VOLT®Jolt Mini Brass Spotlight (Bronze)
VAL-2010-BBZ
INSTALLATION INSTRUCTIONS
- 2 -
www.voltlighting.com
Important: Please Read Before Installation
!
Important Safety Instructions
!
This luminaire is intended for installation in accordance with local codes
and the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situations.
1. Make sure that the power is turned OFF before installing or servicing this
xture.
2. Warning: this xture is not intended to be installed within 10 feet [3
meters] of a pool, spa or fountain.
3. This xture is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.
4. Underground Low Energy Cable must not be buried over 6” (15.2 cm) in
order to connect to the main low voltage cable.
5. Wiring connections must be made with UL Listed wire connectors that
are suitable for the application.
6. Position the wire connector so that it is located within 6 inches (15.2 cm)
from a building structure, a luminaire, or tting.
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS
Lighted lamp is HOT!
WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS.
1. Turn o/unplug and allow to cool before reducing lamp.
2. Lamp gets HOT quickly!
3. Do not touch the hot lens, guard or cowl.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time.
6. Use a soft cloth.
7. Oil from skin may damage lamp.
8. Do not operate the xture with a damaged or missing lens or shield.

- 3 -
[email protected] • 813.978.3700
Package Contents
Product Dimensions
Install Stake
1
A. (1) Fixture Body
1.54”
1.54”
1.58”
3.35”
Determine the desired location
for mounting the stake mount.
Hammer the stake into the
ground until ange of stake
is ush to grade. To avoid
damage to the stake, place a
board on top of the stake while
hammering.
Note: If the ground is hard and
the stake is dicult to install,
make a crosscut in the ground
using a at shovel.
Board
Ground
Soil
Stake

VOLT®Jolt Mini Brass Spotlight (Bronze)
VAL-2010-BBZ
INSTALLATION INSTRUCTIONS
- 4 -
www.voltlighting.com
Install Fixture Body to Stake
2
Pass the xture wire through
the center hole of the stake.
Thread the xture body onto
the stake and hand tighten until
snug.
Fixture Body
Fixture Wire
Ground
Soil
Stake
Wire Connections
3
Strip both leads from the xture body. Using two wire connectors (sold
separately), connect the leads from the xture body to the main supply
cable leads.
Pigtail
Main Supply Cable
Supply Wire from
Fixture Body
Wire Connectors

- 5 -
[email protected] • 813.978.3700
Remove Glare Guard
4
Loosen the set screw to
remove the glare guard
from the xture body.
Fixture Body Set Screw
Glare
Guard
Install MR11 Bulb
5
Insert MR11 Bulb with the
correct wattage and type
marked on xture label and
secure into place.
CAUTION: Do not exceed
maximum wattage marked on
luminaire label.
Socket MR11 Bulb
Install Glare Guard
6
Place the glare guard back onto
the xture body and secure
with the previously removed set
screw. Hand tighten until snug.
Fixture Body Set Screw
Glare
Guard
