Vivo DESK-M051MW User manual

White Compact Crank Height Adjustable Desk Frame
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
Instruction Manual
https://vivo-us.com/products/desk-m051mw
SKU: DESK-M051MW
[email protected]om www.vivo-us.com 309-278-5303
Chat live with an agent!
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST

2
If you do not understand these directions, or if you have any doubts about the safety of the
installation, please call a qualified technician. Check carefully to make sure there are no missing or
defective parts. Improper installation may cause damage or serious injury. Do not use this product
for any purpose that is not explicitly specified in this manual and do not exceed weight capacity.
We cannot be liable for damage or injury caused by improper mounting, incorrect assembly, or
inappropriate use.
WARNING!
TOOLS NEEDED
Phillips
Screwdriver
DO NOT EXCEED WEIGHT CAPACITY.
Failure to do so may result in serious injury.
154lbs
70kg
Level
WARNING: CHOKING HAZARD
SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.
PACKAGE CONTENTS
A (x1)
Crossbar
B (x1)
Leg
D (x1)
Crossbar Spacer
E (x2)
Side Bracket
S-A (x16)
M6x12 Bolt
S-C (x10)
7/8” Screw
C (x1)
Leg with
Gearbox
S-B (x4)
3/4” Screw
Drill
F (x1)
Sync Rod
H (x2)
Foot
G (x1)
Crank
S-D (x10)
Anti-Vibration
Pad
S-E (x1)
Allen Wrench

3
STEP 2
Place the crossbar spacer (D) on the leg (B) as shown. Attach the telescopic crossbar to the legs (B,
C) as shown using M6x12mm bolts (S-A), and tighten with the Allen wrench (S-E). NOTE: Insert all
necessary screws into holes before tightening.
ASSEMBLY STEPS
STEP 1
Loosen the two set screws on the telescopic crossbar (A) using the Allen wrench (S-E). Adjust the
crossbar length to suit the desktop. Retighten all screws.
STEP 3
Attach the side brackets (E) to both ends of the frame using four
M6x12mm bolts (S-A). Tighten with the Allen wrench (S-E).

4
STEP 4
Loosen the knob on the socket end of the sync rod (F) and slide the sync rod onto the sha of the leg
with gearbox. Tighten the knob.
STEP 5
Loosen the knob on the other end of the sync rod and extend the hex sha into the socket in the leg,
making sure the sha is fully inserted. Tighten the knob.

5
STEP 6
Place the frame upside down on desktop and drill pilot holes for the screws. Use a 3/32” or 3mm bit,
and drill holes to a depth of 3/8” (10mm). Readjust the sync rod if necessary.
STEP 7
Insert the anti-vibration pads (S-D) into the desktop mounting holes in the crossbar and side
brackets. Place the assembled frame on the desktop, making sure the pre-drilled holes are aligned
with the desk frame, and secure the frame using 7/8” screws (S-C).
