR LIFTS
MAY BE REQUIRED
General Information
