Volt VPL-3024-BBZ User manual

VOLT®Low Voltage Landscape Lighting
VOLT®Elevator Path & Area Light
VPL-3024-BBZ
INSTALLATION INSTRUCTIONS
Specications and product details subject to change without notice.
© Copyright 2018, VOLT® Lighting, Lutz FL USA 33549 • All rights
reserved. [email protected] • 813.978.3700
- 1 -
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)

VOLT®Elevator Path & Area Light
VPL-3024-BBZ
Important: Please Read Before Installation
INSTALLATION INSTRUCTIONS
!
www.voltlighting.com
- 2 -
This xture is intended for installation in accordance with local codes
and the National Electric Code (NEC). Failure to adhere to these codes
and instructions may result in serious injury, property damage and void
the warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situation.
1. Make sure that the power is turned OFF before installing or servicing
this xture.
2. Warning: this xture is not intended to be installed within 10 feet [3
meters] of a pool, spa or fountain.
3. This xture is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.
4. Underground Low Energy Cable must not be buried over 6” (15.2 cm) in
order to connect to the main low voltage cable.
5. Wiring connections must be made with wire connectors that are suitable
for outdoor use.
6. Position the wire connector so that it is located within 6 inches (15.2
cm) from a building structure, a luminaire, or tting.
Important Safety Instructions
!
LIGHTED LAMP IS HOT!
WARNING – TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS.
1. Turn o/unplug and allow to cool before reducing lamp.
2. Lamp gets HOT quickly!
3. Do not touch the hot lens, guard or cowl.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time.
6. Use a soft cloth.
7. Oil from skin may damage lamp.
8. Do not operate the xture with a damaged or missing lens or shield.

[email protected] • 813.978.3700
Package Contents
A. (1) Fixture Body
B. (1) Extension Pole
C. (1) Stake
Parts Required (sold separately)
A. (1) LED Lamp
Product Dimensions
24.5”
2.5”
4”
2”
- 3 -

INSTALLATION INSTRUCTIONS
VOLT®Elevator Path & Area Light
VPL-3024-BBZ
Remove Faceplate
Install/Replace Lamp
1
2
Unscrew the faceplate, then remove
it from the xture body.
Insert the lamp with the correct
wattage and type marked on the
xture label.
CAUTION: Do not exceed maximum
wattage marked on luminaire label.
NOTE: DO NOT touch lamp with
bare hands. Use soft cloth to handle
lamp.
NOTE: The “Wafer” Bi-Pin LED lamp
also can be used in this xture.
Fixture Body
Faceplate
Socket
Lamp
www.voltlighting.com
- 4 -
“Wafer” Bi-pin LED Lamp

[email protected] • 813.978.3700
Install Faceplate
3
Screw the Faceplate back onto the
xture body. Hand tighten until snug.
Faceplate
Fixture
Body
- 5 -

INSTALLATION INSTRUCTIONS
VOLT®Elevator Path & Area Light
VPL-3024-BBZ
www.voltlighting.com
- 6 -
Install Fixture to Stake
5
Fixture
Pigtail
Wireway Slot
Stake
Install Stake
4
Board
Stake
Soil
Ground
Clear away an area on the ground
at the wireway slot on top of
the stake. Lay the luminaire
pigtail into the wireway slot and
thread the xture onto the stake.
Tighten until snug using the lock
nut to secure it to the base.
Determine the desired location for
mounting the xture. Hammer the
stake into the ground until the ange
of the stake is ush to grade. To avoid
damage to the stake, place a board on
top of the stake while hammering.
NOTE: If the ground is hard and the
stake is dicult to install, make a
crosscut in the ground using a at
shovel.

[email protected] • 813.978.3700
Wire Connections
6
Pigtail
Main Supply Cable
Wire Connectors
- 7 -
Strip both leads from the luminaire pigtail. Using two wire connectors
(sold seperately), connect the leads from the luminaire to the main
supply cable leads.

is-VPL-3024-BBZ-ver3.pdf
